LG Electronics LS180HEV2 18,000 BTU Single Zone Wall Mounted Split System with GoldFin, Inverter

Engineering Manual

For LS180HEV2.

PDF File Manual, 69 pages, Read Online | Download pdf file

SINGLE ZONE MEGA AND MEGA 115V

WALL MOUNTED

ENGINEERING MANUAL

3/4, 1, 1-1/2, and 2 Tons

Mega Models:

LS090HEV2

LS120HEV2

LS180HEV2

LS240HEV2

3/4 and 1 Tons

Mega 115V Models:

LS090HXV LS120HXV

Loading ...

File type: PDF

File name: 14935311_ls180hev2.pdf

File size: 8.32 MB

File Language: English

Pages: 69

Author: LG Electronics

File created: 2019-04-30

Published: 2024-05-11

Updated: 2024-05-11

Download File

Specifications

Brand: LG Electronics

Model: LS180HEV2

Category: Tools - Home Improvement

Width: 30 5/16 Inch

Depth: 11 5/16 Inch

Height: 21 1/2 Inch

Net Weight: 98.1 Lbs.

Shipping Weight: 108 Lbs.

Heating Capacity: 19,000 BTU

Min Connectable Capacity: 3,685 BTU

Max Connectable Capacity: 18,493 BTU

Liquid Line Outer Diameter: 1/4 Inch

Suction Line Outer Diameter: 1/2 Inch

Piping Length: 24.6 Ft.

Min. Line Length Each: 9.8 Ft.

Max. Line Length Each: 65.6 Ft.

Min. Line Length Total: 9.8 Ft.

Max. Line Length Total: 65.6 Ft.

Max. Height Diff. btwn. Indoor and Outdoor Units: 32.8 Ft.

Operation: Cooling with Heat Pump

Compressor Noise Level Cooling: 55 dB

Compressor Noise Level Heating: 55 dB

Drain Line Outer Diameter: 27/32 Inch

Drain Line Inner Diameter: 5/8 Inch

Outside Temperature Range for Cooling Min.: 14 °F

Outside Temperature Range for Cooling Max.: 118 °F

Outside Temperature Range for Heating Min.: 14 °F

Outside Temperature Range for Heating Max.: 65 °F

Sleep Mode: Yes

Low Ambient Operating Threshold: 14

Operating Sound Level Quiet: 32 dB

Operating Sound Level Low: 38 dB

Operating Sound Level Medium: 43 dB

Operating Sound Level High: 48 dB

Temperature Sensor: Thermistor

Program Timer: Yes

Quiet/Sleep Mode: Yes

Self Cleaning Indoor Coil: Yes

Min No. of Connectible Indoor Units: 1

Max No. of Connectible Indoor Units: 1

Wireless Remote Control Included: Included

Refrigerant Connection Type: Flare

Condensate Sensor Connection: Yes

Power Input Cooling Rated: 1,500 Watts

Power Input Heating Rated: 1,583 Watts

Rated Amps: 10.4 Amps

Power and Communication Cable No.: 4

Power and Communication Cable AWG: 18

Power Supply Cable No. x AWG: 3 x 14

Refrigerant Charge: 2.98 Ft.

Voltage: 230/208 Volts

Manual Power Switch: Yes

Auto Restart on Power Failure: Yes

Refrigerant Control: EEV
