INSTRUCTION MANUAL
LED FLOOD LIGHT
TECHNICAL DATA
MODEL VT-44204
SKU 23444
POWER 200 W
LUMENS 17540 Lm
DF >0.9
CRI 70
LIFE SPAN 25,000 Hours
`
ON/OFF CYCLE 15,000 Times
BEAM ANGLE 115°
COLOUR TEMPERATURE 6500K
INPUT VOLTAGE AC: 220-240V, 50Hz
OPERATION
TEMPERATURE
-20°C to +40°C
NET WEIGHT 2.5Kg
BODY TYPE Aluminium
MAX. MOUNTING HEIGHT <5M
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
toaccess the manual in
multiple languages.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
*This product contains a light source of energy eciency class<F>,where <F> shall be replaced by
the energy class of the contained light source.
PROJECTED AREA (mm
2
) 140673.75
DIMENSION 402.5x349.5x44 mm
