USER’S MANUAL
Sofa Bed
HW68469
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: cs.us@costway.com
UK: cs.uk@costway.com
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
02
ASSEMBLY INSTRUCTION
WARNING:
·This sofa bed has been designed for seating and as an
alternate sleep product for two(2)average adults.To prevent
injury and damage to this unit,PROHIBIT jumping on the seat
and back.
·This product is designed for home use and not intended for
commercial use.
·WARNING FOR YOUNG CHILDREN-This product contains
small components,please ensure that they are kept away from
young children.Children under the age of 5,small infants and
babies must not sleep on this futon for safty reasons.
·Recommended number of people needed for assembly: 1
person. (however it is always better to have an extra
hand)estimated assembly time is 15 minutes.
03
Body：
Parts List
QTY 2
A
LEG-1
QTY:2
B
LEG-2
QTY:4
C
04
Hardware List
BOLT 1
M10 x 25mm
QTY:8
D
HEX KEY
6mm
QTY:1
F
BOLT 2
M10 x 35mm
QTY:4
E
05
As shown below,unfold the cushion(A),and then go to the next
step.
1
06
Open the flaps,find legs(B)and (C),and use bolts(D)(E) and
hex key(F)to insert them inside the cushion(A),as shown
below.
2
07
Fix leg(B) with bolt (E) by hex key(F),fix leg(C)with bolt(D) by
hex key(F),shown as below.
3
08
F
F
Completed! Turn the cushion all over & set it on its legs.
4
09
Convert to sofa:In bed(flat) position,simply lift backrest upward
with each click sound until you reach the sofa position.
5
Bed position
Sofa position
10
Convert to bed:From sofa or split position,lift backrest all the
way up until the last click is heard ,then unlock the mechanism
and carefully return to the flat position.
6
Split back position
Bed position
11
