Setting the new standard in residential
and light commercial wiring devices
X Series Wiring Devices
Smarter connectivity. Better looks.
Faster installations.
The new Square D™ X Series has changed the
game in wiring devices, overnight. It’s as if a switch
was flipped on — and now switches will never be
the same. Neither will outlets nor dimmers.
Why? Because the X Series sets the new benchmark
for what homeowners and electricians can expect
out of their wiring devices. Unlike conventional
options, they’re faster and easier to install.
Their flush-facing and smooth surfaces look great.
And they can support Wi-Fi and Z-Wave connectivity.
se.com/us/connectedhome
2 Life is On | Schneider Electric
Square D X Series wiring devices
Switches
• Swap and upgrade plates without the
need to remove the switch from the wall
• Support single pole, three-way,
and four-way switches
Dimmers
• Eliminate near-o ickering on LED lights
• Power dimmable compact uorescent and
LED lamps up to 150 W
• Accommodate incandescent and halogen
bulbs up to 600 W
• Comply with California Title 24
Sensors
• Detect both occupancy and vacancy in one
device, with 180-degree views and up to
800 square feet of coverage
• Adjust timing for fans and lights in increments
of 10, 20, or 30 minutes
• Set relative humidity levels between 45 – 80%
• Control manually at any time via pushbuttons
Receptacles
• Elevate safety with discreet tamper-resistant
black shutters
• Install faster with a ground wire hole that lets
you quickly wrap the ground wire to the
ground screw
• Speed up wiring with easy-to-access side-mount
pressure plates
• Enhance kitchen and bathroom safety with GFCI
receptacles with auto-monitoring every 90 minutes
• Charge two devices at once with USB
receptacles that deliver up to 2.4 A per port
Wall plates
• Choose from a full oering of both screwless and
standard screw-style plates
• Remove and replace plates quickly, without
sacricing secure mounting
• Extend product lifetime with super durable
polycarbonate resin
Fan control
• Install quickly with clearly identied rear wires
and other quick connection features
XX = No Color
Black
(BK)
White
(WH)
Light Almond
(LA)
Gray
(GY)
Available in
four colors
Switches
Description Catalog No. Color
Switch resi single pole 30 pk SQR14103 WH
3-way switch module resi 10 pk SQR14130 XX
4-way switch module resi SQR14141 XX
Switch mod universal rocker plate 10 pk SQR16100
WH, LA, BK, GY
Includes both
the switch
module and
rocker plate
EZ Selector
Simplify the product
selection process
with EZ Selector
• Choose the right
product with self-
guided questions
• Find direct links to
product information
scan me
Receptacles
Description Catalog No. Color
TR 15 A receptacle resi 30 pk SQR44103
WH
WR / TR 15 A receptacle resi SQR44104
WH
TR 20 A receptacle comm 30 pk SQR44203
WH
TR GFCI 15 A receptacle resi SQR51101
WH, LA, BK, GY
USB A / A 4.8 A charger TR duplex 15 A receptacle
SQR55141
WH, LA, BK, GY
USB A / C 5.4 A charger TR duplex 15 A receptacle
SQR55153
WH, LA, BK, GY
Sensors
Description Catalog No. Color
Occupancy sensor light control single pole SQR73101
WH, LA, BK, GY
Occupancy / humidity sensor and fan / light control
SQR73105
WH, LA, BK, GY
Fan control
Description Catalog No. Color
Slide fan 3-speed control single pole SQR31103
WH, LA, BK, GY
3
Square D X Series wiring devices
Life is On | Schneider Electric
Specialty covers
Description Catalog No. Color
1-gang blank matte wall plate SQWS140001
WH, LA, BK, GY
2-gang blank wall plate SQWS140002
WH, LA, BK, GY
Wall plates
Description Catalog No. Color
1-gang screwless matte wall plate SQWP141001
WH, LA, BK, GY
2-gang screwless matte wall plate SQWP141002
WH, LA, BK, GY
3-gang screwless matte wall plate SQWP141003
WH, LA, BK, GY
4-gang screwless matte wall plate SQWP141004
WH, LA, BK, GY
5-gang screwless matte wall plate SQWP141005
WH, LA, BK, GY
1-gang mid+ wall plate with screws SQWS141001
WH, LA, BK, GY
2-gang mid+ wall plate with screws SQWS141002
WH, LA, BK, GY
3-gang mid+ wall plate with screws SQWS141003
WH, LA, BK, GY
4-gang mid+ wall plate with screws SQWS141004
WH, LA, BK, GY
5-gang mid+ wall plate with screws SQWS141005
WH, LA, BK, GY
Outdoor weatherproof covers
Description Catalog No. Color
1-gang weatherproof clear cover universal SQWS83211 XX
2-gang weatherproof clear cover universal SQWS83221 XX
Vertical
mount
And we’re just
getting started.
Discover our screwless,
matte-nish X Series
cover plates
X Series devices
with X Series
cover plates
Take connectivity and efficiency
to the next level with Wiser Energy
smart home energy monitor.
Real-time energy monitoring
for your home’s electrical system
• See what’s powered on in your home at any time,
from anywhere, including Square D Wiring Devices
• Know when appliances have been left on
• Save energy by setting goals and eliminating waste
• Monitor and manage what’s powered on in your
home at any time, from anywhere, with the Square D
edition of the Sense app
• Monitor and control your home with Square D
switches, dimmers, and outlets by enabling the
Wiser Home integration in the Square D edition of
the Sense app
© 2023 Schneider Electric. All Rights Reserved. Schneider Electric, Square D, Wiser Energy, and Life Is On Schneider Electric are trademarks and the property of Schneider Electric, its subsidiaries,
and aliated companies. All other trademarks are the property of their respective owners.. • 998-21631550_GMA-US
Wiser Energy™
Home Power Monitor
Schneider Electric
800 Federal Street
Andover, MA 01810
888 SQUARED (888-778-2733)
se.com/us
se.com/us/connectedhome
Explore the full connected home solution
