NII64G00AZ
EN User Manual | Hob
aeg.com\register
Welcome to AEG! Thank you for choosing our appliance.
Get usage advice, brochures, troubleshooting, service and repair information:
www.aeg.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 4
3. INSTALLATION...............................................................................................6
4. PRODUCT DESCRIPTION............................................................................. 8
5. DAILY USE......................................................................................................9
6. ADDITIONAL FUNCTIONS...........................................................................12
7. HINTS AND TIPS.......................................................................................... 17
8. CARE AND CLEANING................................................................................ 19
9. TROUBLESHOOTING.................................................................................. 20
10. TECHNICAL DATA..................................................................................... 23
11. ENERGY EFFICIENCY...............................................................................23
12. ENVIRONMENTAL CONCERNS................................................................24
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
2 ENGLISH
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: The appliance and its accessible parts become
hot during use. Keep children and pets away from the
appliance when in use and when cooling down.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
• WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
• Smoke is an indication of overheating. Never use water to
extinguish the cooking fire. Switch off the appliance and
cover flames with e.g. a fire blanket or lid.
• WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
• CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
• WARNING: Danger of fire: Do not store items on the
cooking surfaces.
ENGLISH 3
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.
• Do not use the appliance before installing it in the built-in
structure.
• Do not use water spray and steam to clean the appliance.
• After use, switch off the hob element by its control and do
not rely on the pan detector.
• WARNING: If the surface is cracked, switch off the
appliance to avoid the possibility of electric shock. In case
the appliance is connected to the mains directly using
junction box, remove the fuse to disconnect the appliance
from power supply. In either case contact the Authorised
Service Centre.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorized Service or similarly qualified
persons in order to avoid a hazard.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
WARNING!
Risk of injury or damage to the appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Seal the cut surfaces of the cabinet with a
sealant to prevent moisture from causing
swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance next to a door
or under a window. This prevents hot
cookware from falling from the appliance
when the door or the window is opened.
• Each appliance has cooling fans on the
bottom.
• If the appliance is installed above a
drawer:
4 ENGLISH
– Do not store any small pieces or
sheets of paper that could be pulled in,
as they can damage the cooling fans
or impair the cooling system.
– Keep a distance of minimum 2 cm
between the bottom of the appliance
and parts stored in the drawer.
• Remove any separator panels installed in
the cabinet below the appliance.
2.2 Electrical Connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to a socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
cable. Contact our Authorised Service
Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and electric shock.
• Do not change the specification of this
appliance.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on the
cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
disconnect immediately the appliance from
the power supply. This to prevent an
electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it may
splash.
• Do not use aluminum foil or other
materials between the cooking surface
and the cookware, unless otherwise
specified by the manufacturer of this
appliance.
• Use only accessories recommended for
this appliance by the manufacturer.
ENGLISH 5
WARNING!
Risk of fire and explosion.
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature than
oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
WARNING!
Risk of damage to the appliance.
• Do not keep hot cookware on the control
panel to avoid the risk of burns.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Cookware made of cast iron or with a
damaged bottom can cause scratches on
the glass / glass ceramic. Always lift these
objects up when you have to move them
on the cooking surface.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects, unless
otherwise specified.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your local authority for information
on how to dispose of the appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the
information below from the rating plate. The
rating plate is on the bottom of the hob.
Serial number ...........................
3.2 Built-in hobs
Only use the built-in hobs after you assemble
the hob into correct built-in units and work
surfaces that align to the standards.
3.3 Connection cable
• For a single phase or two phase
connection, use the cable type: H03V2V2-
6 ENGLISH
F or H05BB-F which withstands a
temperature of 90 °C or higher.
• To replace the damaged mains cable, use
the cable: H03V2V2-F or H05BB-F which
withstands a temperature of 90 °C or
higher. Contact an Authorised Service
Centre. The connection cable may only be
replaced by a qualified electrician.
3.4 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
min.
50mm
min.
500mm
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
Combination with standard oven
Combination with double oven
A = min. 6 mm, for double ovens from AEG,
Electrolux and Zanussi.
