ULTRASONIC COOL MIST
HUMIDIFIER
FOR MODEL:
PAU16
Before using your ultrasonic humidifier, please
read this manual carefully and keep it for
future reference, along with your receipt.
USER MANUAL
CONTENTS
Safety Guidelines ....................................................... 2
Technical Data............................................................. 3
Features....................................................................... 3
Parts Diagram ............................................................. 3
Humidifier Set Up ...................................................... 4
Operating Instructions.............................................. 4-5
Maintenance Instructions ......................................... 5-6
Storage Instructions .................................................... 6
Warranty ...................................................................... 8
Troubleshooting .......................................................... 7
1
2
SAFETY GUIDELINES
When using any electrical appliances, basic safety precautions should always be followed. Failure to follow these safety precautions may result
in personal injury, property damage, fire or shock
.
1. There must be water in the tank when operating the unit.
2. We recommend using only filtered or distilled water. Using tap water with a high mineral content (hard water) will result in a white
dust and the need for more frequent cleanings. Hard water can damage the nebulizer and may eventually cause it to fail.
3. Be sure the cap is firmly fastened onto the tank.
4. Position the unit so the mist control output nozzle is aimed away from children, walls and furniture in the room (min. 36 in/91 cm
clearance) to avoid condensation and property damage.
5. When removing the tank, grasp it firmly with both hands, before using one hand to support the bottom.
6. DO NOT use this unit if the tank is cracked.
7. DO NOT place the humidifier near heat sources such as a stove, oven, or direct sunlight. Keep the cord away from hot surfaces and
areas where it can be stepped on or tripped over.
8. Use only a dedicated, grounded 120V AC outlet, making sure the unit is plugged in firmly and completely. Plug and unplug the unit
with dry hands only.
9. Turn off and unplug the unit when moving or cleaning it, or when it's not in use.
10. T
o avoid the risk of fire, shock, or personal injury, do not use an extension cord or power strip.
Warning: Never operate the unit with a
damaged cord or plug.
11. DO NOT place on the floor or carpet. Always place the unit on a flat, level, waterproof surface at least 24 in. (61 cm) off the floor
AWAY from direct sunlight, computers or other sensitive electronics.
12.
DO NOT place the humidifier on wood furniture or other surfaces that can be damaged by water.
13. DO NOT place the unit on towels or soft surfaces. This will block the air vent and cause overheating.
14. DO NOT add medicine, essential oils, or cleaning products of any type into the mist control nozzle, base or water tank (See the
“Weekly Maintenance Cleaning & Care” section for proper cleaning instructions). NEVER cover or block any openings on the unit.
NEVER drop or insert any objects into any openings.
15. The unit should not be left unattended in closed rooms as air could become too humid and leave condensation on the walls or
furniture. Always leave a door partially open.
16. DANGER: NEVER immerse the humidifier base (motor unit) in water or other liquids as electrical shock may occur.
17. DO NOT use the unit outdoors.
18. Turn the humidifier OFF if the relative humidity exceeds 60% or if you notice condensation on the windows. For a proper humidity
reading, use a hygrometer which is available in many retail stores.
19. The nebulizer (ultrasonic transducer) is highly sensitive. Keep this important part clean and treat it gently. Clean only according to the
instructions on page 7.
WARNING:
Do not touch the nebulizer while the unit is operating, as possible burns could result.
Do not touch the nebulizer with fingers. Any residue on the metal will reduce mist output.
20. The unit contains no user serviceable parts. To reduce the risk of electrical shock, do no attempt to open the base of humidifier.
DANGER! To reduce the risk of electrical shock, this product has a polarized plug (one blade is wider than the other). As a safety
feature this plug will fit into the outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. DO NOT attempt to bypass this safety feature. Improper use of electric cords and plugs can cause a fire or electric
shock hazard. NEVER pull on the cord to remove the plug from the outlet. Grip the plug and pull directly from the outlet. Check the power
cord and plug for damage. If the cord or plug are damaged, contact Customer Service before using the humidifier.
3
TECHNICAL DATA
Model: PAU16
Voltage: 120V~/60Hz
Watts: 20W
Max. Run Time: 10 hours
Water Tank Capacity: 0.4 gal (1.9 L)
FOR HOUSEHOLD USE ONLY
All data was tested by the factory and are for reference only. This
unit is designed for home use only.
DANGER!
Improper use of electric cords and plugs can cause a fire or electric shock hazard.
NEVER pull on the cord to remove the plug from the outlet. Grip the plug firmly and pull directly away from the outlet. Check the power cord
and plug for damage. A damaged cord or plug must be repaired before using the humidifier. In the event of damage, contact Customer
Service.
