For your safety, please read the manual before using the machine.
USER
MANUAL
Hot Dog Griller Machine
08
CLEANING & MAINTENANCE
Cleaning steps:
For your safety, please read the instructions before using the machine.
WARNING
1. DO NOT touch the hot surface to avoid burns.
2. DO NOT immerse product and cable into water to avoid electric shock.
3.MUST beware all age under 18 or area which near children when using the
product.
4. UNPLUG the product and let it to cool down before cleaning or after using.
5. ONLY find the nearby authorized service agency for inspection, repair and
adjustment when the appliance,cable or the cord being damaged.
6. NEVER use not from the manufactured electrical appliance to avoid injury.
7. NEVER for outdoor using.
8. DO NOT hang the wires on table edges or any hot surface.
9. DO NOT operate or place the product near hot gas or electic stoves.
10. MUST becareful when moving the machine that contain hot oil to avoid burns.
11. MUST turn off all control or functions keys before uplug the product.
12.NEVER use the product for other purposes.
13KEEP and SAVE the instruction properly.
01
1. Press the power button to "O" and don't reset the rotary knob. After natural cooling,
cover the roller surface with a wet cloth and clean the machine after the adhesive softens.
2. With a soft cloth well soaked, gently wipe each roller until it is completely clean.
Wipe direction must be from the end to the middle to remove adhesive from the roller,
and avoid machine breakdown caused by adhesive's falling into bearing.
3. After the roller is wiped clean,please tum off the power,unplug the plug,take out the
chassis,scrub with hot soapy water or deergent, rinse with water chassis,
and add the chassis.
4. Wipe the rest of the machine thoroughly with a damp, hot soft cloth until it is
completely clean.
Clean attention:
a. The placement site should have no direct sunlight, no dust, and have
good ventilation.
b. We paint unstick coat on the roller surface, so just use the wooden scoop or
cloth when cleaning, in case of the unstick coat break away from the
roller surface.
c. Please don't clean the roller with water, it may damage the machine.
06
INSTALLATION
03
a. Add a little edible plant oil on both end of the moving roller before using, and this
is to make sure that the rollers can move steady.
b.Tum on the power switch.
c.There are two switches on the front-panelof the machine, and they control
two-group rollers, the left rotary knob controls the front rollers, and the right rotary
knob controls the back rollers. so the user can turn on one switches or two accord-
ing to the need and the hot-dag quantity firstly, adjust the temperature to a suitable
centigrade secondly, the the heating indicator light is on, it will be out when the
temperature reaches the setted one.if the temperature become lower after some
time using, the heating indicator light will be on again,then startheating again.It
works circularly, this can save energy, on the other hand, it will ensure the hot dog
quality cooking.
d.Temperature setting suggestion:
122-212 ℉ : Used for heat preservation.
212-392 ℉ : Normal heating temperature range.
248-320℉ : The best heating range, usually takes 10-15 minutes to heat.
450-482℉ : Heating quickly, it is necessary to check the heating
condition frequently to prevent burning.
e.Turn off the power switch after using.
STEP 1
Use a screwdriver to unscrew the screws in the ①-④
holes of the sausage machine.
As shown in the picture, fully
tighten the screws.
Put the trapezoidal glass &
slope upwar. Align the gasket
hole 1. B hole align with the
right-angle gasket hole 3.
Insert the flat angle screw
through the gasket into the
hole a, and screw on the nut,
tighten it.
Align the wide holes with 2
pieces of silver spacers holes
①&② to screw in the previous
step.
Tighten the screws as shown
in the picture.
Align the wide holes with 2
pieces of silver spacers holes
③&④ to screw in the previous
step
STEP 2
STEP 5 STEP 6
STEP 7
STEP 3
STEP 4
NOTE
Set according to the actual usage temperature.
