FORK SEAL DRIVER KIT
MODEL NO: SMC49
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
8 DO NOT use the driver for a purpose it is not designed to perform.
8 DO NOT use the driver if it is damaged, it could scratch the stanchion.
8 DO NOT make any modifications to the driver.
9 Maintain the driver in a good clean condition for the best and safest performance.
9 When not in use, store in a dry location.
2. INTRODUCTION
A comprehensive fork seal driver kit for fork sizes 35mm-50mm. Supplied with six
dierentsizeplasticadaptorsandcanbeusedonbothconventionaland
upside-down forks. Ergonomically designed main driver body for accurate
operation using less power.
3. SPECIFICATION
Model No.: ................................................................. SMC49
Seal Driver Inserts: 35-36, 40-41, 42-43, 45-46, 47-48, 49-50
4. OPERATION
NOTE: Always refer to the original manufacturer’s manual for assembly/disassembly
of the motorcycle fork seals.
4.1. Select appropriate size adaptor pair.
4.2. Firmly press tab on adaptors into slots in steel bodies.
4.3. Align pins and holes on the two halves of the tool and join together.
4.4. Holding the two halves together, slide the arrangement over the forks and locate
onto seal.
5. MAINTENANCE
5.1. After use, wipe clean all elements with dry soft cloth and replace in moulded
storage case.
SMC49 Issue 1 09/07/20
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
