TEMPORARY PUNCTURE REPAIR & SERVICE KIT
MODEL NO: TST09
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. SAFETY INFORMATION FOR WHOLE KIT
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this tool.
WARNING! This kit contains flammable glue. If you require a safety data sheet, contact your Sealey stockist.
WARNING! Familiarise yourself with the specific applications and limitations of the kit, as well as any potential hazards.
9 This kit should be used in conjunction with inspection maintenance procedures recommended in the vehicle manufacturer’s manual.
9 Ensure that the kit is correct for the task.
9 Wear the appropriate personal protective equipment for the task. A full range is available from your Sealey stockist.
8 DO NOT use the kit for any purpose other than that for which it is designed.
9 Ensure that the vehicle is properly supported with axle stands before working under the vehicle.
9 Ensure there is adequate lighting prior to using the kit. A range of inspection lamps are available from your Sealey stockist.
9 Keep children and unauthorised persons away from the working area.
9 DO NOT use the kit if any parts are damaged or missing, as this may cause failure and/or personal injury.
9 DO NOT use the kit when you are tired, or under the influence of alcohol, drugs or intoxicating medication.
9 After use, store in a safe, dry childproof area.
1.2. SAFETY INFORMATION FOR REPAIR SOLUTION
Contents of the Repair Solution do not exceed 125 ml, Hazard Statements and Precautionary Statements have been omitted from the
product label.
Signal Word: DANGER
HAZARD STATEMENTS:
9 Highlyammableliquidandvapour.
9 May be fatal if swallowed and enters airways.
9 Causes skin irritation.
9 May cause drowsiness or dizziness.
9 Very toxic to aquatic life. Very toxic to aquatic life with long lasting effects.
PRECAUTIONARY STATEMENTS:
9 Keepawayfromheat/sparks/openames/hotsurfaces.–Nosmoking.
9 Keep container tightly closed.
9 Ground/bond container and receiving equipment.
9 Use explosion-proof electrical/ventilating/lighting equipment.
9 Use only non-sparking tools.
9 Take precautionary measures against static discharges.
9 Avoid breathing dust/fume/gas/mist/vapours/spray.
9 Use only outdoors or in a well-ventilated area.
9 Avoid release into the environment.
9 Wash hands thoroughly after use.
9 Wear protective gloves/protective clothing/eye protection/face protection.
9 Avoid release into the environment.
9 Wash hands thoroughly after use.
9 IF ON SKIN (or hair): Remove/take off immediately all contaminated clothing.
9 Rinse with water/shower.
9 Incaseofre:Usepowder,foam,carbondioxideforextinction.
9 Store in a well ventilated place. Keep cool.
9 Keep container tightly closed
9 IF INHALED: Remove victim to fresh air and keep at rest in a position comfortable for breathing
9 Call a POISON CENTRE or doctor/physician if you feel unwell.
9 If skin irritation occurs: Get medical advice/attention.
9 Take off contaminated clothing and wash before reuse
9 IF SWALLOWED: Immediately call a POISON CENTRE or doctor/physician.
8 DO NOT induce vomiting.
9 Collect spillage.
Refer to
instruction
manual
Wear eye
protection
Wear protective
gloves
Wear protective
clothing
HarmfulHighly
flammable
liquid & vapour
May be fatal if
swallowed and
enters airways
Very toxic to
aquatic life with
long lasting
effects
Original Language Version
© Jack Sealey Limited
Safety symbols referring to Repair Solution
TST09 | Issue:2 (1) 05/05/20
Original Language Version
© Jack Sealey Limited
9 Store locked up. Dispose of contents/container in accordance with local regulation
2. INTRODUCTION
Idealforrepairingpuncturesontubedandtubelesstyresttedtoagriculturalandoffroadvehicles.Canalsobeusedasatemporary/emergency
xoncarsandcommercialvehicles.Repairstripsallowtubelesstyrestoberepairedwithoutremovingthetyrefromthewheel.Alsoincludes
parts and tools for general tyre servicing. Not to be used as a permanent repair for road vehicles.
3. CONTENTS
4. OPERATION
4.1. Release residual air from the tyre in a safe, controlled manner before attempting any tyre repair.
4.2. TUBELESS TYRE REPAIR:
4.2.1. Remove object (causing puncture) from tyre if required..
4.2.2. Clean/widen puncture hole with rasp.
4.2.3. Fit repair strip in the middle of the insertion needle, with 50% protruding from each end. A small amount of glue can be applied along
the length of the repair strip (optional). A puncture can be repaired successfully without the use of glue.
4.2.4. Push the repair strip most of the way through the tyre with the insertion needle, leave 20mm of the strip sticking out.
4.2.5. Pull the insertion needle back out.
4.2.6. There will now be a loop and 2 ends, that need to be cut off protruding from tyre.
4.3. INNER TUBE REPAIR:
4.3.1. Having located the puncture, roughen the rubber in the vicinity (larger than the patch that’s going to be applied) with the abrasive
scraper.
4.3.2. Clean the area of the puncture with a solvent and cloth.
4.3.3. Apply glue to the inner tube over a slightly larger area than the patch.
4.3.4. Wait for the glue to dry partially (it will be tacky in about 10 minutes). The drying time will vary according to temperature and humidity.
4.3.5. Pressthepatchrmlyontothetube.
4.3.6. Placetheinnertubeonaatsurfaceandwork the patch with a smooth object to remove any bubbles and help bond the patch to the
inner tube.
4.3.7. Remove the protective backing from the rear of the patch from centre outwards.
4.3.8. Leavetodrycompletelybeforettingbackintothetyre.Chalkdustcanbeusedtospeedthedryingprocessup.
4.4. Clean items in the kit. Store kit in a safe, childproof location.
.
Temporary Tubeless Repair:
1 Rasp
2 Insertion needle
3 Repair strips x 10
Tube Repair:
4 Patches - 3 x Round Ø30mm
5 Patches - 3 x Round Ø57mm
6 Abrasive scraper
7 Glue
8 Valve caps x 4
9 Valve cores x 4
Tools:
10 Tyre pressure gauge (10-50psi)
11 Tyre valve service tool
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
