Induction Hob
Instruction Manual / Installation Manual
MODE L:CAID4PG
2 3
5
4
7
6
1
1
1 2 3
5 4
ÿÿ
2. Max. 2100W Zone
3. Max. 1500W Zone
1. Max. 1500W Zone
4. Max. 2100W Zone
5. Glass Plate
6. Control Panel
7. ON/ OFF control
How does the power sharing work?
1. Zone 1 – maximum power level of 2
2. Zone 2 – maximum power level of 3
3. Zone 3 – maximum power level of 4
4. Zone 4 – maximum power level of 5
If you are only using one zone, you will experience
optimal results with the full available power in use.
If you are using 2 zones, the power limiter will activate
and the maximum available power for either zone will
be 7.
If 3 or 4 zones are used, the power limiter will activate,
and the available heat levels will adjust for each active
zone as described below:
Cook with any three or four zones simultaneously and
the maximum available power level will adjust to:
CAID4PG
