BAUMR-AG SAWMCTBM4CBA Metal Cut Off Saw 2400W User Manual

User Manual

[Revision 1.0]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY

VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,

assembly, inclusions, specifications, description, and packaging.

CS-400 Cut Off Saw

E&OE © Baumr-AG 2

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases, or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

•

Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

•

Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol, or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory, or

mental capabilities.

General Fuel Safety

•

Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well-ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start, or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

•

Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors, and

vents.

General Equipment Use and Care

•

The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage, or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases, or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids, or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 3

General Electrical Safety

•

Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

•

Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

•

The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories, or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service-related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

Child Choking Hazard!

• W

ARNING: CHOKING HAZARD - CHILDREN UNDER 8 YRS. CAN CHOKE OR SUFFOCATE ON SMALL PARTS. ADULT

SUPERVISION REQUIRED.

• Carefully inspect anything a baby or child could gain access to, including this product & packaging.

• Dangers include anything of a size that could become stuck or lodged in a baby or child's airway.

• Dangers include things like raw, hard fruit and vegetable pieces, large pieces of meat, bones or sausage skins, popcorn, nuts,

hard lollies and corn chips, small magnets and batteries, coins, beads, marbles and small uninflated balloons, broken toys and smaller toys,

buttons, keys, and coins. But there are also many more.

• Pay particular attention to accessories, nuts, bolts, screws, washers, caps, covers, loose parts, parts that could be removed or break off, pieces

of packaging, staples, tape etc.

• In the case of any doubt, secure the item of concern in an appropriate manner, or completely remove the possibility of access by a baby or child.

Cut Off Saw Safety

• W

ARNING! WHEN USING MAINS POWERED TOOLS, BASIC SAFETY PRECAUTIONS, INCLUDING THE FOLLOWING, SHOULD ALWAYS

BE FOLLOWED TO REDUCE THE RISK OF THE FIRE, ELECTRIC SHOCK, PERSONAL INJURY, AND MATERIAL DAMAGE.

• Read all of this manual carefully before operating the tool.

• Before operating the tool, make sure that you know how to switch the tool off in emergency.

• Retain this manual for future preference.

Work Area Safety

•

Keep work area clean and well lit. Cluttered or dark areas invite accidents.

• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

• Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical Safety

•

Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed(grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock.

• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges, and refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

• Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

• Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the power tool. Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords increase the risk of electric shock.

• When operating a power tool outdoors, use an extension cord suitable for outdoor sue. Use of a cord suitable for outdoor use reduces the risk of

electric shock.

• If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.

Personal Safety

•

Be alert, pay attention to the operation and keep awake while operating the power tool. Do not operate a power tool when you feel tired or have a

drug, alcohol, or treatment response. Instant negligence in operating a power tool can result in serious personal injury.

• Use personal protective devices. Always wear protective goggles. Protective devices, such as dust mask, anti-skid safety shoes, safety helmet,

and hearing protection devices under appropriate conditions, can reduce personal injury.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 4

• Prevent accidental start. Make sure the switch is in the off position before connecting the power and / or battery pack, picking up or handling

tools. Carry your finger on the switch or power up when the switch may turn on.

• Remove all the adjustment keys or wrenches before the power tool is connected. A wrench or key left on the rotating part of the power tool can

cause personal injury.

• Don't stretch your hands too much. Always pay attention to the foothold and the body balance. This gives better control of the power tools in

unexpected situations.

• Dress appropriately. Do not wear loose clothes or accessories. Keep your hair and clothes away from the moving parts. Loose clothing,

accessories, or long hair may be involved in moving parts.

• If a device is provided to connect with the dust removal and dust collection equipment, ensure that the connection is intact and is properly used.

The use of dust collecting device can reduce the risk caused by dust.

• Don't ignore the safety standards of the tools. A certain careless action may cause serious injury in an instant.

Power Tool Use and Care

•

Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for

which it wats designed.

• Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must

be repaired.

• Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or

storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the

power tool. Power tools are dangerous in the hands of untrained users. Maintain power tools. Check for misalignment or binding of moving parts,

breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many

accidents are caused by poorly maintained power tools.

• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

• Use the power tool, accessories, and tool bits etc. In accordance with these instructions, considering the working conditions and the work to be

performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

Service

•

Have you power tools serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power

tool is maintained.

Safety Rules for Cut-Off Machine

•

Use only the voltage shown on the nameplate to supply power. Using a voltage higher than shown will increase the rotation speed abnormally

and can cause injuries.

• Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. Contact

with a live wire will make exposed metal parts of the tool live and shock the operator. If cutting into existing walls or other blind areas where

electrical wiring may exist is unavoidable. Disconnect all fuses or circuit, breakers feeding this worksite.

• Always make sure the work surface is free from nails& other foreign objects, cutting into a nail can cause the bit and the tool to jump and damage

the bit. Never hold the work piece in one hand and the tool in the other hand when in use. Never place hands near or below cutting surface.

Clamping the material and guiding the tool with both hands is safer.

• Remove this unit a safe distance away from electrical conductors when cleaning sections carrying electrical power such as the electrical panel.

• Do not sue in locations where inflammable materials such as lacquer, paint, benzene, thinner or gasoline are present. Also do not let items such

as lighted cigarette butts be suctioned inside at such locations. Explosion or fires might result.

• Do not use in environments subject to heavy doses of chemicals, etc. Plastic sections such as the vanes on the inner section of the unit might

weaken and break, and injuries might occur.

• If you notice the unit is operating poorly or making abnormal noises, immediately stop using and shut off the power switch. Request an inspection

and repair from the dealer where you purchased the unit. Continuing to use while operating abnormally might cause injuries.

• If the unit is mistakenly dropped or strikes another object, make a thorough check of the unit for cracks, breakage, or deformation, etc. Injuries

might occur if the unit has cracks, breakage, or deformation.

• Do not use near objects generating high heat such as stoves. Fires might occur if used near such locations.

• Do not leave on locations such as benches or floors while still rotating. Injuries might occur.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 5

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases, or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases, or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing, and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 6

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp, or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

Choking Hazard

Children under 8 yrs. Can choke

or suffocate on small parts. Adult

supervision required.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 7

Table of Contents

Safety ............................................................................................................................................................. 2

Safety Symbols ........................................................................................................................................................... 5

Parts Identification ....................................................................................................................................... 8

Assembly and Operation ........................................................................................................................... 11

Install and Remove the Cutting Sheet ...................................................................................................................... 11

Machine Lock ............................................................................................................................................................ 11

Handle Installation .................................................................................................................................................... 12

Securing a Workpiece............................................................................................................................................... 12

Adjusting the Cutting Angle ...................................................................................................................................... 13

Turning ON/OFF ....................................................................................................................................................... 13

Effective and Safe Cutting Method ........................................................................................................................... 13

Maintenance ................................................................................................................................................ 14

Specifications ............................................................................................................................................. 15

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 8

Parts Identification

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 9

PART.NO DESCRIPTION QUANTITY UNIT

1 HEX.BOLT 8*30 MS 4 PCS

2 MOTOR 1 PCS

3 MOTOR BASE 1 PCS

4 CONNECTED SHAFT 1 PCS

5 SHAFT 1 PCS

6 BEARING 205 1 PCS

7 GRINDING WHEEL COVER 1 PCS

8 GRNDING WHEEL COVER SWITCH 1 PCS

9 INNER FLANGE 1 PCS

10 BLADE 1 PCS

11 OUTER FLANGE 1 PCS

12 HEX.NUT 10*25 1 PCS

13 PIN SHAFT 1 PCS

14 HEX.NUT 10*25 3 PCS

15 CONNECTED PLATE 1 PCS

16 DUSTCOVER 1 SET

17 HEX.NUT 6*8 2 PCS

18 BOLT 6*8 1 PCS

19 WHEEL PIN 1 PCS

20 WHEELS 4 PCS

21 BASE 1 SET

22 FIXED GUIDE 1 PCS

23 MOVED GUIDE 1 PCS

24 HANDLE WHEEL 1 PCS

25 VISE SCREW 1 PCS

26 VISE SCREW COVER 1 PCS

27 SPRING 1 PCS

28 HEX.BOLT 8*10 1 SET

29 VISE PLATE 1 PCS

30 HANDLE 1 PCS

31 HEX.NUT 10*25 2 PCS

32 SWITCH 1 PCS

33 BEARING 205 1 PCS

34 BEARING CAP 1 PCS

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

E&OE © Baumr-AG 10

PART.NO DESCRIPTION QUANTITY UNIT

35 HEX.NUT 6*12 4 PCS

36 V-PULLEY Ø 100*24 1 PCS

37 BELT 2 PCS

38 BELT COVER 1 PCS

39 HEX.NUT 6*8 2 PCS

40 HEX.BOLT 8*10 2 PCS

41 BELT COVER PLATE 1 PCS

42 BELT WHEEL Ø 80*24 1 PCS

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

Assembly and Operation

Install and Remove the Cutting Sheet

Remember: before replacing the cutter sheet, be sure to use the power supply

1. Pull out the plug.

2. Installation: First, loosen the butterfly knob of the small shield, pull the small shield up to expose the flange

plate and screw, press the lock knob in the direction of the cutting plate, release the screw on the flange

plate, remove the cutting plate pressure plate, and then install the cutting plate on the platform of the inner

pressure plate, and then install the cutting plate, flange plate and screw.

