User Manual
HMDNB 5182WK
HMDNB 5182XK
HMDNB 5182WWDK
HMDNB 5182XWDK
CONTENTS
1. Safety 1
2. Proper use of the refrigerator 11
2.1 Placement 11
2.2 Leveling feet 12
2.3 Door right-left change 12
2.4 Changing the light 15
2.5 Starting 15
3. Structure and fuctions 16
3.1 Key components 16
3.2 Functions 17
4. Maitenance and care of the refrigerator 19
4.1 Overall cleaning 19
4.2 Cleaning the glass shelf 19
4.3 Defrosting 19
4.4 Out of operation 19
5. Troubleshooting 20
Thank you for purchasing this product.
Before using your refrigerator, please carefully read this instruction manual in order to
maximize its performance. Store all documentation for subsequent use or for other owners.
This product is intended solely for household use or similar applications such as:
- the kitchen area for personnel in shops, offices and other working environments
- on farms, by clientele of hotels, motels and other environments of a residential type
- at bed and breakfasts (B & B)
- for catering services and similar applications not for retail sale.
This appliance must be used only for purposes of storage of food, any other use is considered
dangerous and the manufacturer will not be responsible for any omissions. Also, it is
recommended that you take note of the warranty conditions.
SAFETY INFORMATION
Please read the operating and installation instructions carefully!
They contain important information on how to install, use and maintain the
appliance.
The manufacturer is not liable if you fail to comply with the instructions
and warnings.
Retain all documents for subsequent use or for the next owner.
• Do not connect the appliance to the electricity
supply until all packing and transit protectors
have been removed. Keep children away from
packaging and its parts.
Danger of suffocation from folding cartons and
plastic film!
• Leave to stand for at least 4 hours before
switching on the product, to allow compressor
oil to settle if transported horizontally.
• Make sure there is no transport damage.
1. SAFETY
1
• Do not damage the refrigerant circuit.
• Maintain the ventilation openings in the
appliance enclosure or in the built-in
structure, free of obstruction.
• Never use water to wash the compressor
position, wipe it with a dry cloth thoroughly
after cleaning to prevent rust.
• Handle the appliance always with at least two
persons because it is heavy.
• Install and level the appliance in an area
suitable for its size and use.
• Make sure that the electrical information on
the rating plate agrees with the power supply.
If it does not, contact an electrician.
• The appliance is operated by a 220-240
VAC/50 Hz power supply. Abnormal voltage
fluctuation may cause the appliance to fail to
start, or damage to the temperature control or
compressor, or there may be an abnormal
noise when operating. In such case, an
automatic regulator shall be mounted.
• Only for UK: The appliance’s power cable is
fitted with 3-cord (grounding) plug that fits a
standard 3-cord (grounded) socket. Never cut
off or dismount the third pin (grounding). After
the ap- pliance is installed, the plug should be
accessible.
• Make sure that mains cable is not caught under
2
the appliance during and after
carrying/moving the appliance, to avoid the
mains cable becoming cut or damaged. If the
supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified person in order to avoid a hazard.
• Do not install the appliance in humid, oily or
dusty places, nor expose it to direct sunlight
and to water.
• Do not install the appliance near heaters or
inflammable materials.
• FOR appliances with a freezer compartment: if
there is a power failure do not open the lid.
Frozen food should not be affected if the failure
lasts for less than the hours indicated on the
rating label (Temperature rise time). If the
failure is longer, then the food should be
checked and eaten immediately or cooked and
then refrozen.
• If you find that the lid of the appliance is
difficult to open just after you have closed it,
don’t worry. This is due to the pressure
difference which will equalize and allow the lid
to be opened normally after a few minutes.
• Do not store medicines, bacteria or chemical
agents in the appliance. This appliance is a
household appliance, it is not recommended to
store materials that require strict
temperatures.
3
• Do not excessively pull or fold the power cord
or touch the plug with wet hands.
• Do not store products which contain
flammable propellant (e.g. spray cans) or
explosive substances in the appliance. Risk of
explosion!
