Installation & Programming
Video available on Raindrip.com/timers
R675CT
Tool-Free!
Installation
Tip:
Must have minimum
of 15 PSI at hose bib.
Visit Raindrip.com/timers
Hose Bib
Timer
Hand Tighten
Programming
Tip:
“AUTOMATIC” light
will flash when in
automatic mode.
Programming Changes
! If you avoid the RESET position, Frequency and Run Time dial settings
can be made at any time and will not change your original start time.
! Turn dial from RESET position at the time of day
watering is to start (e.g. at 7:00 am)
1. Set Frequency
(Frequency = How OFTEN you want the water to come on.)
From RESET position, turn dial to
desired setting.
(Example has timer starting once a day.)
2. Set Run Time
(
Run Time = How LONG you want the water to run.)
Set dial to the desired setting.
(Example has timer running for 15 min.)
Getting Started
Tip:
Firmly push down on the
battery tray to ensure it is
clicked into the timer.
Visit Raindrip.com/timers
1. Make sure
you have:
•
(2) Alkaline AA batteries
(not included)
2. Load the batteries
as shown:
Timer
Batteries
Extra Features
Rain Delay
(Rain Delay = Watering delayed for a specified
period of time)
From RESET position, turn dial to
desired “Rain Delay” setting.
(The example shows the program will resume
in 48 hours.)
Manual Watering
(Manual Mode = Watering in between
scheduled programming)
From RESET position, turn dial to
desired “Manual Water” setting.
(The example shows the timer will water manually
for 30 minutes.)
!
Automatic watering will resume automatically
after manual mode is complete
Tip:
Manual light will flash
when in Manual or
Rain Delay modes.
Troubleshooting
Visit Raindrip.com/timers
Water does not come on:
POSSIBLE PROBLEM SOLUTION
Water off Turn water on
Battery power low Replace batteries
Batteries not installed Correct battery
properly installation
Run time is longer or Increase Frequency
the same as Frequency or reduce run time.
(Example: If Frequency dial is set to 1-hour,
then Run Time dial must be 30 minutes or less.)
Winterize: remove from faucet, remove batteries and store indoors.
Warranty: Limited three year warranty from date of purchase.
(original receipt required for warranty claim)
2855 S. East Ave.
Fresno, CA 93725
Technical Service: 888-825-4716
