USERMANUAL

AXISQ7411VideoEncoder

Aboutthisdocument

ThismanualisintendedforadministratorsandusersoftheAXISQ7411

VideoEncoder,andisapplicabletormware5.40andlater.Itincludes

instructionsforusingandmanagingtheproductonyournetwork.

Previousexperienceofnetworkingwillbeofusewhenusingthis

product.SomeknowledgeofUNIXorLinux-basedsystemsmayalsobe

benecial,fordevelopingshellscriptsandapplications.Laterversionof

thisdocumentwillbepostedtotheAxiswebsite,asrequired.Seealso

theproduct’sonlinehelp,availableviatheweb-basedinterface.

Liability

Everycarehasbeentakeninthepreparationofthismanual.Please

informyourlocalAxisofceofanyinaccuraciesoromissions.Axis

CommunicationsABcannotbeheldresponsibleforanytechnicalor

typographicalerrorsandreservestherighttomakechangestothe

productandmanualswithoutpriornotice.AxisCommunicationsAB

makesnowarrantyofanykindwithregardtothematerialcontained

withinthisdocument,including,butnotlimitedto,theimplied

warrantiesofmerchantabilityandtnessforaparticularpurpose.Axis

CommunicationsABshallnotbeliablenorresponsibleforincidentalor

consequentialdamagesinconnectionwiththefurnishing,performance

oruseofthismaterial.Thisproductisonlytobeusedforitsintended

purpose.

IntellectualPropertyRights

AxisABhasintellectualpropertyrightsrelatingtotechnologyembodied

intheproductdescribedinthisdocument.Inparticular,andwithout

limitation,theseintellectualpropertyrightsmayincludeoneormore

ofthepatentslistedathttp://www.axis.com/patent.htmandoneor

moreadditionalpatentsorpendingpatentapplicationsintheUSand

othercountries.

Thisproductcontainslicensedthird-partysoftware.Seethemenuitem

“About”intheproduct’suserinterfaceformoreinformation.

ThisproductcontainssourcecodecopyrightAppleComputer,

Inc.,underthetermsofApplePublicSourceLicense2.0(see

http://www.opensource.apple.com/apsl).Thesourcecodeisavailable

fromhttp://developer.apple.com/darwin/projects/bonjour/

EquipmentModications

Thisequipmentmustbeinstalledandusedinstrictaccordancewiththe

instructionsgivenintheuserdocumentation.Thisequipmentcontains

nouser-serviceablecomponents.Unauthorizedequipmentchangesor

modicationswillinvalidateallapplicableregulatorycertications

andapprovals.

TrademarkAcknowledgments

Apple,Boa,Bonjour,Ethernet,InternetExplorer,Linux,Microsoft,

Mozilla,Real,SMPTE,QuickTime,UNIX,Windows,WindowsVistaand

WWWareregisteredtrademarksoftherespectiveholders.Javaand

allJava-basedtrademarksandlogosaretrademarksorregistered

trademarksofOracleand/oritsafliates.UPnP

isacertication

markoftheUPnP

ImplementersCorporation.

ElectromagneticCompatibility(EMC)

Thisequipmenthasbeendesignedandtestedtofulllapplicable

standardsfor:

•Radiofrequencyemissionwheninstalledaccordingtothe

instructionsandusedinitsintendedenvironment.

•Immunitytoelectricalandelectromagneticphenomenawhen

installedaccordingtotheinstructionsandusedinitsintended

environment.

USA

Thisequipmenthasbeentestedusingashieldednetworkcable(STP)

andfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules.Theselimitsaredesigned

toprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgenerates,usesandcanradiate

radiofrequencyenergyand,ifnotinstalledandusedinaccordance

withtheinstructions,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyoneormoreofthe

followingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfrom

thattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Canada

ThisClassBdigitalapparatuscomplieswithCanadianICES-003.

Europe

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofEN55022.

Thisproductfulllstherequirementsforimmunityaccording

toEN61000-6-1residential,commercialandlight-industrial

environments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN61000-6-2industrialenvironments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN55024ofceandcommercialenvironments.

Australia/NewZealand

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofAS/NZSCISPR22.

Korea

이기기는가정용(B급)전자파적합기기로서주로가정에

서사용하는것을목적으로하며,모든지역에서사용

할수있습니다.

Japan

この装置は、クラスB情報技術装置です。この装置は、家庭

環境で使用することを目的としていますが、この装置がラジ

オやテレビジョン受信機に近接して使用されると、受信障

害を引き起こすことがあります。取扱説明書に従って正し

い取り扱いをして下さい。

Safety

ThisproductcomplieswithIEC/EN/UL60950-1,SafetyofInformation

TechnologyEquipment.

Thepowersupplyusedwiththisproductshallfullltherequirements

forSafetyExtraLowVoltage(SELV)andLimitedPowerSource(LPS)

accordingtoIEC/EN/UL60950-1.

Support

Shouldyourequireanytechnicalassistance,pleasecontactyourAxis

reseller.Ifyourquestionscannotbeansweredimmediately,your

resellerwillforwardyourqueriesthroughtheappropriatechannelsto

ensurearapidresponse.IfyouareconnectedtotheInternet,youcan:

•downloaduserdocumentationandsoftwareupdates

•ndanswerstoresolvedproblemsintheFAQdatabase.Search

byproduct,category,orphrase

•reportproblemstoAxissupportstaffbyloggingintoyourprivate

supportarea

•chatwithAxissupportstaff(selectedcountriesonly)

•visitAxisSupportatwww.axis.com/techsup/

LearnMore!

VisitAxislearningcenterwww.axis.com/academyforusefultrainings,

webinars,tutorialsandguides.

AXISQ7411VideoEncoder

TableofContents

HardwareOverview..........................................5

Connectors....................................................5

LEDIndicators..................................................6

AccessingtheProduct.......................................7

AccessfromaBrowser...........................................7

AccessfromtheInternet..........................................8

SettheRootPassword...........................................8

TheLiveViewPage..............................................9

MediaStreams.............................................12

HowtoStreamH.264............................................12

MJPEG........................................................12

AXISMediaControl(AMC)........................................12

AlternativeMethodsofAccessingtheVideoStream....................13

AccessingAudioStreams.........................................14

SettingUptheProduct......................................15

BasicSetup....................................................15

VideoandAudio............................................16

VideoStream...................................................16

StreamProles.................................................18

CameraSettings................................................18

Overlay........................................................19

PrivacyMask...................................................19

AudioSettings..................................................20

AudioClips....................................................21

LiveViewCong............................................22

PTZ(PanTiltZoom).........................................25

InstallingaPTZdriver............................................25

PresetPositions.................................................25

GuardTour.....................................................26

Advanced......................................................26

ControlQueue..................................................27

Detectors..................................................28

CameraTampering..............................................28

MotionDetection...............................................28

AudioDetection................................................30

Applications...............................................31

Events....................................................32

SettingUpanActionRule........................................33

Recipients.....................................................33

Schedules......................................................34

Recurrences....................................................34

Recordings.................................................35

RecordingList..................................................35

ContinuousRecording............................................35

SystemOptions.............................................37

Security.......................................................37

Date&Time....................................................39

Network.......................................................39

Storage.......................................................44

Ports&Devices.................................................45

Maintenance...................................................46

Support.......................................................46

Advanced......................................................47

ResettoFactoryDefaultSettings...................................48

Troubleshooting............................................49

CheckingtheFirmware...........................................49

UpgradingtheFirmware..........................................49

EmergencyRecoveryProcedure....................................49

Symptoms,PossibleCausesandRemedialActions.....................50

TechnicalSpecications......................................54

Connectors....................................................56

AXISQ7411VideoEncoder

TableofContents

PerformanceConsiderations.......................................58

AXISQ7411VideoEncoder

HardwareOverview

21 3 4 5 6 7 8 9

11 12

MicroSDmemorycardslot

I/Oconnector

RS485/422connector

Controlbutton

Powerconnector

Networkconnector

Videoinput

Audioinput

Audiooutput

PowerLED

StatusLED

NetworkLED

Connectors

Fortechnicalspecications,seepage54.

Networkconnector-RJ-45Ethernetconnector.SupportsPoweroverEthernet(PoE).

NOTICE NOTICE

NOTICE

Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkswitch

shallbeshielded(STP)andintendedfortheirspecicuse.Makesurethatthenetworkswitchisproperlygrounded.See

ElectromagneticCompatibility(EMC)forregulatoryrequirements.

Audioin(pink)-3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).

Audioout(green)-3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactivespeaker

withabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

AXISQ7411VideoEncoder

HardwareOverview

SDcardslot-Astandardorhigh-capacitymicroSDcard(notincluded)canbeusedforlocalrecordingwithremovablestorage.

NOTICE NOTICE

NOTICE

Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeremoval.Tounmount,gotoSetup>System

Options>Storage>SDCardandclickUnmount.

Controlbutton-Thecontrolbuttonisusedfor:

•ConnectingtoanAXISVideoHostingSystemservice.Seepage40.Toconnect,pressandholdthebuttonfor

about1seconduntiltheStatusLEDashesgreen.

•ConnectingtoAXISInternetDynamicDNSService.Seepage41.Toconnect,pressandholdthebuttonfor

about3seconds.

•Resettingtheproducttofactorydefaultsettings.Seepage48.

Powerconnector-2-pinterminalblockforpowerinput.

I/Oterminalconnector-Useinapplicationsfore.g.motiondetection,eventtriggering,timelapserecordingandalarmnotications.

InadditiontoanauxiliarypowerandaGNDpin,theI/Oterminalconnectorprovidestheinterfaceto:

•Digitaloutput–ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedby

theVAPIX®ApplicationProgrammingInterface,outputbuttonsontheLiveViewpageorbyanActionRule.The

outputwillshowasactive(shownunderSystemOptions>Ports&Devices)ifthealarmdeviceisactivated.

•Digitalinput–Analarminputforconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,for

example:PIRs,door/windowcontacts,glassbreakdetectors,etc.Whenasignalisreceivedthestatechangesand

theinputbecomesactive(shownunderSystemOptions>Ports&Devices).

RS-485/RS-422connector-Two2-pinterminalblocksforRS-485/RS-422serialinterfaceusedtocontrolauxiliaryequipment,

e.g.PTZdevices.

LEDIndicators

LED

Color

Indication

Green

Steadyforconnectiontoa100MBit/snetwork.Flashesfornetworkactivity.

Amber

Steadyforconnectiontoa10MBit/snetwork.Flashesfornetworkactivity.

Network

UnlitNonetworkconnection.

GreenSteadygreenfornormaloperation.

Amber

Steadyduringstartupandwhenrestoringsettings.

Status

Red

Slowashforfailedupgrade.

Green

Normaloperation. Power

Amber

Flashesgreen/amberduringrmwareupgrade.

Note

•TheStatusLEDcanbeconguredtoashwhileaneventisactive.

•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.

AXISQ7411VideoEncoder

AccessingtheProduct

ToinstalltheAxisproduct,refertotheInstallationGuidesuppliedwiththeproduct.

Theproductcanbeusedwithmostoperatingsystemsandbrowsers.TherecommendedbrowsersareInternetExplorerwithWindows,

SafariwithMacintoshandFirefoxwithotheroperatingsystems.SeeTechnicalSpecications,onpage54.Toviewstreamingvideoin

InternetExplorer,allowinstallationofAXISMediaControl(AMC)whenprompted.

Note

•QuickTime

isalsosupportedforviewingH.264streamsandforaudio.

•Ifyourcomputerrestrictstheuseofadditionalsoftwarecomponents,theproductcanbeconguredtouseaJavaapplet

forviewingMotionJPEG.

AccessfromaBrowser

1.Startabrowser(InternetExplorer,Firefox,Safari).

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’sLocation/Addresseld.Toaccesstheproductfroma

Macintoshcomputer(MacOSX),clickontheBonjourtabandselecttheproductfromthedrop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabouthowto

discoverandassignanIPaddress,seetheInstallationandManagementSoftwareCDorthedocumentAssignanIPAddress

andAccesstheVideoStreamonAxisSupportwebatwww.axis.com/techsup

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe

congured.Forinstructions,seeSettheRootPassword,onpage8.

4.Theproduct’sLiveViewpageappearsinyourbrowser.

Note

ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsand

userpreferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedin

yourownLiveViewpage.

AXISQ7411VideoEncoder

AccessingtheProduct

AccessfromtheInternet

Onceconnected,theAxisproductisaccessibleonyourlocalnetwork(LAN).ToaccesstheproductfromtheInternetyoumust

congureyournetworkroutertoallowincomingdatatrafctotheproduct.Todothis,enabletheNAT-traversalfeature,which

willattempttoautomaticallyconguretheroutertoallowaccesstotheproduct.ThisisenabledfromSetup>SystemOptions>

Network>TCP/IPAdvanced.

Formoreinformation,pleaseseeNATtraversal(portmapping)forIPv4,onpage42.SeealsoAXISInternetDynamicDNSServiceat

www.axiscam.netForTechnicalnotesonthisandothertopics,visittheAxisSupportwebatwww.axis.com/techsup

SettheRootPassword

TogainaccesstotheAxisproduct,youmustsetthepasswordforthedefaultadministratoruserroot.ThisisdoneintheCongure

RootPassworddialog,whichappearswhentheproductisaccessedforthersttime.

Topreventnetworkeavesdropping,therootpasswordcanbesetviaanencryptedHTTPSconnection,whichrequiresanHTTPS

certicate.HTTPS(HypertextTransferProtocoloverSSL)isaprotocolusedtoencrypttrafcbetweenwebbrowsersandservers.The

HTTPScerticateensuresencryptedexchangeofinformation.SeeHTTPS,onpage42.

Thedefaultadministratorusernamerootispermanentandcannotbedeleted.Ifthepasswordforrootislost,theproductmustbe

resettothefactorydefaultsettings.SeeResettoFactoryDefaultSettings,onpage48.

TosetthepasswordviaastandardHTTPconnection,enteritdirectlyintherstdialog.

TosetthepasswordviaanencryptedHTTPSconnection,followthesesteps:

1.ClickCreateself-signedcerticate.

2.ProvidetherequestedinformationandclickOK.Thecerticateiscreatedandthepasswordcannowbesetsecurely.All

trafctoandfromtheproductisencryptedfromthispointon.

3.Enterapasswordandthenre-entertoconrmthespelling.ClickOK.Thepasswordhasnowbeencongured.

AXISQ7411VideoEncoder

AccessingtheProduct

CongureCaptureMode

TheLiveViewPage

ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsanduser

preferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedinyourownLiveView

page.Thefollowingprovidesanoverviewofeachavailablecontrol.

ControlsontheLiveViewPage

TheStreamProledrop-downlistallowsyoutoselectacustomizedorpre-programmedstreamprole.Stream

prolesareconguredunderVideo&Audio>StreamProles.SeeStreamProles,onpage18.

ClickPulsetoactivatetheoutputforadenedperiodoftime,suchasswitchingonanexternallightfor20seconds.