• Do not place unstable articles (heavy objects,
containers filled with water) on top of the
refrigerator, to ovoid personal injury caused
by falling or electric shock caused by contact
with water.
• Do not use electrical appliances inside the food
storage compartments, unless they are of the
type recommended by the manufacturer.
• Do not touch internal cooling elements,
especially with wet hands, to avoid cracks or
injuries.
• At risk here are children, people who have
limited physical, mental or sensory abilities, as
well as people who have inadequate
knowledge concerning safe operation of the
appliance.
• Check that children and vulnerable people
have understood the hazards. A person
responsible for safety must supervise or
instruct children and vulnerable people who
are using the appliance. Only children aged 8
years and above may use the appliance.
4
• Children should not play with the appliance.
• Children aged from 3 to 8 years are allowed to
load and unload this appliance.
• FOR appliances with a freezer compartment:
do not store bottled or canned liquids
(especially carbonated drinks) in the freezer
compartment. Bottles and cans may burst!
• FOR appliances with a freezer compartment:
never put frozen food straight from the freezer
compartment in your mouth. Risk of low-
temperature burns!
• Keep plastic parts and the door seal free of oil
and grease. Otherwise, plastic parts and the
door seal will become porous.
• Before performing any operation, unplug the
power cord from the power socket.
• Do not use mechanical devices or other means
to accelerate the defrosting process, other than
those recommended by the manufacturer.
• Do not use pointed or sharp-edged objects such
as knives or forks to remove the frost.
• Never use hairdryers, electrical heaters or
other such electrical appliances for defrosting.
• It is recommended to keep the plug clean, any
excessive dust residues on the plug can be the
cause fire.
• Do not try to repair, disassemble or modify the
appliance by yourself. In case of repair please
5
contact always our customer service.
• Supervise children while the appliance is being
cleaned or maintained.
• Do not clean the cold glass shelves with hot
water. Sudden temperature change may cause
the glass to break.
• WARNING: The tubes of the refrigeration
circuit convey a small quantity of an
environmentally friendly but flammable
refrigerant (R600a) and insulating gas
(cyclopentane). It does not damage the ozone
layer and does not increase the greenhouse
effect. If refrigerant escapes, it may injure your
eyes or ignite.
• If the refrigerant circuit should be damaged:
- Switch off the appliance and pull out the
mains plug,
- Keep naked flames and/or ignition sources
away from the appliance,
- Thoroughly ventilate the room for several
minutes,
- Inform customer service.
• WARNING: Do not damage the plug and/or the
power cord; this could cause electrical shocks
or fires.
• WARNING: Do not use multiple portable
socket-outlets or portable power supplies. We
do not recommend the use of extension leads
and multi-way adapters.
6
• Do not attempt to sit or stand on the top of the
appliance. You could injure yourself or damage
it. This appliance is not designed for stacking
with any other ones.
• The product is designed and built for domestic
household use only.
• Only original parts supplied by the
manufacturer may be used. The manufacturer
guarantees that only these parts satisfy the
safety requirements.
• Opening the door for long periods can cause a
significant increase of the temperature in the
compartments of the appliance.
- Clean regularly surfaces that can come in
contact with food and accessible drainage
systems.
- Clean water tanks if they have not been used
for 48h; flush the water system connected to a
water supply if water has not been drawn for 5
days.
- Store raw meat and fish in suitable containers
in the refrigerator, so that it is not in contact
with or drip onto other food.
- Two-star frozen-food compartments(if they
are presented in the appliance) are suitable for
storing pre-frozen food, storing or making ice-
cream and making ice cubes.
- One-, two- and three -star compartments, if
present in the appliance, are not suitable for
7
the freezing of fresh food.
- If the appliance is left empty for long periods,
switch off, defrost, clean, dry and leave the
door open to prevent mould developing within
the appliance.
• FOR Wine Coolers: this appliance is intended to
be used exclusively for the storage of wine
• FOR a free standing appliance: this
refrigerating appliance is not intended to be
used as a built-in appliance
• FOR appliances without a 4-star compartment:
this refrigerating appliance is not suitable for
freezing foodstuffs
8
SCRAPPING OLD APPLIANCES
This appliance is marked according to the European directive 2012/19/EU on Waste
Electrical and Electronic Equipment (WEEE).
