Video Intercom Villa Door Staon
User Manual
Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in
supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Video Intercom Villa Door Staon User Manual
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Video Intercom Villa Door Staon User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Video Intercom Villa Door Staon User Manual
iii
Safety Instrucon
Warning
●
All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
●
Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●
When the product is installed on wall or ceiling, the device shall be
rmly xed.
●
If smoke, odors or noise rise from the device, turn
o the power at once and unplug the power
cable, and then please contact the service center.
●
If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauon
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
The device cover for indoor use shall be kept from rain and moisture.
●
Exposing the equipment to direct sun light, low
venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause
re danger).
●
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
●
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Please keep all wrappers
aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to
addional costs.
Video Intercom Villa Door Staon User Manual
iv
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●
Input voltage should meet both the SELV and the Limited Power Source according to 60950-1
standard.
●
The power supply must conform to LPS. The recommended adaptor models and manufacturers
are shown as below. Use the aached adapter, and do not change the adaptor randomly.
Model Manufacturer Standard
ADS-24S-12 1224GPCN SHENZHEN HONOR ELECTRONIC
CO.,LTD
CEE
G0549-240-050 SHENZHEN GOSPELL DIGITAL
TECHNOLOGY CO.,LTD
CEE
TS-A018-120015Ec SHENZHEN TRANSIN TECHNOLOGIES
CO., LTD
CEE
Video Intercom Villa Door Staon User Manual
v
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the
instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the
separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired
operaon.
Video Intercom Villa Door Staon User Manual
vi
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operaon is subject to
the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence.
L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2.
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est
suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the
transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres
ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
Video Intercom Villa Door Staon User Manual
vii
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
Video Intercom Villa Door Staon User Manual
viii
Contents
Chapter 1 Appearance ................................................................................................................ 1
Chapter 2 Terminal and Wiring Descripon ................................................................................. 3
2.1 Terminal Descripon .............................................................................................................. 3
Chapter 3 Installaon ................................................................................................................. 5
3.1 Accessory Introducon .......................................................................................................... 5
3.2 Surface Mounng .................................................................................................................. 6
3.3 Flush Mounng ...................................................................................................................... 8
Chapter 4 Acvaon ................................................................................................................. 10
4.1
Acvate Device Locally ......................................................................................................... 10
4.2 Acvate Device via Web ....................................................................................................... 10
4.3 Acvate Device via Client Soware ...................................................................................... 11
Chapter 5 Local
Conguraon ................................................................................................... 12
5.1 Quick Conguraon ............................................................................................................. 12
5.2 Authencaon via Admin .................................................................................................... 18
5.3 Forget Admin Password ....................................................................................................... 20
5.4 User Management ............................................................................................................... 22
5.5 Network Parameters
Sengs .............................................................................................. 24
5.5.1 Edit Wired Network Parameters ................................................................................. 24
5.5.2 Connect to Wi-Fi ......................................................................................................... 26
5.5.3 Cloud Service
Sengs ................................................................................................. 27
5.5.4 Device Hotspot ............................................................................................................ 28
5.6 Local
Sengs ....................................................................................................................... 30
5.7 System Maintenance ............................................................................................................ 31
Chapter 6 Local
Operaon ........................................................................................................ 34
6.1 Call from the Device ............................................................................................................. 34
6.1.1 Call Resident ............................................................................................................... 34
Video Intercom Villa Door Staon User Manual
ix
6.1.2 Call Center ................................................................................................................... 37
6.2 Unlock Door ......................................................................................................................... 37
6.2.1 Unlock by Password .................................................................................................... 37
6.2.2 Unlock by Face ............................................................................................................ 37
6.2.3 Unlock by
Presenng Card .......................................................................................... 37
6.2.4 Unlock by QR Code ..................................................................................................... 37
Chapter 7 Quick Operaon via Web Browser ............................................................................ 39
7.1 Change Password ................................................................................................................. 39
7.2 Select Language ................................................................................................................... 39
7.3 Time Sengs ........................................................................................................................ 39
7.4 Environment Sengs ........................................................................................................... 40
7.5 Administrator Sengs ......................................................................................................... 40
7.6 No. and System Network ..................................................................................................... 41
Chapter 8 Operaon via Web Browser ...................................................................................... 42
8.1 Login .................................................................................................................................... 42
8.2 Forget Password ................................................................................................................... 42
8.3 Overview .............................................................................................................................. 42
8.4 Person Management ............................................................................................................ 44
8.5 Device Management ............................................................................................................ 46
8.6
Conguraon ....................................................................................................................... 47
8.6.1 Set Local Parameters ................................................................................................... 47
8.6.2 View Device Informaon ............................................................................................. 47
8.6.3 Set Time ...................................................................................................................... 47
8.6.4 Set DST ........................................................................................................................ 48
8.6.5 Change Administrator's Password ............................................................................... 48
8.6.6 Online Users ................................................................................................................ 48
8.6.7 View Device Arming/Disarming
Informaon .............................................................. 49
8.6.8 Network
Sengs ......................................................................................................... 49
Video Intercom Villa Door Staon User Manual
x
8.6.9 Set Video and Audio Parameters ................................................................................ 53
8.6.10 Set Image Parameters ............................................................................................... 54
8.6.11
Moon Detecon ...................................................................................................... 55
8.6.12 Event Linkage ............................................................................................................ 56
8.6.13 Access Control Sengs ............................................................................................. 57
8.6.14 Intercom Sengs ...................................................................................................... 60
8.6.15 Set Card Security ....................................................................................................... 63
8.6.16 Set Biometric Parameters ......................................................................................... 63
8.6.17 Set Screen Display ..................................................................................................... 65
8.6.18 Upgrade and Maintenance ....................................................................................... 66
8.6.19 Device Debugging ..................................................................................................... 67
8.6.20 Cercate Management ........................................................................................... 67
Appendix A.
