ETFE FOLDABLE SOLAR PANELS
MODEL NO: SPP110, SPP220
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
8 DO NOT ex or bend the folding solar panels.
8 DO NOT place folding solar panels in shaded areas.
8 DO NOT soak the solar panels in water.
9 Clean with a damp cloth only.
8 DO NOT use or store near open ames or ammable materials.
8 DO NOT scratch the surface of the solar panels with sharp objects.
8 DO NOT use corrosive substances to clean the solar panels.
8 DO NOT step on, or place heavy objects on the solar panels.
8 DO NOT disassemble the product.
9 The output circuit must be correctly connected to the equipment.
8 DO NOT short-circuit the positive and negative terminals.
8 Ensure there is no gap between the connector and the insulated connector in order to avoid electric shock.
9 Check all connections, including cables, wires and plugs.
2. INTRODUCTION
Monocrystalline silicon solar cells are highly efficient, with a conversion rate of up to 23.5%. This provides better performance than
traditional solar panels. Supplied with 4 outputs: MC-4, Anderson, XT60 and DC5521 8-piece set of Connectors, these can be used to
connect to a multitude of devices and power stations, including the Sealey SPB2200W Portable Power Station. ETFE laminated solar
panels are IP65 rated, making them suitable for use outdoors. Features handles for easy transportation and eyelets for hanging or
suspending off the ground while in use. Built-in kickstands to optimise the angle and absorb as much sunlight as possible. Foldable,
allowing for compact storage.
3. SPECIFICATION
MODEL NO. SPP110 SPP220
Folded (W x D x H): 650mm x 600mm x 35mm 655mm x 600mm x 50mm
IP Rating: IP65 IP65
Nett Weight: 5.56Kg 8.72Kg
Wattage: 110W 220W
Output: MC4, Anderson, XT60, DC5521 Adaptor Set Including Sizes: DC6014,
DC5525, DC5521, DC5517, DC5010, DC4817, DC7406 and DC7909.
Peak Power: 110W 220W
Working Voltage: 19V DC 19V DC
Working Current: 5.79A 11.57A
Open Voltage: 22.8V 22.8V
Short Circuit Current: 6.07A 12.15A
Supply: DC - Direct Current DC - Direct Current
Unfolded (W x D x H): 1310 x 600 x 20mm 2430 x 600 x 20mm
4. MAINTENANCE
4.1. CLEANING
4.1.1. Wipe clean with a soft damp cloth. DO NOT use corrosive substances.
4.2. STORAGE
4.2.1. Store in a clean, dry environment away from children.
NOTE: This product is NOT designed to be disassembled and should be replaced if damaged.
SPP110 SPP220 Issue 2 03/04/24
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
