Before using this product, please read this manual carefully.
Portable Printer
User Guide
M834
English
01. Package Contents
*Attention: All pictures in this instruction manual are for illustration purposes
only. The actual product may vary due to product enhancement.
Printer*1 Flannel Bag*1 Data Cable*1 Quick Start Guide*1
02. Printer Components
(Power) Button Function
Turn on the printer
Print QR code
Turn off the printer
Operation
Press and hold the button for around 3 seconds
until the power indicator light turns on.
Double-press the button to print QR code. You can
scan the QR code using the App on the phone and
connect to the printer.
Press and hold the button for around 3 seconds
until the power indicator light turns off.
Button Function
Status Power Indicator
Printer
Status
Normal Lit (Green)
Cover is open Lit (Green)
Charging while powered off Off
Charging while powered on Off
Fully Charged Lit (Green)
Low Power Blink Slowly (Red)
Bluetooth: Connected
Lit (Green)
Normal Lit (Green)
No Paper / Paper Not Detected Lit (Red)
Print Head is overheated Lit (Red)
Reset Button Off
Paper
Status
Connection
Status
Others
Indicator Light
Power Button
Power Indicator
Reset Button
Power Port
Open Cover
Button
03. Precautions
① Please use 5V 2A input for charging.
② Please connect the USB cable to the power adapter before charging，please gently
insert or unplug the charging cable when charging, to prevent excessive force from
damaging the port.
③ After the charging is completed, please unplug the charging cable in time.
④ In order to avoid danger, do not use or charge in the environment of high temperature,
high humidity, heavy smoke and dust, such as in bathroom, steam room, near to open
flame, etc.
⑤ Improper charging may cause damage to the print head.
⑥ Do not touch the print head to prevent scalding caused by overheating.
⑦ The tearing blade is sharp, please be careful to avoid touching it by mistake.
⑧ If the machine is malfunctioning, insert the reset hole to restart the machine.
* It is forbidden to disassemble, hit, squeeze the battery, or throw it into fire;
* If severe swelling occurs, please do not reuse it;
* Do not place in a high temperature environment, and it is strictly prohibited to use the
battery after soaking in water;
* There is a danger of explosion if the battery is replaced by the wrong type. Be sure to
dispose of the used battery according to the instructions;
* If consumers use a power adapter for power supply, they should purchase a power
adapter that meets the requirements of corresponding safety standards or a power
adapter with CCC certification.
Battery warning instructions
04. Install App
1. Download the App
Please search for "Phomemo" on your phone’s App market and download
the App.
Phomemo
Search for Phomemo in the Apple App Store, click to
download and install
Search for Phomemo in the Google App Store, click to
download and install
2. How to download and install driver
Download the latest driver from the official website. Download the
relevant driver according to the your operating system version and follow
the instruction to install the driver.
Download
M834.phomemo.com
PC Driver For Windows
PC Driver For MAC
07. Warranty card
Return Exchange Repair
Name: Gender: Phone:
Address:
Purchase date:
Product order number:
Product Serial Number:
Reason description:
Failure condition:
Handling situation:
Maintenance ticket number:
Maintenance person:
Delivery date:
Delivery date:
User Info
Product Info
Maintenance
records
Requirements
of return
/replacement
/repair
08. FCC Warning
FCC Warning statement：
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC RF exposure statement:
The device has been evaluated to meet general RF exposure requirement. The device can
be used in portable exposure condition without restriction.
09. IC Warning
IC Warning statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1.This device may not cause interference.
2.This device must accept any interference, including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes:
1.L’appareil ne doit pas produire de brouillage;
2.L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
RF exposure statement
IC RF exposure statement:
The device has been evaluated to meet general IC RF exposure requirement. The device
can be used in portable exposure condition without restriction.
IC Déclaration d'exposition aux RF:
L'appareil a été évalué pour répondre aux exigences générales d'exposition aux RF d'IC.
L'appareil peut être utilisé dans des conditions d'exposition portable sans restriction.
Press the two Open Cover Buttons at the
same time to open the cover.
1. Instructions for consumable usage
①
Take out the randomly included paper roll
and unfold it.
②
Press and hold the power button for 3 seconds
to start the printer.
④
Install the paper roll back into the paper
compartment and pull the paper out of the
Paper Output Slot. Close the Cover.
③
Hint: How to differentiate the front and back of the printing paper
① Take a piece of printing paper and scratch both sides of the paper with your
fingernails. The front side is the side with colors. Install the paper with the front side
facing upward.
② This product can print different sizes of paper. Please adjust the position of the
consumable holder according to the width of the consumables.
③ To achieve the best result, please use our genuine printing paper.
2. Instructions for single sheet paper and folded paper usage.
Hint
① The paper must be inserted aligned to the paper feeder.
② This product can print different sizes of paper. Please adjust the position of the
consumable holder according to the width of the con
③ When using "Folded paper" , after printing your documents, tear along the
perforation lines.
07. Connect the printer to the App
Turn on the Bluetooth on your phone, launch the Phomemo APP, tap on the icon at the
upper right corner of the Phomemo APP main interface, and select the corresponding
model from the drop-down list to establish a connection.
3-1. Connect the printer to the App
① Method 1
Double-press the printer’s power button to print a QR code. Open your Phomemo
App and press the button on the top right of your Phomemo App home page. On the
selection page, press scan and scan the QR code to connect to the printer.
② Method 2
*Note: system needs to enable positioning and allow app to obtain relevant
permissions.
3-2. Connect the printer to the computer
Connect one end of the data cable to your computer and the other end to the printer’s
USB port. Turn on your printer.
① Step One
Enter official website and download the printer’s drivers. Install the printer’s driver.
② Step Two
Add the printer to your computer and establish a connection. Once the connection is
established, you can print your documents from your computer.
③ Step Three
Official website: M834.phomemo.com
05. Instructionsl
06. Official Printing Paper Type
① Normal thermal paper: Does not contain Bisphenol-A.
② Writable Quick-drying thermal paper： Thermal paper that does not contain
Bisphenol-A, can be written on, and dries ink quickly.
* The printing papers mentioned above are official printing papers.
* Any issues with your printer arising from using non-official printing papers will not be
covered under our warranty policy.
ON/OFF
1
2
3
Adjust the paper roll guides to accommodate
different size paper rolls.
