User Manual
Products:
WQE5600
2 www.westinghouse.com
CONTENTS
WE’RE THINKING OF YOU
Thank you for choosing Westinghouse. We have designed this product to make your life
simpler and deliver impeccable performance for many years. Please spend a few minutes
reading this document to get the best from your new Westinghouse appliance.
Visit our website to:
Get usage advice or service information:
www.westinghouse.com
Register your product for better service:
www.westinghouse.com/support/register-warranty
Buy Accessories, Consumables and Original spare parts for your appliance:
https://shop.westinghouse.com.au/
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Customer care cantact : Call 13 13 49
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Subject to change without notice.
CONTENTS
................................................................................................ 3
............................................................................ 5
.......................................................................................................... 19
......................................................................... 24
.................................................................................... 25
29..............................................................................................
............................................................................ 30
1. SAFETY INFORMATION
2. DESCRIPTION OF THE APPLIANCE
3. CONTROL PANEL
4. INSTALLING YOUR NEW APPLIANCE
5. USING YOUR REFRIGERATOR
6. AUTOMATIC ICE MAKER
............................................................................................... 31
7. CLEANING YOUR REFRIGERATOR
8. FOOD STORAGE GUIDE
32....................................................................................................
........................................................................................................................... 35
9. TROUBLESHOOTING
10. NOISES
WE’RE THINKING OF YOU
CUSTOMER CARE AND SERVICE
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
Visit our website to:
Subject to change without notice.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Thank you for choosing this Electrolux product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the follow-
ing data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
1. SAFETY INFORMATION .........................................................................................................................3
2. DESCRIPTION OF THE APPLIANCE ..................................................................................................5
3. INSTALLING YOUR NEW APPLIANCE ..............................................................................................6
4. TEMPERATURE CONTROL ...................................................................................................................9
5. STORAGE FEATURES ........................................................................................................................... 12
6. GENERAL INFORMATION ................................................................................................................... 14
7. FOOD STORAGE GUIDE ...................................................................................................................... 15
8. TROUBLESHOOTING ........................................................................................................................... 16
9. NOISES .................................................................................................................................................... 20
3
EN
1. SAFETY INFORMATION
Note: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your customer care centre.
The manufacturer will not accept liability, should
these instructions or any other safety instructions
incorporated in this book be ignored.
WARNING
• It is essential the electric outlet is properly
earthed to ground. Consult a qualified electrician
if you are unsure.
• Do not use electrical appliances inside the food
storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
• Unplug the refrigerator before cleaning or
moving it to avoid electric shock.
• Never unplug the refrigerator by pulling the
electrical cord as this may damage it. Grip the
plug firmly and pull straight out.
• If the power cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
• Don’t use a steam cleaner. If livecomponents
come into contact with condensing steam, they
may short-circuit or cause an electric shock.
• Do not store explosive substances such as
aerosol cans with a flammable propellant this
appliance. If pressurised aerosol containers
bear the word ‘flammable’ and/or a small flame
symbol, do not store them inside any refrigerator
or freezer.If you do so you may cause an
explosion.
• Do not damage the refrigerant circuit.
• This appliance contains insulation formed with
flammable blowing gases. Avoid safetyhazards
by carefully disposing of this appliance.
• If you wish to discard this refrigerator, please
contact your local authorities and ask for the
correct method of disposal.
• When you dispose of your old refrigerators
and freezers, remove any doors. Children can
suocate if they get trapped inside.
• When positioning the appliance, ensure the
supply cord is not trapped or damaged.
• Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the
appliance.
WARNING
R600a refrigerant warning
This appliance contains flammable
R600a refrigerant. Avoid safety hazards
by carefully installing,handling, servicing
and disposing of this appliance.
• Ensure that the tubing of the refrigerant circuit
is not damaged during transportation and
installation.
• Leaking refrigerant may cause eye injuries or
ignite.
• The room for installing appliance must be at
least 1m
3
per 8g of refrigerant.The amount of
refrigerant in the appliance can be found on the
rating plate inside the appliance.
• If you are unsure of the refrigerant check the
rating plate inside the refrigerator compartment.
• It is hazardous for anyone other than an
Authorised Service Person to service this
appliance. In Queensland Australia the
Authorisation Service Person MUST hold a Gas
Work Authorisation for hydrocarbon
refrigerants to carry out servicing or repairs
which involve the removal of covers.
