6.The power plug must be accessible directly.
WARNING: fill with potable water only. Only use drinking water.
DANGER
*Improper use of the grounded plug can result in the risk of electrical shock.
If the power cord
is damaged, please call our customer service.
1.
This unit should be properly grounded for your safety. The power cord of this appliance is equipped
with a grounding plug which mates with standard grounding wall outlets to minimize the possibility of
electric shock.
2.Plug your appliance into an exclusive, properly installed, grounding wall outlet. Do not under any
circumstances; damage the grounding means of the plug. Any questions concerning power and/or
grounding should be directed toward a certified electrician.
3.
This appliance requires a standard 110-120lt, 60Hz electrical outlet with good grounding means.
Before using your ice maker, it is strongly recommended to clean it thoroughly.
Unplug the unit bere cleaning or making any maintenance.
1.
ke out the ice basket.
2.
Clean the interior with diluted detergent, warm water and a soft cloth.
3.
Then use the water to rinse the inside parts, and drain out the water by unplugging the drain cap on
front bottom side.
4.
The outside of the ice maker should be cleaned regularly with a mild detergent solution and warm
water.
5.
Dry the interior and exterior with a clean soft cloth.
6.
When the machine is not to be used for a long time, drain water completely & dry the interior.
MA
How to start the unit
1.
ke out the ice basket, pour potable water into water reservoir, 0.3 gallon water at most at one time.
2.
Put back the ice basket.
5
pour water
System Cleaning/Sanitizing Procedure
1.Unplug the nugget ice maker.
2.ke o the bottom drain cap and drain out the water to a sink.
See the figure below.
3.Produce a solution by diluting one teaspoon of household bleach with five cups of water
for daily cleaning.
For monthly cleaning of removing mineral deposits , please use the white vinegar instead of the
above water solution (and then plug in to turn on the "cleaning function" for about 5 minutes. Aer
that, unplug it again to leave the white vinegar in the unit more than 12hours).
4.Pour the solution into the water reservoir, up to the "MAX" water level.See the figure below.
7
5.Plug in the Nugget ice maker,press and hold the "Clean" button for 5 seconds to
initiate the cleaning process(15mins).See the figure below.
Ice Ful
0
0
lce,Clean
6.When the "cleaning" indicator lights off, take off
the drain cap and drain out the water to a sink.
7.Repeat the step 4 to 6 with fresh water for two more cycles to rinse the inside.
8.Replace the drain cap on the bottom. See the figure below.
9.When completed, fill the unit with fresh water and press the "Ice" button to start ice making process.
See the figure below.
Ice F
0
Wat
0
8
How to obtain the ice-cube
1.Before we start making ice, please make sure the water drain cap has been inserted into the
appliance; otheise it will not work properly.
2.
Press "ICE/CLEAN" button , Ring indicator light flashes white, it begin to work, Press this button
again, it will stop making ice.
3.
For the first time, or if the appliance has not been used r a long time, it is recommended to clean
this appliance bere you start to make ice.
4.
In the process of making ice, if the "Add water" indicator light is on,and the machine stops working, it
needs adding water. Aer adding water, please restart the machine; Otheise, it needs waiting for a
long time and then automatically start making ice again. When the ice making machine is restarted,
the compressor will have a waiting time of 3 minutes.
5.
When the machine is full of ice, it will automatically stop working. The "ice full" indicator light will be
on, and the ring indicator light will be white. Aer the ice is removed, the machine starts working
automatically.
ice scoop postion
Put the scoop on the top back cover
Ice scoop
Ice scoop holder
9
TROUBLESHOOTING
I ;{t] ::fl
I t1 :1:
h
•H
"Add Water "
Lack of Water.
indicator turns on
There is too much ice.
"ICE FULL"
indicator turns on
No ice cube inside.
Ambient temperature
or
water
temperature in inner tank is too high.
Ring indicator light
Refrigerant liquid leakage.
flashes red
Cover motor is broken
Pipe
in
the
cooling system
is
blocked.
Hot Air outlet has been blocked by
Making Ice too
something.
�IUl•J�I
Stop the ice maker, fill water, and
press "ICE/CLEAN" button again
to restart the unit.
Suggest you
to
obtain
the
ice-cube.
Remove
the
probable obstacle
inside or clean the inside wall of
the ice storage
Please run the
ice maker below
90
Fahrenheit
degree
ambient
and pour colder water into tank.
Press the ICE button twice, restart
ice making program, if this
problem shows up again,
verify it by a qualified technician.
Hot Air outlet must be guaranteed
to have
more than
15
CM
of
ventilation distance.
slowly
Water temperature in the inner
tank is too high.
Refrigeration system malfunctions.
Water temperature requirement
is between TC-32 'C .
Veri it by a qualified technician.
Put the drain plug in place.
Water leakage
Veri it by a qualified technician.
Drain plug is not in place
Pipe Joint in the appliance
maybe loose
The seal has reached its seice life
Veri it by a qualified technician.
10