ClicktheActive/Inactivebuttonstomanuallystartandstopaconnecteddevice—e.g.switchanexternallight

onandoff.

TheManualTriggerbuttonisusedtotriggeranactionrulefromtheLiveViewpage;seepage10.Enablethis

buttonfromLiveViewCong>ActionButtons.

ClickSnapshottosaveasnapshotofthevideoimage.Right-clickthevideoimagetosaveitinJPEGformatonyour

computer.ThisbuttonisprimarilyintendedforusewhentheAXISMediaControlviewertoolbarisnotavailable.

EnablethisbuttonfromLiveViewCong>ActionButtons.

TheAudioclipdrop-downlistallowsyoutoplayanaudioclipfromtheLiveViewpage.Selecttheaudio

clipandclickthePlaybutton.

AXISQ7411VideoEncoder

AccessingtheProduct

ManualTrigger

TheManualTriggerisusedtotriggeranactionrulefromtheLiveViewpage.Themanualtriggercanforexamplebeusedto

validateactionsduringproductinstallationandconguration.

Tocongurethemanualtrigger:

1.GotoSetup>Events.

2.ClickAddtoaddanewactionrule.

3.FromtheTriggerdrop-downlist,selectInputSignal.

4.Fromtheseconddrop-downlist,selectManualTrigger.

5.Selectthedesiredactionandconguretheothersettingsasrequired.

Formoreinformationaboutactionrules,seeEvents,onpage32.

ToshowthemanualtriggerbuttonsintheLiveViewpage:

1.GotoSetup>LiveViewLayout.

2.UnderActionButtons,selectShowmanualtriggerbutton.

AXISMediaControlviewertoolbar

TheAXISMediaControlviewertoolbarisavailableinInternetExploreronly.SeeAXISMediaControl(AMC),onpage12formore

information.Thetoolbardisplaysthefollowingbuttons:

ThePlaybuttonconnectstotheAxisproductandstartsplayingamediastream.

TheStopbuttonstopsthemediastream.

TheSnapshotbuttontakesasnapshotofthevideoimage.Thelocationwheretheimageissavedcanbespecied

intheAMCControlPanel.

ClicktheViewFullScreenbuttonandthevideoimagewilllltheentirescreen.PressESC(Escape)onthecomputer

keyboardtocancelfullscreenview.

TheRecordbuttonisusedtorecordthecurrentvideostream.Thelocationwheretherecordingissavedcanbespeciedin

theAMCControlPanel.EnablethisbuttonfromLiveViewCong>ViewerSettings.

AMCAudioControls

AMCaudiobuttonscontrolthespeakersandmicrophoneconnectedtotheclientcomputer.Thebuttonsareonlyvisiblewhen

audioisenabled.

Speakerbutton—Clicktoturnthespeakersonoroff.

Microphonebutton–Clicktomuteorunmutethemicrophone.InSimplex-speakeronlymode,theMicrophoneandTalk

buttonsmustbothbeactivetosendaudiototheAxisproduct.Clickeitherbuttontostopaudiotransmission.

AXISQ7411VideoEncoder

AccessingtheProduct

Usetheslidertocontrolthevolumeofthespeakersandthemicrophone.

Half-duplexmode

TheTalk/Listenbuttonisusedtoswitchbetweensendingandreceivingaudio.Thebuttoncanbecongured

fromtheAudiotabintheAMCControlpanel:

•Push-To-Talkmode:Clickandholdthebuttontotalk/send.Releasethebuttontolisten.

•Togglemode:Clickoncetoswitchbetweentalkingandlistening.

Simplex–speakeronlymode

Tosendaudio,theTalkandMicrophonebuttonsmustbothbeactive.Clickeitherbuttontostopaudio

transmission.

PTZControls

TheLiveViewpagealsodisplaysPan/Tilt/Zoom(PTZ)controls.Theadministratorcanenable/disablecontrolsforspeciedusersunder

SystemOptions>Security>Users.

WiththePTZControlQueueenabledthetimeeachuserisincontrolofthePTZsettingsislimited.Clickthebuttonstorequestor

releasecontrolofthePTZcontrols.ThePTZControlQueueissetupunderPTZ>ControlQueue.

ClicktheEmulatejoystickmodebuttonandclickintheimagetomovethecameraviewinthedirectionofthe

mousepointer.

ClicktheCentermodebuttonandclickintheimagetocenterthecameraviewonthatposition.Thecentermode

buttoncouldalsobeusedtozoominonaspecicarea.Clickintheimageanddragtodrawarectanglesurrounding

theareatobemagnied.Tozoomout,rotatethemousewheel.

ClicktheCtrlpanelbuttontoopenthePTZcontrolpanelwhichprovidesadditionalPTZcontrols.

User-denedbuttonscanalsoappearintheControlpanel.SeeControls,onpage27.

PanandTiltbars–Usethearrowstopanandtiltthecameraview,orclickonapositiononthebartosteerthe

cameraviewtothatposition.

Zoombar–Usethearrowstozoominandout,orclickonapositiononthebartozoomtothatposition.

ThePTZcontrolscanbedisabledunderPTZ>Advanced>Controls,seeControls,onpage27.

AXISQ7411VideoEncoder

MediaStreams

TheAxisproductprovidesseveralaudioandvideostreamformats.Yourrequirementsandthepropertiesofyournetworkwill

determinethetypeyouuse.

TheLiveViewpageintheproductprovidesaccesstoH.264andMotionJPEGvideostreams,audiostreamsandtothelistofavailable

streamproles.Otherapplicationsandclientscanaccessvideoandaudiostreamsdirectly,withoutgoingviatheLiveViewpage.

HowtoStreamH.264

ThevideocompressionstandardH.264makesgooduseofbandwidth,andcanprovidehighqualityvideostreamsatlessthan1Mbit/s.

Decidingwhichcombinationofprotocolsandmethodstousedependsonyourviewingrequirements,andonthepropertiesof

yournetwork.TheavailableoptionsinAXISMediaControlare:

UnicastRTP

Thisunicastmethod(RTPoverUDP)isused

forliveunicastvideo,especiallywhenitis

importanttoalwayshaveanup-to-datevideo

stream,evenifsomeimagesaredropped.

RTPoverRTSP

Thisunicastmethod(RTPtunneledoverRTSP)

isusefulasitisrelativelysimpletocongure

rewallstoallowRTSPtrafc.

RTPoverRTSPoverHTTP

Thisunicastmethodcanbeusedtotraverse

rewalls.Firewallsarecommonlyconguredto

allowtheHTTPprotocol,thusallowingRTPto

betunneled.

Unicastingisusedforvideo-on-demand

transmissionsothatthereisnovideotrafc

onthenetworkuntilaclientconnectsand

requeststhestream.

Notethatthereareamaximumof20

simultaneousunicastconnections.

MulticastRTP

Thismethod(RTPoverUDP)shouldbeusedforlivemulticastvideo.Thevideostreamisalways

up-to-date,evenifsomeimagesaredropped.

Multicastingprovidesthemostefcientusageofbandwidthwhentherearelargenumbersof

clientsviewingsimultaneously.Amulticastcannothowever,passanetworkrouterunlessthe

routerisconguredtoallowthis.ItisnotpossibletomulticastovertheInternet,forexample.

Notealsothatallmulticastviewerscountasoneunicastviewerinthemaximumtotalof20

simultaneousconnections.

AXISMediaControlnegotiateswiththeAxisproducttodeterminethetransportprotocoltouse.Theorderofpriority,listedinthe

AMCControlPanel,canbechangedandtheoptionsdisabled,tosuitspecicrequirements.

Note

H.264islicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

MJPEG

ThisformatusesstandardJPEGstillimagesforthevideostream.Theseimagesarethendisplayedandupdatedataratesufcient

tocreateastreamthatshowsconstantlyupdatedmotion.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage

containedinthestream.TherecommendedmethodofaccessingMotionJPEGlivevideofromtheAxisproductistousetheAXIS

MediaControlinInternetExplorerinWindows.

AXISMediaControl(AMC)

AXISMediaControl(AMC)inInternetExplorerinWindowsistherecommendedmethodofaccessinglivevideofromtheAxisproduct.

AXISQ7411VideoEncoder

MediaStreams

TheAMCControlPanelcanbeusedtocongurevariousvideoandaudiosettings.PleaseseetheAXISMediaControlUser’s

Manualformoreinformation.

TheAMCControlPanelisautomaticallyinstalledonrstuse,afterwhichitcanbecongured.OpentheAMCControlPanelfrom:

•WindowsControlPanel(fromtheStartmenu)

•Alternatively,right-clickthevideoimageinInternetExplorerandclickSettings.

AlternativeMethodsofAccessingtheVideoStream

YoucanalsoaccessvideoandimagesfromtheAxisproductinthefollowingways:

•MotionJPEGserverpush(ifsupportedbytheclient,Firefox,forexample).ThisoptionmaintainsanopenHTTPconnection

tothebrowserandsendsdataasandwhenrequired,foraslongasrequired.

•StillJPEGimagesinabrowser.Enterthepathhttp://<ip>/axis-cgi/jpg/image.cgi

•WindowsMediaPlayer.ThisrequiresAXISMediaControlandtheH.264decodertobeinstalled.Thefollowingpaths

canbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

AXISQ7411VideoEncoder

MediaStreams

Note

•<ip>=IPaddess

•TheAxisproductsupportsQuickTime6.5.1andlater.

•QuickTimeaddslatencytothevideostream.

•ItmaybepossibletouseotherplayerstoviewtheH.264streamusingthepathsabove,althoughAxisdoesnotguarantee

this.

AccessingAudioStreams

TheLiveViewpageprovidesaccesstoaudiothroughAXISMediaControl;inadditionaudiocanbeaccessedinthefollowingways:

•VAPIX®ApplicationProgrammingInterface(API)Formoreinformation,visitwww.axis.com/developer

•WindowsMediaPlayersupportssimplexaudio.Thefollowingpathscanbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

supportsG.711andAACaudioencoding.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

•TheJavaappletsupportssimplexaudiowithG.711encoding.

AXISQ7411VideoEncoder

SettingUptheProduct

TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin

thetopright-handcorneroftheLiveViewpage.

•Administratorshaveunrestrictedaccesstoallsettings.

•OperatorshaveaccesstoallsettingsexceptSystemOptions

Seealsotheonlinehelp

BasicSetup

BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:

1.Users.Seepage37.

2.TCP/IP.Seepage39.

3.Date&Time.Seepage39.

4.VideoStream.Seepage16.

5.AudioSettings.Seepage20.

TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.

AXISQ7411VideoEncoder

VideoandAudio

Thevideoandaudiosettingscanbeusedtooptimizevideoandaudioquality.Youcancongurethefollowing:

•Videostreamsettings.Seepage16.

•Streamproles.Seepage18.

•Camerasettings.Seepage18.

•Overlayimage.Seepage19.

•Privacymask.Seepage19.

•Audiosettings.Seepage20.

•Audioclips.Seepage21.

VideoStream

YoucandenethefollowingvideostreamsettingsfromVideo&Audio>VideoStream:

•Image.Seepage17.

•H.264.Seepage17.

•MJPEG.Seepage17.

PixelCounter

Thepixelcountershowsthenumberofpixelsinanareaoftheimage.Thepixelcounterisusefulinsituationswherethereisa

requirementthattheimageisacertainsize,forexampleinfacerecognition.

Thepixelcountercanbeaccessedfrom:

AXISQ7411VideoEncoder

VideoandAudio

•Video&Audio>VideoStream.UnderPreview,clickOpenandselecttheShowpixelcounteroptiontoenablethe

rectangleintheimage.Usethemousetomoveandresizetherectangle,orenterthenumberofpixelsintheWidth

andHeighteldsandclickApply.

•TheLiveViewpageinInternetExplorerinWindows.Right-clickintheimageandselectPixelcounter.Usethemouse

tomoveandresizetherectangle.


ThedefaultimagesettingscanbeconguredunderVideo&Audio>VideoStream.SelecttheImagetab.

Thefollowingsettingsareavailable:

•Resolution.Selectthedefaultresolution.

•Compression.Thecompressionlevelaffectstheimagequality,bandwidthandlesizeofsavedimages;thelowerthe

compression,thehighertheimagequalitywithhigherbandwidthrequirementsandlargerlesizes.

•Rotateimage.Ifrequired,theimagecanberotated.

•Mirror.Ifrequired,theimagecanbemirrored.

•Maximumframerate.Toavoidbandwidthproblems,theframerateallowedtoeachviewercanbeLimitedtoaxed

amount.Alternatively,theframeratecanbesetasUnlimited,whichmeanstheAxisproductalwaysdeliversthehighest

frameratepossibleunderthecurrentconditions.

•Overlaysettings.SeeOverlay,onpage19.

ClickSavetoapplythenewsettings.

H.264

H.264,alsoknownasMPEG-4Part10/AVC,isavideocompressionstandardthatprovideshighqualityvideostreamsatlowbitrates.

AnH.264videostreamconsistsofdifferenttypesofframessuchasI-framesandP-frames.AnI-frameisacompleteimagewhereas

P-framesonlycontainthedifferencesfrompreviousframes.

TheGOVlengthisthenumberofframesbetweentwoconsecutiveI-frames.IncreasingtheGOVlengthmaysaveconsiderablyon

bandwidthrequirementsinsomecases,butmayalsohaveanadverseaffectonimagequality.

TheAxisproductsupportstwoH.264proles.TheMainproleprovideshighercompressionthantheBaselineprolewiththesame

videoquality,butrequiresmoreprocessingpowertodecode.

ThebitratecanbesetasVariableBitRate(VBR)orConstantBitRate(CBR).VBRadjuststhebitrateaccordingtotheimage

complexity,usingupmorebandwidthforincreasedactivityintheimage,andlessforlowerimageactivity.CBRallowsyoutoseta

xedTargetbitratethatconsumesapredictableamountofbandwidth.Asthebitratewouldusuallyneedtoincreaseforincreased

imageactivity,butinthiscasecannot,framerateandimagequalityareaffectednegatively.Topartlycompensateforthis,itis

possibletoprioritizeeitherframerateorimagequality.Notsettingaprioritymeansthatframerateandimagequalityareequally

affected.Youmustsaveyoursettingsbeforetheycantakeeffect.

Thecurrentbitratecanbesettoappearastextoverlay.Todothis,selecttheIncludetextcheckboxoptionunderOverlay

Settingsandenterthemodier#bintheeld.

MJPEG

Sometimestheimagesizeislargeduetolowlightorcomplexscenery.Adjustingthemaximumframesizehelpstocontrolthe

bandwidthandstorageusedbytheMotionJPEGvideostreaminthesesituations.SettingtheframesizetotheDefaultsetting

providesconsistentlygoodimagequalityattheexpenseofincreasedbandwidthandstorageusageinlowlight.Limitingtheframe

sizeoptimizesbandwidthandstorageusage,butmaygivepoorimagequality.Topreventincreasedbandwidthandstorageusage,

themaximumframesizeshouldbesettoanoptimalvalue.