• Keep ventilation openings in the appliance
enclosure or in the built-in structure, clear of
obstruction.
• Do not use mechanical devices or other means
to accelerate the defrosting process, other than
those recommended by the manufacturer.
• Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the
appliance.
4 www.westinghouse.com
GENERAL WARNINGS
Read the following carefully to avoid damage
or injury. It is important to use your refrigerator
safely. Check these safety points before using your
refrigerator.
• The appliance must be plugged into its own
dedicated electrical outlet.
• The plug must be accessible when the
refrigerator is in position.
• It is essential the powerpoint is properly earthed
to ground. Consult a qualified electrician if you
are unsure.
• Don’t use extension cords or adapter plugs with
this refrigerator.
• Unplug the appliance before cleaning and before
changing the light bulb(when fitted) to avoid
electric shock.
• Never unplug the refrigerator by pulling the
electrical cord as this may damage it. Grip the
plug firmly and pull straight out.
• Choose a location for your refrigerator that isn’t
too cold. The ambient room temperature should
be above 10°C.
• Stand your refrigerator in a dry place avoid areas
of high moisture or humidity.
• Don’t put the refrigerator in frosty or
unprotected areas like a garage or on the
verandah.
• Don’t plug your refrigerator into a timer fitted to
the powerpoint.
• Do not put the refrigerator in direct sunlight,
near stoves, fires or heaters.
• Do not put the refrigerator on an uneven surface.
• Do not store flammable materials on or under
the appliance, e.g. aerosols.
• Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance.
• Never store fizzy drinks in the freezer
compartment.
• Never try to repair the refrigerator yourself, only
use a qualified or authorised service person for
repairs.
• Never use electric heaters or dryers to defrost
the freezer because you can receive an electric
shock.
• When transporting and installing the refrigerator,
care should be taken to ensure that no parts of
the refrigerating circuit are damaged.
• When installed correctly, your refrigerator
should:
– Have adequate space at the back and
sides for air circulation.
– Be vertically aligned to the surrounding
cupboards.
– Have doors that will self-close from a
partially open position.
• The appliance is not to be used by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children being supervised not to play with the
appliance.
NOTE: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your Customer Care
Department. The manufacturer will not accept
liability, should these instructions or any other safety
instructions incorporated in this book be ignored.
ENVIRONMENTAL INFORMATION
This appliance is intended to be used in
household and similar applications such as,
• The kitchen areas in shops, offices and
other working enviroments;
• Farm house and by clients in hotels,
motels and other residential type
enviroments;
• Bed and breakfast type environments;
• Catering and similar non-retail
applications;
5
EN
QUATTRO FRENCH DOOR REFRIGERATOR FEATURES
WQE5600 illustrated
1
2
3
1
1
3
4
4
5
6 6
7
8
7
7 7
7 7
1
Door Bins*
2
Door Bin Small*
3
Bottle Storage Bins
4
Glass shelves
5
UI Control Panel (on the left side wall)
6
Humidity Control Drawer
7
Freezer Drawer
8
Ice Ball Tray
2. DESCRIPTION OF THE APPLIANCE
NOTE:
* Door bin (2) is the slighly smaller than Door bin (1) ,Position must be installed as per above picture.
6 www.westinghouse.com
Product Dimensions
Total width (W) mm 896
Total depth (D) mm 723
Maximum height (H) mm 1795
Cabinet width (W1) mm 890
Cabinet depth (D1) mm 640
Depth door open 90° (D2) mm 1104
When positioned in a corner area, spacing of at
least 285mm on the hinge side will allow the doors
to open enough to enable the removal of bins and
shelves.
Installation options for optimal aesthetics :
Minimum side clearance kitchen cabinet
Fridge body must sit 10mm proud of kitchen
cabinetry.
Minimum cabinetry opening (WxDxH) :
900mm x 649mm x 1800mm
30 mm
5 mm
10mm
5 mm
Front of fridge body in line with kitchen cabinet
Side clearance must be 25mm either side of fridge
body, to have the fridge doors siting proud of the
kitchen cabinetry.
Minimum cabinetry opening (WxDxH) :
940mm x 659mm x 1800mm
30 mm
25 mm 25 mm
Note : Spacers supplied to assist
3. INSTALLING YOUR NEW APPLIANCE
Unpacking
ENVIRONMENT
Most of the packing materials are
recyclable. Please dispose of those
materials through your local recycling
depot or by placing them in appropriate
collection containers.
