2_ Safety information
Safety information
• Before using your new Samsung Refrigerator, please read this manual
thoroughly to ensure that you know how to operate the features and functions
that your new appliance oers safely and eciently.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or those who lack experience
and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances.
• Warnings and Important Safety Instructions in this manual do not cover all
possible conditions and situations that may occur. It is your responsibility to use
common sense, caution, and care when installing, maintaining, and operating
your appliance.
• Because these following operating instructions cover various models, the
characteristics of your refrigerator may dier slightly from those described in this
manual and not all warning signs may be applicable. If you have any questions
or concerns, contact your nearest service center or find help and information
online at www.samsung.com.
• R-600a or R-134a is used as a refrigerant. Check the compressor label on the
rear of the appliance or the rating label inside the fridge to see which refrigerant
is used for your refrigerator. When this product contains flammable gas
(Refrigerant R-600a), contact your local authority in regard to safe disposal of
this product.
• In order to avoid the creation of a flammable gas-air mixture if a leak in the
refrigerating circuit occurs, the size of the room in which the appliance may be
sited depends on the amount of refrigerant used.
NW2-FDR_DA68-01868A-26_EN.indd 2 7/3/2019 4:56:58 PM
Safety information _3
• Never start up an appliance showing any signs of damage. If in doubt, consult
your dealer. The room must be 1 m³ in size for every 8 g of R-600a refrigerant
inside the appliance. The amount of refrigerant in your particular appliance is
shown on the identification plate inside the appliance.
• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When
refrigerant leaks from the pipe, avoid any naked flames and move anything
flammable away from the product and ventilate the room immediately.
- Failing to do so may result in fire or explosion.
• It is hazardous for anyone other than an Authorized Service Person to service
this appliance.
• To avoid contamination of food, please respect the following instructions:
- Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
- Clean regularly surfaces that can come in contact with food and accessible
drainage systems.
- Clean water tanks if they have not been used for 48 h; flush the water
system connected to a water supply if water has not been drawn for 5 days.
- Store raw meat and fish in suitable containers in the refrigerator, so that it is
not in contact with or drip onto other food.
- Two-star frozen-food compartments are suitable for storing pre-frozen food,
storing or making icecream and making ice cubes.
- One-, two- and three-star compartments are not suitable for the freezing of
fresh food
- If the refrigerating appliance is left empty for long periods, switch o,
defrost, clean, dry, and leave the door open to prevent mould developing
within the appliance.
Warning; Risk of re / ammable materials
NW2-FDR_DA68-01868A-26_EN.indd 3 7/3/2019 4:56:59 PM
4_ Safety information
Safety information
Important safety symbols and precautions:
Please follow all safety instructions in this manual. This manual uses the
following safety symbols.
WARNING
Hazards or unsafe practices that may result in severe personal injury,
property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal injury
and/or property damage.
NOTE
Useful information that helps users understand or benefit from the
refrigerator.
These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
NW2-FDR_DA68-01868A-26_EN.indd 4 7/3/2019 4:56:59 PM
Safety information _5
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance, care should be taken to
ensure that no parts of the refrigerating circuit are damaged.
- Refrigerant leaking from the pipe work could ignite or cause an
eye injury. If a leak is detected, avoid any naked flames or potential
sources of ignition and air the room in which the appliance is
standing for several minutes.
- This appliance contains a small amount of isobutane refrigerant
(R-600a), a natural gas with high environmental compatibility that
is, however, also combustible. When transporting and installing
the appliance, care should be taken to ensure that no parts of the
refrigerating circuit are damaged.
• When transporting and installing the refrigerator, do not touch the
water hose on the back side of the refrigerator.
- This may damage the refrigerator and as a result the water
dispenser can not be used.
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place where it may
come in contact with water.
- Deteriorated insulation on electrical parts may cause an electric
shock or fire.
• Do not place this refrigerator in direct sunlight or expose it to the heat
from stoves, room heaters, or other appliances.
NW2-FDR_DA68-01868A-26_EN.indd 5 7/3/2019 4:56:59 PM
6_ Safety information
Safety information
• Do not plug several appliances into the same multiple power strip. The
refrigerator should always be plugged into its own individual electrical
outlet which has a voltage rating that matches the voltage listed on the
refrigerator’s rating plate.
- This provides the best performance and also prevents overloading
of house wiring circuits, which could cause a fire hazard from
overheated wires.
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of fire.
• Do not use a power cord that has cracks or abrasion damage along its
length or at either end.
• Do not bend the power cord excessively or place heavy objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a heavy object
on the power cord, insert the power cord between objects, or push the
power cord into the space behind the appliance.
• When moving the refrigerator, be careful not to roll over or damage the
power cord.
- This may result in an electric shock or fire.
• Never unplug your refrigerator by pulling on the power cord. Always
grip the plug firmly and pull straight out from the outlet.
- Damage to the cord may cause a short-circuit, fire, and/or electric
shock.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Do not install this appliance near a heater or inflammable material.
• Do not install this appliance in a location where gas may leak.
- This may result in an electric shock or fire.
NW2-FDR_DA68-01868A-26_EN.indd 6 7/3/2019 4:57:00 PM
Safety information _7
• This refrigerator must be properly located and installed in accordance
with the instructions in this manual before you use it.
• Connect the power plug in the proper position with the cord hanging
down.
- If you connect the power plug upside down, the wire can get cut o
and cause a fire or electric shock.
• Make sure that the power plug is not crushed or damaged by the back
of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suocation if a child puts the packing
materials on his or her head.
• The appliance must be positioned so that the plug is accessible after
installation.
- Failing to do so may result in an electric shock or fire due to electric
leakage.
• Do not install this appliance in a humid, oily or dusty location, in a
location exposed to direct sunlight and water (rain drops).
- Deteriorated insulation of electrical parts may cause an electric
shock or fire.
• If any dust or water is in the refrigerator, pull out power plug and
contact your Samsung Electronics service center.
- Otherwise there is a risk of fire.
• Do not stand on top of the appliance or place objects (such as laundry,
lighted candles, lighted cigarettes, dishes, chemicals, metal objects,
etc.) on the appliance.
- This may result in an electric shock, fire, problems with the product,
or injury.
• You need to remove all the protective plastic film before you initially
plug the product in.
NW2-FDR_DA68-01868A-26_EN.indd 7 7/3/2019 4:57:00 PM
8_ Safety information
Safety information
• Children should be supervised to ensure that they do not play with the
snap rings used for door adjustment or the water tube clips.
- There is risk of death by suocation if a child swallows a snap ring
or water tube clip. Keep the snap rings and water tube clips out of
children’s reach.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the refrigerator before
attempting to investigate or repair any part of the appliance. Power
leakages can cause severe electric shock.
• Never use gas pipes, telephone lines, or other potential lightning
attractors as an electrical ground.
- You must ground the refrigerator to prevent any power leakages or
electric shocks caused by current leakage from the refrigerator.
- This may result in an electric shock, fire, explosion, or problems
with the product.
• Plug the power plug into the wall socket firmly. Do not use a damaged
power plug, damaged power cord, or loose wall socket.
- This may result in an electric shock or fire.
• If the power cord is damaged, have it replaced immediately by the
manufacturer or one of its service agents.
• The fuse on the refrigerator must be changed by a qualified technician
or service company.
- Failing to do so may result in an electric shock or personal injury.
NW2-FDR_DA68-01868A-26_EN.indd 8 7/3/2019 4:57:00 PM
Safety information _9
Installation cautions
CAUTION
• Allow sucient space around the refrigerator and install it on a flat
surface.
