LED-M80NO
For video wall composition with superior luminance uniformity
High brightness provides vivid images in a range of lighting conditions
Superior contrast ratio
Broadcast grey processing gives more image details
Superior brightness and color uniformity maintains smooth and complete image quality
Ultra high refresh rate
Nanosecond response time
Long service life
Wide viewing angle
High aperture ratio and wide color gamut coverage
Specification
Model
LED-M80NO
Module
Pixel
Configuration
1R1G1B
Pixel Pitch
Category
P8.0
Pixel Pitch
8.0 mm
Dimensions
320mm × 160 mm
Module
Resolution
40x20
Pixel Density
15625 pitch/m2
Display
Color
Temperature
3500k to 10000k adjustable
Viewing Angle
Horizontal 140°, vertical 120°
Brightness
Uniformity
≥ 97%
Optical
Brightness
≥4500cd/㎡
Processing
Performance
Brightness
Control
Auto/Manual
Driving
Method
Constant current driving
Frame
Frequency
60 Hz
Refresh Rate
1920 Hz
Grey Level
65,536
Display Color
16,777,216
Processing
Depth
16 bit
Power
Max.
Consumption
800 W/m2
Average
Consumption
300 W/m2
Working
Environment
Working
Temperature
-20 to 50 ºC
General
Working
humidity
10 to 80% (non-condensing)
Available Model
LED-M80NO
，
8mm
，
320x160mm