ULTRASONIC TECHNOLOGY
An ultrasonic transducer atomizes water droplets into ultra-fine particles which are dispersed into the air as a refreshing
cool mist.
AUTO SHUT OFF PROTECTION / WATERLESS INDICATOR
When the water tank is empty, the motor will shut off automatically and the Power Indicator Light will turn red.
OVERLOAD PROTECTION
The unit will automatically shut off if a circuit is overloaded.
NIGHT LIGHT
Creates a soft illumination. To turn on the night light, push the night light button. Repeat the process to turn it off.
PARTS DIAGRAM
Power indicator light
Water
Gauge
Water Tank
Mist Outlet
Power Cord
Air Outlet
Upper Base
Tank Cap
Power / Output
Adjustment Knob
TOP VIEW OF THE BASE
Pictures are for reference only.
Air Outlet
Water Reservoir
Nebulizer – Black ring with a white center
Water Level
Sensor
4
SETTING UP YOUR HUMIDIFIER
1. Carefully pull the water tank up to remove it from
the base.
2. Turn the water tank upside down.
3. Turn the cap counter-clockwise (to the left).
5. Replace the tank cap by firmly turning it clockwise
(to the right).
7. Plug the humidifier directly into a grounded 120V
wall outlet.(See page 3)
6. Carefully reattach the water tank onto the base. The base
will partially fill with water.
mist volume
Maximum
mist volume
8. Turn the unit on by turning the knob clockwise. This turns
the indicator light and mist output on. To adjust the mist
volume, turn the knob as shown below. The indicator light
turns red when the water tank is empty.
NOTE: Turn the unit
off before refilling the tank or moving the unit.
4. Fill the water tank with
FILTERED or distilled water.
Off
Minimum
OPERATING INSTRUCTIONS
IMPORTANT NOTES REGARDING HUMIDIFIER USE
We recommend the humidifier base be cleaned prior to the first use, according to the cleaning instructions on the next page.
Position the unit at least 24 in. (61 cm) off the floor, on a firm, level, non-porous surface. Do not place the unit on wood or a soft,
unstable surface, such as a towel or bed, as they will block the air vent and cause overheating. The humidifier should be placed at
least 24 in. (61 cm) away from all walls or heat sources, and at least 6 ft. (1.83 m) from any electronics such as a TVs, speakers,
laptops, etc.
1.
2.
5
• Always unplug the unit before filling and replacing the tank.
• Distilled or filtered water is highly recommended. The minerals in (hard) tap water may cause a “white dust” to appear on your
furniture and can eventually cause unit failure.
DO NOT ADD ANY ESSENTIAL OILS, MEDICINES, OR ADDITIVES TO THE WATER,
AS THEY WILL CAUSE DAMAGE AND POTENTIAL FAILURE TO THE UNIT.
• Extreme temperatures can damage the unit. Water temperatures should NEVER be too hot or too cold.
• Return the tank securely to the base before turning on the humidifier.
TO TURN THE UNIT ON
1. With dry hands, plug the humidifier directly into a grounded115-120V AC wall outlet only. Do not use an extension cord.
2. Turn the On/Off Output Adjustment Knob clockwise (the right) to begin operating the unit and to adjust the mist output level.
TO TURN THE UNIT OFF
Turn the unit off when the desired room humidity is achieved. Turn the On/Off Adjustment Knob counter-clockwise, to the far left.
• Always turn the unit off when the water tank is empty.
• The unit will automatically stop creating mist when the water level in the base is very low.
• Do not let water sit in the tank or base for more than 24 hours without use.
• Unplug the unit when it's not in use.
OPERATING INSTRUCTIONS (CONTINUED)
WHEN FILLING THE TANK, NOTE:
Water tank
shut-off
protection
switch
Tank
Water tank
shut-off
protection
switch
A - TOP VIEW OF THE BASE
Air outlet
DO NOT LET
WATER ENTER
THROUGH HERE
IMPORTANT: DISPOSING OF WATER FROM THE BASE
When emptying water out of the base, it is important to hold the base from the side with the air outlet and pour away from it (see fig. B).
Avoid pouring the water from the base towards the air outlet and protection switch. It is important that water NEVER enters the air outlet,
because if it does, the water may cause damage to the motor and electronics, damaging the unit.
• ALWAYS unplug the unit from the outlet before cleaning.
• NEVER use any cleansers (especially abrasive, corrosive, or flammable ones like alcohol) in the unit as these can damage the unit
and, if used, will void the warranty.
CLEANING INSTRUCTIONS
For optimal performance, clean your humidifier once a week by following the instructions below. Using tap water in the tank may require
cleanings every couple of days, as hard water leaves mineral deposits in the unit and creates “white mist.”