Communicaon Matrix and Device Command ...................................................... 69
Video Intercom Villa Door Staon User Manual
xi
Chapter 1 Appearance
Figure 1-1 Device Appearance
Table 1-1
Descripon
No. Descripon
1 IR Light
2 Microphone
3 IR Light
4 Camera
5 Touch Screen
6 Buon
7 TF Card Slot
Video Intercom Villa Door Staon User Manual
1
No. Descripon
8 Debugging Port
9 TAMPER
10 Terminals
11 Network Interface
12 Loudspeaker
Video Intercom Villa Door Staon User Manual
2
Chapter 2 Terminal and Wiring Descripon
2.1 Terminal Descripon
Figure 2-1 Terminal Descripon
Table 2-1 Descripon of Terminal and Interfaces
Name Interface Descripon
DOOR NC2 Door Lock Relay Output 2 (NC)
COM2 Common Interface
NO2 Door Lock Relay Output 2 (NO)
NC1 Door Lock Relay Output 1 (NO)
COM1 Common Interface
NO1 Door Lock Relay Output 1 (NO)
ALARM IN AI1 Alarm Input 1 (For the access of Door Contact)
AI2 Alarm Input 2 (For the access of Door Contact)
Note
Before accessing to the Door Contact, select
Input as Door Status in I/O Sengs page rst.
AI3 Alarm Input 3 (For the access of Exit Buon)
Video Intercom Villa Door Staon User Manual
3
Name Interface Descripon
AI4 Alarm Input 4 (For the access of Exit Buon)
Note
Before accessing to the Exit Buon, select
Input as Exit Buon in I/O Sengs page rst.
GND Grounding
RS-485 485+ RS-485 Communicaon Interface
485-
Power Input GND 12 VDC Input
Video Intercom Villa Door Staon User Manual
4
Chapter 3 Installaon
Note
●
Make sure the device in the package is in good condion and all the assembly parts are included.
●
Make sure your power supply matches your door staon.
●
Make sure all the related equipment is power-o during the installaon.
●
Check the product
specicaon for the installaon environment.
3.1 Accessory Introducon
Figure 3-1 Installaon Plate
Note
The dimension of plate for door staon is: 160.3 mm × 86 mm.
Video Intercom Villa Door Staon User Manual
5
3.2 Surface Mounng
Steps
1.
Sck the mounng template on the wall. Drill screw holes according to the mounng template.
Remove the template from the wall.
Video Intercom Villa Door Staon User Manual
6
Figure 3-2 Mounng Template
2.
Secure the mounng plate on the gang box with the 4 supplied screws (SC-KA4X25). Remove the
back cover and route the cable through the cable hole, wire the cables and insert the cables in
the gang box.
Video Intercom Villa Door Staon User Manual
7
3.
Align the device with the mounng plate, and secure the device on the mounng plate with 1
supplied screw (SC-M3X8NL-SUS316L-GB78).
Figure 3-3 Surface Mounng
3.3 Flush
Mounng
Steps
1.
Make sure the gang box is installed on the wall.
2.
Secure the
mounng plate on the gang box with the four supplied screws (SC-KA4X25).
3.
Remove the back cover and route the cable through the cable hole, wire the cables and insert
the cables in the gang box.
4.
Align the device with the
mounng plate, and secure the device on the mounng plate with 1
supplied screw (SC-M3X8NL-SUS316L-GB78).
Video Intercom Villa Door Staon User Manual
8
Figure 3-4 Flush Mounng
Video Intercom Villa Door Staon User Manual
9
Chapter 4 Acvaon
4.1 Acvate Device Locally
You are required to acvate the device rst by sengs a strong password for it before you can use
the device.
Steps
1.
Power on the device to enter the acvaon page automacally.
2.
Create a password and conrm it.
Note
You can tap to enable or disable password reveal.
3.
Tap Next to nish acvaon.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum
of 8 characters, including at least three kinds of following categories: upper case leers, lower
case leers, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can beer protect your product.
What to do next
Aer acvang the device, the quick conguraon page will pop-up automacally. Refers to Quick
Conguraon for details.
4.2
Acvate Device via Web
You are required to acvate the device rst by seng a strong password for it before you can use
the device.
Default parameters of the door
staon are as follows:
●
Default IP Address: 192.0.0.65.
●
Default Port No.: 8000.
●
Default User Name: admin
Steps
1.
Power on the device, and connect the device to the network.
2.
Enter the IP address into the address bar of the web browser, and click Enter to enter the
acvaon page.
Video Intercom Villa Door Staon User Manual
10
Note
The computer and the device should belong to the same subnet.
3.
Create and enter a password into the password eld.
4.
Conrm the password.
5.
Click OK to
acvate the device.
4.3 Acvate Device via Client Soware
You can only congure and operate the door staon aer creang a password for the device
acvaon.
Default parameters of door staon are as follows:
●
Default IP Address: 192.0.0.65.
●
Default Port No.: 8000.