A = min. 12 mm, for double ovens from other
brands.
Find the video tutorial "How to install your
AEG Induction Hob - Worktop installation" by
typing out the full name indicated in the
graphic below.
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG
Induction Hob - Worktop installation
ENGLISH 7
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
3 2
1
1
1
Induction cooking zone
2
Control panel
3
Flexible induction cooking area consisting
of four sections
4.2 Control panel layout
5
6
7 98
11
1
12
234
10
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
The antiscratch glass surface has a unique finishing texture which may change the way
symbols and elements of the user interface appear in various lighting conditions.
Sensor
field
Function Description
1
On / Off To activate and deactivate the appliance.
2
Pause To activate and deactivate the function.
3
Timer To set the function.
4
/
- To increase or decrease the time.
5
- Timer display To show the time in minutes.
6
Flex Bridge (Flexible Bridge) To switch between three modes of the function.
7
PowerSlide To activate and deactivate the function.
8 ENGLISH
Sensor
field
Function Description
8
Bridge To activate and deactivate the function.
9
Hob²Hood To activate and deactivate the manual mode of the
function.
10
- Control bar To set a heat setting.
11
PowerBoost To activate the function.
12
Lock / Child Safety Device To lock / unlock the control panel.
4.3 Display indicators
Indicator Description
+ digit
There is a malfunction.
/ /
OptiHeat Control (3 step Residual heat indicator): continue cooking / keep warm / resid‐
ual heat.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Activating and deactivating
Press and hold to activate or deactivate
the hob.
5.2 Pot detection
This feature indicates the presence of
cookware on the hob and deactivates the
cooking zones if no cookware is detected
during a cooking session.
If you put cookware on a cooking zone before
you select a heat setting, the indicator above
0 on the control bar appears.
If you remove cookware from an activated
cooking zone and set it aside temporarily, the
indicators above the corresponding control
bar will start blinking. If you do not place the
cookware back on the activated cooking zone
within 120 seconds, the cooking zone will
automatically deactivate.
To resume cooking, make sure to put the
cookware back on the cooking zones within
the indicated timeout.
5.3 Using the cooking zones
Place the cookware in the centre of the
selected zone. Induction cooking zones adapt
to the dimension of the bottom of the
cookware automatically.
For optimal heat transfer use cookware
with bottom diameter similar to the size of
the cooking zone (i.e. the maximum
cookware diameter value in "Technical
data" > "Cooking zones specification").
Make sure that the cookware is suitable
for induction hobs. For more information
on cookware types refer to "Hints and
tips".
ENGLISH 9
The antiscratch glass surface has an
unique finishing texture that maximizes
scratch resistance. The friction between
the cookware and the glass surface may
produce noises.
You can cook with large cookware placed on
two cooking zones at the same time using
Bridge function. The cookware must cover
the centres of both zones but not go beyond
the area marking. If the cookware is located
between the two centres, Bridge function will
not be activated.
5.4 Heat setting
1. Press the desired heat setting on the
control bar.
The indicators above the control bar appear
up to the selected heat setting level.
2. To deactivate a cooking zone, press 0.
5.5 PowerBoost
This function makes more power available to
the induction cooking zones. The function can
be activated for the induction cooking zone
only for a limited period of time. After this time
the induction cooking zone automatically sets
back to the highest heat setting.
Refer to “Technical data” chapter.
To activate the function for a cooking
zone: touch .
To deactivate the function: change the heat
setting.
5.6 OptiHeat Control (3 step
Residual heat indicator)
WARNING!
/ / As long as the indicator is
visible, there is a risk of burns from
residual heat.
The induction cooking zones produce the
heat necessary for the cooking process
directly in the bottom of the cookware. The
glass ceramic is heated by the heat of the
cookware.
The indicators appear when a cooking zone
is hot. They show the level of the residual
heat for the cooking zones you are currently
using:
- continue cooking,
- keep warm,
- residual heat.
The indicator may also appear:
• for the neighbouring cooking zones even if
you are not using them,
• when hot cookware is placed on cold
cooking zone,
• when the hob is deactivated but the
cooking zone is still hot.