Important – check for any damages or marks.
If you find the refrigerator is damaged or marked,
you must report it within 7 days should you wish to
claim for damage/ marks under the manufacturers
warranty. This does not aect your statutory rights.
Clean your refrigerator thoroughly following the
instructions in the “Cleaning” section and wipe o
any dust that has accumulated during shipping.
Locating the refrigerator
CAUTION
Automatic aerosol systems (such as insect
control) should not be located adjacent to
the product as the spray may cause long
term damage to the external plastics of the
appliance.
Do not put the refrigerator in a location that is too
cold or is unprotected, for example in a garage or
on a veranda. The ambient temperature should be
above 10°C.
Put the refrigerator in a dry place avoiding areas of
high moisture or humidity.
Ensure the refrigerator is located on an even
surface.
Installing your refrigerator
W1
D2
D1D
90
°
W
H
126°
Fresh food door
126°
Fresh food door
120°
Freezer door
120°
Freezer door
285
mm
285
mm
7
EN
4. Check the alignment of the refrigerator to the
surrounding cupboards to see if it is level. You
can adjust the level as detailed in step 2 and 3.
aligned to
cupboards
ie. even gap
top of refrigerator
is level ie. horizontal
adjust front feet
for uneveness of
floor eg. wind this
foot down or up
5. If you find your refrigerator rocks from corner
to corner, it means your floor is uneven. Find a
piece of plastic or hardboard etc. and pack it
firmly under the roller.
6. You may now need to fine-tune the installation
by repeating steps 3, 4 and 5.
7. When you have the appliance in its final
position, it needs to be stabilised. Wind the
stability foot under the door hinge down to
the floor until it just makes contact with the
floor. Lift the front of the appliance to take the
weight o the stability foot, then turn it half
a turn further to ensure firm contact with the
floor. Wind the large height adjusting nut back
up to ensure all the weight is now on the front
stability foot. Wind the large height adjusting
nut back up to ensure all the weight is now on
the front stability foot.
stability foot
wound down
Front view
8. Repeat step 7 for the stability foot on the handle
side. Whenever you need to move the appliance,
be sure to wind the feet back up so that the
appliance can roll freely and be sure to reset it
when reinstalling.
9. Plug your refrigerator straight into its own
power point and never use a double adapter.
If you need to roll the refrigerator to get to the
socket, remember to raise the stability foot first.
10. Before you put any food in your refrigerator,
it’s recommended you leave it on for 2 or 3
hours to check it is running properly.
Fridge door flush with the cabinetry
Side clearance must be 90mm either side of the
fridge body, to have the fridge doors siting flush
with the kitchen cabinetry.
Minimum cabinetry opening (WxDxH) :
1070mm x 741mm x 1800m
30 mm
90 mm 90 mm
Note : Top gap all 5 mm.
1. Roll the refrigerator into place.
The rollers are designed for forward or backward
movement only. They are not castors. Moving
the refrigerator sideways may damage your floor
and the rollers. Before moving your refrigerator
ensure height adjusting nut and the stability foot
are fully wound up o the floor.
2. Wind the large height adjusting nut under door
hinge down until the refrigerator is tilted back
by 10mm (see diagram).
Height
adjusting
nut
Fixed rear
rollers
10-33mm
For adjustment
where floor is not level
3. Wind the large height adjusting nut on the
handle side down until the refrigerator is level
and stable. If you have difficulty winding the nut
or height adjusting foot down, have someone tilt
the refrigerator back so you have better access.
stability foot
wound up
8 www.westinghouse.com
Flipper Mullion
Adjust Flipper Mullion for proper connection with
the mullion guide by ensuring the flipper mullion
is folded and perpendicular to the fresh food door.
If the mullion guide is not in the correct position, it
could prevent the door from closing completely.
Door opening
Your refrigerator should be positioned to allow easy
access to a counter when removing food. For best
use of refrigerator drawers and freezer baskets,
the refrigerator should be in a position where both
door can be fully opened.
WARNING
LED lighting
Your appliance is fitted with long life LED
lighting. In the unlikely event the LED lights
should fail, then the LED lights should be
serviced by the service agent, to avoid a
safety hazard. Refer to the warranty page
for contact details.
