Smart Pedestal Air Circulator Fan
PolyFan 704S
USER MANUAL
Your support means the world to us. We
hope you enjoy our product as much as
we did creating it.
Thanks for
Choosing
DREO!
CONTENTS
04
02
06
01
05
03
3-51-2
USING YOUR PEDESTAL
AIR CIRCULATOR
IMPORTANT SAFETY
INSTRUCTIONS
KNOWING YOUR
PEDESTAL AIR
CIRCULATOR
6 7-8
14-16
9-13
07
17
CLEANING
AND MAINTENANCE
TROUBLESHOOTING
08
18-20
DREO CUSTOMER
CARE
ASSEMBLING YOUR
PEDESTAL AIR
CIRCULATOR
CONNECTING TO YOUR
PEDESTAL AIR CIRCULATOR
POLYFAN 704S
01
1
IMPORTANT SAFETY
INSTRUCTIONS
General Safety
Operation Safety
READ ALL CAUTIONARY
MARKINGS ON THE APPLIANCE
AND SAFETY INSTRUCTIONS
IN THE USER MANUAL BEFORE
Do not cover the
air inlet and outlet
while in operation.
Do not use the air
circulator near
flammables and
combustibles.
1. Place the appliance on a flat, dry surface before use.
2. Do not immerse in water and any other liquids.
3. Do not use the appliance until the base is installed.
4. Do not insert your fingers, pencil and any other objects into the grilles under any
circumstances.
5. Do not dismantle, repair, or modify. All servicing should be performed by qualified
personnel.
6. Do not operate the unit close to the curtain. Do not hang foreign objects
on the grille to prevent damaging the balance of the fan or rotational structure.
7. Do not operate the fan under overly humid, high-temperature, dusty environment
or the place where acid or alkali is stored.
8. Fans should never blow directly on infants, the elderly, and patients for a long time.
1. Children shall not play with the appliance. Cleaning and maintenance shall not be
performed by children without supervision.
2. Use the appliance as described in the user manual only. Any other use not recommended
in the user manual may cause fire, electrical shock, or personal injury.
3. This appliance can be used by children aged above 8 years and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of this appliance in a safe way and
understand the hazards involved.
01
2
FOR HOUSEHOLD USE
ONLY READ
AND SAVE THESE
INSTRUCTIONS
Electricity Safety
Check the appliance regularly and
refer to TROUBLESHOOTING or
contact our customer support if it
shows any of the following signs:
- Power cord or plug is damaged.
- Loud noise, unusual smell or excessive heat.
Gentle Reminder: Specifications
Model No.: DR-HPF004S
Power Supply
Rated Power 48W
Baery Type CR2025 3V
24V 1.5A
Power Adapter
Input:
120V~60Hz 1.0A
Output:
24V 2.0A
WARNING:
1. Make sure that the voltage of your electricity supply is the same as that indicated on the
appliance.
2. Always unplug before cleaning or leaving the appliance unused for a long period of time.
Keep your hands dry when plugging/unplugging.
3. Do not operate any air circulator with a damaged cord or plug. Discard air circulator or
return to an authorized service facility for examination and/or repair.
4. Do not run cord under carpeting. Do not cover cord with throw rugs, runners,or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from
traic area and where it will not be trippbed over
5. WARNING: To reduce the risk of fire or electric shock, do not use this air circulator with
any solid-state speed control device.
6. Use 24V/1.5A power adapter only. Turn o the appliance before plugging.
7. WARNING: To reduce the risk of fire, electric shock or injury to persons, do not use
replacement parts that have not been recommended by the manufacturer (e.g. parts
made at home using a 3D printer).
8. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
ASSEMBLING YOUR
PEDESTAL AIR
CIRCULATOR
Assembly Instructions
1
2
3
Push the air circulator into the
base by aligning the cutout on
the boom of the air circulator
with the juing point in the
middle of the base.
Thread the screw through the flat
washer, insert into the base, and
use the included screwdriver to
drive the screw into the boom of
the air circulator.
Put the air circulator upright, hold
the main body while rotating the
Adjustment Collar counterclockwise
to raise or lower the air circulator to
the desired height.
Adjustable:
0-5.9 inch
02
When using the appliance for the first time, remove the wraps and aach the
parts by following the steps below.
3
4
Tighten the adjustment collar by rotating clockwise. Plug the power
adapter into the power (located at the back of the air circulator), and into
the power outlet.
CAUTION
Do not operate the air
circulator if the base has not
been installed.
4
Package Contents
Base
Air Inlet
Air Outlet
User
Manual
Remote Control
(Baery Included)
Quick
Start
Guide
Control Panel
Power Adapter Flat Washer Screw
for Base
Screwdriver
for Base
LED Display
Control Panel
Carry from
Here
Power Input
Adjustment
Collar
5
03
CONNECTING TO YOUR
PEDESTAL AIR
CIRCULATOR
POLYFAN 704S
This device includes the radio transmiing module whose
CMIIT ID is FCC ID: 2A3SYHPF004S.
