www.PyleUSA.com
battery compartment
button
This user manual contains important information for safe operation and optimal megaphone performance.
Please carefully read and follow safety notes and instructions. Save this manual for future reference.
Ensure it is available to all persons using this device.
PRECAUTIONS
• Ensure that plastic bags, packaging, etc., are removed.
• Never let children use electrical devices unattended.
• Observe proper polarity when inserting batteries. Incorrectly inserted batteries may cause damage & the risk of re.
• Leaking batteries can cause permanent damage to the device.
• Remove batteries if the megaphone will not be used for long periods.
Battery Insertion
• Ensure correct polarity of cells used. Insert the
batteries correctly by aligning the (-) marks on the
batteries with the spring in the back cover.
• Use new batteries/cells whenever possible.
• When the megaphone is not in use for a long
period, remove the dry cells and replace them.
Drained cells or rechargeable batteries may result
in insufficient sound volume.
SAFETY
This megaphone is intended to be used only as
described in this user manual. Any other use or use
under different operating conditions is considered
improper and may result in personal injury or device
damage. Please use the megaphone as described and
supervise its use when used by children or minors.
Press the button located near the back, underside of the megaphone.
The button will release the lid to reveal the battery compartment.
Observe the correct battery direction placement on the top side of the
opening battery compartment lid. Insert batteries, close the cover, and
secure the clip to lock it in place.
NOTE:
Make sure the batteries are inserted correctly, observing the correct
polarity.
Visit Our Website
SCAN ME
PyleUSA.com
USER GUIDE
Compact & Portable Megaphone Speaker
PMP31BL - PMP32GR - PMP33SL - PMP34PK
Speaker
Grip
Shoulder Strap
PA Talk Trigger Switch
Back Cover
Battery Container
www.PyleUSA.com
1. Open the back cover by pressing down on the 'battery
compartment button'.
2. Insert (4) x ‘D’ Batteries, then close the back cover until it
locks into position. Your megaphone is now ready to operate.
3. To activate the megaphone, press the 'ON/OFF' button on
the back cover.
4. Press Speak button to speak and unpress the button to play
music
5. When using the megaphone, place your lips as close as
possible to the megaphone when speaking.
Adjust the 'Volume' to the desired level without causing
howling or feedback.
5. Slide the switch on the rear of the megaphone to ‘ALARM’
button to activate emergency siren/alarm.
OPERATING INSTRUCTIONS
Music Mode
• Press the 'Music' button to activate soft music.
• Adjust the desired volume level using the rear slider switch on the megaphone.
Alarm/Siren Mode
• Press the 'ALARM' button to activate emergency siren/alarm.
• Adjust the desired volume level using the rear slider switch on the megaphone.
Features:
•
Compact Megaphone Speaker
• Portable Battery Operated Design
• (2) Audio Modes: Voice Talking & Siren Alert
• Voice Mode: Amplies Your Voice as Spoken into the
Microphone
• Siren Alert Mode: Button-Activated Emergency
Alarm Tone
• High-Powered PA Sound Projection
• Adjustable Volume Control
• Convenient Quick Folding Handle
• Ergonomic Pistol Grip and Mini Light-Weight Chassis
Technical Specs:
•
Power Output: 30 Watt MAX
• Audio Projection Range: Up to 800+ Yards
• Battery Operated: Requires (4) x ‘D’ Batteries, Not Included
• Power ON/OFF Switch
• Megaphone Size (Diameter x Length):
6.3’’ x 10.0’’-inches
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Register Product
Thank you for choosing PyleUSA.
By registering your product, you ensure
that you receive the full benets of our
exclusive warranty and personalized
customer support. Complete the form
to access expert support and to keep
your PyleUSA purchase in perfect
condition.
PyleUSA.com/register
Volume
control
Microphone
battery compartment
button
Speak/Music
Button
Alarm/Siren
Button
ON/OFF Button