Cabinet Leveling & Refrigerator Door
Alignment (if necessary)
All four corners of the cabinet must rest firmly on
the floor
• The front should be slightly elevated to ensure
that doors close and seal properly.
• Doors should align with each other and be level.
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1. Lower anti-tip legs until they are both touching
the floor. Use a pair of pliers to adjust.
To raise: turn leg clockwise.
To lower: turn leg counterclockwise.
Anti-Tip
Legs
2. Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
Door Door
9
EN
4. TEMPERATURE CONTROL
The following pages explain the various functions of the user interface to help you better understand
how to get the most out of your new refrigerator.
IMPORTANT
NOTE: When you set a temperature, you set an average temperature for the whole refrigerator
cabinet. Ensuring that you make only small adjustments and wait at least 24 hours to see if the
new temperature is correct to your liking.
Checking the softness of ice cream is a good indication that your freezer is the right
temperature, while checking the temperature of water kept in the refrigerator is a good way
of checking the temperature of the food compartment.
Temperatures inside each compartment may vary, depending on how much food you store
and where you place it.
High or low room temperature may also aect the actual temperature inside the refrigerator.
4.1 Functions of the user interface
1
Quick Chill Control
2
Quick Freeze Control
3
Fridge Temp Tontrol
4
Freezer Temp Control
5
Drinks Chill Button
1
2
3
4
5
10 www.westinghouse.com
Function / Icon Operation (depending on model)
1
Quick Chill
Control
Quick chill indicator
Tap on Quick chill button.
When Quick chill is ON, the Quick chill indicator lights up.
When Quick chill is OFF, the Quick chill indicator turns o.
Use the Quick Chill when you add a large amount of food to the refrigerator
compartment after grocery shopping or to quickly cooled your drink. When
Quick chill is on, the cold air circulate into the refrigerator to temporarily reduce
the temperature to 1°C for 6 hours, Freezer compartment continue to run at set
temperature.
Quick chill auto turn o on either of this condition:
- 6 hours has elasped
- Fridge temp is adjusted
2
Quick Freeze
Control
Quick Freeze
indicator
Tap on Quick Freeze button.
When Quick freeze is ON, the Quick Freeze indicator lights up.
When Quick freeze is OFF, the Quick Freeze indicator turns o.
Use the Quick freeze function when you add a large amount of food to the freezer
compartment after grocery shopping, to speed up the freezing process. When Quick
freeze is on, the compressor will run continuously for 6 hours. Fridge compartment
continue to run at set temperature.
Quick freeze auto turn o on either of this condition:
- 6 hours has elasped
- Freezer temp is adjusted
NOTE: Quick Freeze and Fast Ice cannot be activated at the same time. If Fast ice is ON,
Quick Freeze cannot be activated.
3
Fridge Temp
Control
Tap on the display to cycle through the temperature range supported by the
Fridge.
From 7°C
To 1°C
Default 4°C
4
Freezer Temp
Control
Tap on the display to cycle through the temperature range supported by the
Freezer
From -14°C
To -23°C
Default -18°C
5
DrinksChill
Drinks Chill timer
indicator
The Drinks Chill timer is used to quickly chill a bottle inside the freezer
compartment and to warn the user when it ends.
Tap on Drinks Chill button,
Freezer display shows 20 ,"Min" and Drink Chill LED turns on.
The timer option is from 20 minutes and the user can add time in 5 min intervals
up to 45 minutes. After it starts the timer will show the countdown minute by
minute.
NOTE:
When timer countdown is in progress, the timer duration cannot be adjusted. User
will need to deactivate Drinks Chill and activate Drinks chill again to set a new timer.
11
EN
Function / Icon Operation (depending on model)
4
+
5
Sabbath mode
Press and hold Freezer and Drinks chill for 5 seconds and "Sb" shows on Fridge
disply.
When activated, all lights and UI will not work until Sabbath Mode is deactivated.
The Sabbath Mode is a feature that disables portions of the refrigerator and its
controls in accordance with observance of the weekly Sabbath and religious
holidays within the Orthodox Jewish Community.
NOTE: All alarm functions are deactivated except High temperature alarm is
not disabled for health reasons. If high temp alarm active, The alarm will sound
intermittently for 10 minutes. The alram will silence on its own.
The unit stays in Sabbath Mode after power outage recovery. It must be
deactivated by the user.
Error codes
Both Fridge & Freezer displays are used to
communicate problems by code.
