IRR2-BT
Solar Irradiance Meter Pro
Users Manual
Introduction
The Fluke IRR2-BT Solar Irradiance Meter Pro (the Meter or
Product) provides digital measurements related to photovoltaic
(PV) panels.
The Meter measures and reads:
Solar irradiation (W/m
2
) on the surface of a photovoltaic (PV)
panel
Temperature (°F or °C) on the surface of a photovoltaic (PV)
panel
Inclination (degrees) of a photovoltaic (PV) panel
Cardinal degrees with the compass function
The Meter can wirelessly transfer measurements to the
SMFT-1000 PV Analyzer (the Analyzer). This data is used for
IV curve performance analysis of the solar panel and other
measurements of the roof slope and the compass.
Note
The Meter does not connect to smart phones and other
smart devices.
When the date and time on the Meter and the Analyzer match
and the Meter is out of wireless connection range with the
Analyzer, the Meter automatically records the data to memory.
This data can be transferred later to the SMFT-1000.
PN 5339484 (English) 8/2022
©2022 Fluke Corporation. All rights reserved.
Specifications are subject to change without notice. All Product
names are trademarks of their respective companies.