WEEE contains both polluting substances (which can cause negative consequences for the
environment) and basic components (which can be re-used). It is important to have WEEE
subjected to specific treatments, in order to remove and dispose properly all pollutants, and
recover and recycle all materials.
Individuals can play an important role in ensuring that WEEE does not become an
environmental issue; it is essential to follow some basic rules:
- WEEE should not be treated as household waste;
- WEEE should be handed over to the relevant collection points managed by the
municipality or by registered companies. In many countries, for large WEEE, home
collection could be present.
In ma
ny countries, when you buy a new appliance, the old one may be returned to the retailer
who has to collect it free of charge on a one-to-one basis, as long as the equipment is of
equivalent type and has the same functions as the supplied equipment.
Conformity
By placing the mark on this product, we are confirming compliance to all relevant
European safety, health and environmental requirements which are applicable in legislation
for this product.
Guarantee
Minimum guarantee is: 2 years for EU Countries, 3 years for Turkey, 1 year for UK, 1 year for
Russia, 3 years for Sweden, 2 years for Serbia, 5 years for Norway, 1 year for Morocco, 6
months for Algeria, Tunisia no legal warranty required.
9
Energy Saving
For better energy saving we suggest :
• Installing the appliance away from heat sources and not exposed to direct sunlight
and in a well ventilated roo.
• Avoid putting hot food into the refrigerator to avoid increasing the internal
temperature and therefore causing continuos functionaliting of the compressor.
• Do not excessively stuff foods so as to ensure proper air circulation.
• Defrost the appliance in case there is ice to facilitate the transfer of cold.
• In case of absence of electrical energy, it is advisable to keep the refrigerator door
closed.
• Open or keep the doors of the appliance open as little as possible
• Avoid adjusting the setting to temperatures too cold.
• Remove dust present on the rear of the appliance
10
2 Proper use of refrigerators
2.1 Placement
�
1'1
m
•
Before use, remove all packing materials, including bottom cushions,
foam pads and tapes inside of the refrigerator; tear off the protective
film on the doors and the refrigerator body.
•
Keep away from heat and avoid direct sunlight. Do not place the
freezer in moist or watery places to prevent rust or reduction of
insulating effect.
•
Do not spray or wash the refrigerator; do not put the refrigerator in
moist places easy to be splashed with water so as not to affect the
electrical insulation properties of the refrigerator.
•
The refrigerator is placed in a well-ventilated indoor place; the ground
shall be flat, and sturdy (rotate left or right to adjust the wheel for
levelling if unstable).
•
The top space of the refrigerator shall be greater than 30cm, and the
refrigerator should be placed against a wall with a free distance more
than 10cm to facilitate heat dissipation.
0 Precautions before installation:
Before installation or adjusting of accessories, it shall be ensured that the refrigerator is
disconnected from power.
Precautions shall be taken to prevent fall of the handle from causing any personal injury.
Install this appliance at a location where the ambient temperature corresponds to the climate class
indicated on the rating plate of
the appliance:
- extended temperate: this refrigerating appliance is intended to be used at ambient temperatures
ranging from 10 °Clo 32 °C; (SN)
- temperate: this refrigerating appliance is intended to be used at ambient temperatures ranging from
16 °C to 32 °C;(N)
- subtropical: this refrigerating appliance is intended to be used at ambient temperatures ranging from
16 °C to 38 °C;(ST)
- tropical: this refrigerating appliance is intended to be used at ambient temperatures ranging from 16
°C to 43 °C;(T)
11
2.2 Leveling feet
Schematic diagram of the leveling feet
H
{The picture above is only for reference.The actual configuration will depend on the physical product
or statement by the distributor)
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
2.3 Door right-left change
List of tools to be provided by the user
�-
q
Putty knife
Cross screwdriver
thin-blade screwdriver
�
5/16"
�
Masking tape
socket and ratchet
Parts to be used for door reverse
Number
Name
Num.