Before connecting the appliance to your mobile device,
please scan the QR code on the left or go to the app store
and search “Dreo”, then select and download the app.
Look for "PolyFan 704S" when connecting your new
pedestal air circulator
You can use the Dreo app to connect your smart pedestal air
circulator to Amazon Alexa or Google Assistant.
Please follow the in-app instructions to set up your voice assistant.
NOTE: You must create a Dreo account to access voice assistants.
Launch Dreo and sign in or create account by following in-app
instructions.
Enable Bluetooth on your mobile device and plug in your air circulator.
Follow in-app instructions to complete WiFi connection.
Tap + Add Device and select PolyFan 704S.
1
4
5
3
2
You're now ready to control the appliance on your app.
6
(Tip: To restart connection seings, hold the Power buon
for 10 seconds.)
(Tip: The WiFi icon will keep flashing when pairing.)
Hold the Oscillation buon for 5 seconds to start WiFi connection
seings.
6
04
KNOWING YOUR
PEDESTAL AIR
CIRCULATOR
Control Panel
Timer Buon
• Select to set a timer (0-8h)
Power Buon
• Turn power on/o
• Long press 10 seconds to reset to factory seings
Mode Buon
• Switch between Normal/Auto/Turbo/Natural/Custom
• Long press 3s to mute/unmute
Fan Speed Buon
• Adjust airflow speed (1-9 levels)
Note: This appliance is muted by default. To turn on buon sounds, go to the Dreo app.
Vertical Oscillation Buon
• Touch to change the vertical angle. Display will flash &
0/1/2/3/4 indicating the current angle -30°/0°/30°/60°/90°
5s for WiFi
Touch to change the vertical angle.
Horizontal Oscillation Buon
• Display will flash & 0/1/2/3/5 indicating the current angle
/0°/60°/90°/120°/150°) Long press 5 seconds to start network
seings and device pairing
7
LED Display
Vertical
Oscillation
Horizontal
Oscillation
Vertical
Oscillation
Auto Mode
Fan Speed Timer Indicator
Fan Speed / Timer
Hour / Oscillation
Angle
8
05
USING YOUR PEDESTAL
AIR CIRCULATOR
Geing the Most out of Your
Air Circulator
Use with Air Conditioner
Summer:
Position the air circulator in front of your
AC to circulate cold air and provide beer
cooling.
Use with Heater
Winter:
Send the heat to corner of the room and
circulate warm air faster.
Circulation
Spring & Fall:
Make the indoors as fresh and pleasant as
the outdoors.
9
General Operations
Working Modes
1
2
4
5
Touch to turn on the air
circulator.
Touch to adjust airflow
speed.
Touch or to change
theairflow direction.
Touch to set a timer.
Normal Mode
Air circulator runs at the fixed speed.
Auto Mode
Air circulator speed adapts to the
ambient temperature.
Natural Mode
Air circulator runs at alternating
speeds.
(Available in the Dreo app)
Turbo Mode
Air circulator runs at the maximum
speed.
Sleep Mode
(Available in the Dreo app)
Mute auto on.
Air circulator speed decreases
every 30 minutes.
Speed decreases by two levels
at most and will remain constant
if at level 3, 2, or 1:
For level 9: 9 8 7
For level 8: 8 7 6
For level 7: 7 6 5
For level 6: 6 5 4
For level 5: 5 4 3
For level 4: 4 3
For level 3: 3
For level 2: 2
For level 1: 1
Air circulator speed changes according
to temperatures or time you desire.
Custom Mode
(Available in the Dreo app)
(Press on the remote)
5s for WiFi
3
Touch to choose a working
mode.
10
Additional Features
Memory
If the fan is turned OFF or disconnected from power, it will operate
under the previous seings (except the Timer seing ) when it is
turned ON again.
When the fan is ON/OFF, touch the timer buon repeatedly to
set a timer from 1 to 8 hours. When the timer ends, the fan will
stop/start running automatically. To cancel, set the time to 0 hour.
Timer
Display will show “ ” during the update process.
Do not operate until the update is completed.
Check the firmware version on the Dreo app and update regularly
for the air circulator to work more eiciently.
Firmware Update
Display turns o after 1 minute (after 5 seconds in sleep mode).
Wake up the display with any buon.
To disable this feature, please go to the Dreo app.
Display Auto O
Child Lock
Long press the Horizontal Oscillation buon and Vertical
Oscillation buon at the same time for 3 seconds to turn
on/o Child Lock.
Note: Child Lock doesn't apply to operations from the remote control and
the Dreo app. You can also turn o Child Lock by re-plugging in, reseing
to factory seings, or through the Dreo app.
Note:
When the auto o timer is enabled, display will return to fan speed
after 3 seconds.
Display will show 8 if the timer is beyond 8 hours. To set a timer beyond 8
hours, please go to the Dreo app.
11
Baery Replacement
Note: If the indicator on the remote control
doesn’t turn on any more, please consider
1
Press the locking buon to pop out the
baery holder.
2
Replace with the same baery type with
the (+) side facing up.