- Keep the ventilation space in the appliance enclosure or mounting
structure clear of obstructions.
• Allow the appliance to stand for 2 hours before loading foods after
installation and turning on.
• We strongly recommend you have a qualified technician or service
company install the refrigerator.
- Failing to do so may result in an electric shock, fire, explosion,
problems with the product, or injury.
• Overload on any one door may fell the refrigerator, causing physical
injury.
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall and cause
personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as chopsticks, etc.)
into the bottom or the back of the refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
• Do not touch the inside walls of the freezer or products stored in the
freezer with wet hands.
- This may cause frostbite.
NW2-FDR_DA68-01868A-26_EN.indd 9 7/3/2019 4:57:00 PM
10_ Safety information
Safety information
• Do not put a container filled with water on the refrigerator.
- If spilled, there is a risk of fire or electric shock.
• Do not keep volatile or flammable objects or substances (benzene,
thinner, propane gas, alcohol, ether, LP gas, and other such products)
in the refrigerator.
- This refrigerator is for storing food only.
- This may result in fire or explosion.
• Children should be supervised to ensure that they do not play with the
appliance.
- Keep fingers out of “pinch point” areas. Clearances between the
doors and cabinet are necessarily small. Be careful when you open
the doors if children are in the area.
• Do not let children hang on the door or door bins. A serious injury may
occur.
• Do not let children go inside the refrigerator. They could become
trapped.
• Do not insert your hands into the bottom area under the appliance.
- Any sharp edges may cause personal injury.
• Do not store pharmaceutical products, scientific materials, or
temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must not be stored
in the refrigerator.
• Do not place or use electrical appliance inside the refrigerator/freezer,
unless they are of a type recommended by the manufacturer.
• If you smell pharmaceutical or smoke, pull out power plug immediately
and contact your Samsung Electronics service center.
• If any dust or water is in Refrigerator, pull out power plug and contact
your Samsung Electronics service center.
- Otherwise there is a risk of fire.
NW2-FDR_DA68-01868A-26_EN.indd 10 7/3/2019 4:57:00 PM
Safety information _11
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the refrigerator is
unattended and do not let children enter inside the refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suocation by entrapment or personal
injury.
• Do not overfill the refrigerator with food.
- When you open the door, an item may fall out and cause personal
injury or material damage.
• Do not spray volatile material such as insecticide onto the surface of
the appliance.
- As well as being harmful to humans, it may also result in an electric
shock, fire, or problems with the product.
• Never put fingers or other objects into the water dispenser hole, ice
chute and ice maker bucket.
- It may cause a personal injury or material damage.
• Do not use or place any substances sensitive to temperature such as
flammable sprays, flammable objects, dry ice, medicine, or chemicals
near or inside of the refrigerator.
• Do not use a hair dryer to dry the inside of the refrigerator. Do not
place a lighted candle in the refrigerator for removing bad odours.
- This may result in an electric shock or fire.
• Fill the water tank, ice tray and water cubes only with potable water
(mineral water or purified water).
- Do not fill the tank with tea, juice or sports drink, this may damage
the refrigerator.
NW2-FDR_DA68-01868A-26_EN.indd 11 7/3/2019 4:57:00 PM
12_ Safety information
Safety information
• Do not stand on top of the appliance or place objects (such as laundry,
lighted candles, lighted cigarettes, dishes, chemicals, metal objects,
etc.) on the appliance. This may result in an electric shock, fire,
problems with the product, or injury. Do not put a container filled with
water on the appliance.
- If spilled, there is a risk of fire or electric shock.
• Do not use mechanical devices or any other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not damage the refrigerant circuit.
• Do not put fridge shelf in upside down. Shelf stopper could not work.
- It may cause a personal injury because of glass shelf drop.
• Keep fingers out of “pinch point” areas. Clearances between the doors
and cabinet are necessarily small. Be careful when you open the doors
if children are in the area.
• If a gas leak is detected, avoid any naked flames or potential sources
of ignition, and air the room in which the appliance is standing for
several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or fire.
• Use only the LED Lamps provided by the manufacturer or its service
agents.
• Bottles should be stored tightly together so that they do not fall out.
• This product is intended only for the storage of food in a domestic
environment.
• Never put fingers or other objects into the water dispenser hole, ice
chute and ice maker bucket.
- It may cause a personal injury or material damage.
NW2-FDR_DA68-01868A-26_EN.indd 12 7/3/2019 4:57:00 PM
Safety information _13
• Do not attempt to repair, disassemble, or modify the refrigerator
yourself.
• Unauthorized modifications can cause safety problems. To reverse
an unauthorized modification, we will charge the full cost of parts and
labor.
• Do not use any fuse (such as cooper, steel wire, etc.) other than a
standard fuse.
• If your refrigerator needs to be repaired or reinstalled, contact your
nearest service center.
- Failing to do so may result in an electric shock, fire, problems with
the product, or injury.
• If the interior or exterior LED lamp has gone out, contact your nearest
service center.
• If the refrigerator emits a burning smell or smoke, unplug the
refrigerator immediately and contact your Samsung Electronics service
center.
- Failing to do so may result in an electric or fire hazards.
• Pull the power plug out of the socket before changing the interior
lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience diculty changing a non-LED light, contact a
Samsung service center.
• If the product is equipped with LED lamps, do not disassemble the
Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
• Plug the power plug into the wall socket firmly.
• Do not use a damaged power plug, damaged power cord or loose wall
socket.
- This may result in an electric shock or fire.
NW2-FDR_DA68-01868A-26_EN.indd 13 7/3/2019 4:57:00 PM
14_ Safety information
Safety information
Usage cautions
CAUTION
• Do not re-freeze frozen foods that have thawed completely. Do not
place carbonated or fizzy drinks in the freezer compartment. Do not
put bottles or glass containers in the freezer.
- When the contents freeze, the glass may break and cause personal
injury.
• Use only the ice maker provided with the refrigerator.
• Have the refrigerator’s water supply connected only to a potable
water supply. To operate the ice maker properly, water pressure of
20 ~ 125 psi (138 ~ 862 kPa) is required. If you will be away from
home for a long period of time (on vacation, for example) and won’t be
using the water or ice dispensers, close the water valve.
- Otherwise, water leakage may occur.
• If you won’t be using the refrigerator for a very long period of time, (3
weeks or more) empty the refrigerator including the ice bucket, unplug
it, close the water valve, wipe excess moisture from the inside walls,
and leave the doors open to prevent odors and mold.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of the
refrigerator as this can obstruct free air circulation in the refrigerator
compartment.
- Wrap food up properly or place it in airtight containers before
putting it into the refrigerator.
- Do not place glass bottles or carbonated beverages into the freezer.
They can freeze and break. Broken beverage containers can cause
injury.
- Please observe maximum storage times and expiration dates of
frozen goods.
NW2-FDR_DA68-01868A-26_EN.indd 14 7/3/2019 4:57:00 PM
Safety information _15
- There is no need to disconnect the refrigerator from the power
supply if you will be away for less than three weeks. However, if you
will be away for more than three weeks, remove all the food and
ice in the ice bucket, unplug the refrigerator, close the water valve,
wipe excess moisture from the inside walls, and leave the doors
open to prevent odors and mold.
• Do not place glass or bottles or carbonated beverages into the freezer.
- The container may freeze and break, and this may result in injury.
• Do not place carbonated or fizzy drinks in the freezer compartment. Do
not put bottles or glass containers in the freezer.