Note
1
Right upper hinge
1
Pre-installed on the refrigerator, removed when the door is reversed, and kept for future use
2
Upper right hinge cover
1
Pre-installed on the refrigerator, removed when the door is reversed, and kept for future use
3
Hole cover
1
Pre-installed on the refrigerator, still used when door is reversed
4
Door lamp switch
1
Pre-installed on the right upper hinge cover. remove it and install it on the left hinge cover
5
Lower hinge
1
Pre-installed on the refrigerator, still used when doo is reversed
6
Leveling feet
1
Pre-installed on the refrigerator, still used when door is reversed
7
Decorative cover
1
Pre-installed on the refrigerator, still used when door is reversed
8
Upper hinge cover
1
Pre-installed on the refrigerator, still used when door is reversed
9
Middle hinge
1
Pre-installed on the refrigerator, still used when doo is reversed
10
Middle decorative cover
1
I
n the attached plastic bag, take them out for use when door is reversed
11
Left upper hinge
1
I
n the attached plastic bag, take them out for use when door is reversed
12
Upper left hinge cover
1
I
n the attached plastic bag, take them out for use when door is reversed
12
1 )Please power off this appliance before conduct this operation. Remove all food from door shelves.
2. Remove the upper left hinge cover decorative cover, upper right hinge cover and upper right hinge,
and disconnect the signal line at the top of the box body
3. Remove the refrigerated door body (be careful not to lose small parts such as the shaft sleeve and
stop on the door);
Remove the middle hinge and remove the decorative cover of hinge hole on the other side.
hinge
4. Remove the freezing door body (be careful not to lose small parts such as the shaft sleeve and stop
on the door);
Remove the hinge and adjust the angle. Remove and install the lower hinge shaft to the other side of
the hinge, and install the modified lower hinge to the other side of the box.
13
5. Change the refrigerator door:
1) Remove the door stop and cap of the upper end cover of the refrigeration door and install them at
the left and right swap positions.
2) Remove the door self-locking, door stop and shaft sleeve of the refrigeration door, install them on
the other side of the refrigeration door.
"
6. Change the freezing door:
1) Remove the shaft sleeve and cap of the upper end cover of the freezing door and install them at
the left and right swap positions.
2) Remove the door self-locking, door stop and shaft sleeve of the freezing door, install them on the
other side of the freezing door.
7. Install the replaced freezing door on the lower hinge, then install the middle hinge and cover the
hinge hole decorative cover.
decorative cover
I
.
.
:::JJI
'
):;,-..
0
1
4
8. Remove the upper left hinge cover and upper left hinge from the accessory bag.
Place the refrigerated door body on the middle hinge and install the upper left hinge. Connect the
refrigerator left top door switch signal line to the left hinge switch line , replace the hinge decorative
cover to the right side of the box body (note: when replacing the hinge decorative cover to the right side
of the box body, the two inserts on the hinge decorative cover (as shown in the figure) shall be cut off)
�--';
I
-----
---
-1
I
I I
N
I I
I
� ___
--
--
--
---
--
-
(The picture above is only for reference.The actual configuration will depend on the physical product
or statement by the distributor)
2.4 Changing the Light
Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its
service agent or similar qualified person.
2.5 Starting
545
v
�
• Before initial start, keep the refrigerator still for two hours before
connecting it to power supply.
• Before putting any fresh or frozen foods, the refrigerator shall have run for
2-3 hours, or for above 4 hours in summer when the ambient temperature
is high.
• Spare enough space for convenient opening of the doors and drawers or
statement by the distributor.
15
3 Structure and functions
3.1 Key components
Fru
vegeta
LED light
~" l
Shelf 2
its &
bles box
Multifunctio
nal soace
Pizza box
Drawer
��
I
1
1
i'
<·
I
I
I
II
I
I
I
I
I I
=
Door switch
�
Door tray
I
(The picture above is only for reference. The actual configuration will depend on the physical
product or statement by the distributor)
The most energy saving configuration requires drawers, food box and shelves to be positioned in
the product
;
please refer to above pictures.
Refrigerating chamber
• The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and other
food consumed in the short term. Cooking foods shall not be put in the refrigerating chamber until cooled
to r
oom temperature.
