LED-M60NO
For video wall composition with superior luminance uniformity
High brightness provides vivid images in a range of lighting conditions
Superior contrast ratio
Broadcast grey processing gives more image details
Superior brightness and color uniformity maintains smooth and complete image quality
Ultra high refresh rate
Nanosecond response time
Long service life
Wide viewing angle
High aperture ratio and wide color gamut coverage
Specification
Model
LED-M60NO
Module
Pixel
Configuration
1R1G1B
Pixel Pitch
Category
P6.0
Pixel Pitch
6.0 mm
Dimensions
192x192mm
Module
Resolution
32x32
Pixel Density
27777 pitch/m2
Display
Color
Temperature
3500k to 9300k adjustable
Viewing Angle
Horizontal 120°, vertical 120°
Brightness
Uniformity
≥ 97%
Color
Uniformity
≤ ± 0.003 Cx, Cy
Optical
Brightness
≥4500cd/㎡
Processing
Performance
Brightness
Control
Auto/Manual
Driving
Method
Constant current driving
Frame
Frequency
60 Hz
Refresh Rate
1920 Hz
Grey Level
65,536
Display Color
16,777,216
Processing
Depth
16 bit
Power
Max.
Consumption
750 W/m2
Average
Consumption
250 W/m2
Working
Environment
Working
Temperature
-20 to 50 ºC
General
Working
humidity
10 to 90% (non-condensing)
Available Model
LED-M60NO
，
6mm
，
192x192mm,