TANK CLEANING
1. Fill the water tank 1/3 of the way with a solution of clean water and 1 tbsp (15 ml) of white vinegar or bleach.
2. Let the cleaning solution stand for 20 minutes, shaking the tank over a sink every few minutes. DO NOT place the tank on the base
or run the unit while cleaning.
3. Empty the tank and rinse it twice with clean water. Use a soft wash cloth to wipe down and dry off the tank.
WEEKLY MAINTENANCE
IMPORTANT:
B - WATER DISPOSAL DI AGRAM
Air outlet
base from this side.
Pour water out of the
6
1. For best results, pour 1 cup (240 ml) of clean water and 2 tbsp (30 ml) of white vinegar or bleach into the base of the unit. Set
aside for 10 minutes. NEVER submerge or place the base under running water.
2. Use a soft bristled brush or cloth to carefully clean around the nebulizer and loosen any mineral deposit build-up. DO NOT
touch nebulizer with your hands as fingerprints or any other residue can affect the mist output.
3. Empty the cleaning solution by holding the base from the side where the air outlet is located and having the water run to the
opposite end.
4. Rinse the base twice by pouring 2 cups (480 ml) of clean water in the base both times. NEVER submerge or place base of
unit under running water.
5. Wipe the base and outer surfaces with a soft, damp wash cloth.
WEEKLY MAINTENANCE (CONTINUED)
BASE CLEANING
1.
Clean the unit thoroughly according to the instructions on the previous page and allow the unit to dry
completely before storing. DO NOT leave water in the tank or base for more than 24 hours.
2.
Store the unit in an upright position away from direct sunlight. Do not store in temperatures below 41ºF (5ºC).
STORAGE INSTRUCTIONS
7
TROUBLESHOOTING
Check the following troubleshooting tips before calling for assistance.
ISSUE POSSIBLE CAUSE SOLUTION
Power light
is off
The unit is not plugged in.
Plug in the unit and turn the power/
output adjustment knob clockwise.
The wall outlet has no power.
Check the circuit and fuse; try another outlet.
The power cord is damaged.
Unit / Mist
has a peculiar
smell
The unit is new.
Air the unit out in a cool place for 12 hours with
the tank separate from the base.
The water is dirty or stale.
Thoroughly clean the unit and place fresh water
in the tank.
Excessive
noise
There are vibrations between the
humidifier and its resting surface.
Place the unit on a stable, waterproof surface.
Low water level in the tank.
Fill the water tank.
White dust
The water contains a
high mineral content.
Switch to distilled or filtered water; clean the
nebulizer according to instructions.
Damp table
or floor
Move the unit closer to the table's edge giving the
mist more time to disperse. Do not place the unit on
the floor.
No mist /
Little mist/
No fan
The base overfilled with water
Empty the base and restart.
The water tank is empty. Add water to the tank.
The power/output adjustment knob
is not turned on.
Rotate the power/output adjustment knob clockwise to
turn the unit on.
There is mineral scale on the
nebulizer/transducer.
Clean the nebulizer/transducer according to the
instructions.
The water level is too low.
The water is dirty or stale.
Thoroughly clean the unit and place fresh water
in the tank.
The nebulizer / transducer
or fan does not work.
Call Customer Service: 1-844-4PA-
AIRE (1-844-472-2473).
Condensation
on the windows
or unit
The room is too small or the
humidity is too high.
Scaling on the
nebulizer/
transducer
The water is too hard
(mineral content is high).
After reviewing the troubleshooting tips above, should you have any questions or concerns, please call Customer
Service at 1-844-4PA-AIRE (1-844-472-2473).
Turn down the mist volume or turn the unit off completely,
and check the room's square footage to ensure proper
sizing
The wrong type of cleanser was
used to clean the tank.
Clean the water tank according to instructions, then
let the tank dry completely.
.
Add water to the tank.
The water in the base overflowed.
The tank cap is not securely attached or
it needs to be replaced.
The unit is too far from the end of
the table or too close to the floor.
If the plug or cord are damaged, call Customer
Service at 1-844-4PA-AIRE (1-844-472-2473).
Use distilled or filtered water.
The humidifier is not on a flat
surface.
Put the humidifier on a flat surface.
CONSUMER PRODUCT INFORMATION
For your own records, please attach a copy of your sales receipt to this manual.
Also, write the store name/location and date purchased below:
Store Name: ________________________________________________________________
Location: ___________________________________________________________________
Date Purchased: ____________________________________________________________
ONE YEAR LIMITED WARRANTY
PERFECT AIRE
®
warrants that during the first year from the original date of purchase, this
product will be free from defects in material and workmanship. Perfect Aire, at its discretion,
will repair or replace this product, or any component of this product, found to be defective
during the warranty period. This is a one-time replacement warranty. If the product is no longer
available, Perfect Aire will replace the unit with a similar model, equal or greater in value.
