MODEL:VTL420I RTJ /VTL400IRTJ
Bar Type License Plate Camera with Night Vision and Trajectory Parking Lines
1.SPECIFICATION
3.Mounting Installation
Camera
Monitor
5 meters long, extra video cable
2.Wiring Installation Guide
Ground
12VDC Ignition or
Reverse Light
M6 HEX NUT (2PCS)
M6 HEX NUT(2PCS)
PLATE WASHER(2PCS)
SPRING WASHER(2PCS)
Loosen
Fix tight
hex.wrench
Loosen the allen screws to adjust the camera angle up and down. Then, lock it in place.
L-shaped
*Trajectory Parking Lines
*IR Night Vision
*0.5 LUX IR Off
*175° Wide View Angle
*Adjustable Camera Angle
*IP 67 Waterproof Rating
The camera angle must be set at a minimum 30°- 40° angle.
Setting the camera angle horizontally straight will affect the
sensitivity and accuracy of the Trajectory Parking Lines.
IMPORTANT INSTALLATION NOT E:
