Children Bed
HY10019/HY10024
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
02
Before You Start
Warning for Assembly
Assembled only by adults
Remove all Packaging, separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
General Security Warning
Caution: The Product is not suitable for the children under 3 years
Danger: Keep all small parts and packaging materials for this product away from babies
and children, otherwise they may pose a choking hazard.
Danger: Lack of attachment may cause a risk of tipping.
WARNING:
CHOKING HAZARD-Small parts.
Not for children under 3 years.
0-3
Please read all instructions carefully and keep it for future reference.
PARTS
CAUTION
DO NOT use this bed without a mattress.
Infants who cannot get in and out of a bed without help can be trapped
between a mattress and a wall and suffocate. NEVER place infants in the bed
without guardrails in place.
NEVER use bed for children under 3 years.
Never place bed near windows where cords from blinds or drapes may
strangle a child.
Do not place items with a string, cord, or ribbon around a child’s neck, such
as hood strings or pacifier cords. Do not suspend strings over a child’s bed
for any reason.
03
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE .
Due to the presence of small parts during assembly, keep out of reach of
children until assembly is completed.
A
Headboard
B
Footboard
C
x 2
D
x 4
04
F Side board x 4
E Mattress support
M
x 4
K
x 24
L
Ø4*38mm
Screws x 4
Q
x 2
P
5/16*40mm Screws x4
N
1/4*38mm Screws x9
J 5/16*18mm
Screws x 20
I M6 Hex wrench
x 1
H x 7
ASSEMBLY INSTRUCTION
Attach the legs (D) to headboard (A) and footboard (B), fasten completely.
Step 1
D
D
x 4
05
Align side boards (F) with wooden center leg(C), fasten with washers (K) and
screws (P).
Align brackets (M) to the end of side boards (F) , fasten with washers (K)
and screws (J).
Step 2
M
J
K
K
P
J
K
Q
C
C
x 1
M x 2
P
x2
J x 6
K x 8
Q
x 1
06
Align assembled side frame to headboard (A), and attach with washers (K)
and screws (J).
Do not tighten screws completely.
Align assembled side frames to footboard (B), and attach with washers (K)
and screws( J ).
Tighten all screws for steps 3 and 4.
Step 3 / Step 4
07
J
K
I
Tool
J x 8K x 8
Fasten wooden support(H) to the mattress support(E) with screws (N) by
household screwdriver.
Step 5
08
N
H
N
x7
H x 7
Place the assembled mattress support on the bed frame. Ensure the middle
slat and end slats next to the headboard and footboard are tightened with
screw (L).
Step 6
09
N
LL
L
x 4
N
x2
Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us !
Do NOT return this item.
US:cs.us@costway.com
UK:cs.uk@costway.com
US office: Fontana UK office: Ipswich AU office: Truganina
