Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352
Air Fryer
use & care
Introduction .......................................................2
Important Safety Information ....................3
Features ..............................................................5
Controls & Operation .....................................6
Care & Cleaning .............................................. 11
Troubleshooting ............................................. 12
Warranty ........................................................... 13
FRAFMLIT0124 (April
2024)
2
This manual is your resource for the use
and care of your product. Please read it
before using your Air Fryer. Keep it handy
for quick reference. If something doesn’t
seem right, the troubleshooting section
will help you with common issues.
Visit Owner Support on
www.frigidaire.com
for access to FAQs,
how-to videos and articles, accessories
and cleaning products.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. If you do need service, we can get
that started for you.
For Peace of Mind Protection, register
you product. Locate your registration
card and/or label on your product with
the photo register icon.
Keep your product info here so it’s easy
to find.
Model Number:
Serial Number:
Purchase Date:
Welcome to our
family
Conforms to UL Std. 1026
Certified to CSA Std. CSA C22.2
No. 60335-1&60335-2-9
INTRODUCTION
ATTENTION
Please read all instructions related to your
product and keep this manual for your
future reference. Follow all the warnings
and instructions described in this manual
to better use your product and get better
results.
ENVIRONMENT
Frigidaire is committed to oering
products that have less impact on the
environment, thus contributing to the
sustainable development. Electronic
equipment, cells and batteries must be
disposed of separately from ordinary
waste. If your equipment has cells or
batteries, when they are replaced or
discarded, they must be sent to an
Frigidaire Authorized Service so that they
have a suitable destination.
Environmentally sound preparation of
packaging and products at the end of life
is everyone’s responsibility.
Definitions
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety messages
that follow this symbol to avoid possible
injury or death.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation,
operation or maintenance information
which is important but not hazard-
related.
WARNING
WARNING indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
3
IMPORTANT SAFETY INFORMATION
SAFETY PRECAUTIONS
Read all instructions before using the
electric appliance. The following basic
precautions should always be followed.
• Children shall not play with the
appliance. Cleaning and user
maintenance shall not be performed
by children without supervision.
Close supervision is necessary when
the air fryer is being used by or near
children.
• Please keep the air fryer and the
power cord out of the reach of
children.
• After unpacking the product, keep
the packaging material out of reach
of children.
• This appliance is intended for
normal household use only. Not for
commercial use.
• Check that the supply voltage is the
same as the product label before
connecting it.
• Unplug the air fryer and allow it to
cool before cleaning
• Do not use the appliance if the plug,
the main cord or the appliance itself
is damaged. Always make sure that
the plug is inserted properly into a
wall outlet.
• Regularly inspect the appliance
and power cord. If the power cord
is damaged or broken, it must be
replaced by a service agent or
similarly qualified persons to avoid
safety hazards.
• Always return the appliance to
an authorized service center for
examination or repair. Do not
attempt to repair the appliance
yourself.
• Keep the power cord away from hot
surfaces or sharp objects to avoid
damage. Do not use an extension
cord. Do not use an outlet under the
counter.
• Do not excessively pinch, bend, twist
or place heavy objects on the power
cord to prevent from exposing or
breaking its shielding. Do not use
the electrical cord to pull or drag the
product.
• Do not let cord hang over edge
of table or counter, or touch hot
surfaces.
• Always attach plug to appliance first,
then plug cord into the wall outlet.
To disconnect, turn the unit o, then
remove plug from wall outlet.
• The accessible surfaces may become
hot during use. Do not touch hot
surfaces. Use handles. Keep hair and
clothing away from heated parts of
the product.
• Do not cover the air inlet and the air
outlet openings while the appliance
is operating.
• Never unplug the product from the
outlet by pulling on the electrical
cable, use the plug.
• Do not place the appliance on or
near a hot gas or electric burner, or in
a heated oven. Do not use outdoors.
• Never put anything flammable,
explosive or corrosive in the basket.
Never place paper, cardboard,
non-heat-resistant plastic or similar
combustible materials into your air
fryer. Never put baking or parchment
paper into the air fryer without food
on top. Air circulation can cause
paper to lift and touch heating coils.
• Do not pour oil into the cooking
basket.
• Be extremely cautious when moving
your air fryer (or removing the
basket) if it contains hot oil or other
hot liquids.
• Never start cooking without the
basket being in place.
• Do not fill up the basket above the
MAX line in order to prevent food
contact with the heating element.
IMPORTANT SAFEGUARDS
4
IMPORTANT SAFETY INFORMATION
• Do not touch the basket directly with
your hands during or after use to
avoid burns. Always use the handle
to remove the basket.
• Do not insert pins, wires or other
objects into any of the openings of
the air fryer to avoid an electrical
shock or injury.
