22 3
1U
Attaching mounting brackets to the switch
Attach cage nuts to the rack posts Mount the switch in the rack
Mounting the switch on a workbench
Attach the rubber feet to the switch bottom
BOM: 3101A13S
HIKVISION DS-3E2500-H & DS-3E3700-H Switch Series Installation Quick Start-APW100
Type B mounting bracket
Type A mounting bracket
Type A mounting bracket
Four screws are required to attach a Type A mounting bracket. Two screws are required to attach a
Type B mounting bracket.
Installation accessories
Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact and is reliably
grounded.
The installation tools are not provided with the switch. Prepare them yourself as required.
1
Flathead screwdriver Phillips screwdriver Needle-nose pliers ESD wrist strap Marker
Cage nutGrounding cable M6 screw
M4 countersunk-head screw
Tool list
!
Mounting brackets Rubber feet Grounding screw
Mounting the switch in a rack
The applicable mounting brackets vary by switch model. Some switch models provide two installation
positions on the two sides for mounting brackets: one at the port side and one at the power module
side. Select an installation position for the mounting brackets as required.
!
(Type A) (Type B)
The applicable installation accessories vary by switch model. Some accessories are not provided
with the switch. The packing list describes the accessories provided with the switch.
Cable tie
Example: Installation at the port side
Installation at the port side
Installation at the power module
side
Installation at the port side
1
2