- When the contents freeze, the glass may break and cause personal
injury and property damage.
• Service Warranty and Modification.
- Any changes or modifications performed by a 3rd party on this
finished appliance are not covered under Samsung warranty
service, nor is Samsung responsible for safety issues that result
from 3rd party modifications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic bag, the
refrigerator can be over cooled. If a cooling period lasts too long,
the water filter may break and cause water leakage.
• Use only the ice-maker provided with the refrigerator.
• Wipe excess moisture from the inside and leave the doors open.
- Otherwise, odor and mold may develop.
• If the refrigerator is disconnected from the power supply, you should
wait for at least five minutes before plugging it back in.
• If you have a long vacation planned or do not intend to use the
refrigerator for a long period of time, (3 weeks or more) empty the
refrigerator including the ice bucket, pull out the power plug, close the
water valve, wipe excess moisture from the inside walls, and leave the
doors open to prevent odors and mold.
NW2-FDR_DA68-01868A-26_EN.indd 15 7/3/2019 4:57:00 PM
16_ Safety information
Safety information
• When the refrigerator got wet by water, pull out the power plug and
contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or property
damage.
• Fill the water tank and ice cube trays with potable water only (tap
water, mineral water, or purified water).
- Do not fill the tank with tea or a sports drink. This may damage the
refrigerator.
• If the refrigerator is flooded, make sure to contact your nearest service
center.
- There is a risk of electric shock or fire.
• Do not keep vegetable oil in your refrigerator’s door bins. The oil can
solidify, making it foul-tasting and dicult to use. In addition, the open
container can leak and the leaked oil can cause the door bin to crack.
After opening an oil container, it is best to keep the container in a cool
and shaded place such as a cupboard or pantry.
- Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc.
NW2-FDR_DA68-01868A-26_EN.indd 16 7/3/2019 4:57:00 PM
Safety information _17
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the refrigerator.
- There is a risk of fire or electric shock.
• Do not use a hair dryer to dry the inside of the refrigerator.
• Do not place a lighted candle in the refrigerator to remove bad odors.
- This may result in an electric shock or fire.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come o.
• If any foreign substance such as water has entered the appliance,
unplug the power plug and contact your nearest service center.
- Failing to do so may result in an electric shock or fire.
• Use a clean, dry cloth to remove any foreign matter or dust from the
power plug blades. Do not use a wet or damp cloth when cleaning the
plug.
- Otherwise, there is a risk of fire or electric shock.
• Do not clean the appliance by spraying water directly onto it.
• Do not use benzene, thinner, or Clorox, Chloride for cleaning.
- They may damage the surface of the appliance and may cause a
fire.
• Before cleaning or performing maintenance, unplug the appliance from
the wall socket.
- Failing to do so may result in an electric shock or fire.
• Use a clean sponge or soft cloth and a mild detergent in warm water to
clean the refrigerator.
NW2-FDR_DA68-01868A-26_EN.indd 17 7/3/2019 4:57:01 PM
18_ Safety information
Safety information
• Do not use abrasive or harsh cleansers such as window sprays,
scouring cleansers, flammable fluids, muriatic acid, cleaning waxes,
concentrated detergents, bleaches, or cleansers containing petroleum
products on exterior surfaces (doors and cabinet), plastic parts, door
and interior liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water when they
are cold. Glass shelves and covers may break if exposed to sudden
temperature changes or impacts such as bumping or dropping.
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product in an
environmentally friendly manner.
• Ensure that none of the pipes on the back of the refrigerator are
damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant. Check the compressor label
on the rear of the appliance or the rating label inside the fridge to see
which refrigerant is used for your refrigerator. If this refrigerator contains
flammable gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/door seals and
door latch so that small children or animals cannot become trapped
inside. Children should be supervised to ensure that they do not play
with the appliance. If trapped inside, a child may get hurt or suocate
to death.
- If trapped inside, the child may become injury and suocate to
death.
NW2-FDR_DA68-01868A-26_EN.indd 18 7/3/2019 4:57:01 PM
Safety information _19
• Cyclopentane is used in the insulation. The gases in the insulation
material require a special disposal procedure. Please contact your
local authorities in regard to the environmentally safe disposal of this
product.
• Keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
- If a child places a bag over his or her head, the child could
suocate.
Additional tips for proper usage
• In the event of a power failure, call the local oce of your electric
company and ask how long the failure is going to last.
- Most power failures that are corrected in an hour or two will not
aect your refrigerator temperatures. However, you should minimize
the number of door openings while the power is o.
- Should the power failure last more than 24 hours, remove and
discard all frozen food.
• The refrigerator might not operate consistently (frozen contents can
thaw or temperatures can become too warm in the frozen food
compartment) if sited for an extended period of time in a location
where ambient air temperatures are constantly below the temperatures
for which the appliance is designed.
• In case of particular foods, keeping it under refrigeration can have a
bad eect on preservation due to its properties.
• Your appliance is frost free, which means there is no need to manually
defrost your appliance. This will be carried out automatically.
• Temperature rise during defrosting complies with ISO requirements. If
you want to prevent an undue rise in the temperature of frozen food
while the appliance defrosts, wrap the frozen food in several layers of
newspaper.
• Do not re-freeze frozen foods that have thawed completely.
NW2-FDR_DA68-01868A-26_EN.indd 19 7/3/2019 4:57:01 PM
20_ Safety information
Safety information
Saving Energy Tips
• Install the appliance in a cool, dry room with adequate ventilation.
Ensure that it is not exposed to direct sunlight and never put it near a
direct source of heat (a radiator, for example).
• Not to block any vents and grilles is recommended for energy
eciency.
• Allow warm food to cool down before placing it in the appliance.
• Put frozen food in the refrigerator to thaw. You can then use the low
temperatures of the frozen products to cool food in the refrigerator.
• Do not keep the door of the refrigerator open for too long when putting
food in or taking food out. The shorter the time the door is open, the
less frost build-up you’ll have in the freezer.
• It is recommended to install the refrigerator with clearance to the back
and sides. This will help reduce power consumption and keep your
energy bills lower.
• For the most ecient use of energy, please keep the all inner fittings
such as baskets, drawers, shelves on the position supplied by
manufacturer.
This appliance is intended to be used in household and similar
applications such as
• sta kitchen areas in shops, oces and other working environments;
• farm houses and by clients in hotels, motels and other residential type
environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
NW2-FDR_DA68-01868A-26_EN.indd 20 7/3/2019 4:57:01 PM
Safety information _21
Instructions about the WEEE
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product
and its electronic accessories (e.g. charger, headset, USB cable) should not be
disposed of with other household waste at the end of their working life. To prevent
possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government oce, for details of where and how they can
take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions
of the purchase contract. This product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product
specific regulatory obligations e.g. REACH, WEEE, Batteries, visit our
sustainability page available via Samsung.com
(For products sold in European countries only)
NW2-FDR_DA68-01868A-26_EN.indd 21 7/3/2019 4:57:01 PM
22_ Contents
ContentsContents
SETTING UP YOUR REFRIGERATOR
23
23 Getting ready to install the refrigerator
24 Installation of the water line (Auto ice maker
model)
25 Using the water filter (Not provided)
26 To use without the water filter section
28 Setting up the refrigerator
28 Removing the refrigerator doors
29 Disassembling the fridge door
30 Disassembling the freezer door (Drawer type)
31 Disassembling the freezer door (Swing type)
32 Reassembling the fridge door
33 Reassembling the freezer door (Drawer type)
33 Reassembling the freezer door (Swing type)
34 How to reverse the door (Option)
37 Adjusting the doors
38 Making minor adjustments between doors
OPERATING YOUR SAMSUNG
REFRIGERATOR
39
39 Parts and features
40 Using the control panel
41 Controlling the temperature
43 Making ice
44 Removing and relocating the fridge
accessories
45 Removing the freezer accessories
46 Using the water dispenser (Option)
48 Cleaning the refrigerator
49 Replacing the interior light
TROUBLESHOOTING
50
50 Troubleshooting
NW2-FDR_DA68-01868A-26_EN.indd 22 7/3/2019 4:57:03 PM
01 SETTING UP
Setting up your refrigerator _23
Setting up your refrigerator
Getting ready to install the refrigerator
Congratulations on your purchase of this Samsung Refrigerator. We hope you enjoy the state-of-art features
and eciencies that this new appliance oers.