• To protect against electric shock, do
not immerse the air fryer cord, plug,
or housing in water or other liquids.
• Do not move or shake the air fryer
during use.
• Do not insert any foreign objects into
the safety switch to avoid any danger.
This switch is designed to shut down
the unit when the door is opened.
• Should the unit emit black smoke,
unplug immediately and wait for
smoking to stop before removing the
cooking basket.
IMPORTANT SAFEGUARDS
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
WARNING
CALIFORNIA RESIDENTS ONLY:
For cancer and reproductive harm
information visit:
www.P65Warnings.ca.gov
CAUTION
• Objects in the direct path of the hot
air vent may suer damage such as
deformation or staining.
• The appliance is not intended for use
as a barbecue. The use of coal inside
the over presents a high risk of fire.
• Do not leave your air fryer
unattended while in use.
• Do not store items on top of the air
fryer when it is turned on.
• Do not use the air fryer for any
purpose other than its intended use.
• When cooking, DO NOT place the
appliance against a wall or against
other appliances. Leave at least
5"/13 cm of free space on the back,
sides, and above the appliance. DO
NOT operate the appliance on or
near combustible materials. DO NOT
block any ventilation openings as hot
steam is released through them. DO
NOT place anything on top of the
appliance.
• The use of accessory attachments is
not recommended by the appliance
manufacturer and may cause injuries.
• Respect the minimum distances
around the product: 5"/13 cm sides;
5"/13 cm rear.
WARNING
FIRE/ELECTRICAL SHOCK HAZARD
DO NOT, under any circumstances, cut,
remove, or bypass the grounding prong.
Grounding-type
wall receptacle
Power Cord
with 3-prong
grounded plug
5
FEATURES
A. Pan E. Control Panel
B. Basket F. Air Inlet
C. Basket Handle G. Air Outlet
D. Basket Release Button H. Main Cord
H
A
G
F
E
B
D
C
6
CONTROLS & OPERATION
1. Remove all packaging and protective materials from the inside and outside of
the Air Fryer.
Before First Use
NOTE
Please ensure that you have removed the cardboard insert between the basket and pan.
1
2. Clean the basket and pan with warm
water and dish soap. Wipe inside
and outside of the appliance with a
soft cloth.
3. Heat the Air Fryer for 10 min using
the Air Fry function.
~
400˚F
7
CONTROLS & OPERATION
Control Panel
1
3
2
5
4 8
7
6
9
12 13 14 15 16
10
11
F
1. On/O 9. Air Fry Function
2. Play/Pause 10. Bake Function
3. Temperature Control 11. Reheat Function
4. Temperature Indicator 12. French Fries/ Frozen Snacks
5. Time Control 13. Vegetables
6. Time Indicator (0-90 min.) 14. Chicken
7. Shake Reminder 15. Steak
8. Preheat Indicator 16. Fish
Using Your Air Fryer
1. Place the appliance on a flat, stable
and heat-resistance surface.
2. Pull out the pan and place it on a
stable surface.
8
CONTROLS & OPERATION
CAUTION
Do not use the appliance without the
inner basket.
3. Put the food in the basket,
observing the MAX capacity
indicator.
4. Push the full pan into the appliance.
6. Press the On button.
6
7. Select the desired cooking method.
For example, Air Fry function.
8. Adjust the time and temperature as
desired or select one of the preset
recipes. (See Preset Recipes.)
9. Press the Play button.
NOTE
Press the temperature and time +
button for 5 seconds to change the
temperature units between Fahrenheit
and Celsius.
5. Plug in the appliance.
9
CONTROLS & OPERATION
CAUTION
• Be careful not to press the ”Basket Release Button” when shaking the food.
• Be careful of hot surfaces when the appliance is in use.
10. Some foods require flipping or shaking per every 7 minutes of cook time. Use
a heat-resistant tool or carefully shake the food inside the basket. (See Preset
Recipes.)
8
11. The Air Fryer beeps at the end of the cook time.
12. Carefully remove the pan and place it on a heat-resistant surface.
13. Follow the instructions below to remove the inner basket from the pan.
CAUTION
Hot steam can come out of the basket when it is opened mid or at the end of cooking.
Make sure your face, arms and hands are away from the steam when opening it.
• Slide the button cover
• Press the "Basket Release Button"
• Lift the basket from the pan
14. Unplug the appliance after using it.
10
CONTROLS & OPERATION
Preset Recipes
Food
Portion (g)
Time Temp.
Shake or turn at half
time elapsed?
