Panic Alarm Station
Quick Start Guide
User Manual
Hangzhou Hikvision Digital Technology CO.,Ltd. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China
COM1
GND
D+
D-
BELL
12 V
GND
AUDIO_IN AUDIO_OUT
GND
LAMP
GND
A1
GND
A2
NO1
NC1
COM2
NO2
NC2
N.O
N.C
N.O
N.C
+ -
1
1
2
2
3 4 5 6 7
8 9 10
190
10052
119 47
60
43
Online Device (2)
Add to Client
IP
xx.xx.xx.xx
xx.xx.xx.xx
xxxxxxxxxxxxx
xxxxxxxxxxxxx
xxxxxxxxxxxxx
xxxxxxxxxxxxx
xxxx-xx-xx xx:xx:xx
xxxx-xx-xx xx:xx:xx
8000
8000
Inactive
Active
Device Type Firmware Version Server PortSecurity Start Time
Add all Modify Netinfo
Reset Password Activate
Filter
Refresh Every 60s
485+ 485-
1
1
33
2
2
6
4
4
6
5
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter
are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to
rmware updates or other reasons. Please nd the latest version of this Manual at the Hikvision website (https://www.hikvi-
sion.com/).
Please use this Manual with the guidance and assistance of professionals trained in supporting the Product.
and other Hikvision's trademarks and logos are the properties of Hikvision in various jurisdictions. Other trademarks
and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY
SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED
ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF
THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE
ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK,
HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL
SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING
THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER
THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY,
INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT
OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE
OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.
This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the
applicable harmonized European standards listed under the RE Directive 2014/53/EU, the EMC Directive 2014/30/EU,
the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in
the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste
in the European Union. See the product documentation for specic battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more information see:www.recyclethis.info
FCC Information
Please take attention that changes or modication not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation
INSTALLATION CAUTION
The additional force shall be equal to three times the weight of the equipment but not less than 50N. The equipment
and its associated mounting means shall remain secure during the installation. After the installation, the equipment,
including any associated mounting plate, shall not be damaged.
1
2
4
3
WIRING
ACTIVATION
1. Camera 2. Speaker 3. Microphone 4. Panic Button 5. Consultation Button 6. Braille
Use iVMS-4200 to activate the device.
INSTALLATION
Specification
User Manual
Scan the QR code for more information and operation help.
1. Network 2, 100 M
1. Surface Mounting
2. Flush Mounting
Tamper-proof
2. Network1, 100 M, PoE 3.4. Audio, 3.5 mm
5. Antenna, 4G 6. Power Input: 12 VDC
7. Strobe light/sounder: 12 VDC, 500 mA
Note:Peripheralsneedexternal power supply if the station uses PoE power input.
8. RS-485 9. Alarm Input 10. Relay Output
The power supply of this device is made by Shenzhen Honor Electronic Co., Ltd and meets
LPS( Limited Power Source) . Do not change the adapter randomly. For PoE power supply,
it is required to use PoE power adapter or switch which compliants with LPS. The recommended
model and manufacturer are DS-3T0310HP-E/HS and Hangzhou Hikvision Digital Technology
Co., Ltd.
E N G L I S H
APPEARANCE
Product Information
138
44
70
6
106
229
196
210
13239
9.5
16.5
210
120
1
Modello
DS-PEAP-CV1(B)
DS-PEAP-CV2(B)
DS-PEAP-CV1E(B)
DS-PEAP-CV2E(B)
DS-PEAP-CVS1(B)
DS-PEAP-CVS2(B)
DS-PEAP-CVS1E(B)
DS-PEAP-CVS2E(B)
DS-PEAP-CVSA1(B)
DS-PEAP-CVSA2(B)
DS-PEAP-CVSA1E(B)
DS-PEAP-CVSA2E(B)
Telecamera Telecamera IR HD 4 MP
Campo visivo
Orizzontale: 103°
Verticale: 54°
Diagonale: 117°
Visualizzazione diurna e notturna Auto
Standard di compressione video H.264/H.265
Risoluzione 2560 × 1440
Ingresso audio
Microfono omnidirezionale integrato a 1 canale, distanza presa: 2 m
Interfaccia audio da 3,5 mm a 1 canale per ingresso audio sorgente esterna
Uscita audio
Altoparlante integrato da 3 W a 1 canale
Interfaccia audio da 3,5 mm a 1 canale per uscita audio esterna
Standard audio G.711U/AAC/OPUS/PCM/ADPCM
Qualità audio Soppressione del rumore e annullamento dell'eco
Integrazione Luce a infrarossi efficiente, distanza di irradiazione: 5 m
Porta Ethernet Porta Ethernet 10M/100M auto-adattiva
Protocollo di rete TCP/IP, RTSP
Trasmissione rete pubblica ISUP/Hik-connect/Standard SIP
Ingresso allarme Rilevamento manomissione
Interfaccia di rete 2 Porte Ethernet 10M/100M RJ45 auto-adattive
3G/4G No No Supportato Supportato Supportato Supportato
Interfaccia di alimentazione
1, 12 V CC
1, RJ45 PoE
Scheda SD Slot scheda Micro SD standard, supporta schede micro SD/SDHC/SDXC, max. 256 Gb
PSTN 1
Alimentazione 12 V CC, PoE, ≤40 W
Temperatura di esercizio Da -40 °C a +65 °C
Modalità di montaggio Superficie A filo Superficie A filo Superficie A filo
Umidità di esercizio 10%-90%
Livello di protezione IP65
Anti-deflagrante IK10
Braille sui tasti Supportato, in base al modello
Dimensioni (L x A x P) mm 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44
2
1
2
Modelo
DS-PEAP-CV1(B)
DS-PEAP-CV2(B)
DS-PEAP-CV1E(B)
DS-PEAP-CV2E(B)
DS-PEAP-CVS1(B)
DS-PEAP-CVS2(B)
DS-PEAP-CVS1E(B)
DS-PEAP-CVS2E(B)
DS-PEAP-CVSA1(B)
DS-PEAP-CVSA2(B)
DS-PEAP-CVSA1E(B)
DS-PEAP-CVSA2E(B)
Cámara Cámara IR HD de 4 Mpx.
Campo de visión (FOV)
Horizontal: 103°
Vertical: 54°
Diagonal: 117°
Día y noche Automática
Norma de compresión de vídeo H.264/H.265
Resolución 2560 × 1440
Entrada de audio
Micrófono omnidireccional integrado de 1 canal, distancia de captación: 2 m
Interfaz de audio de 3,5 mm de 1 canal para la entrada de audio externa
Salida de audio
Altavoz integrado de 3 W y un canal
Interfaz de audio de 3,5 mm y un canal para salida de audio externa
Norma de audio G.711U/AAC/OPUS/PCM/ADPCM
Calidad de audio Supresión del ruido y cancelación del eco
Suplemento Luz infrarroja eficaz, distancia de irradiación: 5 m
Puerto Ethernet Puerto Ethernet autoadaptativo de 10 M/100 M
Protocolo de red TCP/IP, RTSP
Transmisión de red pública ISUP/Hik-connect/Norma SIP
Entrada de alarma Detección de manipulación
Conector de red 2 puertos Ethernet RJ45 autoadaptativos de 10 M/100 M
3G/4G No No Compatible Compatible Compatible Compatible
Interfaz de alimentación
1, 12 VCC
1, RJ45 PoE
Tarjeta SD Ranura para tarjetas microSD tipo, compatible con microtarjetas SD/SDHC/SDXC, 256 G máx.
PSTN 1
Fuente de alimentación 12 VCC, PoE, ≤ 40 W
Temperatura de funcionamiento -40 ºC-65º C
Modo de montaje En superficie Empotrado En superficie Empotrado En superficie Empotrado
Humedad de funcionamiento 10% - 90%
Grado de protección IP65
Grado a prueba de explosiones IK10
Braille sobre el botón Compatible, depende del modelo
Dimensiones (mm) 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44
4
3
CABLAGGIO
ATTIVAZIONE
1. Telecamera 2. Altoparlante 3. Microfono 4. Pulsante antipanico
Utilizzare iVMS-4200 per attivare il dispositivo.