When error codes are displayed in the numeric
display, the unit requires service attention.
"Er" shows up on
Fridge display
Various error codes
on Freezer display
Error code table
Communication error CE
FZ Cavity NTC T1
FZ Evaporator NTC T2
FF Cavity NTC T3
4.2 Alert and Alarms
Door Alarm
The door alarm will sound if a door is left open for
2 minutes. All lights will come on.
The alarm will be turned o by closing the door or
operating any key on the control panel
High Temperature alert
In the event of high temperature condition, audio
alarm is played every 10 seconds until the alert is
acknowledged.
In the event of a high temperature condition, the
audio alarm will be played every 10 seconds and
the display will blink “HI”, until it is cancelled.
The alarm may be cancelled by pressing any key on
the control panel
ECO indicator
Eco mode indicator will light up automatically to
100% when the fridge and freezer compartments
are set within a temperature range.
Fridge range: 4°C to 7°C
Freezer range: -18°C to -14°C
Selecting any of these mode: Quick
Freeze, Quick Chill, Fast Ice or Drinks Chill will
deactivate the Eco mode, the Eco icon will fade.
High Temp indicator
on Fridge display
High Temp indicator
on Freezer display
12 www.westinghouse.com
SpillSafe™ glass shelves
To remove the shelves, gently pull them forward
until the shelf comes clear of the shelf guides.
To return the shelf, make sure there is nothing
behind that may obstruct movement. Gently push
the shelf, into the cabinet and back into position.
Removing glass shelves
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperature change. Allow the glass
shelves to stabilize to room temperature
before cleaning. Do not wash in
dishwasher.
Drawer
Your refrigerator includes a variety of storage
drawers.
Crisper (with humidity control)
Crisper drawers are designed for storing fruits,
vegetables, and other fresh produce. Crispers have
humidity control (Change the humidity by sliding
the humidity control, less humidity conditions are
recommended for fruit, while more humidity
conditions recommended for vegetables)
5. STORAGE FEATURES
Adjust the humidity control
Removing Crisper
To remove the crisper for cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove the drawer.
Doors
Storage bins
The doors to your fresh food compartment use
a system of modular storage bins. All of these
bins are removable for easy cleaning. Bins can be
adjusted to your needs.
Door bins are ideal for storing jars, bottles, cans,
and large drink containers. They also enable quick
selection of frequently used items.
To remove the door bin:
1. lift and unlock from lugs to remove.
2. Replace by lift up and push bin down until the
support lugs lock it in place.
Removing door bin
13
EN
Ice ball tray
1. Prior to using the ice tray , clean it with water
and dish detergent.
2. To make ice ball, fill the ice tray with water until
the water level.
Water
Water Level
3. Close the ice tray with the top cover.
Remove extra water by pressing the ice tray
4. Place the ice tray in freezer compartment.
5. To remove ice balls. Pull the lid handle out to
open the tray.
Lift
up
6. Hold the tray at its ends and twist gently.
Twist
NOTE:
• Place the ice ball tray on a flat surface in freezer
compartment.
• The ice making time depends in your temperature
setting.
Freezer storage
To remove freezer drawers:
All freezer drawers are removable.
1. Open doors completely to gain access to
drawers.
2. Pull the drawer to the stopper. Lift up and pull to
remove it from the cabinet.
3. Reverse the steps to reinstall drawer.
Removing Freezer Drawer
14 www.westinghouse.com
6. GENERAL INFORMATION
CLEANING YOUR REFRIGERATOR
WARNING
BEFORE CLEANING: Turn the refrigerator
o at the power point and unplug the cord
to prevent any chance of electrocuting
yourself.
Doors and exterior
You should only clean the doors with lukewarm
soapy water and a soft cloth.
Interior
Clean the inside of your refrigerator regularly with
a soft cloth, unscented mild soap and lukewarm
water. Thoroughly dry all surfaces and removable
parts and avoid getting water on the controls.
Replace removable parts, plug power cord in and
switch the power on before returning the food.
Door seals
Always keep door seals clean by washing them
with a mild detergent and warm water, followed by
a thorough drying. Sticky food and drink can cause
seals to stick to the cabinet and tear when you
open the door.
Never use hot water, solvents, commercial kitchen
cleaners, aerosol cleaners, metal polishes, caustic
or abrasive cleaners, or scourers to clean your
refrigerator. Many commercially available cleaning
products and detergents contain solvents that will
damage your refrigerator. Use only a soft cloth with
an unscented mild soap and lukewarm water.
