pNEUMATIC VACUUM BRAKE BLEEDER
mODEL NO: Vs021.V3
Thank you for purchasing a sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. sAFETY
9 Keep this product in good working order and condition, take immediate action to repair or replace damaged parts.
9 Use approved parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9 Keep children and unauthorised persons away from the work area.
9 Keep work area clean and tidy and free from unrelated materials.
9 Ensure the work area has adequate lighting.
8 DO NOT use the kit to perform a task for which it is not designed.
8 DO NOT allow untrained persons to use the kit.
8 DO NOT use whilst under the inuence of drugs, alcohol or intoxicating medication.
9 After use, clean equipment and store in a cool, dry, childproof area.
9 Dispose of waste liquids in accordance with local authority regulations.
WARNING! DO NOT pollute the environment by allowing uncontrolled discharge of uids.
9 Always read and comply with the warnings on the brake uid container.
9 Wear eye and skin protection. If brake uid enters eyes rinse with plenty of water and seek medical advice. If swallowed seek
medical advice immediately.
WARNING! Brake uid is ammable - keep away from sources of ignition, including hot surfaces e.g. exhaust manifold.
WARNING! Brake uid will damage paintwork. Any spillage should be ushed with water immediately.
2. INTRODUCTION
Simple, one man operation using standard workshop air supply (90-120psi). Quick, clean and efcient. Does not require specialised brake
reservoir caps. Draws uid from the bleed nipple enabling either bleeding or full replacement of uid in system. Includes reservoir top-up kit
guidance notes. Utilises same vacuum unit as Model no. VS020. Includes reservoir top-up kit.
3. spECIFICATION
model no ................................................................ VS021.V3
Inlet size ....................................................................1/4”BSP
maximum air pressure ................................................. 120psi
Air consumption .......................................................180lt/min
4. CONTENTs
1. Filter
2. Lid assembly
3. Hose
4. Trigger
5. Container
6. Reservoir lid
7. Reservoir
8. Adaptor A
9. Adaptor B
10. Adaptor C
11. Adaptor D
Refer to
instruction
manual
Wear eye
protection
Wear protective
gloves
Original Language Version
© Jack Sealey Limited
VS021.V3 | Issue:3 (H,F) 22/08/19
fig.
1
fig.
2
fig.
3
Original Language Version
© Jack Sealey Limited
5. OpERATION
5.1. BRAKE BLEEDING pROCEDURE
5.1.1. Refer to the vehicle manufacturer’s instructions for brake bleeding and wheel sequence before proceeding.
WARNING! Familiarise yourself with the hazards of brake uid - read manufacturers instructions on the container. DO NOT touch the
vehicle’s brake pedal whilst bleeding the brakes.
5.1.2. Remove the cap of the vehicle’s brake uid reservoir. If the uid level is not at maximum top it up.
5.1.3. Remove the cap assembly (g.1-A) from the replenishment bottle and invert it within the neck of the reservoir as shown in g.1. The
threaded outlet ‘B’ must be immersed in the brake uid. If it is not, rotate the three legged moulding ‘C’ clockwise towards the valve ‘D’
until sufcient thread is exposed to allow the outlet to be immersed in the brake uid.
5.1.4. Ensure the valve is closed as shown in g.1-D.
5.1.5. Fill the replenishment bottle just under half full with new brake uid and screw the cap assembly back down onto the bottle. Invert
the bottle over your container of new brake uid and open the valve so that the uid level begins to drop towards the level marked on
the bottle. As soon as the level mark is reached close the valve.
5.1.6. Place the bottle into the neck of the vehicle brake uid reservoir as shown in g.1. and open the valve. As the brakes are bled the uid
level in the reservoir will begin to drop and expose the bottle outlet. Brake uid will begin to ow from the replenishment bottle. Once
the level in the reservoir has risen sufciently to cover the outlet the ow will automatically stop.
5.1.7. Connect the brake bleeder to a suitable compressed air supply.
5.1.8. Mount the black rubber pipe onto the brake nipple on the rst wheel and open the nipple about ¼ of a turn (g.2).
5.1.9. Activate the brake bleeder’s trigger. The vacuum created will draw the brake uid from the vehicle’s brake system.
5.1.10. Continue to bleed the system until there are no air bubbles visible in the clear tube (g.3).
5.1.11. Close the brake nipple (g.2).
5.1.12. Remove the rubber pipe from the brake nipple.
5.1.13. Depress the trigger to clear brake uid from the clear pipe.
5.1.14. Repeat the process at each wheel in turn.
5.2. ChANGING ThE BRAKE FLUID
5.2.1. Repeat the brake bleeding procedure as described above. As the uid is being completely changed regularly check the level in the
replenishment bottle.
5.2.2. When new uid can be seen in the clear tube tighten the brake nipple.
5.2.3. Repeat this procedure at every wheel. When brake bleeding and/or uid changing is complete, test the action of the brake pedal to
ensure that the brakes are working correctly, before driving the vehicle on the road.
.