AXISQ7411VideoEncoder

VideoandAudio

StreamProles

Astreamproleisasetofpredenedstreamsettingsincludingresolution,compression,framerateandoverlaysettings.Stream

prolescanbeused:

•Whensettinguprecordingusingactionrules.SeeEvents,onpage32.

•Whensettingupcontinuousrecording.SeeContinuousRecording,onpage35.

•IntheLiveViewpage–selectthestreamprolefromtheStreamproledrop-downlist.

Forquicksetup,useoneofthepredenedstreamproles.Eachpredenedprolehasadescriptivename,indicatingitspurpose.If

required,thepredenedstreamprolescanbemodiedandnewcustomizedstreamprolescanbecreated.

Tocreateanewproleormodifyanexistingprole,gotoSetup>Video&Audio>StreamProles.

ToselectadefaultstreamprolefortheLiveViewpage,gotoSetup>LiveViewCong.

CameraSettings

TheVideo&Audio>CameraSettingspageprovidesaccesstoadvancedimagesettingsfortheAxisproduct.

ImageAppearance

IncreasingtheColorlevelincreasesthecolorsaturation.Thevalue100givesmaximumcolorsaturation.Thevalue0givesa

blackandwhiteimage.

TheimageBrightnesscanbeadjustedintherange0–100,whereahighervalueproducesabrighterimage.

TheContrastchangestherelativedifferencebetweenlightanddark.Itcanbeadjustedusingtheslidebar.

Videoinput

•EnteradescriptivenameforyourvideosourceintheVideosourcenameeld.

•ThevaluesintheOffsetAdjustmentseldsaffectthehorizontalandverticalsynchronizationfortheimage.Thiscan

beusedtoeliminateanyblackbordersurroundingtheimage.Highvalues,bothnegativeandpositivecanputthe

imageoutofsync.

•De-interlacing-isusedtoimprovevideostreamimagequalityfromanalogdevices.Selectanyofthefollowingoptions

fromtheDe-interlacingdrop-downlist.SelectNoneifde-interlacingisnotnecessary;Blendingforimprovedimage

qualitythatisnotasprocessorintensive;AdaptiveInterpolationperformsde-interlacingofthevideostreambyapplying

differentltersontheimage.ThismaygiveabetterresultthanMotionAdaptiveInterpolationinrarecases;Motion

AdaptiveInterpolationperformsde-interlacingofthevideostreambyapplyingdifferentltersdependingonthemotion

indifferentpartsoftheimage.Thiswillinmostcasesresultinthebestimagequality.

•Antialiasingwillminimizedistortionknownasaliasing,whichhappenswhenahigh-resolutionimageisrepresentedat

alowerresolution.

•Foreachvideoinput75Ohmvideoterminationcanbeenabled/disabledviatheproduct'swebpageatVideo&Audio

>VideoInput>Videotermination.Theseterminationsareenabledonfactorydefault.Incaseswheretheproduct

istobeconnectedinparallelwithotherequipment,foroptimumvideoquality,itisrecommendedthatterminationbe

enabledforonlythelastdeviceinthevideosignalchain.

ImageSettings

Noisereduction-SettoOntoenablenoisereduction.Noisereductionmayincreasetheamountofmotionblur.

AXISQ7411VideoEncoder

VideoandAudio

Overlay

Overlaysareusedtoprovideextrainformation,forexampleforforensicvideoanalysisorduringproductinstallationand

conguration.Overlaysaresuperimposedoverthevideostream.

Anoverlaytextcandisplaythecurrentdateandtime,oratextstring.Whenusingatextstring,modierscanbeusedtodisplay

informationsuchasthecurrentbitrateorthecurrentframerate.Forinformationaboutavailablemodiers,seeFileNaming&

Date/TimeFormatsintheonlinehelp

Toenableoverlays:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.Toincludeanoverlayimage,selectIncludeoverlayimageatthecoordinates.Theoverlayimagemustrstbeuploadedto

theAxisproduct,seeOverlayImage.

3.Toincludedateandtime,selectIncludedateandIncludetime.

4.Toincludeatextstring,selectIncludetextandenterthetextintheeld.Modierscanbeused,seeFileNaming&

Date/TimeFormatsintheonlinehelp

5.Selectthetextcolor,thetextbackgroundcolorandthepositionoftheoverlay.

6.ClickSave.

Tomodifythedateandtimeformat,gotoSystemOptions>Date&Time.SeeDate&Time,onpage39.

OverlayImage

Anoverlayimageisastaticimagesuperimposedoverthevideostream.Theimage,forexamplecompanylogo,isusedtoprovide

extrainformationortomaskapartoftheimage.

Touseanoverlayimage,theimagemustrstbeuploadedtotheAxisproduct:

1.GotoVideo&Audio>OverlayImage.

2.ClickBrowseandbrowsetothele.

3.ClickUpload.

4.SelecttheimagetousefromtheUseoverlayimagelist.

5.ClickSave.

Todisplaytheoverlayimage:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludeoverlayimageatthecoordinatesandentertheXandYcoordinates.

3.ClickSave.

Forinformationaboutsupportedimageformats,seetheonlinehelp

PrivacyMask

Aprivacymaskisanareaofsolidcolorthatprohibitsusersfromviewingpartsofthemonitoredarea.Privacymaskscannotbe

bypassedviatheVAPIX®ApplicationProgrammingInterface(API).

ThePrivacyMaskList(Video&Audio>PrivacyMask)showsallthemasksthatarecurrentlyconguredintheAxisproductand

indicatesiftheyareenabled.

AXISQ7411VideoEncoder

VideoandAudio

Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.

Formoreinformation,seetheonlinehelp

Important

Addingmanyprivacymasksmayaffecttheproduct’sperformance.

AudioSettings

TheaudiofunctionalityforeachvideostreamisenabledunderVideo&Audio>VideoStream>Audio.

AudioModes

TheAxisproductsupportsthefollowingaudiomodes:

Fullduplex-Simultaneoustwo-wayaudioallowingtheAxisproducttotransmitandreceiveaudioatthesametime.Thereisno

echocancellation;iffeedbackloopsappear,trymovingthemicrophoneorthespeaker.

Half-duplex-AudiocanbetransmittedtoandfromtheAxisproductbutonlyinonedirectionatatime.Totransmitaudiousingthe

LiveViewpage,usetheTalkandListenbuttons,seeAMCAudioControls,onpage10.

Simplex—speakeronly-AudioistransmittedfromaclienttotheAxisproductandcanbeplayedbyaspeakerconnected

totheproduct.TotransmitaudiousingtheLiveViewpage,theTalkandMicrophonebuttonsmustbothbeactive,seeAMC

AudioControls,onpage10.

Simplex—microphoneonly-AudiocapturedbytheproductmicrophoneistransmittedfromtheAxisproducttooneormoreclients.

Tosettheaudiomode,gotoVideo&Audio>AudioSettingsandselectthedesiredmodefromtheAudiomodedrop-downlist.

AudioInput

Anexternalmicrophoneoralinesourcecanbeconnectedtotheproduct’sAudio-inconnector.Conguretheaudioinputsettings

underVideo&Audio>AudioSettings.

Source-SelectMicrophoneforanexternalmicrophoneorLineforaLineindevice,e.g.anaudiomixerformultiplemicrophonesor

amicrophonewithabuilt-inamplier.

Microphonepower-TheEnablemicrophonepoweroptionprovidesDCpowerforanexternalmicrophone.Microphonepower

shouldonlybeusedwithmicrophonesthathavenobattery.Thissettingshouldnotbeenabledwhenusingadynamicorbattery

poweredmicrophone.Microphonepowerwillnotharmthemicrophone;ifyouareuncertain,tryswitchingitoffandon.Tousea

professionalmicrophonerequiring48Vphantompower,youneedanexternalpowersupplyandabalanced-unbalancedconverter

(audiotransformer)inbetween.

Inputgain-Controlthevolume(dBFullScale)oftheaudioinput.Ifthesoundistoolow,chooseahigherdB,toamplifythe

sound.Ifthesoundistoohigh,choosealowerdB.TheLevelbargivesavisualrepresentationoftheaudiosignallevelindB

relativetothefull-scaleinputlevel.

•Green—thesignalisatagoodlevel.

•Yellow—thesignalisbecomingdistorted.

•Red—thesignalisdistorted.

Encoding-Selectdigitalaudioencodingformat.

•AACrequiresalicenseforbothencodinganddecoding.AACistheleastcomplicatedandmostwidelyusedcodec.

Ifachievingthebestpossibleaudioqualityisapriority,AACistherecommendedcodectouse.AnAAClicense

isincludedintheAxisproduct.

•G711

AXISQ7411VideoEncoder

VideoandAudio

•G726

Samplerate-Thenumberoftimespersecondthesoundissampled.Ahighersampleratewillprovidebetteraudioquality,but

alsorequiresagreaterbandwidth.

Bitrate-Settherequiredbitratedependingontheselectedencoding.Ahigherbitratewillgivebetteraudioquality.Alowerbit

ratemayhavelatencyordelay,butwillrequirelessbandwidth.

Formoreinformationaboutthesesettings,pleaseseetheonlinehelp.

AudioOutput

Anexternalspeakercanbeconnectedtotheproduct’sAudio-outconnector(abuilt-inamplierisrequiredforthis).Theoutputcan

beconnectedtoanotheramplierwithspeakers.Astereoconnectormustbeusedfortheaudioout.

ConguretheaudiooutputsettingsunderVideo&Audio>AudioSettings.

Outputgain-Controlthevolume(dBFullScale)ofthelineaudiooutput.Ifthesoundistoolow,chooseahigherdB.Ifthe

soundistoohigh,choosealowerdB.

AudioClips

AnaudioclipisasoundlethatcanbeplayedwheneventsoccurordirectlyfromtheLiveViewpage.Theaudioclipmustrstbe

uploadedtotheAxisproductorrecordedbyamicrophoneconnectedtotheproduct.

Toadd,download,modifyorremoveaudioclips,gotoVideo&Audio>AudioClips.Formoreinformationseetheonlinehelp

ToconguretheAxisproducttoplayaudioclipswhenaneventoccurs,anactionrulemustbesetup.Formoreinformation,see

Events,onpage32.

Note

Audioclipscannotbeusediftheproduct’saudiofunctionalityisenabled.TheaudiofunctionalityisenabledontheAudio

tabunderVideo&Audio>VideoStream.

AXISQ7411VideoEncoder

LiveViewCong

YoucancustomizetheLiveViewpageandalterittosuityourrequirements.Itispossibletodenethefollowingfeaturesof

theLiveViewpage.

•StreamProle.Seepage18.

•DefaultViewerforBrowser.Seepage22.

•ViewerSettings.Seepage23.

•ActionButtons.ThesearethebuttonsdescribedinControlsontheLiveViewPage,onpage9.

•UserDenedLinks.Seepage23.

•OutputButtons.Seepage23.

DefaultViewerforBrowsers

FromLiveViewCong>DefaultViewerselectthedefaultmethodforviewingvideoimagesinyourbrowser.Theproductattempts

toshowthevideoimagesintheselectedvideoformatandviewer.Ifthisisnotpossible,theproductoverridesthesettingsand

selectsthebestavailablecombination.

AXISQ7411VideoEncoder

LiveViewCong

BrowserViewerDescription

AMC

RecommendedviewerinInternetExplorer(H.264/MotionJPEG).

QuickTime

H.264.

Javaapplet

AslowerimagingalternativetoAMC(MotionJPEG).Requiresoneofthe

followinginstalledontheclient:

•JVM(J2SE)1.4.2orhigher.

•JRE(J2SE)5.0orhigher.

WindowsInternetExplorer

StillimageDisplaysstillimagesonly.ClicktheRefreshbuttoninyourbrowsertoviewa

newimage.

ServerPush

Recommendedviewerforotherbrowsers(MotionJPEG).

QuickTime

H.264.

Javaapplet

AslowerimagingalternativetoServerPush(MotionJPEGonly).

Otherbrowsers

StillimageDisplaysstillimagesonly.ClicktheRefreshbuttoninyourbrowsertoviewa

newimage.

Formoreinformation,pleaseseetheonlinehelp.

ViewerSettings

Tocongureoptionsfortheviewer,gotoLiveViewCong>ViewerSettings.

•SelectShowviewertoolbartodisplaytheAXISMediaControl(AMC)ortheQuickTimeviewertoolbarunderthevideo

imageinyourbrowser.

•H.264decoderinstallation.TheadministratorcandisableinstallationoftheH.264decoderincludedwithAXISMedia

Control.Thisisusedtopreventinstallationofunlicensedcopies.Furtherdecoderlicensescanbepurchasedfromyour

Axisreseller.

•SelectShowcrosshairinPTZjoystickmodetoenableacrossthatwillindicatethecenteroftheimageinPTZjoystick

mode.

•SelectUsePTZjoystickmodeasdefaulttoenablejoystickmode.Themodecanbechangedtemporarilyfromthe

PTZcontrolpanel.

•SelectEnablerecordingbuttontoenablerecordingfromtheLiveViewpage.Thisbuttonisavailablewhenusingthe

AMCviewer.TherecordingsaresavedtothelocationspeciedintheAMCControlPanel.SeeAXISMediaControl

(AMC),onpage12.

UserDenedLinks

Todisplayuser-denedlinksintheLiveViewpage,selecttheShowcustomlinkoption,givethelinkanameandthenentertheURL

tolinkto.Whendeningaweblinkdonotremovethe'http://'fromtheURLaddress.Customlinkscanbeusedtorunscriptsor

activateexternaldevicesconnectedtotheproduct,ortheycanlinktoawebpage.Customlinksdenedascgilinkswillrunthe

scriptinthebackground,inahiddenframe.Deningthelinkasaweblinkwillopenthelinkinanewwindow.

OutputButtons

ExternalI/OdevicesconnectedtotheAxisproduct’soutputportscanbecontrolleddirectlyfromtheLiveViewpage.

TodisplayoutputbuttonsintheLiveViewpage:

1.GotoSetup>LiveViewCong.

2.UnderOutputButtons,selectthetypeofcontroltouse:

AXISQ7411VideoEncoder

LiveViewCong

-Pulseactivatestheoutputforadenedperiodoftime.Thepulsetimecanbesetfrom1/100secondto60

seconds.

-Active/Inactivedisplaystwobuttons,oneoreachaction.

Toconguretheactiveandinactivestates,gotoSystemOptions>Ports&Devices>I/OPortsandsettheport’sNormalstate.

FormoreinformationaboutI/Oports,seeI/OPorts,onpage45.

AXISQ7411VideoEncoder

PTZ(PanTiltZoom)

InstallingaPTZdriver

ThisAxisproductsupportsseveralPTZdevices.Pleaseseewww.axis.comforacompletelistofsupporteddevices,andtoobtainthe

correctdriver.ToinstallaPTZdeviceyouneedtoinstallthePTZdriver.