The indicator disappears when the cooking
zone has cooled down.
10 ENGLISH
5.7 Timer options
Count Down Timer
Use this function to specify how long a
cooking zone should operate during a single
cooking session.
1. Press . 00 appears on the timer
display.
2. Press or to set the time (00-99
minutes).
3. Press to start the timer or wait 3
seconds. The timer begins to count down.
To change the time: select the cooking zone
with
and press or .
To deactivate the function: select the
cooking zone with and press . The
remaining time counts back to 00.
The timer finishes counting down, a signal
sounds and 00 blinks. The cooking zone
deactivates. Press any symbol to stop the
signal and blinking.
Minute Minder
1. Press .
2. Press or to set the time.
The timer finishes counting down, a signal
sounds and 00 blinks. Press any symbol to
stop the signal and blinking.
To deactivate the function: press and
. The remaining time counts back to 00.
5.8 Power management
If multiple zones are active and the
consumed power exceeds the limitation of the
power supply, this function divides the
available power between all cooking zones.
The hob controls heat settings to protect the
fuses of the house installation.
• If the hob reaches the limit of maximum
available power (refer to the rating plate),
the power of the cooking zones will be
automatically reduced.
• The heat setting of the cooking zone
selected first is always prioritised. The
remaining power will be divided between
the other cooking zones according to the
order of selection.
• For cooking zones that have a reduced
power, the control bar blinks and shows
the maximum possible heat settings.
• Wait until the display stops flashing or
reduce the heat setting of the cooking
zone selected last. The cooking zones will
continue operating with the reduced heat
setting. Change the heat settings of the
cooking zones manually, if necessary.
5.9 Menu structure
The table shows the basic menu structure.
User settings
Sym‐
bol
Setting Possible options
b Sound On / Off (--)
H AUTO mode 0 - 6
E Alarm / error histo‐
ry
The list of recent
alarms / errors.
To enter user settings: press and hold
for 3 seconds. Then, press and hold . The
settings appear on the timer of the left
cooking zones.
Navigating the menu: the menu consists of
the setting symbol and a value. The symbol
appears on the rear timer and the value
appears on the front timer. To navigate
between the settings press
on the front
timer. To change the setting value press
or on the front timer.
To exit the menu: press
.
OffSound Control
You can activate / deactivate the sounds in
the Menu > User settings.
Refer to "Menu structure".
When the sounds are off you can still hear
the sound when:
• you touch ,
ENGLISH 11
• the timer comes down, • you press an inactive symbol.
6. ADDITIONAL FUNCTIONS
6.1 Automatic Switch Off
The function deactivates the hob
automatically if:
• all of the cooking zones are deactivated,
• you do not set any heat setting or fan
speed setting after the activation of the
hob,
• you spill something or put something on
the control panel for more than 10
seconds (a pan, a cloth, etc.). A signal
sounds and the hob deactivates. Remove
the object or clean the control panel.
• the appliance gets too hot (e.g. when a
saucepan boils dry). Let the cooking zone
cool down before you use the hob again.
• you do not deactivate a cooking zone or
change the heat setting. After some time,
the hob deactivates.
The relation between the heat setting and
the time after which the appliance
deactivates:
Heat setting The hob deactivates
after
1 - 2 6 hours
3 - 4 5 hours
5 4 hours
6 - 9 1.5 hours
6.2 Pause
This function sets all operating cooking zones
to the lowest heat setting.
When the function operates,
and can
be used. All other symbols on the control
panels are locked.
The function does not stop the timer
functions.
1. To activate the function: press .
The heat setting is lowered to 1.
2. To deactivate the function: press .
The previous heat setting appears.
6.3 Lock
You can lock the control panel while the hob
operates. It prevents an accidental change of
the heat setting.
Set the heat setting first.
To activate the function: press .
To deactivate the function: press
again.
The function deactivates as you
deactivate the hob.
6.4 Child Safety Device
This function prevents an accidental
operation of the hob.
To activate the function: press . Do not
set any heat setting. Press and hold for 3
seconds, until the indicator above the symbol
appears. Deactivate the hob with
.