• Foods are recommended to be sealed up before putting into the refrigerator.
• The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use.
The easy storage box is placed under the fruit&vegetable box at the factory and can be adjusted to under
shelf 2. The box is of lower temperature when it's under the fruit&vegetable box and can be used to store
• meat or eggs for a short time . It's warmer when placed under shelf 2 ,and can be used to store foods
which suit the fridge , in the mean while the multifunctional space can store beer and beverage, etc.
Freezing chamber
• The low temperature freezing chamber may keep food fresh for a long time and it is mainly used to store
frozen foods and making ice.
• The freezing chamber is s
uitable for storage of meat, fish, rice balls and other foods not to be
consumed in short term.
• Chunks of meat are preferably to be divided into small pieces for quick freezing and easy access.
Please be noted food shall be consumed within the shelf time.
• The pizza box is des
igned to store pizza , icecream , etc. and can be turned over. When it's turned over,
the room will be released and you can put some large food in the first drawer.
16
3.2 Functions
Setting key
LEDl
LED2 LED3
LED4
LEDS
LED6
-16 -18
-24 8�
5�
n
SETTING
TEMP.CONTROL
L
SUPER FREEZE
L
SUPER COOL
(The picture above is only for reference.The actual configuration will depend on the physical product
or statement by the distributor)
1. When the power is on for the first lime, full display shall last for 3 seconds, then enter into the
normal operation display;
(When the power is on for the first time, the setting temperature of refrigerator and freezer is 5
°
(/-
18
0
( respectively)
When there is a fault, the fault code is displayed; when there is no fault, the setting range of the
refrigeration compartment is displayed.
The display screen is always on when the door is open while the display screen is always off when
the door is closed;
2. Key operation
After each key operation of temperature adjustment , the corresponding set temperature flashes for
3
S
;
�
In the refrigeration temperature setting mode, long press the setting key
TEM�o,
for 3S to switch to
the freezing temperature selling mode;
In the freezing temperature setting mode, long press the setting key �
for 3S to switch to the
refrigeration temperature setting mode;
TEMe.coN .. o,
3. Locking and unlocking
The locking state shall be automatically entered after 30 seconds without key operation;
No manual lock/unlock settings;
4.When setting the refrigerating temperature, the temperature will cycle in the following order each
lime the setting key is pressed. In the super cool state, LED4 and LED6 will light up at the same
ti meas shown below:
s
a
SUPER COOL
17
5. Freezer setting
When setting the freezer temperature, the temperature will cycle in the following order each time the
setting key is pressed. In the super freeze state, LED1 and LED3 will light up at the same time.as
shown below:
c
-2
4
-
1 B
-
1
6
SUPERFREEZE
1
Recommended setting: Refrigerating chamber 4 °C, Freezing chamber - 18 °C.
6. When the door is opened, the display screen and the corresponding chamber lamp are on. There
is no door opening prompt tone and door opening alarm.
7. Fault indication
The following warnings appearing on the display indicate corresponding faults of the refrigerator. Though
the refrigerator may still have cold storage function with the llowing faults, the user shall contact
a maintenance specialist for maintenance, so as to ensure optimized operation of the appliance.
Fault code
Fault description
LED1, LED
6
flash
Refrigerator temperature sensor fault
LED1, LED3 flash
Freezer temperature sensor fault
LED1, LED5 flash
Frozen defrosting sensor fault
LED1, LED
4
flash
Ambient temperature fault
18
Tips for storing food
• It’s suggested to set the temperature at 4°C in the fridge compartment, and,
whether possible, at -
18°C in the freezer compartment.
• For most food categories, the longest storage time in the fridge compartment is
achieved with colder temperatures. Since some particular products (as fresh
fruits and vegetables) may be damaged with colder temperatures, it is
suggested to keep them in the crisper drawers, whenever present. If not
present, maintain an average setting of the thermostat.
• For frozen food, refer to the storage time written on the food packaging. This
storage time is achieved whenever the setting respects the reference
temperatures of the compartment (one-star -6°C, two stars -12°C, three stars
-18°C)
4. Maintenance and care of the appliance
4.1 Overall cleaning
•
Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and
energy saving.
• Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a so cloth
dampened with soapy water or diluted detergent.
•
The interior of the refrigerator should be cleaned regularly to avoid odor.
•
Please turn off the power before cleaning interior, remove all foods, drinks ,shelves, drawers, etc.
• Use a so cloth or sponge to clean the inside of the refrigerator, with two tablespoons of baking soda and
a quart of warm water. Then rinse with water and wipe clean. Aer cleaning, open the door and let it dry
naturally before turning on the power.
• For areas that are diicult to clean in the refrigerator (such as narrow sandwiches, gaps or corners), it is
recommended to wipe them regularly with a so rag, soft brush, etc. and when necessary, combined with
some auxiliary tools (such as thin sticks) to ensure no contaminants or bacterials accumulation in these
areas.
•
Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause odors in the interior of
the refrigerator or contaminated food.
•
Clean the bottle frame, shelves and drawers with a so cloth dampened with soapy water or diluted
detergent. Dry with a so cloth or dry naturally.
•
Wipe the outer surface of the refrigerator with a soft cloth dampened with soapy water, detergent, etc., and
then wipe dry.
• Do not use hard brushes, clean steel balls, wire brushes, abrasives
(such as toothpastes), organic solvents (such as alcohol, acetone,
banana oil, etc.), boiling water, acid or alkaline items, which may
damage the fridge suace and interior. Boiling water and organic
solvents such as benzene may derm or damage plastic parts.
• Do not rinse directly with water or other liquids during cleaning to
avoid short circuits or aect electrical insulation aer immersion.
( A Please unplug the refrigerator for defrost and cleaning.
)
4.2 Cleaning the glass shelf
• Remove the drawer on the glass shelf;
• Lift up the front of glass shelf(about 60
°
), and then pull out;
• Remove the glass shelf and clean as needed;
•
The reverse operation is for installation of glass shelf.
4.3 De frosting
• The refrigerator is made based on the air-cooling principle and thus has automatic defrosting
function. Frost formed due to change of season or temperature may also be manually removed by
disconnection of the appliance from power supply or by wiping with a dry towel.
4.4 Out of operation
•
Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be
kept for several hours; during the power failure, the times of door opening shall be reduced, and no
more fresh food shall be put into the appliance.
•
Long-time nonuse: The appliance shall be unplugged and then cleaned; then the doors are left
open to prevent odor.
•
Moving: Before the refrigerator is moved, take all objects inside out, fix the glass partitions,
vegetable holder, freezing chamber drawers and etc. with tape, and tighten the leveling feet; close
the doors and fix them with tape. During moving, the appliance shall not be laid upside down or
horizontally, or be vibrated; the inclination during movement shall be no more than 45
°
.
The appliance shall run continuously once it is started. Generally, the operation of
cA the appliance shall not be interrupted;otherwise the service life may be impaired.
19
5 Trouble shooting
You may try to solve the following simple problems by yourself. If them cannot be solved,
please contact the after-sales department.
Failed operation
Odor
Long-time operation
of the compressor
Light fails to get lit
Doors cannot be
properly closed
Loud noise
Door seal fails to
be tight
Water pan overflows
Hot housing
Check whether the appliance is connected to power or
whether the plug is in well contact
Check whether the voltage is too low
Check whether there is a power failure or partial circuits have tripped
Odorous foods shall be tightly wrapped
Check whether there is any rotten od
Clean the inside of the refrigerator
Long operation of the refrigerator is normal in summer
when the ambient temperature is high
It is not recommended having too much food in the appliance at the same time
Food shall get cool before being put into the appliance
The doors are opened too frequently
Check whether the refrigerator is connected to power supply and
whether the illuminating light is damaged
The door is stuck by food packages
The refrigerator is tilted
Check whether the floor is level and whether the refrigerator is placed stably
Check whether accessories are placed at proper locations
Remove foreign matters on the door seal
Heat the door seal and then cool ii for restoration
(or blow it with an electrical drier or use a hot towel for heating)
There is too much food in the chamber or food stored contains
too much water,resulting in heavy defrosting
The doors are not closed properly, resulting in frosting due to entry
of air and increased water due to defrosting
Heat dissipation of the built-in condenser via the housing, which is normal.
