Welcome to AEG! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION AND INSTALLATION............................................. 2
2. PRODUCT DESCRIPTION............................................................................. 2
3. DAILY USE......................................................................................................3
4. CARE AND CLEANING.................................................................................. 5
5. ENVIRONMENTAL CONCERNS....................................................................6
1. SAFETY INFORMATION AND INSTALLATION
WARNING!
Refer to the separate Installation
Instructions booklet for Safety
Information and Installation. Read
carefully the Safety chapters before any
use or maintenance of the appliance.
2. PRODUCT DESCRIPTION
2.1 Control panel overview
1 2 3 4 5 6 7 8 9 10
Function Description
1
On / Off Turns the hood on and off.
2
First speed The fan switches to first speed level.
3
Second speed The fan switches to second speed level.
4
Third speed The fan switches to third speed level.
5
Maximum speed The fan switches to maximum speed level. After 8 minutes the appli‐
ance returns to previous setting.
2 ENGLISH
Function Description
6
Breeze The hood operates on the lowest speed. After 60 minutes the appli‐
ance turns off.
7
Hob²Hood Indicator of the function to control hood from hob.
8
Filter notification Reminds to change or clean the charcoal filter and clean the grease
filter.
9
Light colour temperature Changes the light colour temperature.
10
Lamp Turns the lights on and off. Changes the light intensity.
3. DAILY USE
3.1 Using the hood
Check the recommended speed according to
the table below.
While heating up food, cooking with covered
pots.
While cooking with covered pots on multiple
cooking zones or burners, gentle frying.
While boiling and frying big quantities of food
without a lid, cooking on multiple cooking
zones or burners.
While boiling and frying big quantities of food
without a lid, big humidity.
Refreshes the air in kitchen after cooking at a
very low noise level. The function turns off au‐
tomatically after 60 minutes. Use after cooking
only.
It is recommended to leave the hood
operating for approximately 15 minutes
before and after cooking.
Activating the appliance
To operate the hood:
1. Pull out the drawer of the hood to switch
on the control panel.
You can now activate the functions.
2. To activate the function, touch the
corresponding symbol.
If the fan speed is not set within one
minute after switching on the hood, the
control panel will deactivate. To activate
it again, touch the symbol.
Deactivating the appliance
To turn off the appliance touch symbol
again or close the hood drawer.
When the drawer is closed, the last fan
speed setting will be saved. When the
drawer is pulled out again, the hood will
operate at the last selected fan speed.
Perfect Illumination - Lighting
The hood lighting works independently to
other hood functions.
Activating and deactivating the lighting
To illuminate the cooking surface touch the
symbol. Touch the symbol again to
change the light intensity in the following
order: Maximum, Medium, Low, Off.
To switch off the lights, touch and hold the
symbol for 3 seconds. Closing the drawer has
no effect on the hood light.
ENGLISH 3
Setting the light colour temperature
The hood remembers the last setting of
the light colour temperature.
There are two ways to set the light colour
temperature:
1. Touch the symbol to change the
colour temperature from neutral, through
warm to cold.
2. Touch and hold the symbol to move
smoothly between light colour
temperatures.
Release it once you reach the desired
setting.
3.2 Hob²Hood function
It is an automatic function which connects the
hob with a hood. Both the hob and the hood
have an infrared signal communicator. Speed
of the fan is defined automatically on basis of
mode setting and temperature of the hottest
cookware on the hob. You can also operate
the fan using the hob manually. The function
can be activated from panel of the hob.
If the hood drawer is closed, the
Hob²Hood will only activate the hood
light. The fan will remain off.
If the drawer is open, the function will
activate both the hood light and the fan.
For more information how to use the
function, refer to the hob user manual.
3.3 Filter notification
Filter alarm reminds to change or clean the
charcoal filter and clean the grease filter. The
symbol blinks regularly for 30 seconds if
the grease filter must be cleaned. The
symbol blinks twice per every second for 30
seconds if the charcoal filter must be
replaced.
This function activates independently
after 40 hours of operation for grease
filter and 160 hours of operation for
charcoal filter.
Refer to Cleaning the grease filter in the
Care and cleaning chapter.
Refer to Replacing the charcoal filter in
the Care and cleaning chapter.
The function counter for charcoal filter is
disabled by default. For recirculation
mode, it must be activated.
To activate or deactivate the counter for
charcoal filter:
1. Pull out the hood drawer.
2. Make sure the fan and the light are turned
off.
3. Touch symbol for 3 seconds.
The function is activated if symbol
blinks
once. The function is deactivated if symbol
blinks twice.
To reset the function counter in the
notification period:
1. Pull out the hood drawer.
2. Touch
symbol for 3 seconds.
The symbol stops blinking for the correct
reset.
4 ENGLISH
4. CARE AND CLEANING
4.1 Notes on cleaning
Cleaning Agents
Do not use abrasive detergents and brushes.
Clean the surface of the appliance with a soft cloth with warm water and a mild detergent.
After cooking some parts of appliance can get hot. To avoid stains appliance must be
cooled down and dried with clean cloth or paper towels.
Clean stains with a mild detergent.
Keep the hood
clean
Clean the appliance and grease filters each month. Clean the interior and grease filters
carefully from fat. Fat accumulation or other residue may cause fire.
Grease filters can be washed in a dishwasher.
The dishwasher must be set to a low temperature and a short cycle. The grease filter may
discolour, it has no influence on the performance of the appliance.
Charcoal filter
The time of saturation of the charcoal filter varies depending on the type of cooking and
the regularity of cleaning the grease filter. The activated charcoal filter is not washable,
cannot be regenerated and must be replaced approximately every 4/6 months of opera‐
tion, or more frequently for particularly heavy usage.
Before carrying out any maintenance,
make sure there is no cookware on the
hob and that the hood and the hob are
disconnected from the power supply.
4.2 Cleaning the grease filter
Filters are mounted with the use of clips and
pins on the opposite side.
To clean the filter:
1. Pull the cover to open it.
2. Pull the handle on the filter underneath
the hood and slightly tilt the front of the
filter down.
1
3. Clean the filters using a sponge with non
abrasive detergents or in a dishwasher.
The dishwasher must be set to a low
temperature and a short cycle. The
grease filter may discolour, it has no
influence on the performance of the
appliance.
4. To mount the filters back follow the first
two steps in reverse order.
Repeat the steps for all filters if applicable.
ENGLISH 5
4.3 Replacing the charcoal filter
WARNING!
The charcoal filter is non-washable!
To replace the filter:
1. Remove the grease filters from the
appliance.
Refer to "Cleaning the grease filter" in this
chapter.
2. Pull the tabs towards the bottom part of
the filter.
2
1
1
3. Slightly tilt the front of the filter
downwards, then pull.
4. To install a new filter, refer to the
separate Installation Instructions booklet.
In any case, it is necessary to replace the
filters at least every four months.
4.4 Replacing the lamp
This appliance is supplied with a LED lamp
and separate control gear (LED driver).
These parts can be replaced by a technician
only. In case of any malfunction refer to
"Service" in the "Safety Instructions" chapter.
5. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
