94 BIN MOBILE STORAGE SYSTEM
MODEL NO:TPS94
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
Original Language Version
© Jack Sealey Limited
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general. Workshop practice regulations are adhered to when using this rack.
9 Locate rack in a suitable work area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use rack on level and solid ground, preferably concrete.
9 Keep the rack clean and tidy in accordance with good workshop practice.
8 DO NOT use the rack for any purpose other than that for which it is designed.
9 Keep children and unauthorised persons away from the work area
2. INTRODUCTION
Powder coated steel racking with composite storage bins positioned evenly on both sides. Mounted on heavy-duty castors (two
lockable) for mobility.
3. SPECIFICATION
Model No: ............................................................TPS94
Overall Size: .................................940 x 500 x 1245mm
Bin Dimensions:
Medium Bin (x64): ............................ 110 x 160 x 75mm
Large Bin (x30): ............................. 150 x 235 x 125mm
TPS94 Issue:4 03/07/23
4. ASSEMBLY
4.1. Attach castors x 4 to the underside of the bottom deck.
4.2. Attach upright supports (1) to bottom deck.
4.3. Connect brace supports (2) to upright supports (1) and bottom deck.
4.4. Attach top (3) to uprights (1).
4.5. Attach cross braces x 7 (only 4 shown on diagram) to the upright support brackets (4).
NOTE Ensure all centre support holes on the cross braces are in alignment with each other.
4.6. Attach centre support (5) to cross braces.
4.7. Ensure all xings are secure.
