Specifications:
Input
power: DC 9~14.4V 2A
Output Power
: 60 W
Speaker
impedance: 2-8Ω
Frequency
response: 20Hz-20kHz
Total
harmonic distortion: ＜0.4%
SNR
: ＞80dB
operational life.
PFA200
Class T Amplifier
The
PFA200
uses a Class-T audio amplifier
IC for low distortion and acoustically
accurate reproduction of music.
Tone/direct switching allows for
customized listening via separate bass and
treble adjustments — or the original signal
can be passed through without
enhancement.
The built-in loudspeaker protection circu it triggers when the amplifier is
turned on to protect speakers from high volume bursts of audio.
Over-voltage protection circuit shuts down the amplifier if input voltage
exceeds 14.4 V DC.
State of the art design using surf ace mount components and advanced
engineering for proven performance, reduced signal interference, and long
www.PyleUSA.com
718.535.1800 718.236.2400(fax)
1600 63rd Street, Brooklyn NY 11204
Front Inputs: 3.5mm (1/8”)
Rear Outputs: Speaker, RCA L/R, 1/4” Mic