INSTALLAZIONE
Specifiche
Manuale dell'utente
Eseguire la scansione del codice QR per maggiori informazioni e aiuto sul funzionamento.
1. Rete 2, 100 M
1. Montaggio a parete
2. Montaggio a lo
Anti-manomissione
2. Rete1, 100 M, PoE 3.4. Audio, 3,5 mm
5. Pulsante di consultazione 6. Braille
5. Antenna, 4G 6. Ingresso di alimentazione: 12 V CC
7. Luce intermittente/allarme: 12 V CC 500 mA
Nota: Le periferiche necessitano di alimentazione esterna se la
stazione utilizza l’ingresso di alimentazione PoE.
8. RS-485 9. Ingresso allarme 10. Uscita relè
L’alimentazione di questo dispositivo è realizzata da Shenzhen Honor Electronic Co., Ltd e
soddisfa LPS. Non utilizzare un adattatore diverso da quello in dotazione.
I T A L I A N O
ASPETTO
4
3
CABLEADO
ACTIVACIÓN
1. Cámara 2. Altavoz 3. Micrófono 4. Botón de emergencia 5. Botón de consulta
Utilice el software iVMS-4200 para activar el dispositivo.
6. Braille
INSTALACIÓN
Especificación
Manual de usuario
Escanee el código QR para obtener más información y ayuda sobre el funcionamiento.
1. Red 2, 100 M
1. Montaje en supercie
2. Montaje empotrado
Antimanipulación
2. Network 1, 100 M, PoE 3.4. Audio, 3,5 mm
5. Antena, 4G 6. Alimentación de entrada: 12 VCC
La fuente de alimentación de este dispositivo ha sido fabricada por Shenzhen Honor Electronic
Co., Ltd. y cumple con el suministro eléctrico de baja tensión. No cambie el adaptador al azar.
E S P A Ñ O L
ASPECTO
2 2
1
4
3
CÂBLAGE
ACTIVATION
1. Caméra 2. Haut-parleur 3. Microphone 4. Bouton de panique
5. Bouton de consultation 6. Braille
Utilisez l’iVMS-4200 pour activer l’appareil.
INSTALLATION
Spécification
Manuel d’utilisation
Scannez le code QR pour obtenir plus d’informations et de l’aide sur le fonctionnement.
1. Réseau 2, 100 Mbit/s
1. Montage en surface
2. Montage encastré
Antisabotage
2. Réseau 1, 100 Mbit/s, PoE 3.4. Audio, 3,5 mm
5. Antenne, 4G 6. Entrée d’alimentation : 12 V CC
7. Lumière stroboscopique/sirène : 12 V CC, 500 mA
Remarque : Les périphériques ont besoin d’une alimentation électrique
externe si la station utilise l’entrée PoE.
8. RS-485 9. Entrée d’alarme 10. Sortie du relais
L’alimentation de cet appareil est réalisée par la société Shenzhen Honor Electronic Co., Ltd
et répond aux normes LPS. Ne remplacer pas l’adaptateur par un adaptateur de type
diérent.