The function stays active when you
deactivate the hob. The indicator above
is on.
To deactivate the function: press . Do
not set any heat setting. Press and hold
for 3 seconds, until the indicator above the
symbol disappears. Deactivate the hob with
.
Cooking with the function activated: press
, then press for 3 seconds, until the
indicator above the symbol disappears. You
can operate the hob. When you deactivate
the hob with the function operates again.
12 ENGLISH
6.5 Bridge
The function operates when the pot
covers the centres of the two zones. For
more information on the correct
placement of cookware refer to "Using
the cooking zones".
This function connects two right side cooking
zones and they operate as one.
First set the heat setting for one of the right
side cooking zones.
To activate the function: touch . To set or
change the heat setting touch one of the
control sensors.
To deactivate the function: touch
. The
cooking zones operate independently.
6.6 Flexible induction cooking area
WARNING!
Refer to Safety chapters.
Flex Bridge function
The flexible induction cooking area consists
of four sections. The sections can be
combined into two cooking zones with
different size, or into one large cooking area.
You choose the combination of the sections
by choosing the mode applicable to the size
of the cookware you want to use. There are
three modes: Standard, Big Bridge, and Max
Bridge.
To set the heat setting use the two
control bars on the left side.
Switching between the modes
To switch between the modes press . The
heat setting levels will be kept.
Diameter and position of the cookware
Choose the mode applicable to the size and
the shape of the cookware. The cookware
should cover the selected area as much as
possible.
Place the cookware with the bottom diameter
smaller than 160 mm centrally on a single
section. You can use a roaster pan for the Big
Bridge and the Max Bridge modes.
100-160mm
Place the cookware with the bottom diameter
larger than 160 mm centrally between two
sections.
> 160 mm
ENGLISH 13
Flex Bridge Standard mode
This mode is activated by default when you
activate the function. It connects the sections
into two separate cooking areas. You can set
the heat setting for each area separately. Use
the two control bars on the left side.
Correct cookware position:
Incorrect cookware position:
Flex Bridge Big Bridge mode
To activate the mode press until you see
the correct mode indicator
. This mode
connects the three rear sections into one
cooking area. The front section is not
connected and operates as a separate
cooking zone. You can set the heat setting for
each area separately. Use the two control
bars on the left side.
Correct cookware position:
Make sure to place the cookware on the three
connected sections. If you use cookware
smaller than two sections the control bar
blinks and after 2 minutes the zone
deactivates.
Incorrect cookware position:
Flex Bridge Max Bridge mode
To activate the mode press until you see
the correct mode indicator . This mode
connects all sections into one cooking area.
To set the heat setting use any of the two
control bars on the left side.
14 ENGLISH
Correct cookware position:
Make sure to place the cookware on the four
connected sections. If you use cookware
smaller than three sections the control bar
blinks and after 2 minutes the zone switches
off.
Incorrect cookware position:
PowerSlide
This function allows you to adjust the
temperature by moving the cookware to a
different position on the induction cooking
area.
• The function divides the induction cooking
area into three areas with different heat
settings. The hob detects the position of
the cookware and adjusts the heat setting
corresponding with the position.
• You can place the cookware in the front,
middle or rear position. If you place the
cookware in the front you get the highest
heat setting. To decrease it, move the
cookware to middle or rear position.
• When you activate the function for the first
time you will get the following default heat
settings: 9 for the front position, 6 for the
middle position and 3 for the rear position.
• You can change the heat settings for each
position separately. The hob will
remember your heat settings next time
you activate the function.
• The heat setting display of the left front
control bar shows the heat setting for this
function. To change the heat setting use
the left front control bar only. The left
rear control bar is deactivated while the
function operates.
Use only one pot with a minimum bottom
diameter of 160 mm when you operate
the function.
1. Place the correct cookware on the left
front side of the cooking area.
2. Press and hold to activate the hob.
A signal sounds and indicators above and
appear.
3. Press
to activate the function.
A signal sounds and an indicator above the
symbol appears.
