8” PORTABLE CLIP FAN WITH WORKLIGHT
MODEL NO: SCF8WL
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Always read the safety instructions before use.
9 Always ensure this appliance and the USB cord is not damaged.
9 The fan should be used only with the provided USB cable. The fan is rechargeable, and can only be operated in battery mode.
9 Always turn off when not in use.
9 The fan contains a lithium ion battery, and must be charged prior to use.
8 DO NOT insert any object to ventilation or exhaust opening as this may damage the product and may cause an electrical shock or fire.
8 DO NOT cover fan.
8 DO NOT run fan un-attended.
8 DO NOT attempt to disassemble, repair, or modify, this will void the warranty. The product should be taken to your local service centre.
8 DO NOT use fan for functions other than those descibed in the instruction manual.
8 DO NOT use near inflammable substances or vapour such as alcohol, insecticides, petrol etc.
8 DO NOT immerse the fan or the USB cable in any liquid.
8 DO NOT Conduct out any electrical repairs, the fan has been built in accordance with relevant safety and performance standards. Only
a qualified electrician must carry out all repairs.
WARNING! The fan must be switched off when cleaning.
WARNING! The fan should not be operated by children.
WARNING! plastic wrapping can be a suffocation hazard for babies and young children.
BATTERY SAFETY INSTRUCTIONS
WARNING! Powered by a Polymer Lithium-ion battery which can be dangerous if not handled with care.
9 Charge battery prior to first use. The battery pack will have been shipped in a low charge state. Minimum initial charge time 6 hours.
Note: The light and fan do not work when on charge.
8 DO NOT charge battery when room temperature is below 50°F (10°C) or above 104°F (40°C).
8 DO NOT attempt to recharge the battery by means of a generator or a DC power source.
8 DO NOT short-circuit the battery by linking both terminals with a metal object.
8 DO NOT store the light in locations where the temperature may exceed 104°F (40°C) such as outside sheds, above heaters, or metal
buildings in summer.
WARNING! Dispose of spent battery correctly and in accordance with local regulations.
▲ DANGER! DO NOT attempt to dismantle the battery pack.
9 For safety and environmental reasons DO NOT discard in domestic waste or by burning. ONLY discard or recycle according to local waste
authority regulations.
WARNING! DO NOT allow a leaking battery to come into contact with skin. If contact with battery fluid occurs take immediate action:
Skin contact: Wash immediately with soap and water. Eye contact: Flush eye immediately with cool, clean running water for at least 15
minutes, seek immediate medical attention.
2. INTRODUCTION
Portable 8” fan with a light function. Strong clip and magnet base means you can position the fan in any place at any time. It can be
used on a desk, in a workshop, in and around the house or even outdoors day or night. It has four, easy-to-use, wind speed options
with 360° rotation in all directions. Two light modes are an additional feature. This fan is battery operated and is supplied with a 3.7V
4000mAh battery. It can operate up to 10hrs on a full charge. Supplied with USB-A to USB-C port and cable. It is fully charged within
6hrs. It also has a power bank function with 5V⎓1A output.
3. SPECIFICATION
SCF8WL Issue 1 24/11/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
MODEL NO: SCF8WL
Fan Diameter: 8’’
Height: 250mm
Maximum airow: Low/Natural speed - 4.7mph, Medium speed -
6.4mph, High speed - 8.1mph
Max Air ow - 4.5m³/s
Power: 8W, Output Power: 5V-1A
Supply: 3.7V 4000mAh battery capacity Polymer
Lithium-ion battery
4. OPERATION
WARNING! Ensure you read, understand and apply the safety instructions in
Section 1 before using the fan.
WARNING! DO NOT clamp the fan to any electrical or sensitive electronic
equipment or any surface or object that is too flimsy to resist the force of the spring
loaded clamp and/or the weight of the fan.
4.1. Mount the fan in a suitable location, using the spring loaded clamp to attach it to a
suitable table, shelf or other stable solid surface. Adjust the fan to the desired angle
required.
4.2. CHARGING THE UNIT
9 Plug the supplied USB cable into the USB charging port in the back of the fan.
4.2.1. The fan will charge when plugged into a USB supply. See fig.1. Allow 6 hours to fully
charge. The green LED light will illuminate when charging commences. Subsequent
charging times will depend on the state of discharge of the battery.
4.3. USING THE FAN
4.3.1. Four fan speed options which are easy to use. Low, Medium, High, and natural
speed. A green LED light indicates fan speed. See table below ‘Fan speed
Operation’.
4.4. Select fan speed by pressing the button on the left hand side. See fig.2. See
table below for fan speed operation.
4.5. USING THE WORK LIGHT
4.5.1. Two work light settings. 50% and 100% brightness options. See table below.
4.6. Select the right hand side button indicated in fig.3 for work light brightness
settings.
4.7. POSITIONING THE WORK
LIGHT
4.8. Position work light to the
desired position using the clip
on the base of the fan.
4.9. Strong clip and magnet base
means you can position the
fan in any place at any time.
Note: There is also a thread
on the clip for a tripod stand
to attach. (Tripod stand not
included).
4.10. IDENTIFICATION
LIGHT OPERATION
Press button Once 50% brightness.
Press button Twice On with full brightness.
Press button 3 Times OFF.
FAN SPEED OPERATION
Press button Once Power ON/Low Speed 1st green LED light indication light
illuminated.
Press button Twice Medium Speed 2nd green LED light indication
light illuminated.
Press button 3 Times High Speed 3rd green LED light indication light
illuminated.
Press button 4 Times Natural Speed All green LED lights are
illuminated.
Press button 5 Times Power O -
g.1
SCF8WL Issue 1 24/11/23
Original Language Version
© Jack Sealey Limited
1. LED light switch.
2. LED indicators.
3. Fan switch.
4. USB-A output.
5. Type C charging port.
6. USB-A to USB-C cable.
g.2
g.3
5. MAINTENANCE
9 Always disconnect the cord from the electrical outlet when cleaning the fan.
9 Dust may accumulate in the grilles after some time and may affect the function. Therefore, it is recommended to clean the fan grille.
9 To remove dust, use mild cleaning agent and soft brush in removing the dust and dirt from the grilles.
8 DO NOT submerse the fan in water and NEVER allow water to drip into the motor housing.
8 DO NOT use solvents or other chemicals to clean the fan.
9 Store the fan in its original box or otherwise cover the fan to protect it from dust.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