F R A N Ç A I S
ASPECT
Modèle
DS-PEAP-CV1(B)
DS-PEAP-CV2(B)
DS-PEAP-CV1E(B)
DS-PEAP-CV2E(B)
DS-PEAP-CVS1(B)
DS-PEAP-CVS2(B)
DS-PEAP-CVS1E(B)
DS-PEAP-CVS2E(B)
DS-PEAP-CVSA1(B)
DS-PEAP-CVSA2(B)
DS-PEAP-CVSA1E(B)
DS-PEAP-CVSA2E(B)
Caméra Caméra IR HD 4 Mpx
FOV
Horizontal : 103°
Vertical : 54°
Diagonal : 117°
Jour et nuit Automatique
Norme de compression vidéo H.264/H.265
Résolution 2560 × 1440
Entrée audio
Microphone omnidirectionnel intégré 1 canal, distance de prise de son : 2 m
Interface audio monocanal 3,5 mm pour l’entrée audio externe
Sortie audio
Haut-parleur intégré 1 canal 3 W
Interface audio 1 canal 3,5 mm pour la sortie audio externe
Norme audio G.711U/AAC/OPUS/PCM/ADPCM
Qualité audio Suppression du bruit et annulation de l’écho
Fonction supplémentaire Éclairage IR efficace, distance de rayonnement : 5 m
Port Ethernet Port Ethernet autoadaptatif de 10/100 Mbit/s
Protocole de réseau TCP/IP, RTSP
Transmission sur le réseau public ISUP/Hik-connect/Standard SIP
Entrée d’alarme Détection de sabotage
Interface réseau 2 ports RJ45 Ethernet autoadaptatif 10/100 Mbit/s
3G/4G Non Non Pris en charge Pris en charge Pris en charge Pris en charge
Interface d’alimentation
1 port 12 V CC
1 port RJ45 PoE
Carte mémoire SD Fente pour carte microSD standard, prise en charge des cartes microSD/SDHC/SDXC, 256 Go max.
RTPC 1
Alimentation électrique 12 V CC, PoE, ≤ 40 W
Température de fonctionnement -40 à + 65 °C
Mode de montage Surface Encastrement Surface Encastrement Surface Encastrement
Humidité de fonctionnement 10 à 90 %
Niveau de protection IP65
Niveau antidéflagrant IK10
Bouton avec inscription en braille Prise en charge, selon le modèle
Dimensions (L × H × P) mm 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44
1
4
3
VERKABELUNG
AKTIVIERUNG
1. Kamera 2. Lautsprecher 3. Mikrofon 4. Paniktaste 5. Beratungstaste
7. Luz estroboscópica/altavoz: 12 VCC, 500 mA
Nota: Los periféricos necesitan alimentación externa si la estación usa
una entrada de alimentación PoE.
8. RS-485 9. Entrada de alarma 10. Salida de relé
Verwenden Sie iVMS-4200 zur Aktivierung des Geräts.
INSTALLATION
Technische Daten
Benutzerhandbuch
Scannen Sie den QR-Code für weitere Informationen und Bedienungshilfen.
1. Network 2, 100 Mbit/s
1. Aufputzmontage
2. Unterputzmontage
Sabotagesicherheit
2. Netzwerk 1, 100 Mbit/s, PoE 3.4. Audio, 3,5 mm
6. Blindenschrift
5. Antenne, 4G 6. Eingangsstrom: 12 V DC
7. Stroboskoplicht/Sirene: 12 V DC, 500 mA
Hinweis: Peripheriegeräte benötigen eine externe Stromversorgung,
wenn die Station den PoE-Stromversorgungseingang nutzt.
8. RS-485 9. Alarmeingang
10. Relaisausgang
Das Netzteil dieses Geräts wird von Shenzhen Honor Electronic Co., Ltd. hergestellt und
entspricht LPS. Nur das Originalnetzteil verwenden.
