COB & SMD LED INSPECTION LAMP -
WIRELESS RECHARGEABLE
MODEL NO: LEDWC03 & LEDWC04
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
I
MP
PO
R
RTA
TA
NT:
PLEA
S
E READ THE
S
E IN
S
TRU
C
TI
O
N
S
C
AREFULLY. N
O
TE THE
S
AFE
O
PERATI
O
NAL RE
Q
UIREMENT
S
, WARNIN
GS
&
C
AUTI
O
N
S
. U
S
E
TH
HE
P
PR
O
ODU
C
T
CO
RRE
C
TLY AND WITH
C
ARE F
O
R THE P
U
RP
OS
E F
O
R WHI
C
H IT I
S
INTENDED. FAIL
U
RE T
O
D
O
SO
MAY
C
A
US
E DAMA
G
E AND
/O
R
PE
ER
S
SON
N
AL IN
JU
RY AND WILL INVALIDATE THE WARRANTY. KEEP TH
ESE
IN
STR
UCT
ION
S S
AFE
FO
R F
U
T
U
RE
USE
.
1. SAFETY
1.1. GENERAL SAFETY
Ensure the lamp is fully charged before initial use.
DO NOT turn the lamp on when it is being charged.
DO NOT shine directly into your, another person’s or an animal’s eyes.
DO NOT allow children to use the lamp.
DO NOT handle or move the lamp whilst it is being charged.
DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fi re:
DO NOT attempt to open, disassemble, modify or service the battery pack.
DO NOT crush, puncture, short external contacts or dispose of in fi re or water.
DO NOT expose to temperatures above 60°C (140°F).
Recycle or dispose of used battery as stipulated by local regulation.
2. INTRODUCTION
LEDWC03: Fully versatile inspection lamp with dimming function. Supplied with one strong magnet on the base and two on the back. Front
lamp produces up to 250lm dimming all the way down to 15lm. The top spotlight acts as a torch at 100lm. Operating time is 3hr for the main
light and up to 6hr on the spotlight. Charge time 4hr. Supplied with Type C USB cable. Compatible with Model No’s WCB3 and WCB4 wireless
charging bases sold separately.
LEDWC04: Fully versatile inspection lamp with dimming function. Supplied with one strong magnet on the base and two on the back. Front
lamp produces up to 500lm dimming all the way down to 15lm. The top spotlight acts as a torch at 100lm. Operating time is 2.5hr for the main
light and up to 10hr on the spotlight. Charge time 4.5hr. Supplied with Type C USB cable. Compatible with Model No’s WCB3 and WCB4
wireless charging bases sold separately.
3. SPECIFICATION
MODEL NO: .........................................................LEDWC03 ...................................................LEDWC04
Battery: ...............................................3.7V Li-Poly 1800mAh ...................................3.6V Li-ion 2500mAh
Charging Time: ..................................................................4hr .......................................................... 4.5hrs
IP Rating: ........................................................................IP54 .............................................................IP54
LED Type: ..............................................3W COB + 1W SMD ....................................5W COB + 1W SMD
Lumen Output: .............................Side; 15-250lm/Top; 100lm ..........................Side; 15-500lm/Top; 100lm
Operating Time: .........................................Side; 3hr/Top; 6hr ................................... Side; 2.5hr/Top; 10hr
The battery fi tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before fi rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not
replace the battery regardless of whether it is less than one year old.
NOTE: The lithium battery does not suff er from memory eff ect and once fully charged may be stored for up to six months without another
charge.
4. OPERATION
4.1. CHARGING THE LAMP
4.1.1. Place lamp on charging base (fi g.1). The blue indicator
light will turn off when charged.
4.1.2. To charge via a ‘type C’ cable lift the fl ap on the side of
the lamp marked ‘input’ and connect cable.
4.2. OPERATING THE LAMP
4.2.1. Push the button marked with the power symbol once to
turn the end light on and twice to activate the large light
on the side of the lamp.
fi g.1
LEDWC03 & LEDWC04 Issue 2 28/07/2021
Original Language Version
© Jack Sealey Limited
Refer to
instructions
4.2.2. Hold the power button in to activate the dimming function, release the power button when the lamp is at the required brightness.
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