When housing becomes hot due to high ambient temperature and
storage of too much food,it is recommended to provide sound ventilation
to facilitate heat dissipation.
Condensation on the exterior suace and door seals of the refrigerator
S
urface condensation
is normal when the ambient humidity is too
high. Just wipe the condensate
with a clean towel.
Abnormal noise
Buzz: The compressor may produce buzzes during operation, and the buzzei
are loud particularly upon start or stop. This is normal.
Creak: Refrigerant flowing inside of the appliance may produce creak,
which is normal.
20
12
21
A
VAILABILITY OF SPARE PARTS
Thermostats, temperature sensors, printed circuit boards and light sources
are available for a minimum period of seven years after placing the last unit
of the model on the market.
Door handles, door hinges, trays and baskets for a minimum period of
seven years and door gaskets for a minimum period of 10 year, after
placing the last unit of the model on the market.
EN
FOR appliances without a 4-star compartment: this refrigerating appliance is not suitable for
freezing foodstuffs
FOR a free standing appliance: this refrigerating appliance is not intended to be used as a built-in
ppliance
FOR Wine Coolers: this appliance is intended to be used exclusively for the storage of wine
FOOD STORAGE
Position different food in different compartments according to be below table
Refrigerator compartment
Type of food
Door or balconies of fridge
compartment
• Foods with natural preservatives, such as jams, juices,
drinks, condiments.
• Do not store perishable foods
Crisper drawers (salad drawer)
• Fruits, herbs and vegetables should be placed
separately in the crisper bin
• Do not store bananas, onions, potatoes, garlic in the
refrigerator
Fridge shelf – middle
• Dairy products, eggs
Fridge shelf – top
• Foods that do no need coocking, such as ready-to-eat
foods, deli meats, leftovers.
Freezer drawer(s)/tray
• Foods for long-term storage
• Bottom drawer for raw meet, poultry, fish
• Middle drawer for frozen vegetables, chips.
• Top tray for ice cream, frozen fruit, frozen baked
goods.
• It’s suggested to set the temperature at 4°C in the fridge compartment, and, whether
possible, at -18°C in the freezer compartment.
• For most food categories, the longest storage time in the fridge compartment is achieved
with colder temperatures. Since some particular products (as fresh fruits and vegetables)
may be damaged with colder temperatures, it is suggested to keep them in the crisper
drawers, whenever present. If not present, maintain an average setting of the thermostat.
• For frozen food, refer to the storage time written on the food packaging. This storage
time is achieved whenever the setting respects the reference temperatures of the
compartment (one-star -6°C, two stars -12°C, three stars -18°
POSITIONING
Install the appliance at a location where the ambient temperature corresponds to the climate class
indicated on the rating plate of the appliance:
- Extended temperate (SN): ‘this refrigerating appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C’
- Temperate (N): ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 32 °C’
- Subtropical (ST): ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 38 °C’
- Tropical (T): ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 43 °C’
AVAILABILITY OF SPARE PARTS
“Thermostats, temperature sensors, printed circuit boards and light sources are available for a
minimum period of seven years after placing the last unit of the model on the market.
Door handles, door hinges, trays and baskets for a minimum period of seven years and door gaskets
for a minimum period of 10 year, after placing the last unit of the model on the market”.
GUARANTEE
Minimum guarantee is: 2 years for EU Countries, 3 years for Turkey, 1 year for UK, 1 year for
Russia, 3 years for Sweden, 2 years for Serbia, 5 years for Norway, 1 year for Morocco, 6 months
for Algeria, Tunisia no legal warranty required.
TECHNICAL ASSISTANCE
To contact the technical assistance, visit our website: https://corporate.haier-europe.com/en/
Under the section “website”, choose the brand of your product and your country. You will be
redirected to the specific website where you can find the telephone number and form to contact the
technical assistance
For further information about the product, please consult https://eprel.ec.europa.eu/ or scan the QR
on the energy label supplied with the appliance