ToinstallthePTZdrivergotoPTZ>DriverSelection.Browsetondthedriver(e.g.driver.ptz)andUpload.Ifthedriverwas

successfullyuploaded,itappearsintheSelectdrivertousedrop-downlist.Fromthisdrop-downlist,selectthedrivertoinstall

orremove,andclickSave.

SelectActivatePTZtoenablePTZ.TheaddressoftheconnecteddeviceappearsagainstDeviceID.ChoosetheDevicetypefromthe

drop-downlist.Tondwhichdevicetypetouse,consultthedocumentationsuppliedbythePTZdriver.

TocompletetheinstallationgotoSystemOptions>Ports&Devices>COMPort(seeCOMPort)andverifythesettings.

PresetPositions

Apresetpositionisapredenedviewthatcanbeusedtoquicklysteerthecameratoaspeciclocation.Presetpositionscan

beaccessedinseveralways:

•Whensettingupactionrules.Seepage32.

•WhensettingupGuardTour.Seepage26.

Toaddapresetposition:

1.GotoPTZ>PresetPositions.

2.Usethepan,tiltandzoomcontrolstosteerthecameraviewtothedesiredposition.

3.EnteradescriptivenameintheCurrentpositioneld.

4.ClickAdd.Thecamera’spositionandfocussettingsaresavedasapresetposition.

TheproductcanbeconguredtoreturntotheHomepositionwhenthePTZfunctionalityhasbeeninactiveforaspeciedlength

oftime.EnterthelengthoftimeintheeldandclickSave.Setthetimetozerotopreventtheproductfromautomatically

returningtotheHomeposition.

Toincludethepresetpositionnameintheoverlaytext,gotoVideo&Audio,selectIncludeoverlaytextandenterthemodier#Pin

theeld.Formoreinformationaboutmodiers,seeFileNaming&Date/TimeFormatsintheonlinehelp

AXISQ7411VideoEncoder

PTZ(PanTiltZoom)

GuardTour

Aguardtourdisplaysthevideostreamfromdifferentpresetpositions,one-by-one,inapredeterminedorderoratrandomandfor

congurabletimeperiods.Theenabledguardtourwillkeeprunningaftertheuserhasloggedofforclosedthebrowser.

Toaddaguardtour:

1.GotoPTZ>GuardTourandclickAdd.

2.Enteradescriptivename.

3.Specifythepauselengthbetweenruns.

4.SelectanavailablepresetpositionandclickApply.

5.SpecifytheViewTimeinsecondsorminutes.

6.SpecifytheViewOrderorselecttheRandomvieworderoption.

7.ClickSave.

Tomodifyorremoveguardtours,gotoPTZ>GuardTour,selecttheguardtourintheGuardTourListandclickModify/Remove.

Formoreinformationseetheonlinehelp

TourRecording

Theguardtourfunctioninthisproductincludestourrecording,whichallowsrecordingofacustomtourusinganinputdevicesuch

asajoystick,mouse,keyboardorthroughtheVAPIX®ApplicationProgrammingInterface(API).Arecordedtourdisplaysthevideo

streamoftherecordedsequenceofPan/Tilt/Zoommovements,includingtheirvariablespeedsandlengths.

1.GotoPTZ>GuardTourandclickAdd.

2.SelectCreatearecordtourandclickOK.

3.Enteradescriptivename.

4.Specifythepauselengthbetweenruns.

5.Click

tostartrecordingthePan/Tilt/Zoommovements.

6.Whensatised,click.

7.ClickOK.

Note

Onlythenameoftherecordedtourandpausebetweenrunscanbemodied.Startinganewrecordingwilloverwritethe

existingguardtour.

TherecordedtourcanbeactivatedfromtheLiveViewandGuardTourpagesorthroughevents.Formoreinformationsee

theonlinehelp.

Advanced

DeviceSettings

TheDeviceSettingswindowdisplaysdriverspecicsettings.Theappearanceofthiswindowcanvarydependingonthedriver

installed.Optionsthatcanbeconguredinclude:

•DriverSpecicSettingsfromVideoSource

AXISQ7411VideoEncoder

PTZ(PanTiltZoom)

•MechanicalLimitsforMovingVideoSource

•LightControlVideoSource

•ExtendedDriverSpecicSettingsforVideoSource

FordownloadandinstallationinformationaboutPTZdriversforyourAxisproductpleasevisitwww.axis.com/techsup/

Controls

PanelShortcutCommandButtonscanbeconguredtoprovidedirectaccesstocommandsissuedviatheVAPIX®Application

ProgrammingInterface.ThebuttonswillbedisplayedinthePTZcontrolpanel,whichisavailableintheLiveViewpagethrough

theCtrlpanelbutton,seepage11.

DeselecttheoptionsunderEnable/Disablecontrolstodisablethepan,tilt,zoomandfocuscontrols.

Note

DisablingPTZcontrolswillnotaffectpresetpositions.Forexample,ifthetiltcontrolisdisabled,theproductcanstillmoveto

presetpositionsthatrequireatiltmovement.

ControlQueue

TheadministratorcansetupaqueueforPTZcontrollersfromPTZ>ControlQueue.Oncesetup,thePTZControlQueuebuttons

appearintheLiveViewpageofferingoneviewerexclusivecontrolforalimitedperiodoftime.Otheruserswillbeplacedinqueue.

Auserwhobelongstoagroup(seeUsers,onpage37)withahigherPTZprioritycangobeforeotherusersinthequeueand

takecontroloftheproduct.Theorderofpriorityisasfollows:

1.Administrator—AnadministratortakesoverPTZcontrolregardlessofwhoisrstinqueue.Theadministratorwillbe

removedfromthequeue60secondsafterthelastPTZcontrolcommand.

2.Event—TheAxisproductcanbeconguredtogotoapresetpositionwhentriggeredbyanalarm(seeEvents,onpage32).

Theeventwillimmediatelybeplacedrstinthequeueexceptwhenanadministratorisincontrol.

3.Operator—Sameasadministratorbutwithlowerpriority

4.GuardTour—Aguardtour(seepage26)hasPTZcontrolforanindeniteperiodoftime.Itmaybeoverriddenbyan

operator,eventoradministrator.Theguardtourwillresumewhenhigherprioritygroupsleavethequeue.

5.Viewer—Multipleviewersmustwaitfortheirturn.Theviewerhas60secondsPTZcontrolbeforecontrolispassed

ontothenextviewerinqueue.

Note

•TheadministratorcanenableanddisablePTZcontrolsforselectedusers.

•Toidentifydifferentusersintheviewergroup,cookiesmustbeenabledontheclient.

OSDMenu

IfthePTZunitsupportsaninternalcongurationmenu,thiscanbeaccessedusingtheOn-ScreenDisplay(OSD).Congurethe

analogcamerabyopeningandnavigatingthroughitsinternalmenuinthisdisplay.

AXISQ7411VideoEncoder

Detectors

CameraTampering

CameraTamperingcangenerateanalarmwheneverthecameraisrepositioned,orwhenthelensiscovered,sprayedorseverely

defocused.Tosendanalarm,forexampleanemail,anactionrulemustbesetup.

Toconguretampering:

1.GotoDetectors>CameraTampering.

2.SettheMinimumduration,thatis,thetimethatmustelapsebeforeanalarmisgenerated.Thiscanhelpprevent

falsealarmsforknownconditionsthataffecttheimage.

3.SelectAlarmfordarkimagesifanalarmshouldbegeneratediflightsaredimmedorturnedoff,orifthelensissprayed,

covered,orrenderedseverelyoutoffocus.

4.ClickSave.

Toconguretheproducttosendanalarmwhentamperingoccurs:

1.GotoEvents>ActionRules.

2.ClickAddtosetupanewactionrule.

3.EnteraNamefortheactionrule.

4.UnderCondition,selectDetectorsfromtheTriggerlist.

5.SelectTamperingfromthelistofdetectors.

6.Selectthevideochannel.

7.Optionally,selectascheduleandsetadditionalconditions.

8.Selecttheaction.Tosendanemail,selectSendNoticationandselectaRecipientfromthelistofdenedrecipients.

Note

TheWhiletheruleisactiveoptionunderDurationcannotbeusedwithcameratampering,sincecameratamperingdoesnot

haveadurationandonceithasbeentriggereditwillnotautomaticallyreturntoitsuntriggeredstate.

Formoreinformationonactionsrules,seeEvents,onpage32.

MotionDetection

Motiondetectionisusedtogenerateanalarmwhenevermovementstartsorstopsinthecameraview.

Motiondetectionisconguredbydeningupto10IncludeandExcludewindows:

•Includewindows—deneareaswheremotionshouldbedetected

•Excludewindows—deneareaswithinanIncludewindowthatshouldbeignored(areasoutsideIncludewindows

areautomaticallyignored).

Forinstructions,seeSetUpMotionDetectionWindows,onpage29.

Tocontrolthenumberofmotiondetectionalarms,theparametersObjectSize,HistoryandSensitivitycanbeadjusted.See

MotionDetectionParameters,onpage29.

Oncemotiondetectionwindowsarecongured,theAxisproductcanbeconguredtoperformactionswhenmotionisdetected.

Possibleactionsincludeuploadingimagesandstartrecording.Formoreinformation,seeSettingUpanActionRule,onpage33.

AXISQ7411VideoEncoder

Detectors

Note

Usingthemotiondetectionfeaturemaydecreasetheproduct’soverallperformance.

SetUpMotionDetectionWindows

TosetupamotiondetectionIncludeWindow,followtheseinstructions:

1.GotoDetectors>MotionDetection.

2.SelecttheCongureIncludedWindowsoptionandclickNew.Selectthenewwindowinthelistofwindowsand

enteradescriptivename.

3.Adjustthesize(dragthebottomright-handcorner)andtheposition(clickonthetextatthetopanddragtothedesired

position)ofthewindow.

4.AdjusttheObjectSize,HistoryandSensitivityprolesliders(seeMotionDetectionParametersfordetails).Anydetected

motionwithinanactivewindowisindicatedbyredpeaksintheActivitywindow.

5.ClickSave.

Toexcludepartsoftheincludewindow,selecttheCongureExcludedWindowsandpositiontheexcludewindowwithinthe

includewindow.

Todeleteanincludeorexcludewindow,selectthewindowinthelistofwindowsandclickDel.

MotionDetectionParameters

Theparameterscontrollingmotiondetectionaredescribedinthetablebelow:

Parameter

ObjectSize

History

Sensitivity

Description

Objectsizerelativetowindow

size.

Objectmemorylength.

Differenceinluminance

betweenbackgroundand

object.

Highlevel(100%)

Onlyverylargeobjectstrigger

motiondetection.

Anobjectthatappearsin

thewindowtriggersmotion

detectionforalongtime

beforeitisconsideredas

non-moving.

Ordinarycoloredobjectson

ordinarybackgroundstrigger

motiondetection.

Mediumlevel(50%)

Alargedifferenceinluminance

isrequiredtotriggermotion

detection.

AXISQ7411VideoEncoder

Detectors

Lowlevel(0%)

Evenverysmallobjectstrigger

motiondetection.

Anobjectthatappearsin

thewindowtriggersmotion

detectiononlyforaveryshort

timebeforeitisconsideredas

non-moving.

Onlyverybrightobjectson

adarkbackgroundtrigger

motiondetection.

Recommendedvalues

5–15%60–90%75–95%

Defaultvalues

15%90%90%

Note

•Totriggeronsmallobjectsormovements,useseveralsmallmotiondetectionwindowsratherthanonelargewindow

andselectalowobjectsize.

•Toavoidtriggeringonsmallobjects,selectahighobjectsize.

•IfnoobjectsshouldappearintheIncludeWindow,selectahighhistorylevel.Thiswillcausemotiondetectiontotriggeras

longastheobjectispresentinthewindow.

•Toonlydetectashinglight,selectalowsensitivity.Inothercaseshighsensitivityisrecommended.

AudioDetection

TheAxisproductcanbeconguredtogenerateanalarmwhenaudiorisesaboveorfallsbelowthethresholdvalue.Thethreshold

valuecanbesetintherange0–100where0isthemostsensitiveand100theleastsensitive.

1.GotoDetectors>AudioDetection.

2.SettheaudioalarmlevelandclickSave.

3.GotoEvents>ActionRulesandsetupanactionrule,seeSettingUpanActionRule,onpage33.

DetectedaudioisindicatedbycoloredpeaksintheActivityindicator.Aneventistriggeredwhendetectedaudiorisesaboveorfalls

belowthethresholdvalue,whichisrepresentedbythebar.

AXISQ7411VideoEncoder

Applications

ThirdpartyapplicationscanbeuploadedtoandinstalledontheAxisproduct.Forinformationaboutavailableapplications,

downloads,trialsandlicenses,gotowww.axis.com/applications

Touploadanapplication,gotoApplications>Overview,clickBrowsetolocatetheleandthenclickUploadPackage.Clickonthe

uploadedapplication’snametoopenthemenuoptionsSettings,LicenseandAbout.Forcongurationinstructions,pleasereferto

thedocumentationprovidedwiththeapplication.

Mostapplicationsneedalicensetorun.Toinstallthelicense,selecttheLicensemenuoption.Iftheproductisconnected

totheInternet,AutomaticInstallationappearsinthewebpage.IftheproductisnotconnectedtotheInternet,goto

www.axis.com/applicationstoacquireaLicensekey.Youwillneedalicensecodeandtheproduct’sserialnumber(foundonthelabel

andunderSystemOptions>Support>SystemOverview)toreceivealicensekey.

InstalledApplicationslistsinstalledapplicationswithinformationabouttheversionandthevendor,thestatusoftheapplication

(runningornotrunning),andinformationaboutthelicense.

UsetheStartandStopbuttonstostartandstoptheapplication.

Togeneratealoglefortheapplication,selecttheapplicationandclickLog.

Note

Itisrecommendedtorunoneapplicationatatime.Avoidrunningapplicationswhenmotiondetectionisactive.

AXISQ7411VideoEncoder

Events

TheAxisproductcanbeconguredtoperformactionswhendifferenteventsoccur,forexample,startarecordingwhenmotionis

detected.ThesetofconditionsthatdeneshowandwhentheactionistriggerediscalledanActionRule.

AvailableActionRuletriggersandconditionsinclude:

•Applications—useinstalledapplicationstotriggertherule,seeApplications,onpage31.

•Detectors

-AudioDetection—triggertherulewhenaudioisdetected,seeAudioDetection,onpage30.

-MotionDetection—triggertherulewhenmotionisdetected,seeMotionDetection,onpage28.

-Tampering—triggertherulewhentamperingisdetected,seeCameraTampering,onpage28.

•Hardware

-VideoSignal—triggertheruleifvideosignalislost.

-Network—triggertheruleifnetworkconnectionislostorrestored.Thiscanforexamplebeusedtostart

recordingtotheSDcard.

•InputSignal

-DigitalInputPort—triggertherulewhenanI/Oportreceivesasignalfromaconnecteddevice,seeI/O

Ports,onpage45.

-ManualTrigger—triggertheruleusingtheManualTriggerbuttonintheLiveViewpage,seeControlson

theLiveViewPage,onpage9.Thiscanforexamplebeusedtovalidateactionsduringproductinstallation

andconguration.