CAUTION
To clean a crisper or freezer bin with
telescopic extension slides, simply wipe
with a damp cloth and warm soapy water.
Never immerse the cover in water, as this
could aect the operation of the slide.
Switching o your refrigerator
If you switch o your refrigerator for an extended
period, follow these steps to reduce the chances of
mould.
1. Remove all food.
2. Remove the power plug from the power point.
3. Thoroughly clean and dry the Interior.
4. Ensure that all the doors are wedged open
slightly for air circulation.
15
EN
7. FOOD STORAGE GUIDE
IMPORTANT
Please note, use this information as a guide only, actual storage times will vary depending on how
you use your refrigerator, climatic conditions and the freshness of the food.
CATEGORY FREEZER
REFRIGERATOR
STORAGE TIPS
Meat Sausages and Mince 1-2 Days 2-3 Months
Chops and Steak 4-6 Months3-4 Days
Cold Meats
Keep cold meat at the back of the
refrigerator where it is coldest.
4-6 Months
3-5 Days
Roasts
12 Months3-5 Days
Plastic can cause meat to sweat if
stored in refrigerator for more than
a day.
Poultry Chicken 2 Months1-2 Days
Roast Chicken 12 Months3-5 Days
Eggs 6 Weeks Not Suitable
If poultry takes on a smell or colour
you are unsure about it is best to
throw it out.
Seafood Whole fish and fillets 2 Months2-3 Days
Whole eggs are not suitable for
freezing, slightly beaten eggs may
be frozen for four months.
Store in an airtight container or foil.
Lobster and crabs 2 Months1-2 Days
Prawns 2 Months1-2 Days
Dairy Milk
Never freeze prawns in salty water
as this will dehydrate the flesh.
Yoghurt Not Suitable7-10 Days
Hard Cheeses
If dairy takes on a smell or colour
and you are unsure about it, it is
best to throw it out.
2 Weeks – 2
Months
2 Months
(Grated)
Soft Cheeses Not Suitable1-2 Weeks
Butter
Depending on the variety hard
cheese can last from 2 weeks to
2 months.
12 Months8 Weeks
Fruit &
Vegetables
8-12 Months
When freezing
chop and
blanch in
small
portions.
Every fruit and vegetable has a
dierent shelf life. Some stay fresh
for a couple of days e.g beans,
others can last for a couple of
months e.g. onions.
Keep vegetables in the crisper and
away from the air vents to avoid
freezing.
Don’t wash fruit and vegetables
before storing them in the
refrigerator as this can make them
susceptible to rotting.
PRODUCT
7-10 Days Not Suitable
Roast can take up to 48 hours to
defrost properly, transfer frozen
roast to the refrigerator 2 days
before use.
Left Overs
Homemade meals
3-4 Days
2-6 Months
Store in sealed container.
Freeze meals in small portion
sizes to limit wastage.
16 www.westinghouse.com
8. TROUBLESHOOTING
CONCERN WHAT TO DO
Refrigerator is too warm • Adjust the refrigerator to a colder setting
• Ensure food is allowed to cool before placing inside the refrigerator.
• Ensure the appliance is set up as per instructions
• Ensure that contents are not obstructing the cooling vents.
• Ensure the door is not held open or is being opened too frequently.
Freezer is too warm • Adjust temperature to a colder setting.
• Ensure food is allowed to cool before placing inside the freezer.
• Ensure the appliance is set up as per instructions
• Ensure that contents are not obstructing the cooling vents.
• Ensure the door is not held open or is being opened too frequently.
Food is freezing in the
refrigerator
• Adjust temperature to a warmer setting.
• Ensure that fruit and vegetables are stored in the crisper. Items with
a high water content should not be placed near the cooling vents.
Unable to change
temperature settings
• Refer to sections “temperature control” and “about the user interface”.
• Ensure that user interface is in “awake” mode before trying to adjust
temperature settings.
Appliance does not operate at desired temperature
In a modern frost free refrigerator / freezer, cold air is circulated around the various compartments through
air vents using a high efficiency fan.
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you,
you might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls
and cabinets, can make the sounds seem louder than they actually are. The following describes the kinds of
sounds and what may be making them.
