INSTRUCTIONS FOR
12-24V ANTI-THEFT BATTERY TERMINAL
AND FUSE HOLDER
MODEL NO: BTANT1224V
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. PERSONAL PRECAUTIONS
Ensure that there is another person within hearing range and close enough to come to your aid, should a problem arise when
working near a lead-acid battery.
Wear safety eye protection and protective clothing. Avoid touching eyes while working near battery.
Have fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes.
Washimmediatelywithsoapandwaterifbatteryacidcontactsskinorclothing.Ifacidenterseye,usheyeimmediatelywithcool,
clean running water for at least 15 minutes and seek immediate medical attention.
Remove personal metallic items such as rings, bracelets, necklaces and watches. A lead-acid battery can produce a short-circuit
current which is high enough to weld such items to the vehicle and cause severe burns.
Ensure that hands, clothing (especially belts) are clear of fan blades and other moving or hot parts of engine. Remove ties and
contain long hair.
DO NOTsmokeorallowasparkorameinthevicinityofthebatteryorengine.
1.2. GENERAL SAFETY INSTRUCTIONS
Familiarise yourself with the application, limitations and potential hazards of the product. Also refer to the vehicle manufacturer’s
hand book. IF IN ANY DOUBT CONSULT A QUALIFIED ELECTRICIAN.
Keep tools and other items away from the engine and ensure that you can see the battery and working parts of engine clearly.
Ifthebatteryterminalsarecorrodedordirty,cleanthembeforettingtheproduct.
Keep children and unauthorised persons away from the work area.
R WARNING! To prevent the risk of sparking, short circuit and possible explosion DO NOT drop metal tools in the battery area, or allow
them to touch the battery terminals.
Ensure there is effective ventilation to prevent a build-up of explosive gases.
2. INTRODUCTION
Battery isolator switch. Fused bypass that maintains computer settings, radio and clock, while the battery is disconnected. Fits both 12V & 24V
batteries.
3. SPECIFICATION
Model No: ........................................................ BTANT1224V
Continuous rate: ............................................................ 125A
Crank rate: .....................................................................500A
Voltage: .................................................................... 12V-24V
Cable size: ................................................................4-6AWG
4. INSTALLATION
Refer to g.1
4.1. Disconnect negative then positive battery lead.
4.2. Fit one end of the fused bypass link to the Anti-theft terminal clamp bolt. Fit the other end to the vehicle’s original clamp bolt.
4.3. Unscrew green knob anticlockwise and remove.
4.4. Connect the vehicle’s Positive battery lead and tighten clamp.
4.5. Fit the vehicle’s Negative battery lead with the Anti-theft terminal and tighten clamp. Screw green knob clockwise back into Anti-theft
terminal.
4.6. The fused link will maintain computer settings, radio, clock etc. whilst the battery is disconnected.
Refer to
instruction
manual
BTANT1224V | Issue 1 21/05/15
Original Language Version
© Jack Sealey Limited
Wear eye
Protection
Warning:
Explosive
Material
Warning:
Corrosive
substance
5. OPERATION
5.1. Unscrew the knob anticlockwise a few turns to disconnect the battery.
5.2. Reconnect the battery by tightening the knob clockwise.
5.3. The knob can be removed completely to deter theft.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