•Storage

-Available—triggertherulewhenthestoragedeviceisunmountedorremoved.Thiscanforexamplebe

usedtosendmaintenancenotications.

-Full—triggertherulewhenthestoragedeviceisfull.Undernormaloperation,theoldestrecordingswillbe

overwrittentopreventthestoragedevicefrombecomingfull.

-Locked—triggertheruleifthestoragedeviceislocked(writeprotected).

•System

-SystemInitializing—triggertherulewhentheproductisbeingstarted.Thiscanforexamplebeusedtosenda

noticationwhentheproductrestarts.

•Time

-Recurrence—triggertheruleperiodically,seeRecurrences,onpage34.Thiscanforexamplebeusedtoupload

animageevery5minutes.

-UseSchedule—triggertheruleaccordingtotheselectedschedule,seeSchedules,onpage34.

Availableactionsinclude:

•OutputPort—activateanI/Oporttocontrolanexternaldevice.

•PlayAudioClip—seeAudioClips,onpage21.

-PresetPosition—gotoapresetposition.

-GuardTour—startaguardtour,seeGuardTour,onpage26.

AXISQ7411VideoEncoder

Events

•RecordVideo—recordvideotoaselectedstorage.

•SendImages—sendimagestoarecipient.

•SendNotications—sendanoticationmessagetoarecipient.

•StatusLED—ashtheLEDindicator.Thiscanforexamplebeusedtovalidatetriggerssuchasmotiondetectionduring

productinstallationandconguration.

SettingUpanActionRule

Anactionruledenestheconditionsthatmustbemetfortheproducttoperformanaction,forexamplerecordvideoorsendemail

notications.Ifmultipleconditionsaredened,allmustbemettotriggertheaction.

Thefollowingexampledescribeshowtosetupanactionruletorecordvideotoanetworkshareifthereismovementinthe

camera’seldofview.

Setupmotiondetectionandaddanetworkshare:

1.GotoDetectors>MotionDetectionandcongureamotiondetectionwindow,seepage29

2.GotoSystemOptions>Storageandsetupthenetworkshare,seepage45.

Setuptheactionrule:

1.GotoEvents>ActionRulesandclickAdd.

2.SelectEnableruleandenteradescriptivenamefortherule.

3.SelectDetectorsfromtheTriggerdrop-downlist.

4.SelectMotionDetectionfromthedrop-downlist.Selectthemotiondetectionwindowtouse.

5.Optionally,selectaScheduleandAdditionalconditions,seebelow.

6.UnderActions,selectRecordVideofromtheTypedrop-downlist.

7.SelectaStreamproleandconguretheDurationsettingsasdescribedbelow.

8.SelectNetworkSharefromtheStoragedrop-downlist.

Toaddadditionalcriteria,selecttheAdditionalconditionsoptionandaddadditionaltriggers.Topreventanactionfrombeing

triggeredrepeatedly,aWaitatleasttimecanbeset.Enterthetimeinhours,minutesandseconds,duringwhichthetrigger

shouldbeignoredbeforetheactionrulecanbeactivatedagain.

TherecordingDurationofsomeactionscanbesettoincludetimeimmediatelybeforeandaftertheevent.SelectPre-triggertime

and/orPost-triggertimeandenterthenumberofseconds.WhenWhiletheruleisactiveisenabledandtheactionistriggered

againduringthepost-triggertime,therecordingtimewillbeextendedwithanotherpost-triggertimeperiod.

Formoreinformation,seetheonlinehelp

Recipients

Recipientsreceivemedialesandnoticationmessages.Thefollowingrecipientsareavailable:

RecipientUsewithaction

SendImages

SendNotication

FTP

SendImages

AXISQ7411VideoEncoder

Events

HTTP

SendImages

SendNotication

NetworkShareSendImages

TCPSendNotication

Note

Anetworksharecanalsobeusedasastoragedeviceforrecordedvideo.GotoSystemOptions>Storagetocongurea

networksharebeforesettingupacontinuousrecordingoranactionruletorecordvideo.SeeStorage,onpage44formore

informationaboutstoragedevices.

Toaddarecipient:

1.GotoEvents>RecipientsandclickAdd.

2.Enteradescriptivename.

3.SelectarecipientType.

4.Entertheinformationneededfortherecipienttype.

5.ClickTesttotesttheconnectiontotherecipient.

6.ClickOK.

Schedules

Schedulescanbeusedasactionruletriggersorasadditionalconditions,forexampletorecordvideoifmotionisdetectedoutside

ofcehours.Useoneofthepredenedschedulesorcreateanewscheduleasdescribedbelow.

Tocreateanewschedule:

1.GotoEvents>SchedulesandclickAdd.

2.Enteradescriptivenameandtheinformationneededforadaily,weekly,monthlyoryearlyschedule.

3.ClickOK.

TousethescheduleinanActionRule,selecttheschedulefromtheScheduledrop-downlistintheActionRuleSetuppage.

Recurrences

RecurrencesareusedtotriggerActionRulesrepeatedly,forexampleevery5minutesoreveryhour.

Tosetuparecurrence:

1.GotoEvents>RecurrencesandclickAdd.

2.Enteradescriptivenameandrecurrencepattern.

3.ClickOK.

TousetherecurrenceinanActionRule,rstselectTimefromtheTriggerdrop-downlistintheActionRuleSetuppageand

thenselecttherecurrencefromtheseconddrop-downlist.

Tomodifyorremoverecurrences,selecttherecurrenceintheRecurrencesListandclickModifyorRemove.

AXISQ7411VideoEncoder

Recordings

TheAxisproductcanbeconguredtorecordvideocontinuouslyoraccordingtoanactionrule:

•Tostartacontinuousrecording,seepage35.

•Tosetupactionrules,seepage33.

•Toaccessrecordings,seeRecordingList,onpage35.

•Tocongurecameracontrolledstorage,seeStorage,onpage44.

RecordingList

RecordedvideosarelistedontheRecordings>Listpage.Thelistshowseachrecording’sstartdateandtime,durationandthe

eventthattriggeredtherecording.

Toplayordownloadarecording,followthesesteps:

1.GotoRecordings>List.

2.Usetheltertonarrowthelistofrecordings.EnterthedesiredltercriteriaandclickFilter.Someltersmaytake

alongtimetocomplete.

3.Selecttherecording.

4.ClickPlaytoplaytherecording,orclickDownloadtodownloadtherecording.

Multiplerecordingscanbedownloadedatthesametime.SelecttherecordingsandclickDownload.Thedownloadedleisaziple

containingaminimumofthreeles,ofwhichtheMatroska(mkv)lesaretheactualrecordings.Therecordingsaretime-stamped

withthedateandtimetheyweredownloaded(thatis,notthedatetherecordingsweremade).

Note

ToplayrecordingsinWindowsMediaPlayer,AXISMatroskaFileSplittermustbeinstalled.AXISMatroskaFileSplitter

canbedownloadedfromwww.axis.com/techsup/software

Fordetailedrecordingandvideoinformation,selectarecordingandclickProperties.

Toremovearecording,selecttherecordingandclickRemove.

ContinuousRecording

TheAxisproductcanbeconguredtocontinuouslysavevideotoastoragedevice.SeeStorage,onpage44formoreinformation

aboutstoragedevices.Topreventthediskfrombecomingfull,itisrecommendedtocongurethedisktoautomaticallyremove

oldrecordings.

Tostartacontinuousrecording,followthesesteps:

1.GotoRecordings>Continuous.

2.SelectEnabled.

3.SelecttypeofstoragedevicefromtheDisklist.

4.SelectaStreamproletouseforcontinuousrecordings.

5.ClickSavetosaveandstarttherecording.

AXISQ7411VideoEncoder

Recordings

Note

Ifanewstreamproleisselectedwhilearecordingisongoing,therecordingwillbestoppedandsavedintherecordinglist

andanewrecordingwiththenewstreamprolewillstart.Allpreviouscontinuousrecordingswillremainintherecording

listuntiltheyareremovedmanuallyorthroughautomaticremovalofoldrecordings.

AXISQ7411VideoEncoder

SystemOptions

Security

Users

UseraccesscontrolisenabledbydefaultandcanbeconguredunderSystemOptions>Security>Users.Anadministratorcan

setupotherusersbygivingthemusernamesandpasswords.Itisalsopossibletoallowanonymousviewerlogin,whichmeans

thatanybodymayaccesstheLiveViewpage.

Theuserlistdisplaysauthorizedusersandusergroups(accesslevels):

Viewer-AccesstotheLiveViewpage

Operator-AccesstotheLiveViewpageandtoallsettingsexceptSystemOptions

Administrator-Unrestrictedaccesstoallsettings;canadd,modifyandremoveotherusers.

UnderHTTP/RTSPPasswordSettings,selectthetypeofpasswordtoallow.Youmayneedtoallowunencryptedpasswordsifthere

areviewingclientsthatdonotsupportencryption,orifyouupgradedthermwareandexistingclientssupportencryptionbutneed

tologinagainandbeconguredtousethisfunctionality.

UnderUserSettings,selecttheEnableanonymousviewerloginoptiontoallowanonymoususersaccesstotheLiveViewpage.

DeselecttheEnableBasicSetupoptiontohidetheBasicSetupmenu.BasicSetupprovidesquickaccesstosettingsthatshouldbe

madebeforeusingtheAxisproduct.

ONVIF

ONVIF(OpenNetworkVideoInterfaceForum)isaglobalinterfacestandardthatmakesiteasierforendusers,integrators,consultants,

andmanufacturerstotakeadvantageofthepossibilitiesofferedbynetworkvideotechnology.ONVIFenablesinteroperablitybetween

differentvendorproducts,increasedexibility,reducedcostandfuture-proofsystems.

BycreatingauseryouautomaticallyenableONVIFcommunication.UsetheusernameandpasswordwithallONVIFcommunication

withtheproduct.Formoreinformationseewww.onvif.org

IPAddressFilter

IPaddresslteringisenabledontheSystemOptions>Security>IPAddressFilterpage.Onceenabled,thelistedIPaddressare

allowedordeniedaccesstotheAxisproduct.SelectAlloworDenyfromthelistandclickApplytoenableIPaddressltering.

Theadministratorcanaddupto256IPaddressentriestothelist(asingleentrycancontainmultipleIPaddresses).

HTTPS

TheAxisproductsupportsencryptedbrowsingusingHTTPS.ThisisconguredontheSystemOptions>Security>HTTPSpage.

Aself-signedcerticatecanbeuseduntilaCerticateAuthority-issuedcerticatehasbeenobtained.ClickCreateself-signed

certicatetoinstallaself-signedcerticate.Althoughself-signedcerticatesarefreeandoffersomeprotection,truesecurityisonly

implementedaftertheinstallationofasignedcerticateissuedbyaCerticateAuthority.

ToobtainasignedcerticatefromanissuingCerticateAuthority,clickCreateCerticateRequest.Whenthesignedcerticate

isreturned,clickInstallsignedcerticatetoimportthecerticate.Thepropertiesofanycerticaterequestcurrentlyresidentin

theproductorinstalledcanbeviewedbyclickingProperties.

ToenableHTTPSintheAxisproduct,theHTTPSConnectionPolicymustbesetforeachusergroup.

Formoreinformation,seetheonlinehelp

AXISQ7411VideoEncoder

SystemOptions

HTTPS

HTTPS(HyperTextTransferProtocoloverSecureSocketLayer,orHTTPoverSSL)isawebprotocolprovidingencryptedbrowsing.

HTTPScanalsobeusedbyusersandclientstoverifythatthecorrectdeviceisbeingaccessed.Thesecuritylevelprovidedby

HTTPSisconsideredadequateformostcommercialexchanges.

TheAxisproductcanbeconguredtorequireHTTPSwhenusersfromdifferentusergroups(administrator,operator,viewer)connect.

TouseHTTPS,anHTTPScerticatemustrstbeinstalled.GotoSystemOptions>Security>Certicatestoinstallandmanage

certicates.See.

ToenableHTTPSontheAxisproduct:

1.GotoSystemOptions>Security>HTTPS

2.SelectanHTTPScerticatefromthelistofinstalledcerticates.

3.Optionally,clickCiphersandselecttheencryptionalgorithmstouseforSSL.

4.SettheHTTPSConnectionPolicyforthedifferentusergroups.

5.ClickSavetoenablethesettings.

ToaccesstheAxisproductviathedesiredprotocol,enterhttps://orhttp://intheaddresseldinabrowser.

TheHTTPSportcanbechangedontheSystemOptions>Network>TCP/IP>Advancedpage.

IEEE802.1X

IEEE802.1Xisastandardforport-basedNetworkAdmissionControlprovidingsecureauthenticationofwiredandwirelessnetwork

devices.IEEE802.1XisbasedonEAP(ExtensibleAuthenticationProtocol).

ToaccessanetworkprotectedbyIEEE802.1X,devicesmustbeauthenticated.Theauthenticationisperformedbyanauthentication

server,typicallyaRADIUSserver,examplesofwhichareFreeRADIUSandMicrosoftInternetAuthenticationService.

InAxisimplementation,theAxisproductandtheauthenticationserveridentifythemselveswithdigitalcerticatesusingEAP-TLS

(ExtensibleAuthenticationProtocol-TransportLayerSecurity).ThecerticatesareprovidedbyaCerticationAuthority(CA).

Youneed:

•aCAcerticatetoauthenticatetheauthenticationserver

•aCA-signedclientcerticatetoauthenticatetheAxisproduct.

Tocreateandinstallcerticates,gotoSystemOptions>Security>Certicates.See.ManyCAcerticatesarepreinstalled.

ToallowtheproducttoaccessanetworkprotectedbyIEEE802.1X:

1.GotoSystemOptions>Security>IEEE802.1X.

2.SelectaCACerticateandaClientCerticatefromthelistsofinstalledcerticates.

3.UnderSettings,selecttheEAPOLversionandprovidetheEAPidentityassociatedwiththeclientcerticate.

4.ChecktheboxtoenableIEEE802.1XandclickSave.

Note

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductshouldbesynchronizedwithanNTP

server.SeeDate&Time,onpage39.

AudioSupport

SelectEnableaudiosupporttoallowclientstoretrieveaudiostreamsfromtheAxisproduct.Forinformationonhowtocongure

audiosettings,seeAudioSettings,onpage20.

AXISQ7411VideoEncoder

SystemOptions

Note

DeselectingthisoptionwilldisableaudiogloballyintheAxisproduct,forconguredeventsandproleswithaudioaswell.

Date&Time

TheAxisproduct’sdateandtimesettingsareconguredunderSystemOptions>Date&Time.

CurrentServerTimedisplaysthecurrentdateandtime(24hclock).Thetimecanbedisplayedin12hclockinthetextoverlay(see

below).

Tochangethedateandtimesettings,selectthepreferredTimemodeunderNewServerTime:

•Synchronizewithcomputertimesetsdateandtimeaccordingtothecomputer’sclock.Withthisoption,dateand

timearesetonceandwillnotbeupdatedautomatically.

