3.1 Insert the 600x12mm discharge hose to the outlet (fig.1A).
3.2 Insert the 1000x6mm intake hose to the inlet (fig.1B).
3.3 Ensure the discharge hose is placed into a container suitable for the substance and quantity to be
transferred.
3.4 Raise and compress the handle (fig.1C), fluid should begin to flow after 3 strokes.
InstRuCtIons foR:
FLUID TRANSFER PUMP
MoDEL no :
TP501
IMPoRtAnt: PLEAsE READ tHEsE InstRuCtIons CAREfuLLY. notE tHE sAfE oPERAtIonAL REQuIREMEnts,
WARnInGs & CAutIons. usE tHE PRoDuCt CoRRECtLY AnD WItH CARE foR tHE PuRPosE foR WHICH It Is
IntEnDED. fAILuRE to Do so MAY CAusE DAMAGE AnD/oR PERsonAL InJuRY AnD WILL InVALIDAtE tHE
WARRAntY. PLEAsE KEEP InstRuCtIons sAfE foR futuRE usE.
WARNING! DO NOT operate using flammable liquids in a confined space, the area should have adequate
ventilation.
3 If pumping flammable liquids, avoid proximity to naked flames or welding operations.
3 Wear appropriate protective clothing when pumping solvents. We recommend eye/face and hand protection,
available from your authorised sealey dealer.
3 Ensure Health & safety, local authority, and general workshop practice regulations are adhered to when
using this equipment.
3 Ensure spillages are dealt with immediately. failure to do so could lead to personal injury or damage to the
environment and possible prosecution by the authorities.
3 Keep children away from areas where solvents are being used.
1. SAFETY INSTRUCTIONS
Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
3. ASSEMbLY / OPERATION
2. SPECIFICATION
Brass constructed pump suitable for syphoning a variety of uids including oils, coolants, transmission uid, diesel
and antifreeze. fitted with removable neoprene end caps. supplied with 1m x 6mm intake hose and 600mm x 12mm
discharge hose. Ideal for draining gearboxes and differentials. Delivers approximately 100ml per stroke.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: no liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: for a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
sales@sealey.co.uk
Sole UK Distributor, Sealey Group,
Kempson Way, suffolk Business Park,
Bury st. Edmunds, suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version
tP501 Issue: 1 - 01/09/11