CONCERN WHAT TO DO
Motor noise (compressor) Nothing. This is normal as your new refrigerator uses a high-speed
compressor which switches on and o during operation.
Note that the compressor noise may seem louder at the start of the on
cycle.
Motor noise (compressor); These refrigerators are fitted with a variable speed compressor and fan.
At start up and on warm days they run at a higher speed to provide
additional cooling. When less cooling is required the compressor and
fan will run at a lower speed. As a result it is normal for sound levels to
change depending on operating conditions.
A clicking noise heard just
before the compressor starts.
Nothing. This is normal as your new refrigerator has an automatic
switching action of the temperature control, turning the compressor on
and o.
Occasional gurgling, similar to
water boiling.
Nothing. As each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing in your refrigerator system.
Nothing, this is normal as your new refrigerator uses high efficiency
fans to circulate air. Fan speed and noise may increase during periods of
heavy usage or hot weather.
17
EN
Crisper Operation
CONCERN WHAT TO DO
Rattling and other noises. • Ensure that the cabinet is level and stable, refer to Installation
Instructions
• Check the surrounds of the appliance to ensure there is nothing
touching or placed on top of the appliance.
• Ensure that contents of the appliance are not placed in such a way
that they are vibrating (such as bottles).
CONCERN WHAT TO DO
Excess moisture build up in
crisper
It is normal for there to be
some moisture and humidity
in the crisper bin.
• Ensure that the crisper is not over packed.
• Adjust crisper humidity slides.
Crisper bin can not be
removed
• If crisper bin interferes with the door bins, remove door bins before
removing crisper.
• Position cabinet so that the door can be fully opened.
Freezing items in the crisper • Adjust temperature to a warmer setting.
Refrigerator operation
CONCERN WHAT TO DO
Appliance will not run
It is normal for the freezer
fan not to operate during
the automatic defrost cycle,
or for a short time after the
appliance is switched on.
• Ensure that the cord is plugged into a live power outlet and outlet is
switched on.
• Ensure that the household circuit breaker has not tripped or that the
fuse has not blown.
• The appliance maybe in defrost mode, check again in half an hour.
Compressor motor seems to
run too long
At normal room
temperatures, expect your
motor to run about 40%
to 80% of the time. Under
warmer conditions, expect it
to run more often.
• Ensure that the doors are not held open.
• Check that large amounts of warm food have not just been placed
inside the appliance.
• Note that the appliance will run more than normal just after you
install it or when adjusting the temperature setting changes.
Compressor motor seems
to run too long. These
appliances use a variable
speed compressor, which
by design can run for long
periods of time, this is normal
• The variable speed compressor and fan that at start up and on warm
days, runs at high speeds to provide additional cooling. When less
cooling is required the compressor and fan will run at a lower speed,
but still may not switch o. This is normal.
• It is possible that the only time the compressor and fan will stop is
when the refrigerator is defrosting which is approximately once per
day.
18 www.westinghouse.com
CONCERN WHAT TO DO
The exterior of the appliance
is warm or hot to touch
This is normal because the
appliance transfers heat from
the inside out through the
outer panels and the divider
between the doors.
• Ensure the appliance has the external clearances recommended in
the section “Installing your new appliance”.
• The exterior of the cabinet will be much warmer on warmer days it
may even feel hot to touch, as the appliance is working harder.
User interface will not
respond
To ensure settings are not
accidentally changed the
user interface will go into
sleep mode when not in use.
Press any button to wake user
interface
• Check that the user interface is in awake mode, refer to section
“About the user interface”.
• Check that the user interface is not locked, refer to section “About
the user interface”.
• If the user interface is frozen turn the appliance o for five minutes
for the memory to clear, then turn back on.
• Check that the user interface is not in Sabbath Mode, refer to control
instructions. (I&W models only).
Alarms Sounding • Check that all doors are fully closed.
• Ensure that the over temperature alarm is not being activated by hot
food placed in the freezer.
• Check if the drinks timer has ended, refer control instructions.
Frost build up • Check that all doors are fully closed.
• Ensure that the doors are not opened too often.
• Ensure that the return air vents are not blocked with packaging.
• Ensure the seals are clean and not obstructed.
Odours • The interior may need cleaning, refer to cleaning guide.
• Ensure that food is stored correctly as some food, containers and
wrapping can produce odours.
• Check appliance for old or unusual food.