Selecting the best location for the refrigerator
• A location with easy access to the water supply.
• A location without direct exposure to sunlight.
• A location with level (or nearly level) flooring.
• A location with enough space for the Refrigerator doors to open
easily.
• Allow sucient space to the right, left, back and top for air
circulation. If the Refrigerator does not have enough space, the
internal cooling system may not work properly.
• Please ensure that appliance can be moved freely in the event of
maintenance & service.
150mm
100mm
100mm
1745mm
1780mm
First thing! Make sure that you can easily move your Refrigerator to its final location by measuring doorways
(both width and height), thresholds, ceilings, stairways, etc.
817mm
RF62* : 1125mm
RF67* : 1175mm
817mm
665mm
1492mm 1492mm
817mm
RF62* : 1172mm
RF67* : 1222mm
RF62* : 1455mm
RF67* : 1505mm
Drawer-Type Swing-Type
NOTE
• Allow clearance to the right, left, back and top when installing. This will help reduce power
consumption and keep your energy bills lower.
• If you install the Refrigerator where is below 10
º
C, it may not function in optimum level.
• Do not locate the refrigerator where the wet condition.
When moving your refrigerator
CAUTION
To prevent floor damage be sure the front leveling legs are in the up
position (above the floor). Refer to ‘Adjusting the doors’ in the manual
(on page 37).
Flat-blade
screwdriver (-)
Control Lever
NW2-FDR_DA68-01868A-26_EN.indd 23 7/3/2019 4:57:04 PM
24_ Setting up your refrigerator
Setting up your refrigerator
Flooring
For proper installation, this refrigerator must be placed on a level
surface of hard material that is the same height as the rest of the
flooring. This surface should be strong enough to support a fully
loaded refrigerator, or approximately 106 kg.
To protect the finish of the flooring, cut a large section of the
cardboard carton and place under the refrigerator where you are
working. When moving the refrigerator, be sure to pull it straight out
and return it to position by pushing it straight in.
Installation of the water line (Auto ice maker model)
Before you install the water line
• The water line installation is not warranted by the refrigerator manufacturer.
So before you install the water line, read the whole steps for installing and follow these instructions
carefully to minimize the risk of expensive water damage.
• Banging pipes (water banging in the pipes) in house plumbing can cause damage to fridge parts
and lead to water leakage or flooding. Call a qualified plumber to correct the problem before
installing the water supply line to the fridge.
• To prevent burns and product damage, do not hook up the water line to the hot water line.
• Do not install the water line in areas where temperatures fall below freezing.
• When using any electrical device (such as a power drill) during installation, be sure the device is
insulated or wired in a manner to prevent electric shock.
• All installations must be in a accordance with local plumbing code requirements.
NOTE
• Water line Kit and water filter are not covered by Samsung’s Warranty. The manufacturer (or dealer,
installer) of them is responsible for any defects and all the loss caused by water filter & water line kit.
• The filter should be replaced according to manufacturer (or dealer)’s instruction.
• To order additional water filters, please contact the manufacturer (or dealer) of the filter.
NOTE
Check the accessories listed below.
Water line fixer and
screws
Pipe connector Water line Fastner
(Refer to ‘Making minor adjustments between
doors’ on page 38.)
NW2-FDR_DA68-01868A-26_EN.indd 24 7/3/2019 4:57:05 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _25
Using the water filter (Not provided)
Connecting to water supply line
• Shut o the main water supply line and turn the Ice maker to the
o position.
• Locate the nearest cold drinking water line.
• Follow the instructions in the water filter installation kit.
• After connecting the water supply line to the Cartridge Holder inlet
and installing the Filter Cartridge (insert plastic line in fully).
• Turn on water supply and flush 3L into a bucket to clear the water
filter.
NOTE
• The water filter must be installed outside the refrigerator.
It is not provided with your new refrigerator. The filter cartridge (8)
and holder (9) kit can be purchased from the retailer where you
purchased this refrigerator.
• Do not use copper line.
• Cut the tubing, making sure the ends are square and clean.
1. Cold Water
line
2. Pipe Clamp.
3. Plastic line
4. Compression
Nut
5. Compression
Sleeve
6. Packing Nut
7. Shut O Valve
8. Filter
Cartridge
9. Cartridge
Holder
90 degree
Incorrect Correct
Connect the water line to the fridge
• Connect the plastic line on the back of your fridge to the
cartridge holder outlet (fully insert the plastic line to the
cartridge holder outlet).
• Insert plastic clip to the cartridge holder inlet and outlet.
• Turn water on and check for any leakage.
NOTE
• You can purchase the necessary filter cartridge at the
retailer where you purchased this refrigerator. Make sure you
buy the SAMSUNG filter cartridge (Replacement cartridge
No : DA29-10105J) to ensure the best performance.
• Water line must be connected to drinkable water only
• A compression fitting and nut kit is supplied with the unit
and it is inside the fridge drawer.
• When pushing the Refrigerator back, make sure you don’t
roll over the power cord or water line (Icemaker supply line).
Cartridge Holder
Clip
Filter cartridge
Plastic line (Provided)
NW2-FDR_DA68-01868A-26_EN.indd 25 7/3/2019 4:57:07 PM
26_ Setting up your refrigerator
Setting up your refrigerator
To use without the water filter section
Connecting to the water supply line
• Shut o the main water supply line and turn the Ice maker to the
o position.
• Locate the nearest cold water drinking line.
1. Cold Water
line
2. Pipe Clamp.
3. Plastic line
4. Compression
Nut
5. Compression
Sleeve
6. Packing Nut.
7. Shut O Valve
The water line must be connected
to the cold water pipe. If it is
connected to the hot water
pipe, it may cause the purifier to
malfunction.
CAUTION
1. First, shut o the main water supply line.
2. Locate the nearest cold, drinking water line.
3. Follow the Water line Installation Instructions in the installation kit.
Close Main
Water pipe
No gap
Close Main
Water pipe
NW2-FDR_DA68-01868A-26_EN.indd 26 7/3/2019 4:57:07 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _27
Connecting the water line to the refrigerator
1. Remove the cap from water line on the unit and insert compression nut to the water line on the unit
after disassembling from provided water line.
2. Connect both water line from the unit and water line in the kit.
3. Tighten the compression nut onto the compression fitting.
There should be no gaps between (A, B & C )
4. Turn water on and check for any leakage.
Loosen a
Remove
cap
Water Line
from unit
Water Line
from unit
No gap
NOTE
Only connect the water line to a drinkable water source.