3. The screw must be tightened, and then pull the small shield to the lower position of the cutting plate and

tighten to secure.

4. Disassembly: according to the above method, you can remove the cutter sheet.

Remember: Make sure that the hexagonal bolts tighten the fixed clip, Otherwise, it will lead to an

accident.

Machine Lock

1. When the tool leaves the factory, it is locked in a lower position to secure the machine during transport. The

locking mechanism should be removed before use. To do this, loosen the bolts at both ends of the iron bar

and remove the iron strip. The machine will then return to its higher position, allowing cutting operations to

begin.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

2. Adjust the position of the cutting blade by adjusting the screw shown in the figure. Loosen the bolt to lower

the position of the cutting blade and tighten it to raise the blade. When cutting larger parts, adjust the

position of the cutting blade to a higher setting.

Handle Installation

1. Loosen the two bolts on the machine handle seat.

2. Install the handle into the handle holder hole, and then tighten the two bolts.

3. Pull the handle firmly to ensure it is securely attached.

Securing a Workpiece

Unscrew the clamping device, place the workpiece on the bottom plate, and then rotate the handle of the

clamping device to secure the workpiece. Ensure that the workpiece is fixed and reliable before commencing

cutting.

Remember: do not secure the workpiece by hand only.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

Adjusting the Cutting Angle

Loosen the screw on the angle plate, adjust the plate to the required angle, and then tighten the screw to secure

the angle plate for the angle cut.

Turning ON/OFF

NOTE: Check before plugging into the power outlet.

1. Ensure that the switch is in the OFF position.

2. To start the tool, turn the switch trigger up.

3. To stop the tool, turn the switch trigger down.

Effective and Safe Cutting Method

1. During operation, ensure that the operator’s body does not come into contact with any grounded metal

objects, such as iron pipes or radiators.

2. When cutting, the material must be as thick as the cutting blade. Therefore, the material to be cut must be

positioned to the left or right of the cutter. Start the tool and allow it to reach maximum speed before slowly

operating the handle to make the cut. When the cutting blade contacts the material, gradually apply

downward pressure to cut through.

3. Once cutting is complete, turn off the power supply. Wait until the cutting blade has completely stopped

before returning it to its original highest position. This prevents the blade from inadvertently contacting the

edges of the material and potentially causing dangerous accidents.

4. When cutting the workpiece, if the speed of the cutter drops, reduce the pressure on the operating handle

promptly to adjust the cutting speed.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

Maintenance

ATTENTION: Surface corrosion will occur on metal surfaces over time and the rate of oxidation

depends on factors such as proximity to the ocean and humidity or condensation of water

vapour on metal surfaces. To mitigate this, WD40 can be used to remove surface corrosion then, when

applied periodically, it will prevent rust from forming.

•

Always remove the plug from the power supply before performing maintenance and inspection.

•

Regularly remove dust, oil residue, and other debris from the tool to keep it clean and the blades sharp.

•

Consistently check that the screws of each connecting part are tight and secure.

•

Regularly inspect the insulation layer of the power cord to ensure it is undamaged.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

CS-400 Cut Off Saw

Specifications

Voltage 240V 50Hz

Power 2400W

Plug Standard Australian 10A

Cord Length 210 cm

Blade Type Abrasive Resin Composite (400 x 3 x 25.4mm)

Blade Diameter 400mm, 16 inches

Speed 3800 RPM

Max Cut

Rectangular:



90 degrees: 85 x 110mm



45 degrees: 45 x 75mm

Square:



90 degrees: 75 x 75mm



45 degrees: 75 x 75mm

Round Pipe:



90 degrees: 135mm



45 degrees: 75mm

Angle Steel:



90 degrees: 75 x 75mm



45 degrees: 75 x 75mm

Please Note: Colour of cutting wheel may vary.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business,

or employee, or financially affect the user, business, or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

BAUMR-AG SAWMCTBM4CBA Metal Cut Off Saw 2400W

Product's Documents

Product manual

Specifications

BAUMR-AG SAWMCTBM4CBA Questions and Answers