INSTALLATION
04 05
FUNCTION FEATURES
PARAMETER
Type
with 5 rollers 110V/60HZ
110V/60HZ
110V/60HZ
0.7 5
580X255X170
580X330X170
580X480X170
7
11
32 °F-482 °F
32 °F-482 °F
32 °F-482 °F
0.9
1.4
with 7 rollers
with 11 rollers
voltts
(V)
Power
(KW)
Temperature
scope
Roller
quantity
Out packing
(mm)
Insert the flat-angle screw
through the right-angle
washer into hole b, screw on
the nut, and tighten.
After complete,use the same
method to the other glass and
repeat steps 6 to 8.
Place the two stainless steel
horizontal strips at right angles
backwards as shown in the
figure, aligning with hole d.
Insert the flat-angle screw
through the stainless steel
bar into the hole d, screw on
the nut, and tighten it.
Insert the flat-angle screw
through the other end of the
stainless steel bar into the hole
c, screw and tight it on the nut.
The installation method of the
stainless steel bar on the other
side, repeat steps 10 to 12.
Place the two stainless steel
horizontal strips at the right
angles backwards aligning
with hole d.
Insert the flat-angle screw
through the stainless steel bar
into the hole d, screw and tight
it on the nut.
Installation Complete
STEP 8
STEP 11
STEP 14 STEP 15 STEP 16
STEP 12 STEP 13
STEP 9 STEP 10
INSTALLATION
04 05
FUNCTION FEATURES
PARAMETER
Type
with 5 rollers 110V/60HZ
110V/60HZ
110V/60HZ
0.7 5
580X255X170
580X330X170
580X480X170
7
11
32 °F-482 °F
32 °F-482 °F
32 °F-482 °F
0.9
1.4
with 7 rollers
with 11 rollers
voltts
(V)
Power
(KW)
Temperature
scope
Roller
quantity
Out packing
(mm)
Insert the flat-angle screw
through the right-angle
washer into hole b, screw on
the nut, and tighten.
After complete,use the same
method to the other glass and
repeat steps 6 to 8.
Place the two stainless steel
horizontal strips at right angles
backwards as shown in the
figure, aligning with hole d.
Insert the flat-angle screw
through the stainless steel
bar into the hole d, screw on
the nut, and tighten it.
Insert the flat-angle screw
through the other end of the
stainless steel bar into the hole
c, screw and tight it on the nut.
The installation method of the
stainless steel bar on the other
side, repeat steps 10 to 12.
Place the two stainless steel
horizontal strips at the right
angles backwards aligning
with hole d.
Insert the flat-angle screw
through the stainless steel bar
into the hole d, screw and tight
it on the nut.
Installation Complete
STEP 8
STEP 11
STEP 14 STEP 15 STEP 16
STEP 12 STEP 13
STEP 9 STEP 10
06
INSTALLATION
03
a. Add a little edible plant oil on both end of the moving roller before using, and this
is to make sure that the rollers can move steady.
b.Tum on the power switch.
c.There are two switches on the front-panelof the machine, and they control
two-group rollers, the left rotary knob controls the front rollers, and the right rotary
knob controls the back rollers. so the user can turn on one switches or two accord-
ing to the need and the hot-dag quantity firstly, adjust the temperature to a suitable
centigrade secondly, the the heating indicator light is on, it will be out when the
temperature reaches the setted one.if the temperature become lower after some
time using, the heating indicator light will be on again,then startheating again.It
works circularly, this can save energy, on the other hand, it will ensure the hot dog
quality cooking.
d.Temperature setting suggestion:
122-212 ℉ : Used for heat preservation.
212-392 ℉ : Normal heating temperature range.
248-320℉ : The best heating range, usually takes 10-15 minutes to heat.
450-482℉ : Heating quickly, it is necessary to check the heating
condition frequently to prevent burning.
e.Turn off the power switch after using.
STEP 1
Use a screwdriver to unscrew the screws in the ①-④
holes of the sausage machine.
As shown in the picture, fully
tighten the screws.
Put the trapezoidal glass &
slope upwar. Align the gasket
hole 1. B hole align with the
right-angle gasket hole 3.