If you have to repair or disassemble the water line, cut o 6.5 mm of the plastic tubing to make sure
you get a snug, leak-free connection.
CAUTION
After the water supply has been installed check all the joints to ensure there are no leaks.
• Samsung Warranty does not cover THE WATER LINE
INSTALLATION.
• The cost of the water line installation is at the customers expense,
unless the retailer has covered this expense in the delivery charge.
• Please contact a Plumber or Authorized Installer for the installation
if needed.
• If Water leakage occurs due to improper installation, Please
contact installer.
NW2-FDR_DA68-01868A-26_EN.indd 27 7/3/2019 4:57:08 PM
28_ Setting up your refrigerator
Setting up your refrigerator
Setting up the refrigerator
Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features
and functions of the appliance. By completing the following steps, your Refrigerator should be fully
operational.
1. Place the Refrigerator in an appropriate location with reasonable clearance between the wall and
the Refrigerator. Refer to installation instructions in this manual. (P 23. Selecting the best location
for the refrigerator)
2. Once the Refrigerator is plugged in, make sure the interior light comes on when you open the
doors.
3. Set the Temperature control to the coldest temperature and wait for an hour. The Freezer will get
slightly chilled and the motor will run smoothly.
4. After powering the Refrigerator, it will take a few hours to reach the appropriate temperature. You
can store food and drinks in the Refrigerator after the temperature is suciently cool.
Required tools (not provided)
Phillips Head
Driver (+)
Flat Head
Driver (-)
Socket Wrench
(10 mm) (for bolts)
Hex Wrench
(Ø 5 mm)
(for Mid hinge)
Hex wrench
(5/32 inch)
(for Mid hinge shaft)
Removing the refrigerator doors
Some installations require door/drawer removal to transport the Refrigerator to its final location.
Do not remove the door/drawer if it is not needed. Before removing the door/drawer make sure you read
following items.
WARNING
Disconnect power to the Refrigerator before removing the door or drawer.
NOTE
• Be careful not to drop, damage or scratch the door/drawer while removing them.
• Be careful not to get injured while removing the door/drawer.
• Reattach the door/drawer properly to avoid:
- Moisture from air leakage.
- Uneven door alignment.
- Wasting energy due to improper door seal.
NW2-FDR_DA68-01868A-26_EN.indd 28 7/3/2019 4:57:08 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _29
Disassembling the fridge door
WARNING
Be careful not to drop and scratch the fridge door while removing the fridge door!
Top Table
Socket wrench
1. Remove the 3 screws holding
down the top table and
remove it.
2. Disconnect electric wire on
the top of the refrigerator.
3. Remove the 3 hex bolts that
hold the hinge on the top
of the refrigerator with the
10 mm socket wrench.
4. Remove the screw that holds
the ground wire with a philips
screwdriver (+).
5. Separate the hinge from the
electric wire and ground wire
as shown above.
6. Lift the door straight up to
remove. Be careful not to
drop and scratch the doors
while removing them.
NW2-FDR_DA68-01868A-26_EN.indd 29 7/3/2019 4:57:11 PM
30_ Setting up your refrigerator
Setting up your refrigerator
Disassembling the freezer door (Drawer type)
Middle Hinge
1. Separate the Cap on the
Middle Hinge.
2. Remove the screw attached to the left and right middle hinges
with a philips screwdriver (+).
Remove the 2 hex head bolts attached to the left and right
middle hinges with an allen wrench (Ø 5 mm).
3. After opening the Freezer
door, lift the drawer box.
4. Remove 4 hex head bolts
from both sides with a socket
wrench (10 mm).
5. Lift up the freezer door from
the rails. Be careful not to
drop and scratch the freezer
door.
NW2-FDR_DA68-01868A-26_EN.indd 30 7/3/2019 4:57:12 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _31
Disassembling the freezer door (Swing type)
Middle Hinge
1. Separate the Cap on the
Middle Hinge.
2. Remove the screw attached to the left and right middle hinges
with a philips screwdriver (+).
Remove the 2 hex head bolts attached to the left and right middle
hinges with an allen wrench (Ø 5 mm).
Middle Hinge
3. Remove the Middle Hinge
connected to the Freezer.
4. Lift up the freezer door from
the hinge.
Be careful not to drop and
scratch the freezer door.
NW2-FDR_DA68-01868A-26_EN.indd 31 7/3/2019 4:57:14 PM
32_ Setting up your refrigerator
Setting up your refrigerator
Reassembling the fridge door
1. Insert and tighten the
screw into the left and right
middle hinges with a philips
screwdriver (+).
2. Insert and tighten the 2 hex
head bolts into the left and
right middle hinges with an
allen wrench (Ø 5 mm).
3. Replace the middle hinge
cap.
4. Place the hole in the bottom
of the left door over the
middle hinge.
5. Insert the left upper hinge
shaft into the hole on the
corner of the fridge door.
6. Insert the upper hinges into
the holes at the top of the
door.
Insert and tighten the 3 hex
head bolts into the left and
right upper hinges with a
socket wrench (10 mm).
7. Insert and tighten the ground
screw into the left and right
upper hinges with a philips
screwdriver (+).
8. Connect the electronic wire
on the top of the refrigerator.
9. Position the top table in
place. Insert and tighten the 3
screws into the top table with
a philips screwdriver (+).
NW2-FDR_DA68-01868A-26_EN.indd 32 7/3/2019 4:57:17 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _33
Reassembling the freezer door (Drawer type)
Slot
1. Pull out the rails to the full
length on each sidle of the
cabinet evenly.
2. Hang the freezer door front
onto open slot on the sides.
3. With the 10 mm wrench,
reattach 4 bolts to connect
the rail with the door.
4. Replace the drawer box.
Reassembling the freezer door (Swing type)
1. Place the hole in the bottom
of the freezer door over the
right side low hinge.
2. Replace the middle hinge connected to the freezer.
3. Insert and tighten the screw into the left and right middle hinges
with a philips screwdriver (+).
Insert and tighten the 2 hex head bolts into the left and right
middle hinges with an allen wrench (Ø 5 mm).
4. Replace the cap on the middle hinge.
NW2-FDR_DA68-01868A-26_EN.indd 33 7/3/2019 4:57:18 PM
34_ Setting up your refrigerator
Setting up your refrigerator
How to reverse the door (Option)
Unplug the refrigerator or disconnect the power.
1. Remove 3 screws on the
hinge cover.
2. Disassemble the hinge cover.
3. Disassemble 2 connectors. (a
housing and a reed switch)
4. Disassemble ground wire by
removing 1 screw on each
side.
5. Disassemble the upper hinge
by removing 3 bolts on each
side with the 10 mm wrench.
1) Avoid the wire damage.
2) Fridge door is possible to tip
over at this time.
6. Remove each fridge doors by
lifting it up.
1) Possible to drop or scratch
the door at this time.
2) Middle hinge cap may come
o with the door.
7. Disassemble middle hinge
cap.
Cap
Cover
8. Remove 1 screw and 2 bolts
of each side (use Ø 5 mm
allen wrench).
1) At first, Remove left side
middle hinge and right side.
2) Be careful not to drop the
freezer door.
9. Remove the freezer door by
lifting it up.
1) Possible to drop or scratch
the door at this time.
2) Low hinge cap may come o
with the door.
10. Remove 2 screws.
11. Separate front leg Cover.
NW2-FDR_DA68-01868A-26_EN.indd 34 7/3/2019 4:57:19 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _35
Cap
12. Separate the Cap of the front
leg Cover. (pull out inside of
Cap)
13. Insert the Cap on the other
side of the front leg Cover.