●
Default User Name: admin.
Steps
1.
Run the client
soware, click Maintenance and Management → Device Management → Device
to enter the page.
2.
Click Online Device.
3.
Select an
inacvated device and click Acvate.
4.
Create a password, and
conrm the password.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum
of 8 characters, including at least three kinds of following categories: upper case leers, lower
case leers, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can beer protect your product.
5.
Click OK to acvate the device.
Note
●
When the device is not acvated, the basic operaon and remote operaon of device cannot
be performed.
●
You can hold the Ctrl or Shi key to select mulple devices in the online devices, and click the
Acvate buon to acvate devices in batch.
Video Intercom Villa Door Staon User Manual
11
Chapter 5 Local Conguraon
5.1 Quick Conguraon
Aer acvang the device, the quick conguraon page will pop up automacally.
Steps
1.
Select the system language and tap NEXT.
Video Intercom Villa Door Staon User Manual
12
Figure 5-1 Select Language
2.
Set password reset method and tap NEXT.
-
Enter the Reserved Email address, then you can reset the admin password by email.
Note
On the security quesons sengs page, you can tap Change to Reserved Email to modify the
password reset method.
Video Intercom Villa Door Staon User Manual
13
Figure 5-2 Password Reset by Seng Reserved Email Address
-
Tap Change to Security Queson. Select 3 security quesons from deciency list and enter
the answers of the
quesons, then you can reset the password by answering security
quesons.
Video Intercom Villa Door Staon User Manual
14
Figure 5-3 Password Reset by Seng Security Quesons
3.
Set network parameters and tap NEXT.
Video Intercom Villa Door Staon User Manual
15
-
Figure 5-4 Wired Network
Set the IP address, Subnet Mask and Gateway manually.
Enable DHCP, the device will get network parameters
automacally.
Video Intercom Villa Door Staon User Manual
16
-
Figure 5-5 Wireless Network
4.
Enable the cloud service funcons and create a vericaon code. Tap NEXT.
Video Intercom Villa Door Staon User Manual
17
Figure 5-6 Cloud Service
5.
Tap Next to nish wizard.
5.2
Authencaon via Admin
You can congure the parameters of the device on the menu page. You should authencate to
enter the menu.
Video Intercom Villa Door Staon User Manual
18
If you want to authencate via face or card, you should add administrator rst. Refers to User
Management for details.
Steps
1.
Hold the screen to enter the
authencaon page.
2.
You can enter the admin password or authencaon via face or card to enter the menu.
Note
Admin password is set as acvaon password.
Video Intercom Villa Door Staon User Manual
19
Figure 5-7 Menu Page
5.3 Forget Admin Password
Admin password is used for
authencang to enter the local conguraon menu. If you forget the
password, you can change it by entering security quesons' answers.
Steps
1.
Hold the main page to enter the authencaon page.
Video Intercom Villa Door Staon User Manual
20
Figure 5-8 Authencaon Page
2.
Tap Forgot Password.
3.
Change the admin password via entering answers of security
quesons or email address.
4.
Create and conrm a new password.
Video Intercom Villa Door Staon User Manual
21
5.4 User Management
On the user management page, you can add new users, congure the user's room informaon,
card informaon, and face informaon.
Before You Start
Authencate and enter the menu rst. Refers to Authencaon via Admin for details.
Steps
1.
On the menu, tap User to enter the
sengs page.
Video Intercom Villa Door Staon User Manual
22
Figure 5-9 User Management
2.
Tap + to enter the add user page.
3.
Set Employee No., Name, Room No. and Floor No..
4.
Add Face.
1) Tap Face Picture, and point the face at the camera.
2) Tap
to add the face.
3) Tap to enable the sengs.
5.
Add Card.
1) Tap Card, and tap + to enter the add card page.
Video Intercom Villa Door Staon User Manual
23
2) Enter the card No. manually or present the card in the card presenng area to obtain the card
No.
3) Tap OK to enable the sengs.
6.
Set User Role as Normal User or Administrator.
7.
Exit the
sengs page.
5.5 Network Parameters Sengs
The device support wired network, wireless network, cloud service sengs and hotspot.
5.5.1 Edit Wired Network Parameters
The device should be connected to the network.
Before You Start
Authencate and enter the menu rst. Refers to Authencaon via Admin for details.
Steps
1.
On the menu, tap Network → Wired Network to enter the sengs page.
Video Intercom Villa Door Staon User Manual
24
Figure 5-10 Wired Network Sengs
2.
Edit the wired network parameters.
-
Edit the wired network parameters manually.
-
Enable DHCP, and the system will get the parameters
automacally.
Video Intercom Villa Door Staon User Manual
25
3.
Select a Wi-Fi and enter the password to connect.
5.5.3 Cloud Service Sengs
Enable the funcon, you can congure the device via mobile client remotely.
Before You Start
Authencate and enter the menu rst. Refers to Authencaon via Admin for details.
Steps
1.
On the menu, tap Network → Cloud Service to enter the
sengs page.
Video Intercom Villa Door Staon User Manual
27
Figure 5-12 Cloud Service Sengs
2.
Slide to enable the funcon.
3.
Edit the Cloud Service Address and create a Vericaon Code.
4.
Tap √ to save the sengs.
5.5.4 Device Hotspot
Set the device hotspot.
Video Intercom Villa Door Staon User Manual
28
On the menu, tap Network → Hotspot to enter the sengs page.
