instructions for
commercial panel stand - door, wing,
bonnet & bumper
model no: mK59.V2
thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. safety
9 only use on firm, level, unobstructed surfaces which are capable of supporting the stand and body panels.
8 do not overload.
9 Always load evenly with the centre of gravity of the load as near the centre as possible.
9 Apply the brakes before commencing work.
8 do not stand/ride on the stand, or allow others to do so.
9 replace or repair damaged parts. use only recommended parts. unauthorised parts may be dangerous and will invalidate the warranty.
warning! failure to comply with these instructions may result in loss of load, damage to the stand or other property and/or personal
injury.
warning! the warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. it must be understood that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
2. introduction
suitable for supporting large panels from cars or commercial vehicles. Features fully adjustable arms to t many styles of bonnets,
wings, doors, bumpers and tailgates. Each level can rotate 360° to suit. Fitted with two xed Ø180mm wheels and two braked castors for
manoeuvrability.
3. specification
model no........................................mK59.V2
Maximum Arm Width.......................1430mm
Maximum Height.............................1600mm
Base Dimensions...................1150 x 700mm
4. assembly
Assemble panel stand according to the parts diagram attached.
mK59.V2 | Issue 1 13/01/17
Original Language Version
© Jack sealey limited
refer to
instructions
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
important: no liability is accepted for incorrect use of this product.
warranty: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
sole uK distributor, sealey Group.
Kempson Way, Suffolk Business Park,
Bury st. edmunds, suffolk.
iP32 7AR
www.sealey.co.uk
sales@sealey.co.uk
01284 757500
01284 703534
environmental protection
recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