14. Remove 2 bolts of each hinge
with the 10 mm wrench.
15. Place them in front of each
side.
16. Separate low hinge shaft
by using 5/32” wrench and
disassemble low hinge leg
by turning it colockwise, and
then assemble the low hinge
by turning it over.
Option
17. Reattach the former right
hinge on the left side and the
former left hinge on the right
side by using 2 bolts.
18. Separate stopper by removing
1 screw on the right lower
side of freezer and assemble
the stopper on the left side by
reversing it.
19. The middle hinge for reversing
the door is in the door bin.
20. Change the middle hinges
assembled on the refrigerator
with the middle hinges in the
door bin.
21. Use the black hinge cap of
the middle hinge assembled
at refrigerator. Then place it at
the bottom of the left middle
hinge supplied separately.
- Use the Flat-blade
screwdriver (-).
NW2-FDR_DA68-01868A-26_EN.indd 35 7/3/2019 4:57:21 PM
36_ Setting up your refrigerator
Setting up your refrigerator
22. Place the hole in the bottom
of the freezer door over the
low hinge.
23. Replace the middle hinge connected to the freezer.
24. Insert and tighten the screw into the left and right middle hinges
with a philips screwdriver (+). Insert and tighten the 2 hex head
bolts into the left and right middle hinges with an allen wrench
(Ø 5 mm).
25. Replace the cap on the middle hinge.
26. Place the hole in the bottom
of the left door over the
middle hinge.
27. Insert the left upper hinge
shaft into the hole on the
corner of the fridge door.
28. Insert the upper hinges into
the holes at the top of the
door.
Insert and tighten the 3 hex
head bolts into the left and
right upper hinges with a
socket wrench (10 mm).
29. Insert and tighten the ground
screw into the left and right
upper hinges with a philips
screwdriver (+).
30. Connect the electronic wire
on the top of the refrigerator.
31. Position the top table in
place. Insert and tighten the
3 screws into the top table
with a philips screwdriver (+).
NW2-FDR_DA68-01868A-26_EN.indd 36 7/3/2019 4:57:22 PM
01 SETTING UP01 SETTING UP
Setting up your refrigerator _37
Adjusting the doors
After putting the doors back on the Refrigerator, make sure the Refrigerator is level so that you can make
final adjustments.
If the Refrigerator is not level, it will not be possible to get the doors perfectly even.
For example, when the left side is lower than the right side, insert a flat-blade screwdriver into a notch on
the left control lever, and turn it clockwise or counter clockwise to level the door.
Turning it clockwise to raise the refrigerator and counterclockwise to lower it.
For the left side is higher, do it with right lever.
WARNING
Both control levers must be surely touching the floor to avoid the possible personal injury or property
damage because of tipping.
Screwdriver (-)
When the left side is lower.
When the left side is higher.
Screwdriver (-)
Control Lever
Control Lever
NW2-FDR_DA68-01868A-26_EN.indd 37 7/3/2019 4:57:22 PM
38_ Setting up your refrigerator
Setting up your refrigerator
Making minor adjustments between doors
Remember, a level Refrigerator is necessary for getting the doors perfectly even. If you need help, review
the previous section on leveling the Refrigerator.
When the left door is
lower than the right
door.
When the left door is
higher than the right
door.
Adjustment part
Adjustment part
1. Pull out the freezer drawer ( 1 ), then you can see the middle hinge ( 2 ).
2. Insert the hex wrench (4 mm) ( 3 ) into the shaft ( 4 ) of the middle hinge.
3. Please adjust the height by turning the hex wrench ( 3 ) clockwise (
) or counter-clockwise
( ).
1
2
3
4
3
NOTE
When you turn the hex wrench counter-clockwise (
), the door will move up.
Only the left-door height is adjustable for Swing-Type.
1. After adjusting the doors, please insert the supplied fastener ( 5 ) using Pliers ( 6 ) in the gap
between the hinge-grommet ( 7 ) and the middle hinge ( 8 ). The number of fasteners you’ll need to
insert depends on the gap.
NOTE
2 fastener are enclosed with the refrigerator. The thickness of each fastener is 1.0 mm.
NW2-FDR_DA68-01868A-26_EN.indd 38 7/3/2019 4:57:24 PM
02 OPERATING
Operating your samsung refrigerator _39
Operating your samsung refrigerator
Parts and features
Use this page to become more familiar with the parts and features of the Refrigerator.
Fridge
Option
1 2 43
Freezer
5
Drawer Type Swing Type
1. Water tank 2. Vegetable & Fruit Drawer 3. Shelf
4. Door bin 5. Freezer drawer bin
NW2-FDR_DA68-01868A-26_EN.indd 39 7/3/2019 4:57:25 PM
40_ Operating your samsung refrigerator
Operating your samsung refrigerator
Using the control panel
1. For auto ice maker model
1 42 53 6
2. For normal ice maker model
1 42 53 6
Temperature & Function select / Control panel
1
Ice On/Of (Option)
When the Ice On/Of button is pressed, ice will not be produced.
Use this function only when it is needed.
1
Alarm Of (Option)
When the Alarm Of button is pressed, alarm will not sound in case of
door open.
Use this button only when it is needed.
2
Power Freeze
Press this button to freeze food quickly.
(Power Freeze will last 72 hours.)
3
Freezer
Freezer temperature set button.
Press this button to set the Freezer temp between -14
º
C and -25
º
C.
(At initial power on, the default setting is -19
º
C.)
4
Fridge
Fridge temperature set button.
Press this button to set the Fridge temperature in 1
º
C intervals
between 7
º
C and 1
º
C.
(At initial power on, the default setting is 3
º
C.)
5
Power Cool
Press this button to cool the food in the fridge quickly.
Power Cool will shut o when -4
º
C is reached or after 2 and a half
hours.
6
E.Saver
Press the E.Saver button for better energy eciency. If water drops
appear on the doors, turn the Energy Saver function o.
NW2-FDR_DA68-01868A-26_EN.indd 40 7/3/2019 4:57:25 PM
02 OPERATING02 OPERATING
Operating your samsung refrigerator _41
Controlling the temperature
Setting the freezer temperature
If you want to control the freezer temperature, follow as below.
Press the Freezer button (Refer the picture)
• The temperature can be set in 1
º
C interval between -25
º
C and -14
º
C.
When selecting the temperature, the set temperature is displayed
initially for 5 seconds, then the actual temperature is displayed.
(There may be slight dierence between the set temperature and
displayed actual temperature, but it will be corrected to the set
temperature automatically.)
NOTE
• The Freezer temperature will change depending on the number of door openings, quantity of food,
ambient temperature, etc.
• The temperature display will blink when freezer temperature increases due to frequent door
opening, keeping warm food, etc.
(Blinking will stop when the refrigerator reaches normal temperature. If for some reason it does not
stop after a long period of time, contact a Samsung service center.)
Setting the fridge temperature
If you want to control the fridge temperature, follow as below.
Press the Fridge button (Refer the picture)
• The temperature can be set in 1
º
C interval between 1
º
C and 7
º
C.
When selecting the fridge temperature, the set temperature is
displayed initially for 5 seconds, then the actual temperature is
displayed.
(There may be slight difference between the set temperature and
displayed actual temperature, but it will be corrected to the set
temperature automatically.)
NW2-FDR_DA68-01868A-26_EN.indd 41 7/3/2019 4:57:26 PM
42_ Operating your samsung refrigerator
Operating your samsung refrigerator
NOTE
• The Fridge temperature will change depending on the number of door openings, quantity of food,
ambient temperature, etc.