Figure 5-13 Hotspot Sengs
Click to enable Hotspot. Set hotspot Name and Password.
Click Save.
Video Intercom Villa Door Staon User Manual
29
5.6 Local Sengs
Steps
1.
Tap Local on the sengs page.
Figure 5-14 Local
Sengs
2.
Tap Language and select a language at your needs.
3.
Tap Number Conguraon and set the building No., oor No., room No., project No., and unit
No. Tap < to save the
sengs.
Video Intercom Villa Door Staon User Manual
30
4.
Tap Mode Selecon to choose live view or custom theme.
5.
Tap to Enable Face Auth., Open Door via QR Code and Call Management Centerat your needs.
6.
Tap Brightness and drag the block to adjust the screen light.
5.7 System Maintenance
You can restore the device, upgrade system, reboot device or view device informaon, capacity
and user manual on the system maintenance page.
Tap Maint. on the
sengs page to enter the system maintenance page.
Video Intercom Villa Door Staon User Manual
31
Figure 5-15 System Maintenance
System Informaon
You can view the device model, serial No., APP version and disclaimer.
Capacity
You can view the used and total capacity of user, face and card.
Device Upgrade
Tap Upgrade to get the upgrade package online.
Video Intercom Villa Door Staon User Manual
32
User Manual
You can scan the QR code to get the user manual.
Restore to Factory Sengs
Tap Restore to Factory Sengs to restore all parameters and reboot the system.
Restore to Default
Sengs
Tap Restore to Default Sengs to restore the default sengs and reboot the system.
Reboot
Tap to reboot the device.
Video Intercom Villa Door Staon User Manual
33
Chapter 6 Local Operaon
6.1 Call from the Device
Door staon supports calling users or management center.
6.1.1 Call Resident
Call Resident from Door Staon
On the main page, tap to enter the calling page.
Video Intercom Villa Door Staon User Manual
34
Figure 6-1 Calling
Enter the Room No., and tap to call residents.
Tap contact
buon to enter the contact list. Select a contact from the list to call.
Video Intercom Villa Door Staon User Manual
35
Figure 6-2 Contacts
Call Resident from Outer Door
Staon
On the main page of the outer door staon, tap Call to enter the calling page.
Enter Phase No. + # + Building No. + # + Unit No. + # + Room No., and tap Call again to call
residents.
Enter Phase No. + # + Building No. + # + Unit No. + # + Room No., and tap Call again to call
residents.
Enter Phase No. + # + Room No., and tap Call again to call residents.
Video Intercom Villa Door Staon User Manual
36
6.1.2 Call Center
On the sengs page, tap Local and enable Call Management Center to set the calling shortcut key.
Tap
on the main page to call management center administrator. Tap cancel buon to cancel
during calling management center.
6.2 Unlock Door
You can unlock door staon in following methods: Unlock by password, unlock by card, unlock by
face, and unlock by QR code.
6.2.1 Unlock by Password
Tap call buon on the main page to enter the calling page.
Enter 【 # + Public Password 】, and tap unlock
buon.
6.2.2 Unlock by Face
Note
Make sure that you have added your face picture to the device. Refers to the User Management for
details.
Face forward at the camera to unlock.
Note
●
Face recognion distance: 0.3 m to 2 m
●
Face recognion duraon: ＜ 0.2 s per person
6.2.3 Unlock by Presenng Card
Note
Make sure you have issued the card to the device. Refers to User Management for details.
Present the card on the card reading area to unlock.
6.2.4 Unlock by QR Code
Door staon supports unlock by QR code. You can generate a QR code through the mobile phone
client, and use the door
staon camera to scan the mobile phone QR code to open the door.
Video Intercom Villa Door Staon User Manual
37
Steps
Note
●
Make sure that the door staon IP has been added to the indoor staon, and the indoor staon
and the door staon can communicate normally.
●
Make sure that the door staon is connected to the network.
●
QR code is for visitors only.
1.
Installing Hik-Central Pro on your PC.
2.
Register user accounts according to the prompts, and log in.
3.
Follow the prompts to add the indoor
staon by scanning the QR code/barcode or manually
entering the serial number.
4.
Enter unlock by QR code page and generate the QR code.
5.
On the main page of door
staon, tap down buon to enter the unlock by QR code page.
6.
Aim the QR code generated by the phone at the camera and scan the code to open the door.
Note
●
It is recommended that when installing the door staon, try to select a locaon that does not
cause reecons, otherwise it may aect the QR code scanning. If it is acrylic door staon,
make sure that the membrane on the surface of the door machine has been torn o.
●
It is recommended to align the mobile phone's QR code with the door
staon camera
horizontally when scanning the QR code.
●
QR code
recognion is not supported at night.
Video Intercom Villa Door Staon User Manual
38
Chapter 7 Quick Operaon via Web Browser
7.1 Change Password
You can change the device password.
Click in the top right of the web page to enter the Change Password page. You can set security
quesons from the drop-down list and ll in the answers.
You can set the reserved E-mail address for password reset.
Click Next to complete the sengs.
7.2 Select Language
You can select a language for the device system.
Click
in the top right of the web page to enter the wizard page.
Click Next on the change password page. You can select a language for the device system from the
drop-down list.
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
Click Next to complete the sengs.
7.3 Time
Sengs
Set Time and DST
Click → Time Sengs .
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Video Intercom Villa Door Staon User Manual
39
Server Address Type/Server Address/NTP Port/Interval
You can set the server address type, server address, NTP port, and interval.