Insert the flat angle screw
through the gasket into the
hole a, and screw on the nut,
tighten it.
Align the wide holes with 2
pieces of silver spacers holes
①&② to screw in the previous
step.
Tighten the screws as shown
in the picture.
Align the wide holes with 2
pieces of silver spacers holes
③&④ to screw in the previous
step
STEP 2
STEP 5 STEP 6
STEP 7
STEP 3
STEP 4
NOTE
Set according to the actual usage temperature.
07
TROUBLESHOOTING
Different heating
effects in the roller
Hot dogs heated
unevenly
Actual tempera-
ture is different
from the set
temperature
The stick stops
rolling
3 roaster smokes
Hot dogs may be affected
by the environment. Windy
environment takes away
heat, resulting in uneven
heating.
Internal chain fracture
The roller is not stuck in
the chain
Put the frozen food in
the heated machine.
It's normal to use the
machine for the first
time and bake sausage
at room temperature,
with smoke.
We recommend using a
glass cover (for covered
models) to reduce heat
dissipation and preheat the
hot dog for 3-5 minutes
before putting it on the roller.
If the chain is broken, please
contact us for replacement. If
the chain is not stuck on the
drum, clamp the chain on the
drum. (as picture)
Please open the side panel to
check the inside (if the front
roller is broken, please open
the left panel. If the rear roller
is broken, please open the
right panel).
Brush a layer of oil on it
before use, and preheat the
machine to the baking
temperature for 3-5
minutes.
It is recommended that the
frozen sausage be left at
room temperature for 10-15
minutes before putting it on
the machine.
Lower the temperature
Brush some oil on the
machine with a brush
INSTALLATION
02
Kit Details
Flat shims*2
Right-angle spacers*2
Horizontal strip with folded corners*2
Screws*N
Trapezoidal glass on the side*2
Small rectangular glass back panel*2
Large rectangular glass back panel*2
Issue Name
Reason Solution
1
2
3
4
5
6
7
1
5
6
7
2
3
4
08
CLEANING & MAINTENANCE
Cleaning steps:
For your safety, please read the instructions before using the machine.
WARNING
1. DO NOT touch the hot surface to avoid burns.
2. DO NOT immerse product and cable into water to avoid electric shock.
3.MUST beware all age under 18 or area which near children when using the
product.
4. UNPLUG the product and let it to cool down before cleaning or after using.
5. ONLY find the nearby authorized service agency for inspection, repair and
adjustment when the appliance,cable or the cord being damaged.
6. NEVER use not from the manufactured electrical appliance to avoid injury.
7. NEVER for outdoor using.
8. DO NOT hang the wires on table edges or any hot surface.
9. DO NOT operate or place the product near hot gas or electic stoves.
10. MUST becareful when moving the machine that contain hot oil to avoid burns.
11. MUST turn off all control or functions keys before uplug the product.
12.NEVER use the product for other purposes.
13KEEP and SAVE the instruction properly.
01
1. Press the power button to "O" and don't reset the rotary knob. After natural cooling,
cover the roller surface with a wet cloth and clean the machine after the adhesive softens.
2. With a soft cloth well soaked, gently wipe each roller until it is completely clean.
Wipe direction must be from the end to the middle to remove adhesive from the roller,
and avoid machine breakdown caused by adhesive's falling into bearing.
3. After the roller is wiped clean,please tum off the power,unplug the plug,take out the
chassis,scrub with hot soapy water or deergent, rinse with water chassis,
and add the chassis.
4. Wipe the rest of the machine thoroughly with a damp, hot soft cloth until it is
completely clean.
Clean attention:
a. The placement site should have no direct sunlight, no dust, and have
good ventilation.
b. We paint unstick coat on the roller surface, so just use the wooden scoop or
cloth when cleaning, in case of the unstick coat break away from the
roller surface.
c. Please don't clean the roller with water, it may damage the machine.
For your safety, please read the manual before using the machine.
USER
MANUAL
Hot Dog Griller Machine