•SynchronizewithNTPServerobtainsdateandtimefromanNTPserver.Withthisoption,dateandtimesettingsare

updatedcontinuously.ForinformationonNTPsettings,seeNTPConguration,onpage41.

IfusingahostnamefortheNTPserver,aDNSservermustbecongured.SeeDNSConguration,onpage41.

•Setmanuallyallowsyoutomanuallysetdateandtime.

IfusinganNTPserver,selectyourTimezonefromthedrop-downlist.Ifrequired,checkAutomaticallyadjustfordaylightsaving

timechanges.

TheDate&TimeFormatUsedinImagesisthedateandtimeformatdisplayedasatextoverlayinthevideostream.Usethe

predenedformatsorseeFileNaming&Date/TimeFormatsintheonlinehelp

forinformationonhowtocreatecustomdateand

timeformats.Toincludedateandtimeintheoverlaytext,gotoVideo&AudioandselectIncludedateandIncludetime.

Network

BasicTCP/IPSettings

TheAxisproductsupportsIPversion4andIPversion6.Bothversionscanbeenabledsimultaneously,andatleastoneversion

mustalwaysbeenabled.

IPv4AddressConguration

Bydefault,theAxisproductissettouseIPv4(IPversion4)andtoobtaintheIPaddressautomaticallyviaDHCP.TheIPv4settingsare

conguredunderSystemOptions>Network>TCP/IP>Basic.

DHCP(DynamicHostCongurationProtocol)allowsnetworkadministratorstocentrallymanageandautomatetheassignmentof

IPaddresses.DHCPshouldonlybeenabledifusingdynamicIPaddressnotication,oriftheDHCPcanupdateaDNSserver.Itis

thenpossibletoaccesstheAxisproductbyname(hostname).

IfDHCPisenabledandtheproductcannotbeaccessed,runAXISIPUtilitytosearchthenetworkforconnectedAxisproducts,orreset

theproducttothefactorydefaultsettings(seepage48)andthenperformtheinstallationagain.

TouseastaticIPaddress,checkUsethefollowingIPaddressandspecifytheIPaddress,subnetmaskanddefaultrouter.

IPv6AddressConguration

IfIPv6(IPversion6)isenabled,theAxisproductwillreceiveanIPaddressaccordingtothecongurationinthenetworkrouter.

ToenableIPv6,gotoSystemOptions>Network>TCP/IP>Basic.OthersettingsforIPv6shouldbeconguredinthenetworkrouter.

ARP/Ping

Theproduct’sIPaddresscanbeassignedusingARPandPing.Forinstructions,seeAssignIPAddressusingARP/Ping,onpage40.

AXISQ7411VideoEncoder

SystemOptions

TheARP/Pingserviceisenabledbydefaultbutisautomaticallydisabledtwominutesaftertheproductisstarted,orassoonasanIP

addressisassigned.Tore-assignIPaddressusingARP/Ping,theproductmustberestartedtoenableARP/Pingforanadditional

twominutes.

Todisabletheservice,gotoSystemOptions>Network>TCP/IP>BasicandcleartheoptionEnableARP/PingsettingofIPaddress.

Pingingtheproductisstillpossiblewhentheserviceisdisabled.

AssignIPAddressusingARP/Ping

Theproduct'sIPaddresscanbeassignedusingARP/Ping.Thecommandmustbeissuedwithin2minutesofconnectingpower.

1.AcquireafreestaticIPaddressonthesamenetworksegmentasthecomputer.

2.Locatetheserialnumber(S/N)ontheproductlabel.

3.Openacommandpromptandenterthefollowingcommands:

Linux/Unixsyntax

arp-s<IPaddress><serialnumber>temp

ping-s408<IPaddress>

Linux/Unixexample

arp-s192.168.0.12500:40:8c:18:10:00temp

ping-s408408192.168.0.125

Windowssyntax(thismayrequirethatyourunthecommandpromptasanadministrator)

arp-s<IPaddress><serialnumber>

ping-l408-t<IPaddress>

Windowsexample(thismayrequirethatyourunthecommandpromptasanadministrator)

arp-s192.168.0.12500-40-8c-18-10-00

ping-l408-t192.168.0.125

4.CheckthatthenetworkcableisconnectedtotheAxisproductandthenrestarttheproductbydisconnectingand

reconnectingpower.

5.ClosethecommandpromptwhentheproductrespondswithReplyfrom192.168.0.125:...orsimilar.

6.Openabrowserandtypehttp://<IPaddress>intheLocation/Addresseld.

ForothermethodsofassigningtheIPaddress,seetheInstallationandManagementSoftwareCDorthedocumentAssignanIP

AddressandAccesstheVideoStreamonAxisSupportwebatwww.axis.com/techsup

Note

•ToopenacommandpromptinWindows,opentheStartmenuandtypecmdintheRun/Searcheld.

•TousetheARPcommandinWindows7/WindowsVista,right-clickthecommandprompticonandselectRunas

administrator.

•ToopenacommandpromptinMacOSX,opentheTerminalutilityfromApplication>Utilities.

AXISVideoHostingSystem(AVHS)

AVHSusedinconjunctionwithanAVHSservice,provideseasyandsecureInternetaccesstoliveandrecordedvideoaccessiblefrom

anylocation.FormoreinformationandhelptondalocalAVHSServiceProvidergotowww.axis.com/hosting

AVHSisenabledbydefault.ThesettingsareconguredunderSystemOptions>Network>TCPIP>Basic.

AXISQ7411VideoEncoder

SystemOptions

One-clickenabled-Presstheproduct’scontrolbutton(seeHardwareOverview,onpage5)toconnecttoanAVHSserviceoverthe

Internet.Onceregistered,AlwayswillbeenabledandtheAxisproductstaysconnectedtotheAVHSservice.Iftheproductisnot

registeredwithin24hoursfromwhenthebuttonispressed,theproductwilldisconnectfromtheAVHSservice.

Always-TheAxisproductwillconstantlyattempttoconnecttotheAVHSserviceovertheInternet.Onceregisteredtheproductwill

stayconnectedtotheservice.Thisoptioncanbeusedwhentheproductisalreadyinstalledanditisnotconvenienttousethe

one-clickinstallation.

AXISInternetDynamicDNSService

AXISInternetDynamicDNSServiceassignsahostnameforeasyaccesstotheproduct.Formoreinformation,seewww.axiscam.net

ToregistertheAxisproductwithAXISInternetDynamicDNSService,gotoSystemOptions>Network>TCP/IP>Basic.Under

Services,clicktheAXISInternetDynamicDNSServiceSettingsbutton(requiresaccesstotheInternet).Thedomainnamecurrently

registeredatAXISInternetDynamicDNSservicefortheproductcanatanytimeberemoved.

AdvancedTCP/IPSettings

DNSConguration

DNS(DomainNameService)providesthetranslationofhostnamestoIPaddresses.TheDNSsettingsareconguredunderSystem

Options>Network>TCP/IP>Advanced.

SelectObtainDNSserveraddressviaDHCPtousetheDNSsettingsprovidedbytheDHCPserver.

Tomakemanualsettings,selectUsethefollowingDNSserveraddressandspecifythefollowing:

Domainname-Enterthedomain(s)tosearchforthehostnameusedbytheAxisproduct.Multipledomainscanbeseparatedby

semicolons.Thehostnameisalwaystherstpartofafullyqualieddomainname,forexample,myserveristhehostnameinthe

fullyqualieddomainnamemyserver.mycompany.comwheremycompany.comisthedomainname.

Primary/SecondaryDNSserver-EntertheIPaddressesoftheprimaryandsecondaryDNSservers.ThesecondaryDNSserveris

optionalandwillbeusediftheprimaryisunavailable.

NTPConguration

NTP(NetworkTimeProtocol)isusedtosynchronizetheclocktimesofdevicesinanetwork.TheNTPsettingsareconguredunder

SystemOptions>Network>TCP/IP>Advanced.

SelectObtainNTPserveraddressviaDHCPtousetheNTPsettingsprovidedbytheDHCPserver.

Tomakemanualsettings,selectUsethefollowingNTPserveraddressandenterthehostnameorIPaddressoftheNTPserver.

HostNameConguration

TheAxisproductcanbeaccessedusingahostnameinsteadofanIPaddress.ThehostnameisusuallythesameastheassignedDNS

name.ThehostnameisconguredunderSystemOptions>Network>TCP/IP>Advanced.

SelectObtainhostnameviaIPv4DHCPtousehostnameprovidedbytheDHCPserverrunningonIPv4.

SelectUsethehostnametosetthehostnamemanually.

SelectEnabledynamicDNSupdatestodynamicallyupdatelocalDNSserverswhenevertheAxisproduct’sIPaddresschanges.

Formoreinformation,seetheonlinehelp.

Link-LocalIPv4Address

Link-LocalAddressisenabledbydefaultandassignstheAxisproductanadditionalIPaddresswhichcanbeusedtoaccess

theproductfromotherhostsonthesamesegmentonthelocalnetwork.TheproductcanhaveaLink-LocalIPandastatic

orDHCP-suppliedIPaddressatthesametime.

AXISQ7411VideoEncoder

SystemOptions

ThisfunctioncanbedisabledunderSystemOptions>Network>TCP/IP>Advanced.

HTTP

TheHTTPportusedbytheAxisproductcanbechangedunderSystemOptions>Network>TCP/IP>Advanced.Inadditiontothe

defaultsetting,whichis80,anyportintherange1024–65535canbeused.

HTTPS

TheHTTPSportusedbytheAxisproductcanbechangedunderSystemOptions>Network>TCP/IP>Advanced.Inadditionto

thedefaultsetting,whichis443,anyportintherange1024–65535canbeused.

ToenableHTTPS,gotoSystemOptions>Security>HTTPS.Formoreinformation,seepage37.

NATtraversal(portmapping)forIPv4

Anetworkrouterallowsdevicesonaprivatenetwork(LAN)toshareasingleconnectiontotheInternet.Thisisdonebyforwarding

networktrafcfromtheprivatenetworktothe“outside”,thatis,theInternet.Securityontheprivatenetwork(LAN)isincreased

sincemostroutersarepre-conguredtostopattemptstoaccesstheprivatenetwork(LAN)fromthepublicnetwork(Internet).

UseNATtraversalwhentheAxisproductislocatedonanintranet(LAN)andyouwishtomakeitavailablefromtheother

(WAN)sideofaNATrouter.WithNATtraversalproperlycongured,allHTTPtrafctoanexternalHTTPportintheNATrouter

isforwardedtotheproduct.

NATtraversalisconguredunderSystemOptions>Network>TCP/IP>Advanced.

Note

•ForNATtraversaltowork,thismustbesupportedbytherouter.TheroutermustalsosupportUPnP

•Therouterhasmanydifferentnames:“NATrouter”,“Networkrouter”,“InternetGateway”,”Broadbandrouter”,“Broadband

sharingdevice”or“Homerewall”buttheessentialpurposeofthedeviceisthesame.

Enable/Disable-Whenenabled,theAxisproductattemptstocongureportmappinginaNATrouteronyournetwork,usingUPnP

NotethatUPnP

mustbeenabledintheproduct(seeSystemOptions>Network>UPnP).

UsemanuallyselectedNATrouter-SelectthisoptiontomanuallyselectaNATrouterandentertheIPaddressfortherouterin

theeld.Ifnorouterisspecied,theproductautomaticallysearchesforNATroutersonyournetwork.Ifmorethanonerouteris

found,thedefaultrouterisselected.

AlternativeHTTPport-SelectthisoptiontomanuallydeneanexternalHTTPport.Entertheportnumberintheeld.Ifnoportis

enteredhere,aportnumberisautomaticallyselectedwhenNATtraversalisenabled.

Note

•AnalternativeHTTPportcanbeusedorbeactiveevenifNATtraversalisdisabled.ThisisusefulifyourNATrouterdoesnot

supportUPnPandyouneedtomanuallycongureportforwardingintheNATrouter.

•Ifyouattempttomanuallyenteraportthatisalreadyinuse,anotheravailableportisautomaticallyselected.

•Whentheportisselectedautomaticallyitisdisplayedinthiseld.Tochangethis,enteranewportnumberandclickSave.

FTP

TheFTPserverrunningintheAxisproductenablesuploadofnewrmware,userapplications,etc.TheFTPservercanbedisabled

underSystemOptions>Network>TCP/IP>Advanced.

Note

ThisFTPserverhasnothingtodowiththeproduct’sabilitytotransferimagesviaFTPtootherlocationsandservers.

AXISQ7411VideoEncoder

SystemOptions

RTSP

TheRTSPserverrunningintheAxisproductallowsaconnectingclienttostartanH.264stream.TheRTSPportnumbercanbe

changedunderSystemOptions>Network>TCP/IP>Advanced.Thedefaultportis554.

Note

H.264videostreamswillnotbeavailableiftheRTSPserverisdisabled.

SOCKS

SOCKSisanetworkingproxyprotocol.TheAxisproductcanbeconguredtouseaSOCKSservertoreachnetworksontheother

sideofarewallorproxyserver.ThisfunctionalityisusefuliftheAxisproductislocatedonalocalnetworkbehindarewall,and

notications,uploads,alarms,etcneedtobesenttoadestinationoutsidethelocalnetwork(forexampletheInternet).

SOCKSisconguredunderSystemOptions>Network>SOCKS.Formoreinformation,seetheonlinehelp

QoS(QualityofService)

QoS(QualityofService)guaranteesacertainlevelofaspeciedresourcetoselectedtrafconanetwork.AQoS-awarenetwork

prioritizesnetworktrafcandprovidesagreaternetworkreliabilitybycontrollingtheamountofbandwidthanapplicationmayuse.

TheQoSsettingsareconguredunderSystemOptions>Network>QoS.UsingDSCP(DifferentiatedServicesCodepoint)values,the

Axisproductcanmarkthefollowingtypesoftrafc:livevideo,liveaudio,event/alarmtrafcandmanagementtrafc.

Note

LiveaudioDSCPwillbeequaltolivevideoDSCPifH.264overRTSPisused.

SMTP(email)

TosendemailmessagesfromtheAxisproductviaSMTP(SimpleMailTransferProtocol),anSMTPmailservermustbesetup.This

isdoneunderSystemOptions>Network>SMTP(email).

EnterthehostnamesorIPaddressesandportnumbersfortheprimaryandsecondarymailserversintheeldsprovided.AFrom

emailaddressisalsorequired.Ifthemailserverrequiresauthentication,checkUseauthenticationtologintothisserverandenter

thenecessaryinformation.

SNMP

TheSimpleNetworkManagementProtocol(SNMP)allowsremotemanagementofnetworkdevices.AnSNMPcommunityisthe

groupofdevicesandmanagementstationrunningSNMP.Communitynamesareusedtoidentifygroups.

TheAxisproductcanbeconguredtosupportSNMPontheSystemOptions>Network>SNMPpage.

Dependingonthelevelofsecurityrequired,selecttheversiononSNMPtouse.