DST Sengs
Enable DST.
Set the DST start
me, end me and bias me.
Click Next to complete the sengs.
7.4 Environment Sengs
Aer acvang the device, you should select an applicaon mode for beer device applicaon.
Steps
1.
Click
→ Environment Sengs.
2.
Select Indoor or Other.
Note
●
If you install the device indoors near the window or the face recognion funcon is not
working well, select Others.
●
If you do not congure the applicaon mode and tap Next, the system will select Indoor by
default.
●
If you acvate the device via other tools remotely, the system will select Indoor as the
applicaon mode by default.
Click Next to complete the sengs.
7.5 Administrator
Sengs
Steps
1.
Click in the top right of the web page to enter the wizard page. Aer seng device language,
me, environment and privacy, you can click Next to enter the Administrator Sengs page.
2.
Enter the employee ID and name of the administrator.
3.
Select a
credenal to add.
Note
You should select at least one credenal.
1) Click Add Face to upload a face picture from local storage.
Note
The uploaded picture should be within 200 KB, in JPG、JPEG、PNG format.
2) Click Add Card to enter the Card No. and select the property of the card.
Video Intercom Villa Door Staon User Manual
40
Note
Up to 5 cards can be supported.
Click Next to save the sengs and go to the next paramater. Or click Skip to skip administrator
sengs.
7.6 No. and System Network
Steps
1.
Click in the top right of the web page to enter the wizard page. Aer previous sengs, you
can click Next to enter the No. and System Network sengs page.
2.
Set the device type.
If set the device type as Door
Staon or Outer Door Staon, you can set the Community No.,
Building No., Unit No., Floor No., and Door
Staon No.
If set the device type as Outer Door Staon, you can set outer door staon No., and community
No.
3.
Set
Registraon Password, Main Staon IP and Private Server IP.
4.
Oponal: Click to Enable Protocol 1.0.
5.
Click Complete to save the
sengs aer the conguraon.
Video Intercom Villa Door Staon User Manual
41
Chapter 8 Operaon via Web Browser
8.1 Login
You can login via the web browser or the remote conguraon of the client soware.
Note
Make sure the device is acvated.
Login via Web Browser
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
Login via Remote
Conguraon of Client Soware
Download and open the client soware. Aer adding the device, click to enter the Conguraon
page.
8.2 Forget Password
If you forget the password when logging in, you can change the password by email address or
security
quesons.
On the login page, click Forget Password.
Select
Vericaon Mode.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the vericaon code into the vericaon code eld to verify your idencaon.
Click Next, create a new password and conrm it.
8.3 Overview
You can view the live video of the device, linked device, person
informaon, network status, basic
informaon, and device capacity.
Video Intercom Villa Door Staon User Manual
42
Figure 8-1 Overview Page
Funcon Descripons:
Door Status
Click to view the device live view.
Set the volume when starng live view.
Note
If you adjust the volume when starng two-way audio, you may hear a repeated sounds.
You can capture image when starng live view.
Select the streaming type when starng live view. You can select from the main stream, sub
stream or third stream.
Full screen view.
/ / /
The door status is open/closed/remaining open/remaining closed.
Controlled Status
You can control the door1 or door2 to be opened, closed, remaining open or remaining
closed according to your actual needs.
Link Device
You can view the
quanty and status of linked devices.
Person Informaon
Video Intercom Villa Door Staon User Manual
43
You can view the added and not added informaon of person face and card.
Network Status
You can view the connected and registered status of wired network, wireless network, cloud
service and SIP.
Basic
Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, face, and card capacity.
View More
You can click View More to Device Management .
8.4 Person Management
Click Add to add the person's informaon, including the basic informaon, cercate,
authencaon
and sengs.
Video Intercom Villa Door Staon User Manual
44
Figure 8-2 Add Person
Add Basic
Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, oor No., and
room No.
Click Save to save the
sengs.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
Enable Long-Term
Eecve User, or set Validity Period and the person can only has the permission
within the congured me period according to your actual needs.
Click Save to save the sengs.
Add Face Picture
Click Person Management → Add to enter the Add Person page.
Click + on the right to upload a face picture from the local PC.
Video Intercom Villa Door Staon User Manual
45
Note
The picture format should be JPG or JPEG or PNG, and the size should be less than 200 KB.
Click Save to save the sengs.
Add Card
Click Person Management → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Note
Up to 5 cards can be added.
Click Save to save the sengs.
8.5 Device Management
You can manage the linked device on the page.
Steps
1.
Click Device Management to enter the
sengs page.
2.
Click Search Online Device to search for the online devices automacally.
3.
Click Add to add the indoor staon or sub door staon. Enter the parameters and click OK to
add.
4.
Click Import. Enter the
informaon of the device in the template to import devices in batch.
5.
Click Export to export the
informaon to the PC.
6.
Select the device and click Delete to remove the selected device from the list.
7.
Click Device Upgrade and import upgrading package to install the latest version.
8.
Click Upgrade Status to view the upgrading process.
9.
Click to enable
Synchronizaon Sengs.
Note
If enabled, the current device's sengs will be synchronized to other devices.
10.
Click Refresh to get the device informaon.
11.
Oponal: Set Device Informaon.
Edit Device
Informaon Click to edit device informaon.
Delete Device Informaon Click to delete device informaon from the list.
Search Devices Select Status and Device Type to search devices.