D E U T S C H
AUFBAU
Modell
DS-PEAP-CV1(B)
DS-PEAP-CV2(B)
DS-PEAP-CV1E(B)
DS-PEAP-CV2E(B)
DS-PEAP-CVS1(B)
DS-PEAP-CVS2(B)
DS-PEAP-CVS1E(B)
DS-PEAP-CVS2E(B)
DS-PEAP-CVSA1(B)
DS-PEAP-CVSA2(B)
DS-PEAP-CVSA1E(B)
DS-PEAP-CVSA2E(B)
Kamera 4-MP-HD-IR-Kamera
FOV
Horizontal: 103°
Vertikal: 54°
Diagonal: 117°
Tag und Nacht Automatisch
Videokompressionsstandard H.264/H.265
Auflösung 2560 × 1440
Audioeingang
Integriertes omnidirektionales 1-kanaliges Mikrofon, Aufnahmereichweite: 2 m
1-Kanal 3,5 mm Audiobuchse für externen Audioeingang
Audioausgang
Integrierter 1-kanaliger 3-W-Lautsprecher
1-kanaliger 3,5-mm-Audio-Anschluss für externe Audioausgabe
Audiostandard G.711U/AAC/OPUS/PCM/ADPCM
Audioqualität Rausch- und Echounterdrückung
Zusatz Effizientes IR-Licht, Strahlungsreichweite: 5 m
Ethernet-Anschluss Selbstanpassender 10/100-Mbit/s-Ethernet-Anschluss
Netzwerkprotokoll TCP/IP, RTSP
Übertragung über das öffentliche Netz ISUP/Hik-connect/Standard-SIP
Alarmeingänge Sabotageerkennung
Netzwerkanschluss 2 selbstanpassende RJ45-10-/100-Mbit/s-Ethernet-Anschlüsse
3G/4G Nein Nein Unterstützt Unterstützt Unterstützt Unterstützt
Stromversorgungsanschluss
1 12 V DC
1 RJ45 PoE
SD-Karte Steckplatz für Standard-MicroSD-Karte, Unterstützung von microSD, SDHC/SDXC-Karte, max. 256 GB
PSTN 1
Spannungsversorgung 12 VDC, PoE, ≤40 W
Betriebstemperatur -40 °C bis +65 °C
Montagemodus Aufputz Unterputz Aufputz Unterputz Aufputz Unterputz
Betriebsfeuchtigkeit 10% bis 90%
Schutzklasse IP65
Explosionsschutzklasse IK10
Braille (Blindenschrift) auf Taste Unterstützt, je nach Modell
Abmessungen (B x H x T) mm 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44
UD30843B
Model
DS-PEAP-CV1(B)
DS-PEAP-CV2(B)
DS-PEAP-CV1E(B)
DS-PEAP-CV2E(B)
DS-PEAP-CVS1(B)
DS-PEAP-CVS2(B)
DS-PEAP-CVS1E(B)
DS-PEAP-CVS2E(B)
DS-PEAP-CVSA1(B)
DS-PEAP-CVSA2(B)
DS-PEAP-CVSA1E(B)
DS-PEAP-CVSA2E(B)
Camera 4 MP HD IR Camera
FOV
Horizontal: 103°
Vertical: 54°
Diagonal: 117°
Day & night Auto
Video compression standard
H.264/H.265
Resolution 2560*1440
Audio input
1-ch Built-in Omnidirectional Microphone, Pickup Distance: 2 m
1-ch 3.5 mm Audio Interface for External Audio Input
Audio Output
1-ch 3 W Build-in Loudspeaker
1-ch 3.5 mm Audio Interface for External Audio Output
Audio standard G.711U/AAC/OPUS/PCM/ADPCM
Audio quality Noise Suppression and Echo Cancellation
Supplement Ecient IR light, irradiation distance: 5 m
Ethernet port 10 M/100 M Self-adaptive Ethernet Port
Network protocol TCP/IP, RTSP
Public network
transmission
ISUP/Hik-connect/Standard SIP
Alarm input Tampering detection
Network interface 2 RJ45 10 M/100 M Self-adaptive Ethernet Port
3G/4G No No Supported Supported Supported Supported
Power supply interface
1, 12 VDC
1, RJ45 PoE
SD card Standard Micro SD Card Slot, Supports Micro SD/SDHC/SDXC Card, Max. 256G
PSTN 1
Power Supply 12VDC, PoE, ≤40W
Operation temperature -40 °C to +65 °C
Mounting mode Surface Flush Surface Flush Surface Flush
Operation humidity
10％-90％
Protective level IP65
Explosion-proof level IK10
Braille on button Supported, depends on the model
Dimension(W × H × D)mm 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44 190 × 119 × 47 229 × 138 × 44
Loading ...
Loading ...
Loading ...