4. Move the cookware back and forth on the
cooking area as needed. To change the
position of the cookware lift it up and
place it on a different part of the area.
The heat setting level on the control bar
adjusts automatically.
ENGLISH 15
5. To change the default heat setting levels,
move the cookware to the area you want
to adjust first.
6. Press any of the available heat setting
levels on the left front control bar.
The updated heat setting levels will be
remembered for the next time you use the
function.
7. Repeat the procedure for the remaining
cooking areas, if needed.
8. To deactivate the function, press . You
can also press 0 on the left front control
bar.
A signal sounds and the indicator above the
symbol disappears. The heat setting level
changes to 0.
You can set a timer while PowerSlide
operates. In this case the timer does not
deactivate the cooking zones when the set
time runs out. The timer affects all three
cooking areas activated by the function at the
same time.
6.7 Hob²Hood
It is an advanced automatic function which
connects the hob to a special hood. Both the
hob and the hood have an infrared signal
communicator. Speed of the fan is defined
automatically on basis of mode setting and
temperature of the hottest cookware on the
hob. You can also operate the fan from the
hob manually.
For most of the hoods the remote system
is originally activated. In case it is
deactivated, activate it before you use
the function. For more information refer
to hood user manual.
Operating the function automatically
To operate the function automatically set the
automatic mode to H1 – H6. The hob is
originally set to H5. The hood reacts
whenever you operate the hob. The hob
recognizes temperature of the cookware
automatically and adjusts the speed of the
fan.
Automatic modes
Automat‐
ic light
Boiling
1)
Frying
2)
H0 Off Off Off
H1 On Off Off
H2
3)
On Fan speed
1
Fan speed
1
H3 On Off Fan speed
1
H4 On Fan speed
1
Fan speed
1
H5 On Fan speed
1
Fan speed
2
H6 On Fan speed
2
Fan speed
3
1)
The hob detects the boiling process and activates
fan speed in accordance with automatic mode.
2)
The hob detects the frying process and activates fan
speed in accordance with automatic mode.
3)
This mode activates the fan and the light and does
not rely on the temperature.
Changing the automatic mode
1. Deactivate the hob.
2. Press for 3 seconds. The display
comes on and goes off.
3. Press for 3 seconds.
4. Press a few times until H comes on.
5. Press of the timer to select an
automatic mode.
To operate the hood directly on the hood
panel deactivate the automatic mode of
the function.
When you finish cooking and deactivate
the hob, the hood fan may still operate
for a certain period of time. After that time
the system deactivates the fan
automatically and prevents you from
accidental activation of the fan for the
next 30 seconds.
16 ENGLISH
Operating the fan speed manually
You can also operate the function manually.
To do that press when the hob is active.
This deactivates automatic operation of the
function and allows you to change the fan
speed manually. When you press you
raise the fan speed by one. When you reach
an intensive level and press again you will
set fan speed to 0 which deactivates the hood
fan. To start the fan again with fan speed 1
press .
To activate automatic operation of the
function, deactivate the hob and activate
it again.
Activating the light
You can set the hob to activate the light
automatically whenever you activate the hob.
To do so set the automatic mode to H1 – H6.
The light on the hood deactivates 2
minutes after deactivating the hob.
7. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
7.1 Cookware
For induction cooking zones a strong
electro-magnetic field creates the heat in
the cookware very quickly.
Use the induction cooking zones with suitable
cookware.
• To prevent overheating and improve the
performance of the zones, the cookware
must be as thick and flat as possible.
• Ensure cookware bases are clean and dry
before placing on the hob surface.
• Always be careful no to slide or rub the
cookware on the edges and corners of the
glass or the side trim as it may chip or
damage the glass surface.
Cookware material
• correct: cast iron, steel, enamelled steel,
stainless steel, multi-layer bottom (with a
correct marking from a manufacturer).
• not correct: aluminium, copper, brass,
glass, ceramic, porcelain.
Cookware is suitable for an induction hob
if:
• water boils very quickly on a zone set to
the highest heat setting.
• a magnet pulls on to the bottom of the
cookware.