Video Intercom Villa Door Staon User Manual
46
8.6 Conguraon
8.6.1 Set Local Parameters
Set the live view parameters, picture and clip sengs.
Set Live View Parameters
Click Conguraon → Local to enter the Local page. Congure the stream type, the play
performance and click Save.
Picture and Clip
Sengs
Click Conguraon → Local to enter the Local page. Select image format, saving path and click
Save.
You can also click Open to open the
le folder to view details.
8.6.2 View Device
Informaon
View the device name, device No., system type, language, model, serial No., version, number of
channels, IO input, RS-485, register number, alarm input, alarm output, and device capacity, etc.
Click
Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, device No., system type, language, model, serial No., version,
number of channels, IO input, RS-485, register number, alarm input, alarm output, and device
capacity, etc.
8.6.3 Set Time
Set the device's me, me zone, synchronizaon mode, server address, NTP port, and interval.
Click Conguraon → System → System Sengs → Time Sengs .
Click Save to save the
sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
Video Intercom Villa Door Staon User Manual
47
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server Address Type/Server Address/NTP Port/Interval
You can set the server address type, server address, NTP port, and interval.
8.6.4 Set DST
Steps
1.
Click Conguraon → System → System Sengs → Time Sengs .
2.
Enable DST.
3.
Set the DST start
me, end me and bias me.
4.
Click Save to save the sengs.
8.6.5 Change Administrator's Password
Steps
1.
Click
Conguraon → System → User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
8.6.6 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
Video Intercom Villa Door Staon User Manual
48
8.6.7 View Device Arming/Disarming Informaon
View device arming type and arming IP address.
Go to
Conguraon → User Management → Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
8.6.8 Network Sengs
Set TCP/IP, Wi-Fi parameters, and device hotspot.
Set Basic Network Parameters
Click Conguraon → Network → Network Sengs → TCP/IP .
Figure 8-3 TCP/IP Sengs
Set the parameters and click Save to save the sengs.
DHCP
If disable the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default gateway,
preferred DNS server and the Alternate DNS server.
If you check the
funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4
default gateway, preferred DNS server and the Alternate DNS server
automacally.
DNS Server
Video Intercom Villa Door Staon User Manual
49
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Network Sengs → Wi-Fi .
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click Connect of a Wi-Fi in the list and enter the Wi-Fi password.
-
Click Manual Add and enter a Wi-Fi's SSID, working mode, security mode, and password. Click
OK.
4.
Set the WLAN parameters.
1) Set the IP address, subnet mask, and default gateway. Or enable DHCP and the system will
allocate the IP address, subnet mask, and default gateway
automacally.
5.
Set the DNS server. Set the preferred DNS server and alternate DNS server. Or enable DHCP and
the system will allocate the preferred DNS server and alternate DNS server automacally.
6.
Click Save.
Device Hotspot
Set the device hotspot.
On the menu, tap Network → Hotspot to enter the
sengs page.
Video Intercom Villa Door Staon User Manual
50
Figure 8-4 Hotspot Sengs
Click to enable Hotspot. Set hotspot Name and Password.
Click Save.
Network Service
Set the HTTP, HTTPS, HTTP Listening, RTSP and FTP parameters.
Click
Conguraon → Network → Network Service → HTTP(S) .
Video Intercom Villa Door Staon User Manual
51
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is
modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
HTTP Listening
The device can send alarm informaon to the event alarm IP address or domain name via HTTP
protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and
protocol.
Note
The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol
to receive the alarm informaon.
RTSP
Click Conguraon → Network → Network Service → RTSP .
It refers to the port of
real-me streaming protocol.
FTP
Click
Conguraon → Network → Network Service → FTP .
Check to Enable FTP.
Select Server Type. Input the Server IP Address and Port. Congure the user name and
password server login. Set the Directory Structure, Parent Directory and Child Directory. Set
the Delimiter and select Named Item and Named Element.
Note
If you enable Anonymous, you will not need to set user name or password.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click
Conguraon → Network → Device Access → Hik-Connect to enter the sengs page.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
2.
Check Enable to enable the funcon.
3.
Oponal: Check the checkbox of Custom, and you can set the server address by yourself.
4.
Enter the server IP address, and vericaon code.
Video Intercom Villa Door Staon User Manual
52
Note
●
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use
a combinaon of no less than 8 leers or numbers.
●
The vericaon code cannot be 123456 or abcdef (case non-sensive0).
5.
Click Save to enable the sengs.
Device Access Seng
Steps
1.
Click Conguraon → Network → Device Access → SIP to enter the sengs page.
2.
Check Enable VOIP Gateway.
3.
Congure the SIP parameters.
4.
Click Save to enable the sengs.
5.
Click Conguraon → Network → Device Access → SDK Server to enter the sengs page.
6.
Set the Server Port. It refers to the port through which the client adds the device.
8.6.9 Set Video and Audio Parameters
Set the image quality and resoluon.
Set Video Parameters
Click Conguraon → Video/Audio → Video .
Figure 8-5 Video Sengs Page
Video Intercom Villa Door Staon User Manual
53
Set the stream type, the video type, the resoluon, the bitrate type, the video quality, the frame
rate, the Max. bitrate, the video encoding, and I Frame Interval.
Click Save to save the sengs aer the conguraon.
Figure 8-6 Audio Sengs
Set the stream type, audio encoding, input volume, and output volume according to your actual
needs.