THIS WARRANTY IS NOT TRANSFERABLE.
PROOF OF PURCHASE IS REQUIRED IN ORDER TO OBTAIN WARRANTY ASSISTANCE.
THIS WARRANTY DOES NOT COVER:
•
Damages caused by improper installation.
•
Negligent use, or misuse of the unit.
•
Damages as the result of not using the humidifier according to the instructions provided.
•
Damage to the unit, walls, paintings/portraits, furniture, floors, etc. as the result of high mineral content
in the water.
•
Damage to the unit, walls, paintings/portraits, any furniture (wood), floors, etc. as a result of improper
cleaning.
•
Use of improper voltage or current.
•
Additional or extended warranties offered by retail point of sale.
•
Disassembly or repair not completed by a certified technician as authorized by Perfect Aire.
•
Products used in a commercial setting.
•
Floor display 'as-is' models.
•
Damage caused by acts of nature such as hurricane, tornado, fire, etc.
•
Incidental or consequential damages caused by breach of any expressed, implied or statutory warranty
or condition with exception to the extent prohibited by law.*
•
Any performance issues that fall outside of the 1-year warranty period.
*Note: Some states do not allow the exclusion or limitation of incidental or consequential damages.
Such limitations or exclusions may not apply to you.
DO NOT RETURN THIS UNIT TO THE STORE.
If you have any questions about this unit or its warranty, please call customer
service toll-free at 1-844-4PA-AIRE (1-844-472-2473).
8
PZVɈ
O\TPKPÄLYHUKZ\YMHJL
:^P[JO[VKPZ[PSSLKVYÄS[LYLK^H[LY"JSLHU
VYÅVVY
[HISLVY[VVJSVZL[VÅVVY
VUÅVVY
)HZLV]LYÅV^LK
)HZLV]LYÄSSLK
;OLO\TPKPÄLYPZUV[VUH
ÅH[Z\YMHJL
7\[[OLO\TPKPÄLYVUHÅH[Z\YMHJL
VɈJVTWSL[LS`
<ZLKPZ[PSSLKVYÄS[LYLK^H[LY
Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
Distributed by:
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
Specification and performance data is subject to change without notice.
Printed in China
PA/User_PAU16/04252019
CONSUMER PRODUCT OWNERSHIP REGISTRATION
Complete your Consumer
Product Ownership
Registration today. online
at perfectaire.us or by mail.
Have the peace of mind of
knowing we can contact
you in the unlikely event of
a safety modication.
After mailing the
registration form below
or completing the
form online, store this
document, along with
the User Manual and the
original purchase receipt,
in a safe place. These
items contain information
you will need should you
require assistance.
Read your User
Manual carefully.
It will help you
operate your new
product properly.
1
2
3
Choose to register your new product investment online at
perfectaire.us or through mail by following these three steps:
If you prefer to send in your Product Registration, complete the form below, detach, and mail.
Our Consumer Services number is 844.472.2473.
Cut Here
Dear Consumer:
Thank you for purchasing our product and thank you for placing your condence in us. We are
proud to have you as a customer!
Street
Address
FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH
YOUR WARRANTY RIGHTS.
MODEL NUMBER SERIAL NUMBER
CONSUMER PRODUCT OWNERSHIP REGISTRATION
First
Name
Last
Name
Distributed by Perfect Aire, LLC. • 5401 Dansher Rd. • Countryside, IL 60525 • t: 844.472.2473 • f: 630.323.2301 PA/Appliance_Registration/03202020
Apt. #
State
Zip
Code
City
E-mail
Month Name/Location
Day Year
Phone
Number
- -
Date Purchased Store Where Purchased
The serial number is located on the bar code sticker on the product. It is below the bar code and begins with “SN.”
Registration Card Appliances
Concept Approved: _______________________________________
Content Approved:_______________________________________
Content Approved:_______________________________________
Final Approval: __________________________________________
11
Place
Stamp
Here
FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR WARRANTY RIGHTS.
Protecting Your Investment
PRODUCT REGISTRATION
Registering your product guarantees
that you will be contacted in the unlikely
case of a product safety issue.
CONFIRMATION OF OWNERSHIP
In the event of product theft or loss,
the completed Product Registration
veries your ownership.
Takes 5 minutes!
We sincerely appreciate that you have chosen to purchase a Perfect Aire product, therefore we want to help
you protect your investment. Please complete the Product Registration today for:
Perfect Aire, LLC
5401Dansher Rd
Countryside, IL 60525
CONSUMER PRODUCT OWNERSHIP REGISTRATION
Cut Here
12