• Temperature of each shelve or container in the fridge may be dierent.
• The temperature display will blink when fridge temperature is increases due to frequent door
opening, keeping warm food, etc.
(Blinking will stop when the refrigerator reaches normal temperature. If for some reason it does not
stop after a long period of time, contact a Samsung service center.)
If you want to make ice faster (Controlling the Power Freeze)
Press the Power Freeze button. (Refer to the picture.)
• The power freeze light on the display goes on (see
the arrow mark) and this function begins to operate
regardless of the set freezer temperature.
Press the Power Freeze button again to cancel this
function.
• The light goes o and it operates at the set freezer
temperature again.
• The Power Freeze function operates for 72 hours
regardless of the set temperature.
NOTE
This function must be activated before putting large stu in freezer compartment at least 24 hours
before.
If you want to speed up the cooling in the fridge (Power Cool)
Press the Power Cool button. (Refer to the picture.)
• The power cool light on the display goes on (see
the arrow mark) and this function begins to operate
regardless of the set fridge temperature.
Press the Power Cool button again to cancel this function.
• The light goes o and it operates at the set fridge
temperature again.
NOTE
The Power Cool function operates for 2 and a half hours regardless of the set temperature.
NW2-FDR_DA68-01868A-26_EN.indd 42 7/3/2019 4:57:26 PM
02 OPERATING02 OPERATING
Operating your samsung refrigerator _43
Making ice
Auto ice maker model
The ice maker will produce 8 cubes per cycle - approximately
100~130 cubes in a 24-hour period, depending on freezer
compartment temperature, room temperature, number of door
openings and other use conditions.
Throw away the first few batches of ice to allow the water line to
clear.
Be sure nothing interferes with the sweep of the feeler arm.
When the bin fills to the level of the feeler arm, the icemaker will stop
producing ice.
After the icemaker has been turned on again, there will be a time
delay before the icemaker resumes operation.
It is normal for several cubes to be joined together.
If ice is not used frequently, old ice cubes will become cloudy, taste
stale and shrink.
So if you don’t want to make ice, press the Ice On/Of button.
NOTE
When “Ice making” function is selected, ice-making is priority, Then the temperature of freezer will be
ower than the setting temperature. If you don’t need the “Ice making” function, please press the button
of “Ice On/Of”. Failing to do so may cause noise.
Twist ice maker model
1 2 3 4
1. Pull out the Ice-cube trays.
2. Fill trays up to the water level mark (arrow).
3. Put the Ice-cube trays back in position. And close the freezer door.
4. Once the water has become frozen, turn the dials on the Ice cube trays to empty Ice cubes into the
storage bin.
NW2-FDR_DA68-01868A-26_EN.indd 43 7/3/2019 4:57:27 PM
44_ Operating your samsung refrigerator
Operating your samsung refrigerator
Removing and relocating the fridge accessories
1. Door Bins
To remove - Simply lift the bin up and pull straight out.
To replace - Slide it in above the desired location and push down
until it stops.
CAUTION
Injury may occur if the door bins are not firmly inserted.
Do not allow children to play with bins. Sharp corners of the bins
may cause injury.
NOTE
• Empty the bin before adjusting it.
• Dust removal method -Remove the guard and wash in water.
2. Fridge shelves
To remove - When pulling out the shelf, if it does not slide out
easily, lift it up slightly and pull out again.
To replace - When pushing in the shelf, if it does not slide in
easily, lift it up slightly and push in again.
CAUTION
The Glass shelves are heavy.
Use special care when removing them.
3. Vegetable & Fruit Drawers
To remove - Pull the drawer out to full extension. Tilt up the front
of the drawer and pull straight out.
To replace - Insert the drawer into the frame rails and push back
into place.
NOTE
• The drawers need to be removed before the glass shelf
above them can be lifted out.
• To get the best energy eciency of this product, please leave
all selves, drawers and baskets on their original position like
as illustration in page 39.
1
2
NW2-FDR_DA68-01868A-26_EN.indd 44 7/3/2019 4:57:29 PM
02 OPERATING02 OPERATING
Operating your samsung refrigerator _45
Removing the freezer accessories
1. Pull Out Drawer
To remove - Pull the drawer out to full
extension.
Tilt up rear of drawer and lift
straight out.
(Refer to picture 1 & 2.)
Open the freezer door fully and remove
the drawer.
To replace - Place the drawer onto the
rails by tilting it up. Lower
the drawer into place until
it is horizontal and slide the
drawer in.
(Refer to picture 3.)
1 1
2 2
3 3
2. Freezer Drawer Bin
Swing-Type
To remove - Pull the drawer out fully. Tilt up the rear of the bin and lift it
out to remove.
To replace - Place the bin into the rail assembly.
When replacing, place the drawer bin holder into the hole of the rail.
Drawer-Type
To remove the drawer - Pull the drawer out fully. Tilt up the rear of the
bin and lift it out to remove.
To relocate the drawer - Place the bin into the rail assembly.
1
2
NW2-FDR_DA68-01868A-26_EN.indd 45 7/3/2019 4:57:30 PM
46_ Operating your samsung refrigerator
Operating your samsung refrigerator
CAUTION
Do not allow children to play with the
refrigerator, as they could injure themselves
or damage the refrigerator.
Do not sit on the Freezer door. The door may
break. Do not allow children to climb into the
Freezer basket.
Drawer
(RF67****)
Using the water dispenser (Option)
You can easily obtain chilled water with the water dispenser without opening the refrigerator door. In
addition, you can save electricity by reducing the number of times the door is opened by more than 30 %.
Overview
Press lever
Water tank cap
Locking device
Water tank
Water supply device
NW2-FDR_DA68-01868A-26_EN.indd 46 7/3/2019 4:57:31 PM
02 OPERATING02 OPERATING
Operating your samsung refrigerator _47
Filling the water tank
You can fill the water with the water tank sitting inside of the refrigerator or you can remove the water
tank to fill the water.
Method 1
After opening the cap, Fill the water.
If you pour the water too fast, water may overflow.
Method 2
1. Release the lock on the both side of the water tank to
remove the lid on the water tank.
2. Fill the water in the water tank.
CAUTION
• Do not put anything other than water in the water tank.
• Do not put anything other than water in the water tank.
• Fill with water up to 4.0 L. If the water is filled up above the mark, it can spill out when the door
opens and closes.
• Push the cap until you hear a click.
Getting water from the dispenser
Place a glass underneath the water outlet and push it gently against the water
dispenser lever with your glass. Blue light will turn on when you push the lever.
NOTE
• Make sure the glass is in line with the dispenser to prevent the water from
splashing out.
• Water dispenser may not be abailable depending on the model.
When the water dispenser is not in use, the following is recommended
Fix the water supply device tightly into the fixing hole.
The door will not be closed automatically when the
water supply device is pulled out for a long time
because of cold leaking.
NW2-FDR_DA68-01868A-26_EN.indd 47 7/3/2019 4:57:33 PM
48_ Operating your samsung refrigerator
Operating your samsung refrigerator
Cleaning the refrigerator
Caring for your Samsung Refrigerator prolongs the life of your appliance and helps keep it odor and germ
free.
WARNING
• Do not use benzene, thinner, home/car detergent, or Clorox™ to clean the refrigerator.
They may damage the surface of the refrigerator and cause a fire.
• Do not spray water onto the refrigerator. This may cause electric shock.