Lights not working
The LED lighting is designed
to turn on gradually. The
LED lighting is designed
to dim automatically if the
door is left opened for more
than 5 minutes and turn o
completely if the door is open
for more than 7 minutes.
Closing the door will reset
the timer.
• Ensure that the cord is plugged into a live power outlet and outlet is
switched on.
• Ensure that the household circuit breaker has not tripped or that the
fuse has not blown.
• Check that the user interface is not in Sabbath Mode, refer to control
instructions.
• Check the appliance features section to determine lighting
configuration for your model.
19
EN
Door operation
CONCERN WHAT TO DO
Freezer door pops open. • This is normal and should re-close. This happens when the
refrigerator door is closed too quickly.
• If the freezer door stays open, it indicates that the appliance needs
to be tilted backwards a little further. Refer to section “Installing your
new appliance”.
Self close not working. • Check if your appliance has self closing hinges as not all models do.
• It indicates that the appliance needs to be tilted backwards a little
further. Refer to section “Installing your new appliance”.
Door not sealing properly • Ensure there is nothing that is preventing the door from closing such
as appliance contents or items placed near the appliance.
• Ensure that the crisper/freezer bin is closed completely. Refit if
required as referred to in the section “Using your refrigerator”.
• Ensure the appliance is set up as per recommendations.
Door difficult to open and
close
• If the door is difficult to open just after you have closed it this is due
to the pressure equalising, the door will open normally after a few
minutes.
If you still require service
If you have a problem, and the problem persists after you have made the checks mentioned, contact your
nearest Electrolux approved Service Centre or the dealer you bought the refrigerator from. Be ready to
quote the model number, the 9-digit PNC and 8-digit serial number, which is stated on the label inside the
refrigerator compartment.
20 www.westinghouse.com
10. NOISES
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds
are new to you, you might be concerned about them. Most of the new sounds are normal.
Hard surfaces, like the floor, walls and cabinets, can make the sounds seem louder than they
actually are. The following describes the kinds of sounds and what may be making them.
BRRR
!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRR
R!
OK
CLICK!
CLICK!
SSSRRR!
SSSRRR!
BRRR!
BRRR!
HISSS!
HISSS!
BLUBB!
BLUBB!
CRACK!CRACK!
9. NOISES
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you,
you might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls
and cabinets, can make the sounds seem louder than they actually are. The following describes the kinds of
sounds and what may be making them.
This document sets out the terms and conditions of the product
warranties for Westinghouse Appliances. It is an important
document. Please keep it with your proof of purchase documents
in a safe place for future reference should there be a manufacturing
defect in your Appliance. This warranty is in addition to other rights
you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products
Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004
762 341 in respect of Appliances purchased in Australia and Electrolux
(NZ) Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
(e) ‘WarrantyPeriod’meanstheperiodspeciedinclause3ofthis
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand
for a period of 24 months, following the date of original purchase of the
Appliance.Speciccomponentsarewarrantedagainstmanufacturing
defects in Australia and New Zealand for the periods listed below;
• Compressor – Further 3 years
• External Condenser – Further 3 years
• Evaporator – Further 3 years
• Drier – Further 3 years
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
oeredforavalidwarrantyclaimisrepairorreplacement.Electroluxorits
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation will
be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This
warranty does not cover:
(a) lightglobes,batteries,ltersorsimilarperishableparts;
(b) parts and Appliances not supplied by Electrolux;
(c) cosmeticdamagewhichdoesnotaecttheoperationofthe
Appliance;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
(b) theApplianceismodiedwithoutauthorityfromElectroluxinwriting;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the
terms of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11.Condentiality: You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: WESTINGHOUSE REFRIGERATORS AND FREEZERS
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
AUSTRALIA
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call
NEW ZEALAND
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
WFridgeFreezer_Warr_Jul19
email:
web:
NEW ZEALAND
email:
phone:
service:
AUSTRALIA
spare parts:
web:
A24336537-B-282024
© 2017 Electrolux Home Products Pty Ltd.
ABN 51 004 762 341
For more information on all Westinghouse
appliances, or for dimension and installation
information, call into your retailer, phone or email
our customer care team or visit our website:
and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
Used under license. All Rights Reserved.
13 13 49
13 13 50
customercare@electrolux.com.au
westinghouse.com.au
0800 436 245
customercare@electrolux.com.nz
westinghouse.com.nz
