80L PARTS WASHER
MODEL NO: SM40.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all electrical
connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately
by a qualied electrician.
If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
Ensure that repairs are carried out by a qualied electrician.
1.2. GENERAL SAFETY
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are adhered to when using this equipment.
9 Familiarise yourself with application and limitations, as well as the specific potential hazards peculiar to the cleaning tank.
WARNING! Disconnect the cleaning tank from the mains power before changing accessories, servicing or performing any maintenance.
9 Maintain the cleaning tank in good condition (use an authorised service agent).
9 Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Locate the cleaning tank in a suitable working area. Ensure the washer is stood on a firm level surface. Keep area clean and tidy and free
from unrelated materials. Ensure the area is well ventilated and has adequate lighting.
9 Keep the cleaning tank away from heat sources such as heater, sparks, open flames etc.
9 Keep the cleaning tank clean. Remove and clean the filter regularly for best and safest performance.
9 Ensure there are no flammable or combustible materials near the work area.
WARNING! Always wear approved eye or face protection when operating the cleaning tank.
9 Remove ill fitting clothing. Remove ties, watches, rings, and other loose jewellery, and contain long hair.
9 Wear appropriate protective clothing.
9 Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9 Keep children and unauthorised persons away from the working area.
9 Avoid accidental starting of the pump by ensuring the unit is unplugged from the mains power when not in use.
9 In case of fire in parts unit, do not attempt to remove parts, or the tank. The lid is fusible and will automatically close to extinguish flames.
8 DO NOT modify or jam the cleaning tank lid open, as this will make the fusible fire link inoperative which is dangerous practice and will
invalidate the warranty and your insurance.
9 When cleaning parts ensure that nothing in the tank, including any parts basket, is in a position that would prevent the lid from closing fully
if and when the fusible link activates.
8 DO NOT use any solvent with a flash point below 140
O
F. We recommend you use Sealey solvent, contact your stockist for details.
8 DO NOT use the cleaning tank for any purpose other than for which it is designed.
8 DO NOT use cleaning tank in wet or damp locations or areas where there is condensation.
8 DO NOT use the cleaning tank where there are flammable liquids, solids or gases such as paint solvents, etc.
8 DO NOT allow untrained persons to operate the cleaning tank.
8 DO NOT overfill the cleaning tank with solvent.
8 DO NOT operate the cleaning tank if any parts are missing or damaged as this may cause failure and/or possible personal injury.
8 DO NOT leave the cleaning tank operating unattended.
8 DO NOT operate the cleaning tank when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 The tank is not suitable for paint thinners, gun wash or air drying.
9 When not in use switch the cleaning tank off, remove plug from the power supply.
9 Dispose of waste liquids in accordance with national and local authority regulations.
WARNING! DO NOT allow uncontrolled discharge of fluids thus polluting the environment.
WARNING! The warnings, cautions and instructions discussed in this manual cannot cover all possible conditions and situations that
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
Refer to
Instructions
Wear Protective
Gloves
Wear Eye
Protection
Wear a Mask Wear Protective
Clothing
Flammable
Material
Original Language Version
© Jack Sealey Limited
SM40.V2 Issue 3 14/05/24
2. INTRODUCTION
One-piece tank construction with triple baked enamel nish and tted with fully sealed, magnetic drive pump unit. Fluid recirculated through
replaceable lter element and directed onto workpiece through exible metal delivery nozzle. Large capacity tank is suitable for cleaning
larger engine components with up to 80L maximum working capacity. Lid of tank tted with fusible link which automatically snaps lid shut in
the event of a re. Supplied with removable shelf and parts basket.
3. SPECIFICATION
MODEL NO: SM40.V2
Fuse Rating: 3A Plug Type: 3-Pin
Max / Min Working Capacity: 80L/ 57L Power Supply Cable Length: 1.6m
Motor Power: 25W Pump Output/hr: 200L
Nett Weight: 42.4kg Supply: 230V
Overall Dimensions (W x D x H): 1090 x 520 x 890mm Tank Dimensions (W x D x H): 1090 x 520 x 270mm
4. ASSEMBLY
4.1. UNPACKING
4.1.1. Check contents in the course of unpacking the tank. Should there be any damaged or missing parts contact the supplier immediately.
4.2. ASSEMBLY
4.2.1. Open carton and remove lower shelf. Open lid and remove the pump housing set, form the inner box, parts basket and legs from the
tub. Close lid of tub and close carton aps.
4.2.2. Carefully turn the carton with unit upside down (in order to protect against scratching the unit) and open the bottom of carton.
4.2.3. Assemble legs to the brackets on the bottom of the tub with pan screws, spring washers and hex nuts, (hand tight only).
4.2.4. Set the lower shelf between the four legs and x with pan screws, spring washer and hex nuts. Level the shelf and tighten screws.
4.2.5. Now tighten the leg screws and turn assembled unit up correct way onto its legs and remove the outer carton.
4.2.6. Position unit according to safety instructions in chapter 1.
4.2.7. Open lid and place the electrical pump housing through the rectangular hole on the side of tub.
4.2.8. Place the work shelf onto the two welded supports inside the tank.
4.2.9. Screw the 90O connector into the welded bolt on pump housing, then t the tube to the 90O connector.
4.2.10. Check that the tank drain plug is correctly inserted and tightened.
4.2.11. Place the parts basket on work shelf. Check your installation to ensure the unit is ready for use.
5. OPERATION
WARNING! Ensure you have read, understood and apply section 1 safety instructions before using the cleaner.
5.1. Check that the pump power switch is in the o position, and that the unit is unplugged from the mains power supply.
5.2. Fill the tank to appropriate capacity with Sealey solvent, or a general purpose degreaser (contact your local dealer for supply).
8 DO NOT use any other type of solvent.
CAUTION! Ensure you follow any instructions provided with the solvent.
5.3. Plug the washer into the mains power supply and switch the unit on. Check that solvent ows freely through the exible spigot.
5.4. Place parts to be cleaned into the cleaning basket. Direct spray nozzle onto parts. Ensure any splash back stays inside the tank.
If not reposition the spray nozzle. For ground-in marks, leave the parts to soak in the bottom of the tank. Brush parts with cleaning
brush if required. Turn o the pump and leave the parts to drain either in the basket or, if too large, on the shelf.
5.5. When complete turn the washer off and unplug from the mains power supply.
WARNING! DO NOT allow uncontrolled discharge of fluids thus polluting the environment. Dispose of waste liquids in accordance with
local authority regulations.
5.6. Keep the cleaning tank clean. Remove and clean the filter regularly for best and safest performance.
WARNING! When cleaning parts, ensure that nothing in the tank, including any parts basket, is in a position that would prevent the lid
from closing fully if, and when, the fusible link activates.
Original Language Version
© Jack Sealey Limited
SM40.V2 Issue 3 14/05/24
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