3
Push in the holder until securely locked
into place.
Remote Control
CR2025 3V
1
2
3
Power
Power Indicator
Increase Speed
Decrease Speed
Vertical Oscillation
Mode
Timer
Horizontal
Oscillation
replacing the baery.
12
Chemical Burn Hazard. Keep baeries away
from children.
WARNING
This product contains a lithium buon/coin cell baery. If a new or used lithium
buon/coin cell baery is swallowed or enters the body, it can cause severe
internal burns and can lead to death in as lile as 2 hours. Always completely secure
the baery compartment. If the baery compartment does not close securely, stop
using the product, remove the baery, and keep it away from children. If you think
baeries might have been swallowed or placed inside any part of the body, seek
immediate medical aention.
The baeries must be disposed of properly, including keeping them away from
children. Even used cells may cause injury.
13
06
CLEANING AND
MAINTENANCE
Outer Surface
Base
Gently wipe o the dust with a soft, dry cloth.
The base can be disassembled in the reverse
order of assembly.
Always unplug the fan before any cleaning or maintenance to
avoid the risk of fire, electric shock, or injury to persons.
Do not immerse in water or get water inside the motor housing.
Do not use any chemical agents when cleaning the fan.
Store in a cool, dry place and cover it to protect from dust.
CAUTION
1.
2.
3.
4.
14
1
2
3
Remove the screws on the front and rear grilles, rotate the grilles
counterclockwise to take them o.
Front Rear
Rinse cap, blades, and grilles under
running water or with a clean, damp
cloth.
To reduce the risk of electrical shock and injury to persons,
turn o and unplug the appliance before any cleaning and
maintenance.
WARNING
Remove the blade cap by rotating
it as shown and take the blade
assembly out of the shaft.
15
4
5
Dry up all parts, and insert the
blade assembly back into the
shaft by aligning the D-shaped
points on the center.
Align the point on the front grille with the right point on the casing,
then rotate the grille clockwise and install the screw back in place.
Repeat the steps for the rear grille.
Front Rear
16
07
TROUBLESHOOTING
My air circulator won’t turn on!
If your problem is not listed or still persists, please contact our
Customer Support (see page 18)
Make sure that the cord is connected to a powered outlet and the mains
voltage corresponds with the voltage indicated on the air circulator.
My air circulator is shaky and wobbling!
2. Incorrect installation might also cause shakiness. Please refer to the
assembly instructions in
page 3-4.
1. Place the air circulator on a flat, level surface.
My air circulator is making vibration and noise!
1. Place the air circulator on a flat, level surface.
2. Be sure not to insert anything into the air inlet and outlet.
17
08
DREO CUSTOMER CARE
Default 12-Month Warranty
Extend Your Warranty
The warranty will not apply in cases of:
Extend your warranty by registering your new appliance on our website
hps://dreo.com/warranty.
This appliance is covered by Dreo warranty for 12 months from the date of its
original purchase.
1. Accident, misuse, or repairs performed by unauthorized personnel.
2. Any unit that has been tampered with or used for commercial purposes.
3. Normal wear and tear of wearable parts.
4. Use of force, damage caused by external influences.
5. Damage caused by non-observance of the User Manual, e.g. connection to an unsuitable
mains supply or noncompliance with the instructions.
6. Partially or completely dismantled appliances.
7. Defects caused by or resulting from damages from shipping or from repairs, service, or
alteration to the product or any of its parts that have been perform ed by a repair person
not authorized by Dreo.
We can only provide after-sales service for products that are sold by Dreo or Dreo
authorized retailers and distributors. If you have purchased the appliance from a dierent
place, please contact your seller for return and warranty issues.
support@dreo.com(888) 290-1688
Mon - Fri, 9:00 am-5:00 pm PST/PDT
www.dreo.com
18
This device complies with Part 15 of the FCC Rules.
This equipment has been tested and found to comply withthe limits for a
Consumer ISM equipment, pursuant to Part 15 of the FCC FRules. These limits
are designed to provide reasonable protection again.st harmful interference
in a residential installation. This equipment generates, uses andcan radiate
radio frequency energy and,if not installed and used in accordarce with the
instructions, may cause harmful interference to radio comimunications.
However
there is no guarantee that interference will not occur in a pparticular
installation
Please note that changes or modifications of this product is notexpressly
approved by the party responsible for compliance could void thie user's
authority
to operate the equipment.
If this equipment does cause harmful interference to radioor television
reception, which can be determined by turning the equipment c and on, the
user is encouraged to try to correct the interference by onhe or more of the
following measures:
-Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver
-Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for heIp.
FCC STATEMENT
19
Model No.: DR-HPF004S
Rev_1.2_EN
www.dreo.com
Shenzhen Hesung Innovation Technology Co., LTD
26F, Bldg A7, Creative City, Shenzhen, China
MADE IN CHINA
20
Looking for help?
Contact us to get expert support.
www.dreo.com
Mon - Fri, 9:00 am-5:00 pm PST/PDT
support@dreo.com (888) 290-1688 www.dreo.com