Cleaning the Interior
Clean the inside walls and accessories with a mild detergent
and then wipe dry with a soft cloth. You can remove the drawers
and shelves for a more thorough cleaning. Just make sure to dry
drawers and shelves before putting them back into place.
Cleaning the Exterior
Wipe the display panel with damp, clean, soft cloth. Do not spray
water directly on the surface of the Refrigerator.
The doors, handles and cabinet surfaces should be cleaned with a
mild detergent and then wiped dry with a soft cloth. To keep your
appliance looking its best, the exterior should be polished once or
twice a year.
Display panel
Cleaning the Rubber door seals
If the rubber door seals are dirty, the doors may not close properly,
and the Refrigerator will not operate eciently. Keep the door seals
free of grit or grime by cleaning the doors with a mild detergent and
damp cloth. Wipe dry with a clean, soft cloth.
NW2-FDR_DA68-01868A-26_EN.indd 48 7/3/2019 4:57:33 PM
02 OPERATING02 OPERATING
Operating your samsung refrigerator _49
Cleaning behind the Refrigerator
To keep cords and exposed parts free of dust and dirt accumulation,
vacuum behind the appliance once or twice a year.
CAUTION
• Do not remove the back cover. Doing so may cause an electric
shock.
• Use a clean sponge or soft cloth and a mild detergent in warm
water to clean the refrigerator.
• Do not use abrasive or harsh cleansers such as window sprays,
scouring cleansers, flammable fluids, muriatic acid, cleaning
waxes, concentrated detergents, bleaches, or cleansers
containing petroleum products on exterior surfaces (doors and
cabinet), plastic parts, door and interior liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water when
they are cold. Glass shelves and covers may break if exposed
to sudden temperature changes or impacts such as bumping or
dropping.
Replacing the interior light
LED Lamps
To replace the lamps of the refrigerator, contact a local Samsung service center.
WARNING
• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause
electric shock.
NW2-FDR_DA68-01868A-26_EN.indd 49 7/3/2019 4:57:34 PM
50_ Troubleshooting
Troubleshooting
PROBLEM SOLUTION
The Refrigerator does not
work at all or it does not chill
suciently.
• Check that the power plug is properly connected.
• Is the temperature control on the display panel set to the correct
temperature?
Try setting it to a lower temperature.
• Is the refrigerator in direct sunlight or located near a heat source?
• Is the back of the refrigerator so close to the wall that air cannot
keep circulating? (Refer to page 23 for the best location.)
The food in the
Refrigerator is frozen.
• Is the temperature control on the display set to the correct
temperature?
Try setting it to a warmer temperature.
• Is the temperature in the room too low?
• Did you store the food too close to the air vent at the back of the
refrigerator? Move the food away from the air vent.
You hear unusual noise or
sounds.
• Check that the refrigerator is level and stable.
• Is the back of the refrigerator too close to the wall and therefore
keeping air from circulating?
• Was anything dropped behind or under the refrigerator?
• A “ticking” sound is heard from inside the refrigerator. It is normal
and occurs because various accessories are contracting or
expanding according to the temperature of the refrigerator interior.
• When the automatic ice maker is on, ice is made in the ice
container. After the ice is made, the container inverts and the ice
falls into the storage compartment and water flows through the
water valve. These operations cause noise at regular intervals, but
that noise is normal.
The front corners and
horizontal hinged section of
the appliance are hot and
condensation is occurring.
• Some heat is normal as anti-condensators are installed in the
horizontal hinged section of the refrigerator to prevent condensation.
• Is the refrigerator door ajar? Condensation can occur when you
leave the door open for a long time.
Ice Maker is not producing
ice.
• Did you wait for 12 hours after installation of the water supply line
before making ice?
• Is the water line connected and the shut-o valve opened?
• Did you manually stop the ice making function?
• Is the freezer temperature too warm? Try setting the freezer
temperature lower.
You hear water bubbling in
the Refrigerator.
• This is normal. The bubbling comes from the refrigerator coolant
liquid circulating through the refrigerator.
NW2-FDR_DA68-01868A-26_EN.indd 50 7/3/2019 4:57:34 PM
03 TROUBLESHOOTING03 TROUBLESHOOTING
Troubleshooting _51
PROBLEM SOLUTION
There is a bad smell in the
Refrigerator.
• Check for spoiled food.
• Foods with strong odors (for example, fish) should be tightly
covered.
• Clean out your freezer periodically and throw away any spoiled or
suspicious food.
Frost forms on the walls of
the Freezer.
• Is the air vent blocked? Remove any obstructions so air can
circulate freely.
• Allow sucient space between the foods stored for ecient air
circulation.
• Is the freezer drawer closed properly?
NW2-FDR_DA68-01868A-26_EN.indd 51 7/3/2019 4:57:34 PM
CAUTION
NO YES
Clean the ice box if there are some small pieces of ice on the bottom.
NO YES
Throw away the coherent ice if the ice maker is not used for long time.
Set “ICE OFF” for saving energy if the ice maker will not be used for long time.
If you want to buy and use a tool of shoveling ice, put it into special place of ice
box or take it out.
NW2-FDR_DA68-01868A-26_EN.indd 52 7/3/2019 4:57:35 PM
Efective temperature range
The refrigerator is designed to operate normally in the temperature range specified by its class rating.
(This table is not applicable for Austrailia)
Class Symbol
Ambient Temperature range (
°
C)
IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN
+10 to +32 +10 to +32
Temperate N
+16 to +32 +16 to +32
Subtropical ST
+16 to +38
+18 to +38
Tropical T
+16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be aected by the ambient
temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting the
temperature settings as appropriate.
NW2-FDR_DA68-01868A-26_EN.indd 53 7/3/2019 4:57:35 PM
Memo
NW2-FDR_DA68-01868A-26_EN.indd 54 7/3/2019 4:57:35 PM
Memo
NW2-FDR_DA68-01868A-26_EN.indd 55 7/3/2019 4:57:35 PM
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
Country Contact Center Web Site
AUSTRALIA
1300 362 603 (Other)
1300 425 299 (HHP)
www.samsung.com/au/support
NEW ZEALAND
0800 726 786 (All Product)
0800 6 726 786 (Support for Smart Mobile
Devices)
www.samsung.com/nz/support
INDIA
1800 40 SAMSUNG (1800 40 7267864)
(Toll-Free)
www.samsung.com/in/support
MALAYSIA
1800-22-8899 (HHP)
1800-88-9999 (OTH)
+603-7713 7420 (Overseas contact)
www.samsung.com/my/support
PHILIPPINES
Only for HHP PRODUCT :
#GALAXY (just dial #425-299) [ PLDT /
Globe / Smart / Sun Toll Free ]
02-422-2177 [ Standard Landline ]
OTH PRODUCT :
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and
Mobile ]
02-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
SINGAPORE
1800 7267864 | 1800-SAMSUNG (Other)
1800 4252997 | 1800-GALAXYS (HHP)
www.samsung.com/sg/support
PANAMA 800-0101
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/za/support
UK 0330 SAMSUNG (7267864) www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
MYANMAR
+95-1-2399-888
VIP HHP +95-1-2399-990
www.samsung.com/mm/support
SRI LANKA +9411SAMSUNG (+94117267864) www.samsung.com/in/support
BANGLADESH
09612300300
08000300300 (Toll free)
www.samsung.com/in/support
DA68-01868A-26
NW2-FDR_DA68-01868A-26_EN.indd 56 7/3/2019 4:57:35 PM
