GARDEN HOSE REEL 60M CAPACITY
MODEL NO: GH60A
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Disconnect the hose reel from the water supply before changing accessories, servicing or performing any maintenance.
9 Maintain the hose reel in good condition.
9 Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
8 DO NOT operate the hose reel if any parts are damaged or missing as this may cause failure and/or personal injury.
8 DO NOT use for any purpose other than that for which it is designed.
8 DO NOT operate the hose reel when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT direct water from the water hose at yourself or others.
2. INTRODUCTION
Lightweight tubular steel frame with tough plastic snap-together parts - no tools required. Integral handle for easy use and portability.
Two angled 1/2” hose connectors that will t most pipe systems. Reel holds up to 60m of Ø13mm hose.
3. CONTENTS
3.1. Check parts against the parts list below. If anything is missing, contact your Sealey stockist.
PART NO. DESCRIPTION QTY PART NO. DESCRIPTION QTY
1 Stand Holder 2 5 Reel Cross Bar 2
2
Metal Stand
(longer)
2 6 Crank Handle 1
3
Metal Handle
(shorter)
1 7
Elbow Hose
Connector Set
1
4 Reel 2 8 Male Adaptor 1
4. ASSEMBLY
GH60A Issue 2 16/01/24
Original Language Version
© Jack Sealey Limited
FIG.1
Attach the handle and feet to the stand holder (g.1).
FIG.2
Attach the two reels together using the two cross bars (g.2).
NOTE: HOSE PIPE NOT INCLUDED.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Original Language Version
© Jack Sealey Limited
FIG.3
Attach the crank handle through the stand holder (g.3).
FIG.4
FIG.5 FIG.6
Attach the hose and connectors (g.4).
To t your hosepipe to the reel, simply connect your hose to the hose end connector inside the reel, and wind the hose in.
To connect your reel to your water source, you will need to either cut a length from your garden hose or use an individual
extension hose, then x the hose to the outside of the reel using a hose end connector and attach the other end to your tap
using a hose end connector and tap connector”.
NOTE: Hose pipe not included.