SNMPv1/v2providesthelowestlevelofsecurity.Thecommunitynamecanbespeciedasapasswordforreadorread/write

accesstoallsupportedSNMPdevices.ThedefaultpasswordfortheReadcommunityispublicandthedefaultpasswordforthe

Writecommunityiswrite.

Note

IfHTTPSisenabled,SNMPv1andSNMPv2cshouldbedisabled.

TrapsforSNMPv1/v2areusedbytheAxisproducttosendmessagestoamanagementsystemonimportanteventsandstatus

changes.CheckEnabletrapsandentertheIPaddresswherethetrapmessageshouldbesentandtheTrapcommunitythat

shouldreceivethemessage.

Thefollowingtrapsareavailable:

•Coldstart

•Warmstart

AXISQ7411VideoEncoder

SystemOptions

•Linkup

•Authenticationfailed

SNMPv3providesencryptionandsecurepasswords.TousetrapswithSNMPv3,anSNMPv3managementapplicationisrequired.

TouseSNMPv3,HTTPSmustbeenabled,seeHTTPS,onpage37.ToenableSNMPv3,checktheboxandprovidetheinitialuser

password.

Note

Theinitialpasswordcanonlybesetonce.Ifthepasswordislost,theAxisproductmustberesettofactorydefault,see

ResettoFactoryDefaultSettings,onpage48.

UPnP

TheAxisproductincludessupportforUPnP

.UPnP

isenabledbydefaultandtheproductisautomaticallydetectedbyoperating

systemsandclientsthatsupportthisprotocol.

UPnP

canbedisabledunderSystemOptions>Network>UPnP

RTP/H.264

TheRTPportrangeandmulticastsettingsareconguredunderSystemOptions>Network>RTP.

TheRTPportrangedenestherangeofportsfromwhichthevideo/audioportsareautomaticallyselected.Formulticaststreams,

onlycertainIPaddressesandportnumbersshouldbeused.

SelectAlwaysMulticastVideoand/orAlwaysMulticastAudiotostartmulticaststreamingwithoutopeninganRTSPsession.

Bonjour

TheAxisproductincludessupportforBonjour.Bonjourisenabledbydefaultandtheproductisautomaticallydetectedbyoperating

systemsandclientsthatsupportthisprotocol.

BonjourcanbedisabledunderSystemOptions>Network>Bonjour.

Storage

SDCard

NOTICE NOTICE

NOTICE

Topreventcorruptionofrecordings,theSDcardshouldalwaysbeunmountedbeforeitisejected.

TheAxisproductsupportsSDcardswiththefollowinglesystems:

•ext4—recommendedduetoitsresilienceagainstdatalossifthecardisejectedorifthereisabruptpowerloss.Toaccess

datastoredonthecardfromtheWindowsoperatingsystem,athird-partyext4driverorapplicationisrequired.

•vFAT—mostSDcardsarepre-formattedwithvFATwhenpurchased.

Ifrequired,theSDcardcanbere-formattedtothedesiredlesystem.ToformattheSDcard:

1.InserttheSDcardintheSDcardslot.

2.GotoSystemOptions>StorageandclickSDCard.

3.ClickFormatandselectthedesiredlesystem.

Note

Duringformattinganypreviousdatastoredonthediskwillbelost.

AXISQ7411VideoEncoder

SystemOptions

Mountingisdoneautomaticallywhenthecardisinsertedorwhentheproductisstarted.Amanualmountisonlyrequiredifthe

cardhasbeenunmountedandnotejectedandre-inserted.

TounmounttheSDcard:

1.GotoSystemOptions>StorageandclickSDCard.

2.ClickUnmount.

3.Thecardcannowberemoved.

TheSDcardismanagedontheSystemOptions>Storagepage.ClickSDCardtoopenStorageManagement.

Ifthecard’sstatusshowsasfailed,clickCheckdisktoseeiftheproblemcanbefoundandthentryRepair.Thisoptionisonly

availableforSDcardswithext4.ForSDcardswithvFAT,useacardreaderorcomputertotroubleshootthecard.

Toavoidllingthecard,itisrecommendedtoremoverecordingscontinuously.UnderRecordingSettings,selectRemoverecordings

olderthanandselectthenumberofdaysorweeks.

Tostopwritingtothecardandprotectrecordingsfrombeingremoved,selectLockunderRecordingSettings.

NetworkShare

NetworkshareallowsyoutoaddnetworkstoragesuchasaNAS(NetworkAttachedStorage)oranyserverthatusesCIFS(Common

InternetFileSystem)andusethemforstorageofrecordings.

Toaddanetworkshare:

1.GotoSystemOptions>Storage.

2.ClickNetworkShare.

3.EntertheIPaddress,DNSorBonjournametothehostserverintheHosteld.

4.EnterthenameoftheshareintheShareeld.

5.Ifrequired,selectThesharerequiresloginandentertheusernameandpassword.

6.ClickConnect.

ToclearallrecordingsanddatafromtheAxisproduct’sfolderonthedesignatedshare,clickClearunderStorageTools.

Toavoidllingtheshare,itisrecommendedtoremoverecordingscontinuously.UnderRecordingSettings,selectRemoverecordings

olderthanandselectthenumberofdaysorweeks.

Tostopwritingtotheshareandprotectrecordingsfrombeingremoved,selectLockunderRecordingSettings.

Ports&Devices

I/OPorts

TheAxisproductprovidesfourcongurableinputandoutputportsforconnectionofexternaldevices.Forinformationonhowto

connectexternaldevices,seeConnectors,onpage5.

TheI/OportsareconguredunderSystemOptions>Ports&Devices>I/OPorts.Selecttheportdirection(InputorOutput).The

portscanbegivendescriptivenamesandtheirNormalstatescanbeconguredasOpencircuitorGroundedcircuit.

COMPort

TheAxisproducthasoneRS-485/RS-422serialport.Theportsupportsthefollowingmodes:

•GenericHTTPallowstheAxisproducttoreceivedataandsendcommandsviaHTTP.

AXISQ7411VideoEncoder

SystemOptions

•PanTiltZoomisusedtocontrolaPTZdevice.ThePTZdevicerequiresadriver.SeeInstallingaPTZdriverformore

information.Driverscanbedownloadedfromwww.axis.com

•GenericTCP/IPallowstheAxisproducttoreceivedataandsendcommandsviaTCP/IP.Daisychainserver-AllowsDaisy

chainclientstocommunicatewiththeAxisproduct.

SelectthedesiredPortTypefromthedrop-downlist.FormoreinformationonSerialPortSettingsandDaisyChainPortSettings

seetheonlinehelp

PortStatus

ThelistontheSystemOptions>Ports&Devices>PortStatuspageshowsthestatusoftheproduct’sinputandoutputports.

Maintenance

TheAxisproductprovidesseveralmaintenancefunctions.TheseareavailableunderSystemOptions>Maintenance.

ClickRestarttoperformacorrectrestartiftheAxisproductisnotbehavingasexpected.Thiswillnotaffectanyofthecurrent

settings.

ClickRestoretoresetmostsettingstothefactorydefaultvalues.Thefollowingsettingsarenotaffected:

•thebootprotocol(DHCPorstatic)

•thestaticIPaddress

•thedefaultrouter

•thesubnetmask

•thesystemtime

•theIEEE802.1Xsettings

ClickDefaulttoresetallsettings,includingtheIPaddress,tothefactorydefaultvalues.Thisbuttonshouldbeusedwithcaution.The

Axisproductcanalsoberesettofactorydefaultusingthecontrolbutton,seeResettoFactoryDefaultSettings,onpage48.

ToidentifytheproductortesttheStatusLED,clickFlashLEDunderIdentifyandspecifythedurationinseconds,minutesorhours.

Thiscanbeusefulforidentifyingtheproductamongotherproductsinstalledinthesamelocation.

Forinformationaboutrmwareupgrade,seeUpgradingtheFirmware,onpage49.

Support

SupportOverview

TheSystemOptions>Support>SupportOverviewpageprovidesinformationontroubleshootingandcontactinformation,

shouldyourequiretechnicalassistance.

SeealsoTroubleshooting,onpage49.

SystemOverview

TogetanoverviewoftheAxisproduct’sstatusandsettings,gotoSystemOptions>Support>SystemOverview.Informationthat

canbefoundhereincludesrmwareversion,IPaddress,networkandsecuritysettings,eventsettings,imagesettingsandrecentlog

items.ManyofthecaptionsarelinkstotheproperSetuppage.

AXISQ7411VideoEncoder

SystemOptions

Logs&Reports

TheSystemOptions>Support>Logs&Reportspagegenerateslogsandreportsusefulforsystemanalysisandtroubleshooting.If

contactingAxisSupport,pleaseprovideavalidServerReportwithyourquery.

SystemLog-Providesinformationaboutsystemevents.

AccessLog-Listsallfailedattemptstoaccesstheproduct.TheAccessLogcanalsobeconguredtolistallconnectionstothe

product(seebelow).

ServerReport-Providesinformationabouttheproductstatusinapop-upwindow.TheAccessLogisautomaticallyincluded

intheServerReport.

Youcanviewordownloadtheserverreport.Downloadingtheserverreportcreatesa.ziplethatcontainsacompleteserverreport

textleinUTF–8format.SelecttheIncludesnapshotwithdefaultimagesettingsoptiontoincludeasnapshotoftheproduct’s

LiveViewthatalsoshowsthesettingsspeciedunderVideoStream>Image>ImageAppearance.Theserverreport.zipleshould

alwaysbeincludedwhencontactingsupport.

ParameterList-Showstheproduct'sparametersandtheircurrentsettings.Thismayproveusefulwhentroubleshootingor

whencontactingAxisSupport.

ConnectionList-Listsallclientsthatarecurrentlyaccessingmediastreams.

CrashReport-Generatesanarchivewithdebugginginformation.Thereporttakesseveralminutestogenerate.

TheloglevelsfortheSystemLogandtheAccessLogaresetunderSystemOptions>Support>Logs&Reports>Conguration.

TheAccessLogcanbeconguredtolistallconnectionstotheproduct(selectCritical,Warnings&Info).Ifrequired,adifferentlog

levelcanbeusedwhensendingemails.

Advanced

Scripting

Scriptingallowsexperienceduserstocustomizeandusetheirownscripts.

NOTICE NOTICE

NOTICE

ImproperusemaycauseunexpectedbehaviorandlossofcontactwiththeAxisproduct.

Axisstronglyrecommendsthatyoudonotusethisfunctionunlessyouunderstandtheconsequences.AxisSupportdoesnotprovide

assistanceforproblemswithcustomizedscripts.

ToopentheScriptEditor,gotoSystemOptions>Advanced>Scripting.Itisrecommendedtocreateabackuplebefore

customizingthescripts.Ifascriptcausesproblems,resettheproducttoitsfactorydefaultsettings,seepage48.

Formoreinformation,seewww.axis.com/developer

FileUpload

Files,forexamplewebpagesandimages,canbeuploadedtotheAxisproductandusedascustomsettings.Touploadale,go

toSystemOptions>Advanced>FileUpload.

Uploadedlesareaccessedthroughhttp://<ipaddress>/local/<user>/<filename>where<user>isthe

selectedusergroup(viewer,operatororadministrator)fortheuploadedle.

PlainCong

PlainCongisforadvanceduserswithexperienceofAxisproductconguration.Mostparameterscanbesetandmodiedfromthis

page.Helpisavailablefromthestandardhelppages.

ToopenPlainCong,gotoSystemOptions>Advanced>PlainCong.

AXISQ7411VideoEncoder

SystemOptions

ResettoFactoryDefaultSettings

Thiswillresetallparameters,includingtheIPaddress,tothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.PressandholdtheControlbuttonandreconnectpower(seeHardwareOverview,onpage5).

3.KeeptheControlbuttonpressedforabout15secondsuntiltheStatusindicatorashesamber.

4.ReleasetheControlbutton.Theprocessiscompleteafterabout1minute(whentheStatusindicatorturnsgreen).The

producthasbeenresettothefactorydefaultsettings.ThedefaultIPaddressis192.168.0.90

5.Re-assigntheIPaddress.

Itisalsopossibletoresetparameterstofactorydefaultviathewebinterface.GotoSetup>SystemOptions>Maintenance.

AXISQ7411VideoEncoder

Troubleshooting

CheckingtheFirmware

Firmwareissoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootingaproblem

shouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticularproblem.The

currentrmwareversionintheAxisproductisdisplayedinthepageSetup>BasicSetupandinSetup>About.

UpgradingtheFirmware

WhenyouupgradetheproductwiththelatestrmwarefromAxiswebsite,theproductreceivesthelatestfunctionalityavailable.

Alwaysreadtheupgradeinstructionsandreleasenotesavailablewitheachnewrelease,beforeupgradingthermware.

Toupgrade,followtheseinstructions:

1.Savethermwareletoyourcomputer.ThelatestversionofthermwareisavailablefreeofchargefromAxiswebsite

atwww.axis.com/techsup

2.GotoSetup>SystemOptions>Maintenanceintheproductswebpages.

3.UnderUpgradeServer,clickBrowseandlocatetheleonyourcomputer.ClickUpgrade.

Afterstartingtheupgradeprocess,alwayswaitatleast5–10minutesbeforerestartingtheproduct,evenifyoususpectthe

upgradehasfailed.

AXISCameraManagementcanbeusedformultipleupgrades.Seewww.axis.comformoreinformation.

Note

•Yourdealerreservestherighttochargeforanyrepairattributabletofaultyupgradebytheuser.

•Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providingthefeaturesareavailableinthe

newrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

EmergencyRecoveryProcedure

Ifpowerornetworkconnectionislostduringtheupgrade,theprocessfailsandtheproductbecomesunresponsive.FlashingredStatus

indicatorindicatesafailedupgrade.Torecovertheproduct,followthestepsbelow.Theserialnumberisfoundontheproduct’slabel.

1.InUNIX/Linux,typethefollowingfromthecommandline:

AXISQ7411VideoEncoder

Troubleshooting

arp-s<IPaddress><serialnumber>temp

ping-s408<IPaddress>

InWindows,typethefollowingfromacommand/DOSprompt(thismayrequirethatyourunthecommandpromptas

anadministrator):

arp-s<IPaddress><serialnumber>

ping-l408-t<IPaddress>

2.Iftheproductdoesnotreplyin30seconds,restartitandwaitforareply.PressCTRL+CtostopPing.

3.Openabrowserandtypeintheproduct’sIPaddress.Inthepagethatappears,usetheBrowsebuttontoselecttheupgrade

letouse.ThenclickLoadtorestarttheupgradeprocess.

4.Aftertheupgradeiscomplete(1–10minutes),theproductautomaticallyrestartsandshowsasteadygreenonthe

Statusindicator.

5.Reinstalltheproduct,referringtotheInstallationGuide.