Click Save to save the sengs.
8.6.10 Set Image Parameters
You can adjust the image parameters, video parameters, supplement parameters and capture
interval.
Steps
1.
Click Conguraon → Image .
Figure 8-7 Image Sengs
2.
Congure the parameters to adjust the image.
Video Intercom Villa Door Staon User Manual
54
Image Adjustment
Drag the block or enter the value to adjust the live video's brightness, contrast, saturaon,
and sharpness.
Video Adjust
Set the video frame rate when performing live view remotely. Aer changing the standard,
you should reboot the device to take eect.
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
Backlight
Enable or disable WDR.
When there are both very bright and very dark areas simultaneously in the view, WDR
balances the brightness level of the whole image and provide clear images with details.
Image Fusion
Wen the environment is dark, you can select Auto to enable the image fusion
funcon. The
live view page will display the fusion image.
Select Disable to disable the
funcon.
3.
Click Restore Default Sengs to restore the parameters to the default sengs.
8.6.11
Moon Detecon
Moon detecon detects the moving objects in the congured security area, and a series of
acons can be taken when the alarm is triggered.
Steps
1.
Click
Conguraon → Event → Event Detecon → Moon to enter the sengs page.
Video Intercom Villa Door Staon User Manual
55
Figure 8-8 Moon Detecon
2.
Drag the block or set value to adjust sensivity.
3.
Click Modify to edit the arming schedule.
4.
Click on the
me bar and drag to select the me period. Click Save to save the sengs.
5.
Click to enable Nofy Security Center.
Note
Send an excepon or alarm signal to the remote management soware when an event occurs.
6.
Click Save to enable the sengs.
8.6.12 Event Linkage
Set linked acons for events.
Steps
1.
Click Conguraon → Event → Event Detecon → Linkage Sengs to enter the page.
Figure 8-9 Event Linkage
Video Intercom Villa Door Staon User Manual
56
2.
Select device event or door event.
3.
Click to enable or disable Nofy Security Center for event.
Note
Send an excepon or alarm signal to the remote management soware when an event occurs.
8.6.13 Access Control Sengs
Set Authencaon Parameters
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Figure 8-10 Set
Authencaon Parameters
Terminal
Terminal descripon is read-only.
Connuous Face Recognion Interval
You can set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, Person A can only recognized once. If another person
(Person B) has recognized during the interval, Person A can recognized again.
Note
The interval ranges from 1 s to 10 s.
Click Save to save the sengs aer the conguraon.
Set Door Parameters
Click Conguraon → Access Control → Door Parameters .
Door No.
Select the device corresponded door No.
Door Name
Video Intercom Villa Door Staon User Manual
57
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Relay Reverse
Click to enable or disable relay reverse.
Enable QR Code Auth.
Click to enable or disable QR Code
Authencaon.
Enable Face Auth.
Click to enable or disable face Authencaon.
Click Save to save the sengs aer the conguraon.
Elevator Control
Steps
1.
Click Conguraon → Access Control → Elevator Control Parameters .
Figure 8-11 Access Control and Elevator Control
2.
Click to enable Elevator Control.
3.
Set the elevator parameters.
Elevator No.
Select an elevator No.
Main Elevator Controller Model
Select an elevator controller.
Interface Type
If you select RS-485, make sure you have connected the device to the elevator controller with
RS-485 wire.
If you select Network Interface, enter the elevator controller's IP address, port No., user
name, and password for
communicaon.
Video Intercom Villa Door Staon User Manual
58
Negave Floor Capacity
Set the negave oor number.
Note
●
Up to 4 elevator controllers can be connected to 1 device.
●
Up to 10 negave oors can be added.
●
Make sure the interface types of elevator controllers, which are connected to the same
device, are consistent.
RS-485 Sengs
Set the working mode to linked device.
Steps
1.
Click Access Control → RS485 to enter the sengs page.
2.
Select the working mode.
3.
Click Save to enable the
sengs.
Password
Sengs
Set public password.
Click Access Control → Password
Sengs to enter the page.
Click Add to add password.
Video Intercom Villa Door Staon User Manual
59
Figure 8-12 Add Password
Set password and remarks and click to enable electric lock.
Click Save to save the
sengs.
8.6.14 Intercom
Sengs
Device No. Sengs
Steps
1.
Click Device No. to enter the page.
Video Intercom Villa Door Staon User Manual
60
Figure 8-13 Villa Door Staon No. Sengs
2.
Select the device type from the drop-down list, and set the corresponding informaon including
Building No., Floor No., Door Staon No., Community No. and Unit No.
Note
When you select Outer Door Staon as Device Type, only Community No. and Outer Door No.
can be set.
3.
Click Save to enable the device number conguraon.
Linked Network
Sengs
Steps
1.
Click Intercom → Session
Sengs to enter the sengs page.
Figure 8-14 Session Sengs
2.
Set Registraon Password.
3.
Set Main Staon IP and VideoIntercom Server IP.
Video Intercom Villa Door Staon User Manual
61
4.
Enable Protocol 1.0.
5.
Click Save to enable the sengs.
Time Parameters
Go to Intercom → Call Sengs to enter the page.
Congure Max. Communicaon Time and Max. Message Duraon, and click Save.
Note
●
Max. communicaon me between the module indoor staon and client ranges from 90 s to
120 s. The call will end automacally when the actual calling duraon is longer than the
congured one.
