20W SMD LED RECHARGEABLE PORTABLE
FLOODLIGHT & POWER BANK
MODEL NO: LED1800PB
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, other person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery, the lamp casing or the cable is damaged. Consult your Sealey Stockist.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, dismantle, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 40°C or below -10°C.
8 DO NOT Expose to direct sunlight for long periods of time.
8 DO NOT Expose to moisture.
8 DO NOT place the lamp face down while in use.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, wash thoroughly with soap and water. If it gets in your eyes, rinse thoroughly with
cool water and seek immediate medical attention.
2. INTRODUCTION
Super bright 20W SMD Led light produces 1800 lumens with three brightness settings. Built-in power bank with 5V⎓1A USB output
for providing power on the go. Worklight base can be rotated to provide light at any angle. The stand also features strong magnets
so the light can be attached to any ferrous surface and a fold out hook in the stand base can be used to hang the worklight. Ø6mm
Tripod mount can be used for simple positioning of light and hands-free operation, compatible with Sealey TRI01 1.5m Telescopic
Tripod. Easy-to-read charge indicator displays the battery level while charging. Charges via a USB Type-C cable (supplied).
Lightweight unit folds at and is very easy to transport making it ideal for industrial, professional and domestic use.
3. SPECIFICATION
LED1800PB Issue 4 13/09/2024
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Model No: LED1800PB
Battery: 3.7V 4Ah Lithium-Ion
Charging Time: 6hr
IP Rating: IP44
LED Type: SMD LED
Lumen Output: 1800lm
Nett Weight: 0.735kg
Operating Time: High/Medium/Low: 1/2/4hr
Power: 20W
USB Output:
5V ⎓ 1A
NOTE: The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time. We
will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we
will not replace the battery regardless of whether it is less than one year old.
NOTE: The lithium battery does not suer from memory eect and once fully charged may be stored for up to six months without
another charge.
4. CONTENTS
5. OPERATION
5.1. FIRST USE
5.1.1. Ch a r g e t h e b a t t e r y f u l l y b e f o r e t h e r s t u s e . W h e n u s i n g a
holding device (magnets, stand, etc.), ensure to hold the device
rmly and placed securely in order to avoid possible damage
due to the lamp falling.
5.2. OPERATION
5.2.1. Switch the light on and o by pressing the on/o button.
5.2.2. Press the button once to turn on the light in high brightness
mode.
5.2.3. Press again to change it to medium brightness mode.
5.2.4. Press a third time change it to low brightness mode.
5.2.5. Press a forth time to turn the light o.
5.2.6. CHARGE DISPLAY
5.3. During charging, the LED ashes; when fully charged, the LED
illuminates steadily. Then disconnect the oodlight from the
power supply.
NOTE: Whilst charging it is not possible to use the light.
5.4. POWER-BANK FUNCTION
5.5. WARNING! DO NOT use the power bank whilst charging.
5.6. Connect the device that requires charing to the back of the light via the output port.
6. MAINTENANCE
6.1. If the product is not going to be used, charge the battery before storage in order to prevent long term discharge. Repeat this process
regularly to ensure power bank never fully discharges.
Original Language Version
© Jack Sealey Limited
LED1800PB Issue 4 13/09/2024
1 Fold-out hook
2 Swivel joint
3 Charge level indicator LED
4 USB type C charge socket with rubber cover
5 USB connection (powerbank function)
6 On/o button
7 Mounting magnets