Iftheemergencyrecoveryproceduredoesnotgettheproductupandrunningagain,contactAxissupportatwww.axis.com/techsup/

Symptoms,PossibleCausesandRemedialActions

ProblemssettingtheIPaddress

WhenusingARP/Ping

Trytheinstallationagain.TheIPaddressmustbesetwithintwominutesafterpowerhasbeen

appliedtotheproduct.EnsurethePinglengthissetto408.Forinstructions,seeAssignIPAddress

usingARP/Ping,onpage40.

Theproductislocatedona

differentsubnet

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe

productarelocatedondifferentsubnets,youwillnotbeabletosettheIPaddress.Contactyour

networkadministratortoobtainanIPaddress.

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisproductfromthenetwork.RunthePingcommand(inaCommand/DOS

window,typepingandtheIPaddressoftheproduct:

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet.

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingtheproduct.

Theproductcannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordforrootislost,theproductmustberesettothefactorydefaultsettings.See

ResettoFactoryDefaultSettings,onpage48.

AXISQ7411VideoEncoder

Troubleshooting

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshasbeen

changed,useAXISIPUtilityorAXISCameraManagementtolocatedtheproductonthenetwork.

Identifytheproductusingitsmodelorserialnumber.

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,seetheInstallationand

ManagementSoftwareCDorthedocumentAssignanIPAddressandAccesstheVideoStreamon

AxisSupportwebatwww.axis.com/techsup

Certicateerrorwhenusing

IEEE802.1X

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductshouldbe

synchronizedwithanNTPserver.SeeDate&Time,onpage39.

Theproductisaccessiblelocallybutnotexternally

RoutercongurationTocongureyourroutertoallowincomingdatatrafctotheAxisproduct,enabletheNAT-traversal

featurewhichwillattempttoautomaticallyconguretheroutertoallowaccesstotheAxis

product,seeNATtraversal(portmapping)forIPv4,onpage42.TheroutermustsupportUPnP

Firewallprotection

ChecktheInternetrewallwithyournetworkadministrator.

Defaultroutersrequired

Checkifyouneedtoconguretheroutersettings.

ProblemswiththeH.264format

NoH.264displayedinthe

client

CheckthattherelevantH.264connectionmethodsandcorrectinterfaceareenabledintheAMC

ControlPanel(streamingtab).SeeAXISMediaControl(AMC),onpage12.

IntheAMCControlPanel,selecttheH.264tabandclickSettodefaultH.264decoder.

CheckthatRTSPisenabledunderSystemOptions>Network>TCP/IP>Advanced.

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

PoorrenderingofH.264

images

Colordepthsetincorrectlyonclients.Setto16–bitor32–bitcolor.

Iftextoverlaysareblurred,orifthereareotherrenderingproblems,youmayneedtoenable

AdvancedVideoRenderingfromtheVideotabintheAMCControlPanel.

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Refertotheadapter’sdocumentationformore

information.

Lowerframeratethan

expected

Reducethenumberofapplicationsrunningontheclientcomputer.

Limitthenumberofsimultaneousviewers.

Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

CheckintheAMCControlPanel(H.264tag)thatvideoprocessingisNOTsettoDecodeonly

keyframes.

Lowertheimageresolution.

WhydoInotgetmaximum

framespersecond?

SeePerformanceConsiderations,onpage58.

Imagedegeneration

DecreasetheGOVlength.GotoVideo&Audio>VideoStreamandselecttheH.264tab

tomodifytheGOVlength.

AXISQ7411VideoEncoder

Troubleshooting

StatusandNetworkindicatorLEDsareashingredrapidly

Hardwarefailure

ContactyourAxisreseller.

StatusindicatorLEDisashingredandtheproductisinaccessible

Armwareupgradehas

beeninterruptedorthe

rmwarehasotherwisebeen

damaged

SeeEmergencyRecoveryProcedure,onpage49.

Noimagesdisplayedonwebpage

ProblemswithAXISMedia

Control(InternetExplorer

only)

ToenabletheupdatingofvideoimagesinInternetExplorer,setthebrowsertoallowActiveX

controls.Also,makesurethatAXISMediaControlisinstalledonyourcomputer.

Installationofadditional

ActiveXcomponent

restrictedorprohibited

ConguretheAxisproducttouseaJavaappletforupdatingvideoimagesinInternetExplorer.Go

toSetup>LiveViewCongandselectJavaappletunderDefaultviewer.

Poorqualitysnapshotimages

Screenincorrectly

conguredonyourcomputer

Congureyourscreentoshowatleast65000colors,thatis,atleast16bits.Usingonly16or256

colorswillproduceditheringartifactsintheimage.

Overlayimageisnotdisplayed

Incorrectsizeorlocationof

overlayimage

Theoverlayimagemayhavebeenpositionedincorrectlyormaybetoolarge.SeeOverlayImage

Settingsintheonlinehelpformoreinformation.

Privacymaskisnotdisplayed

Incorrectsizeorlocationof

privacymask

Theprivacymaskmayhavebeenpositionedincorrectlyormaybetoolarge.

Browserfreezes

Firefoxcansometimes

freezeonaslowcomputer

Lowertheimageresolution

Problemsuploadingles

LimitedspaceThereisonlylimitedspaceavailablefortheuploadofyourownles.Deleteexistinglestofree

upspace.

MotionDetectiontriggersunexpectedly

Changesinluminance

Motiondetectionisbasedonchangesinluminanceintheimage.Thismeansthatifthereare

suddenchangesinthelighting,motiondetectionmaytriggermistakenly.Lowerthesensitivity

settingtoavoidproblemswithluminance.

AXISQ7411VideoEncoder

Troubleshooting

Noaudio

Incorrectsetup

Checkthesoundcardinthecomputer.Ensurethatmuteisnotselectedandthatthevolume

settingsarecorrect.

Noaudioorverypooraudio

quality

CheckthatEnableaudiosupportisselectedunderSetup>SystemOptions>Security>Audio

Support.

CheckthatthecorrectAudioInputsourceisselectedunderSetup>Video&Audio>Audio

Settings.

Pooraudioquality

CPUoverloaded

Reducethenumberoflistenersandviewers.Decreaseimageresolutionandcompression.

Unsynchronizedaudioand

video

Synchronizetheproduct’sdateandtimesettingswithanNTPserver.GotoSetup>System

Options>Date&Time.

Distortedaudio

CheckthatthecorrectAudioInputsourceisselectedunderSetup>Video&Audio>Audio

Settings.

FeedbackloopsFeedbackloopsmightappearinfull-duplexmode.Trymovingthemicrophoneorthespeaker,or

usehalf-duplexmodeinstead.

Storageanddiskmanagementproblems

Videocannotberecorded

CheckthattheSDcardisnotwriteprotected(thatis,readonly).

SDcardcannotbemountedReformattheSDcardandthenclickMount.

AXISQ7411VideoEncoder

TechnicalSpecications

Function/group

Item

Specications

Model

AXISQ7411

VideoEncoder

Pan/Tilt/Zoom

WiderangeofanalogPTZcamerassupported(driversavailablefordownloadat

www.axis.com)

CompatiblewithCoaxitron®byPelco

100presets/camera,guardtour,PTZcontrolqueue

SupportsWindowscompatiblejoysticks

Video

compression

H.264(MPEG-4Part10/AVC)

BaselineProle(BP)

MainProle(MP)

MotionJPEG

Resolutions

176x120to720x576

FramerateH.264

60/50(NTSC/PAL)fpsinallresolutions

Framerate

MotionJPEG

60/50(NTSC/PAL)fpsinallresolutions

Videostreaming

MultiplestreamsinH.264andMotionJPEG.H.264andMotionJPEG:1streamin

resolutionandframerateasspeciedabove.Morestreamsifidenticalorlimitedin

framerateorresolution

Controllableframerateandbandwidth

VBR/CBRH.264

Video

Imagesettings

Compression,color,brightness,contrast

Rotation:90°,180°,270°

Aspectratiocorrection

Mirroringofimages

Textandimageoverlay

Privacymask

Enhanceddeinterlacelter

Videotermination

Anti-aliasing

Temporalnoiseltering

AudiostreamingTwo-way,fullduplexandhalfduplex

Audio

compression

In:

AAC-LC8or16kHz8-64kbit/s

G.711µ-lawPCM8kHz64kbit/s

G.726ADPCM8kHz32kbit/sor24kbit/s

Out:

G.711µ-lawPCM8kHz64kbit/s

µ-lawPCM16kHz128kbit/s

G.726ADPCM8kHz32kbit/sor24kbit/s

Audio

input/output

Externalmicrophoneorlineinputandlineoutput.

SecurityPasswordprotection,IPaddressltering,HTTPSencryption,IEEE802.1Xnetworkaccess

control,digestauthentication,useraccesslog

Network

Supported

protocols

IPv4/v6,HTTP,HTTPS,QoSlayer3DiffServ,FTP,CIFS/SMB,SMTP,Bonjour,UPnP™,

SNMPv1/v2c/v3(MIB-II),DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,

DHCP,ARP,SOCKS

AXISQ7411VideoEncoder

TechnicalSpecications

Function/group

Item

Specications

Application

Programming

Interface

OpenAPIforsoftwareintegration,includingtheONVIFspecicationavailableat

www.onvif.org,aswellasVAPIX®andAXISCameraApplicationPlatformfromAxis

Communications,specicationsavailableatwww.axis.com

Eventtriggerdatainvideostream

QualityofService(QoS)layer3,DiffServModel

EmbeddedLinuxoperatingsystem

SupportforAXISVideoHostingSystem(AVHS)withOne-ClickCameraconnection

IntelligentvideoVideomotiondetection

Activetamperingalarm

EventtriggersIntelligentvideo

Externalinputs

Videoloss

Audiodetection

EventactionsFileupload:FTP,HTTPnetworkshareandemail

Notication:email,HTTPandTCP

PTZpreset

Externaloutputactivation

Playaudioclip

Videoandaudiorecordingotedgestorage

Pre-andpost-alarmvideobuffering

StatusLED

Videoaccessfrom

webbrowser

Cameraliveview

Videorecordingtole(ASF)

Windows7,Vista,XP,2000,2003server

DirectX9corhigher

Forotheroperatingsystemsandbrowersseewww.axis.com/techsup

System

Integration

Installation,

managementand

maintenance

AXISCameraManagementtoolonCDandweb-basedconguration

FirmwareupgradesoverHTTPorFTP,rmwareavailableatwww.axis.com

CasingCastaluminum

Memory256MBRAM,128MBFlash

Batterybacked-upreal-timeclock

Power

8-28VDC,max5.3W

PoweroverEthernetIEEE802.3afClass2

ConnectorsAnalogcompositevideoBNCinput

RJ-4510BASE-T/100BASE-TXPoE

Terminalblockforfourcongurableexternalinputs/outputs

TerminalblockforRS-485/422(fullduplex)

3.5mmjackformicrophoneorlineinput(mono)

3.5mmjackforaudiooutput(mono)

Edgestorage

MicroSD/SDHCmemorycardslot(cardnotincluded)

Supportforrecordingtonetworkshare(network-attachedstorageorleserver)

Operating

conditions

0to60°C(0to50°Cwithincludedpowersupply)(32to140°F,32to122°Fwith

includedpowersupply)

Humidity10–85%RH(non-condensing)

Approvals

EN55022ClassB,EN61000-3-2,EN61000-3-3,EN55024,EN61000-6-1,

EN61000-6-2,FCCPart15SubpartBITEClassB,ICES-003ClassB,VCCIClassBITE,

C-tickAS/NZSCISPR22

KN22,KN24KCCClassB,IEC/EN/UL60950-1,EN50121–4

Weight

520g(1.1lb)

General

AXISQ7411VideoEncoder

TechnicalSpecications

Function/group

Item

Specications

Included

accessories

InstallationGuide

InstallationandManagementSoftwareCD

Windowsdecoder1-userlicense

Powersupply,

mountingandconnectorkits

Video

management

software

AXISCameraCompanion(incl.),AXISCameraStationandvideomanagementsoftware

fromAxis’ApplicationDevelopmentPartners(notincl.).Formoreinformation,see

www.axis.com/products/video/software

Optional

accessories

AXIST8006PS12(enablesoperationat60°C)

Dimensions

(HxWxD)

37x109x172mm

Connectors

I/Oterminalconnector

6–pinterminalblockfor:

•DigitalInput

•DigitalOutput

•Auxiliarypowerandground(GND)

1 2 3 4 5 6

FunctionPinNotes

Specications

GND

Ground

3.3VDCPower

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

Maxload=250mA

Digitalinput—ConnecttoGNDtoactivate,orleaveoating

(unconnected)todeactivate.

0to+40VDC Congurable

(InputorOutput)

3–6

Digitaloutput—Internalconnectiontogroundwhen

activated,oating(unconnected)whendeactivated.If

usedwithaninductiveload,e.g.arelay,adiodemustbe

Maxload=100mA

Maxvoltage=+40VDC

AXISQ7411VideoEncoder

TechnicalSpecications

connectedinparallelwiththeload,forprotectionagainst

voltagetransients.

3.3 V max 250 mA

I/Oconguredasinput

I/Oconguredasoutput

Powerconnector

DCpowerinput

2-pinterminalblockforpowerinput.

Audioconnector

3.5mmaudioconnectors

(stereo)

123

AudioInput

AudioOutput

1Tip

Microphone/Linein

2Ring

Lineout(mono)

3SleeveGroundGround

AXISQ7411VideoEncoder

TechnicalSpecications

RS-485/422connector

Two2-pinterminalblocksforRS-485/RS-422serialinterface.Theserial

portcanbeconguredtosupport:

•Two-wireRS-485halfduplex

•Four-wireRS-485fullduplex

•Two-wireRS-422simplex

•Four-wireRS-422fullduplexpointtopointcommunication

RX/TX TX

1 2 3 4

FunctionPinNotes

RS-485/RS-422RX/TXA

RS-485/RS-422RX/TXB

(RX)ForfullduplexRS-485/RS-422

(RX/TX)ForhalfduplexRS-485

RS-485/RS-422TXA

RS-485/RS-422TXB

(TX)ForfullduplexRS-485/RS-422

PerformanceConsiderations

Whensettingsupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationswillaffectperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thiswillalsoaffecttheframerate.

Thefollowingfactorsareamongthemostimportanttoconsider:

•Highimageresolutionand/orlowercompressionlevelsresultinimagescontainingmoredata.Bandwidthaffected.

•AccessbylargenumbersofMotionJPEGand/orunicastH.264clients.Bandwidthaffected.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclients.Effectonframerateand

bandwidth.

•AccessingMotionJPEGandH.264videostreamssimultaneously.Framerateandbandwidthaffected.

•Heavyusageofeventsettingsaffecttheproduct’sCPUload.Framerateaffected.

•Heavynetworkutilizationduetopoorinfrastructure.Bandwidthaffected.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformance.Framerateaffected.

UserManualVer.M1.15

AXISQ7411VideoEncoderDate:September2012

PartNo.48259

Axis 0518-002-EOL Q7411 Video Encoder 0518-002

Product's Documents

Axis Q7411 User Manual

Specifications

Axis 0518-002-EOL Questions and Answers
