Sofa Bed
HV10008
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Before You Start
Read each step carefully before starting. It is very important
to ensure each step followed in correct order, otherwise
assembly difficulties may occur.
Most of board parts are labeled or stamped on the raw
edges. Have a check to make sure all parts are included.
Work in a spacious area, preferably on a carpet close to
where the unit will be used.
Keep the handtools close at hand. Do not use power tools to
assemble your furniture. They may scratch or damage the
parts.
02
WARNING
• This product has been designed for seating three (3) average
adults. To prevent injury and damage to this unit, PROHIBIT jumping
on it.
• This product is designed for home use and not intended for
commercial use.
• Recommended # of people needed for handling: 2 (however it is
always better to have an extra hand.)
• THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
03
Sofa Body
1
Front Leg Rear Leg
3 3
2
2
PARTS
A x1
Hex Key
B x4
Bolt
C x4
Washer
M8 x 30mm M8 x 19mm
M5
04
QTY:1
QTY:2 QTY:2
01
02
05
1
B
×4
A
× 1
C
× 4
2
×2
3
×2
C
× 4
× 4
B
× 1
A
1
2
×2
2
A
B
C
2
2
03
06
3
×2
3
3
3
3
3
3
3
3
FUNCTIONS :
Care and Maintenance
Use a soft, clean cloth that will not scratch the surface when dusting.
Use of furniture polish is not necessary.
Should you choose to use polish, test first in an inconspicuous area.
Using solvents of any kind on your furniture may damage the finish.
Never use water to clean your furniture as it may cause damage to the
finish.
Liquid spills should be removed immediately. Using a soft clean cloth, blot
the spill gently. Avoid rubbing.
Check bolts/screws periodically and tighten them if necessary.
It is best to keep your furniture in a climate-controlled environment.
Extreme temperature and humidity changes can cause fading, warping,
shrinking and splitting of wood.
It is advised to keep furniture away from direct sunlight as sun may
damage the finish.
Proper care and cleaning at home will extend the life of your purchase.
Following these important and helpful tips will enhance your furniture as it
ages.
Further advice about wood
furniture care
07
Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us !
Do NOT return this item.
