2-IN-1 BRAKE FLUID TESTER & TYRE
PRESSURE GAUGE
MODEL NO: VS0276
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. INTRODUCTION
Simple-to-read- trac light system to show moisture levels in the brake
uid. Compatible with DOT 3, DOT 4 and DOT 5.1 brake uid. Digital tyre
pressure gauge with light which can be displayed in bar, psi, kPa and
kg/cm². Pressure range 3-150 PSI (0.2-10.4 bar). Bright LED Display,
ideal for reading the screen in low light conditions. Powered by 2 x LR44
batteries (supplied)
2. OPERATION
2.1. BRAKE FLUID TESTING
2.1.1. Remove the cap from the brake uid probe.
2.1.2. Press the BRAKE FLUID button. The green LED will light.
2.1.3. Place the probes of the tester in brake uid. The LED will indicate the
condition of the uid:
• Green 0% = Good.
• Yellow <2% = OK.
• Red >4% = Bad.
2.1.4. Clean the probes with clean water and dry.
2.2. TYRE PRESSURE TESTING
2.2.1. Press the TYRE PRESSURE button. Press to cycle between desired units
(Bar, PSI, kPA, kg/cm
2
)
2.2.2. Push the pressure gauge onto the tyre valve. Ensure a good seal to
prevent air from escaping.
2.2.3. The pressure will display on the LCD screen.
2.2.4. The tool will automatically power o after 40s. Alternatively hold the TYRE
PRESSURE button.
2.3. CHANGING THE BATTERY (FIG.2)
2.3.1. Remove the battery cover from the back of the tool (g.2.1).
2.3.2. Remove the batteries and replace with an equivalent. Ensure the
batteries are inserted with the correct polarity (g.2.2).
PRESSURE GAUGE
& LED LIGHT
TYRE PRESSURE
BUTTON
BRAKE FLUID
BUTTON
LED LIGHTS
(FOR BRAKE FLUID)
BRAKE FLUID
PROBE
FIG.1
FIG.2
1
2
VS0276 Issue 1 29/02/24
Original Language Version
© Jack Sealey Limited
VS0276 Issue 1 29/02/24
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
