User Manual
Extra-Large French Door
Digital Air Fry Oven
P.N. NWL0001408127
Visit us at www.oster.com
TSSTTVFDDAF-GRL-035
TSSTTVFDDAFR-GRL-035
TSSTTVFDDAFBK-GRL-035
MODEL
Using the Grill function:
• Select the Grill function.
• Adjust to desired time & temperature as needed using the respective arrow keys. Reference
grilling chart for suggested cook times.
• Place grill plate onto the wire rack for preheating (see “Positioning Grill Plate” section.)
• Hit the START button to begin preheating.
• NOTE – ensure grill plate is properly inserted into oven prior to beginning preheat.
• After preheating is complete, open doors and place food on grill plate.
• Press START again to begin cooking process. Flip food as needed to ensure even cooking.
• When grilling is completed, open doors fully and remove food carefully.
• For further instructions on grilling, see Quick Start Guide with Cook Chart or visit
www.Oster.com.
NOTE - Upper and Lower heating elements will cycle ON and OFF to maintain grilling
temperature and may not glow.
Positioning Rack
To accommodate a wide variety of foods, the oven has 3
rack positions. (See Figure 3)
Positioning of the rack will depend on the size of the food
and desired browning.
Before removing the rack, allow the unit to cool.
PLEASE NOTE – For best toast, pizza and air fry
results, position the rack in the middle rack position.
Positioning Pan
• To accommodate a wide variety of foods the oven has two pan
positions. The pan can be placed on top of the rack or inserted
into the guide rails below the rack. (See Figure Below)
• Before removing the pan allow the unit to cool.
• Positioning of the oven pan will depend on the desired cooking
method. For baking, place the pan on top of one of the racks.
For broiling, or air frying, insert the pan into the guide rails
below the rack and place the food on top of the rack.
PLEASE NOTE
–
Do not to use the broil pan under the rack
in the lower position.
Positioning Grill Plate
Cleaning Your Countertop Oven
Before cleaning your OSTER
®
Countertop Oven, press Cancel button twice, unplug it and allow it
to cool. To clean, wipe with damp cloth.
CAUTION:
DO NOT IMMERSE IN WATER!
Make sure to use only mild, soapy water. Clean the rack, tray, pan, and grill plate with hot water,
a small amount of dishwashing liquid and a non-abrasive sponge or cleaning pad. Wire racks are
not dishwasher safe. Abrasive cleaners, scrubbing brushes and chemical cleaners will damage the
coating on this unit. Empty crumb tray frequently to avoid accumulation
of crumbs.
This appliance has no user serviceable parts. Any servicing beyond that described in the Cleaning
Section should be performed by an Authorized Service Representative only. See Warranty Section.
Storing Your Countertop Oven
Allow the appliance to cool completely before storing. If storing the countertop oven for long
periods of time make certain that the countertop oven is clean and free of food particles. Store the
countertop oven in a dry location such as on a table or countertop or cupboard shelf. Other than
the recommended cleaning, no further user maintenance should be necessary.
H
elpful
T
ips
/ T
roublesHooTing
P
roblem
• Overcooked /
Undercooked
Foods
• Burnt Smell
• Oven does not
turn ON
• Only one heating
element is
heating up
• Heating elements
do not stay ON
• Cannot change
function button
Solution
• You may have to adjust the time and
temperature to desired taste.
• Because your countertop oven is smaller than
your regular oven, it will heat up faster and
generally cook in shorter periods of time.
• Refer to “Positioning Rack” Section,
Page English-4. Rack may need to be
adjusted to accommodate food type.
• Refer to “Cleaning Your Countertop
Oven” Section, Page English-5.
• Plug the countertop oven into a 120-volt
AC electrical outlet.
• Set timer knob and temperature knob to
desired setting. Both must be turned on
to operate the countertop oven.
• Press Start.
• When toasting, make sure the oven is
not
set to broil setting.
• Be certain that function is as desired.
• Heating elements may not glow.
• Press cancel.
P
ot enti al
C
au Se
• Incorrect temperature or
time setting
• Rack placement
• Food build-up inside
oven, on heating elements
or in crumb tray.
• Unit is unplugged
• Did not press Start.
• Function setting
selection determines
which heating element
will operate.
• Heating elements will
cycle ON and OFF to
maintain proper heat.
• Need to cancel function.
-6- -8--7- -9-
Figure 3
For Baking
For broiling or air frying
For Air Fry
For product questions contact: Sunbeam Consumer Service - USA: 1.800.334.0759 - Canada: 1.800.667.8623 - www.oster.com
© 2022 Sunbeam Products, Inc. All rights reserved. Distributed by Sunbeam Products, Inc., Boca Raton, Florida 33431. Printed in China.
TSSTTVFDDAF-XX_22EM1_GCDS-JC
1 Year Satisfaction Guarantee
Sunbeam Products, Inc., (collectively “Sunbeam”) warrants that for a period of fone year from the
date of purchase, this product will be free from defects in material and workmanship. Sunbeam, at
its option, will repair or replace this product or any component of the product found to be defective
during the guarantee period. Replacement will be made with a new or remanufactured product or
component. If the product is no longer available, replacement may be made with a similar product
of equal or greater value. This is your exclusive guarantee. Do NOT attempt to repair or adjust
any electrical or mechanical functions on this product. Doing so will void this guarantee. This
guarantee is valid for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep the original sales receipt. Proof of purchase is required to obtain satisfaction
guarantee performance. Sunbeam dealers, service centers, or retail stores selling Sunbeam products
do not have the right to alter, modify or any way change the terms and conditions of this guarantee.
This guarantee does not cover damage resulting from any of the following: negligent use or misuse
of the product, use on improper voltage or current, use contrary to the operating instructions,
disassembly, repair or alteration by anyone other than Sunbeam or an authorized Sunbeam service
center. Further, the guarantee does not cover: Acts of God, such as fire, flood, hurricanes and
tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of
any express, implied or statutory guarantee or condition. Except to the extent prohibited by
applicable law, any implied guarantee or condition of merchantability or fitness for a particular
purpose is limited in duration to the duration of the above guarantee. Sunbeam disclaims all
other guarantees, conditions or representations, express, implied, statutory or otherwise. Sunbeam
shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or
inability to use the product including incidental, special, consequential or similar damages or loss of
profits, or for any breach of contract, fundamental or otherwise, or for any claim brought against
purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental
or consequential damages or limitations on how long an implied guarantee lasts, so the above
limitations or exclusion may not apply to you. This guarantee gives you specific legal rights, and
you may also have other rights that vary from province to province, state to state or jurisdiction to
jurisdiction.
How to Obtain Satisfaction Guarantee Service
In the U.S.A.
If you have any question regarding this guarantee or would like to obtain guarantee service, please
call 1-800-334-0759 and a convenient service center address will be provided to you.
In the U.S.A., this guarantee is offered by Sunbeam Products, Inc., located in Boca Raton,
Florida 33431. If you have any other problem or claim in connection with this product, please write
to the Consumer Service Department.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE
ADDRESSES OR TO THE PLACE OF PURCHASE.
Prior to grilling, place grill plate onto wire rack When placed correctly, grill
plate will not slide in any
direction on wire rack
If your grill plate slides,
check to make sure the
features on underside line
up properly to the wire
rack
Once grill plate is installed
properly, insert wire rack into
bottom rack position and slide
to back of oven
TSSTTVFDDAF-XX_22EM1.indd 1TSSTTVFDDAF-XX_22EM1.indd 1 2022/3/18 下午3:422022/3/18 下午3:42