●
Max. message
duraon ranges from 30 s to 60 s. The message will end automacally when the
actual message
duraon is longer than the congured one.
Press Buon to Call
Steps
1.
Click Intercom → Press
Buon to Call to enter the sengs page.
2.
Click Call Schedule Sengs to create a new template plan.
1) Set Schedule Name.
2) drag to set weekly schedule for indoor
staon and center.
3) Click Add, set
specic Start Time and End Time, and drag to set schedule for indoor staon
and center.
4) Click Save.
3.
Click
to congure Buon Sengs and select a call schedule.
4.
Click Save.
Number
Sengs
Link the room No. and SIP numbers.
Click Number
Sengs to enter the page.
Video Intercom Villa Door Staon User Manual
62
Figure 8-15 Number Sengs
Click Add, set the Room No. and SIP numbers in the pop-up dialog box.
8.6.15 Set Card Security
Click Conguraon → Card Sengs → Card Type to enter the sengs page.
Click to Enable Card Encrypon Parameters and set the encrypon sector. By default, Sector 13 is
encrypted. It is recommended to encrypt sector 13.
Click Save.
8.6.16 Set Biometric Parameters
Set Basic Parameters
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Video Intercom Villa Door Staon User Manual
63
Figure 8-16 Smart Sengs Page
Click Save to save the sengs aer the conguraon.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Note
Biometric recognion products are not 100% applicable to an-spoong environments. If you
require a higher security level, use mulple authencaon modes.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face
authencaon.
Recognion Distance
Select the distance between the authencang user and the device camera.
Applicaon Mode
Select either others or indoor according to actual environment.
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
Face Recognion Timeout Value
Set the meout value when face recognizing. If the face recognion me is longer than the
congured value, the system will pop up a prompt.
Video Intercom Villa Door Staon User Manual
64
ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment. You can set the ECO mode threshold and ECO mode (1: N).
ECO Mode (1:N)
Set the matching threshold when
authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
Force to Enable Night Mode
You can click to enable forced night mode when the ECO mode is enabled.
Set Recognion Area
Click Conguraon → Smart → Area Conguraon .
Drag the yellow frame in the live video, drag the block or set value to adjust the recognion area.
Only the face within the area can be recognized by the system.
Select Capture Interval from the dropdown list.
Click Save to save the
sengs.
8.6.17 Set Screen Display
You can set the display theme for the device.
Click Conguraon → Preference → Screen Display .
You can select display theme for device
authencaon. You can select Theme Mode as
Authencaon or Adversement.
Click Save.
Noce
Publicaon
You can set the noce publicaon for the device.
Click
Conguraon → Preference → Noce Publicaon .
Theme Management
Click Media Library Management → + to upload the picture from the local PC.
You can click +, and set Name and Type to create a theme.
Aer creang the theme, click + in
the Theme Management panel to select pictures in the media library. Click OK to add pictures
to the theme.
Video Intercom Villa Door Staon User Manual
65
Note
●
The maximum image le size is 10 MB.
●
The supported image formats are .jpg and .jpeg.
●
We recommend keeping the aspect rao of the image/video the same as that of the screen,
otherwise it will
automacally stretch to ll the screen.
Schedule Management
Aer you have created a theme, you can select the theme and draw a schedule on the me line.
Select the drawn schedule, and you can edit the exact start and end me.
Select the drawn schedule and you can click Clear or Clear All to delete the schedule.
Slide Show Interval
Enter a number to set the slide show interval. The picture will be changed according to the
interval.
8.6.18 Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device version.
Reboot Device
Click Maintenance and Security → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click Maintenance and Security → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
If the device has been connected to Hik-Connect and network, when there is a new
installaon
package in Hik-Connect, you can click Upgrade aer Online Update to upgrade the device system.
Note
Do not power o during the upgrading.
Restore Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Restore All
All parameters will be restored to the factory
sengs. You should acvate the device before
usage.
Restore
Video Intercom Villa Door Staon User Manual
66
The device will restore to the default sengs, except for the device IP address and the user
informaon.
Import and Export Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
8.6.19 Device Debugging
You can set device debugging parameters.
Steps
1.
Click Maintenance and Security → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
To raise network security, disable SSH service. The
conguraon is only used to debug the
device for the professionals.
Capture Network Packet
You can set the Capture Packet
Duraon, Capture Packet Size, and click Start Capture to
capture.
8.6.20
Cercate Management
It helps to manage the server/client cercates and CA cercate.
Note
The funcon is only supported by certain device models.
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security →
Cercate Management .
2.
In the Cercate Files area, select a Cercate Type from the drop-down list.
Video Intercom Villa Door Staon User Manual
67
3.
Click Create.
4.
Input cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The
cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed cercate.
1) Select a cercate type in the Import Passwords area, and select a cercate from the local,
and click Install.
2) Select a
cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Install.
Install Other Authorized
Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Maintenance and Security → Security →
Cercate Management .
2.
In the Import Passwords and Import Communicaon Cercate areas, select cercate type
and upload cercate.
3.
Click Install.
Install CA
Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Create an ID in the Import CA
Cercate area.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Install.
Video Intercom Villa Door Staon User Manual
68
Appendix A. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all
communicaon ports of Hikvision access control and video
intercom devices.
Figure A-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port commands.
Note that the command list contains all commonly used serial ports commands for all Hikvision
access control and video intercom devices.
Figure A-2 Device Command
Video Intercom Villa Door Staon User Manual
69
UD30238B-A