300-700g 10-20 min 360°F Yes
8mm
300-800g 15 min 360°F Yes
100-400g 10-20 min 340°F Yes
100-400g 10 min 400°F
100-400g 10 min 400°F
100-400g 20-30 min 360°F Yes
Ma
x 1k
g
800-1000g 45-60 min 360°F Yes
200-500g 10-15 min 280°F
100-400g 6-10 min 360°F
150-300g 10-15 min 340°F
IMPORTANT
The temperature and preparation times listed in the table are guidelines and vary
depending on the recipes and the amount of ingredients, shape and texture of the
foods. You can adjust the cooking temperature and time as desired.
11
CARE & CLEANING
Cleaning
1. Always unplug the appliance and wait until it cools down before cleaning it.
2. Wipe the outside of the appliance with a soft cloth.
CAUTION
Never submerge the product, its cord
or plug in water or any other liquid.
NOTE
Abrasive cleaning products or metal
tools will damage the non-stick coating.
3. Clean the basket and pan with warm water and dish soap, or place them in the
dishwasher.
4. Clean the heating element with a cleaning brush.
Storage
1. Turn o the Air Fryer and allow it to cool completely.
2. Ensure that all components and accessories are clean and dry.
3. Store your Air Fryer in a flat, dry, safe place away from children.
12
TROUBLESHOOTING
Use this guide to help with common issues that may interfere with the performance of
the product. If this does not help improve the issue, please contact Customer Service.
Problem Possible Cause Solution
Air Fryer does not turn on
or heat up
The Air Fryer is not
plugged into the outlet
Place the power plug into
the socket
The safety lock is not
engaged
Engage the safety lock
The basket and pot are in
the incorrect position
Remove and replace the
basket and pot until they
click into place
The cooking time is not
set
Set a cooking time, or
choose a cooking preset
The pan will not slide into
place
The basket is over filled
with food
Reduce the amount of
food in the basket
The basket is not in the
correct position
Remove and replace the
basket until it clicks into
place
White smoke coming from
Air Fryer
The food in the basket is
excessively greasy
The oil released during
the preparation of some
foods may splash on the
super hot face of the Air
Fryer and produce a white
smoke. This behavior
is normal and does not
aect the final result
Residue from previous use Be sure to clean the Air
Fryer correctly after each
use
The display reads E1 The temperature sensor
has disconnected
Contact Customer Service
The display reads E2 The temperature sensor
has malfunctioned
Contact Customer Service
Model FRAFM100B
Voltage 120V
Frequency 60Hz
Power 1500W
Capacity 5.3Qt
Color Black
13
L
IMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your
original date of delivery, Electrolux will pay all costs for repairing or replacing any
parts of this appliance that prove to be defective in materials or workmanship
when such appliance is installed, used and maintained in accordance with the
provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot
be readily determined.
2. Product that has been transferred from its original owner to another party or
removed outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Products used in a commercial setting.
6. Service calls which do not involve malfunction or defects in materials or
workmanship, or for appliances not in ordinary household use or used other than
in accordance with the provided instructions.
7. Service calls to correct the installation of your appliance or to instruct you how
to use your appliance.
8. Expenses for making the appliance accessible for servicing, such as removal of
trim, cupboards, shelves, etc., which are not a part of the appliance when it is
shipped from the factory.
9. Service calls to repair or replace appliance light bulbs, air filters, other
consumables, or knobs, handles, or other cosmetic parts.
10. Pickup and delivery costs; your appliance is designed to be repaired in the home.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday
service calls, tolls, ferry trip charges, or mileage expense for service calls to
remote areas, including the state of Alaska.
12. Damages to the finish of appliance or home incurred during transportation or
installation, including but not limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies;
use of parts other than genuine Electrolux parts or parts obtained from persons
other than authorized service companies; or external causes such as abuse,
misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE REPAIR
OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR.
ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH
AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS
WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish
the warranty period should service be required. If service is performed, it is in your best
interest to obtain and keep all receipts. Service under this warranty must be obtained by
contacting Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA, Puerto Rico and Canada. In the USA and Puerto
Rico, your appliance is warranted by Electrolux Major Appliances North America, a
division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by
Electrolux Canada Corp. Electrolux authorizes no person to change or add to any
obligations under this warranty. Obligations for service and parts under this warranty
must be performed by Electrolux or an authorized service company. Product features or
specifications as described or illustrated are subject to change without notice.
U
SA & Puerto Rico
1-800 374 4432
Electrolux Home Products, Inc.
10200 David Taylor Drive
Charlotte, NC 28262
C
anada
1-800 265 8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario,
Canada L5V 3E4
welcome home.
Frigidaire.com
1-800-374-4432
Frigidaire.ca
1-800-265-8352
owner support
accessories
service
Our home is your home. Visit us if you
need help with any of these things:
registration
(See your registration card
for more information.)