Cookware dimensions
• Induction cooking zones adapt to the
dimension of the bottom of the cookware
automatically. Refer to "Technical data" >
"Cooking zones specification" for correct
cookware dimensions. Place the cookware
in the centre of the selected cooking zone.
• The efficiency of a cooking zone is related
to the diameter of the cookware. For
optimal heat transfer use cookware with
bottom diameter similar to the size of the
cooking zone (i.e. the maximum cookware
diameter value in "Technical data" >
"Cooking zones specification").
– Cookware with a diameter smaller
than the size of a given cooking zone
receives only part of the power
generated by the cooking zone which
results in slower heating.
– For both safety reasons and optimal
cooking results, do not use cookware
larger than indicated in "Cooking
zones specification". Avoid keeping
cookware close to the control panel
during the cooking session. This might
impact the functioning of the control
ENGLISH 17
panel or accidentally activate hob
functions.
Refer to "Technical data".
7.2 Noises during operation
The noises are normal and do not
indicate any malfunction. Cookware
noises may vary depending on the
cookware material and the power level.
Cookware-related noises:
• cracking noise: cookware is made of
different materials (a sandwich
construction).
• whistling sound: you use a cooking zone
with a high power level and the cookware
is made of different materials (a sandwich
construction).
• humming: you use a high power level.
Hob-related noises:
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
• rhythmic sound: cookware is detected.
7.3 Öko Timer (Eco Timer)
To save energy, the heater of the cooking
zone deactivates before the count down timer
sounds. The difference in the operation time
depends on the heat setting level and the
length of the cooking operation.
7.4 Simplified cooking guide
The correlation between the heat setting of a
zone and its consumption of power is not
linear. When you increase the heat setting, it
is not proportional to the increase of the
consumption of power. It means that a
cooking zone with the medium heat setting
uses less than a half of its power.
The data in the table is for guidance only.
Heat setting Use to: Time
(min)
Hints
1 Keep cooked food warm. as neces‐
sary
Put a lid on the cookware.
1 - 2 Hollandaise sauce; melt: butter, choco‐
late, gelatine.
5 - 25 Mix from time to time.
2 Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on.
2 - 3 Simmer rice and milk-based dishes,
heat up ready-cooked meals.
25 - 50 Add at least twice as much liquid as
rice, mix milk dishes halfway through
the procedure.
3 - 4 Stew vegetables, fish, meat. 20 - 45 Add a few tablespoons of water.
Check the water amount during the
process.
4 - 5 Steam potatoes and other vegetables. 20 - 60 Cover the bottom of the pot with 1-2
cm of water. Check the water level
during the process. Keep the lid on the
pot.
4 - 5 Cook larger quantities of food, stews
and soups.
60 - 150 Up to 3 l of liquid plus ingredients.
6 - 7 Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts.
as neces‐
sary
Turn over when needed.
18 ENGLISH
Heat setting Use to: Time
(min)
Hints
7 - 8 Heavy fry, hash browns, loin steaks,
steaks.
5 - 15 Turn over when needed.
9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
Boil large quantities of water. PowerBoost is activated.
7.5 Hints and tips for Hob²Hood
When you operate the hob with the function:
• Protect the hood panel from direct
sunlight.
• Do not spot halogen light on the hood
panel.
• Do not cover the hob control panel.
• Do not interrupt the signal between the
hob and the hood (e.g. with the hand, a
cookware handle or a tall pot). See the
picture.
The hood pictured below is for illustration
purpose only.
Other remotely controlled appliances
may block the signal. Do not use any
such appliances near to the hob while
Hob²Hood is on.
Cooker hoods with the Hob²Hood function
To find the full range of cooker hoods which
work with this function refer to our consumer
website. The AEG cooker hoods that work
with this function must have the symbol
.
8. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
8.1 General information
• Clean the hob after each use.
• Always use cookware with a clean base.
• For both daily cleaning of the glass
surface and the post-installation cleaning
and removal of any residual glue, use only
a mildly abrasive cleaning milk and an
anti-scratch, delicate sponge. Depending
on the degree of soiling, clean the glass
surface with small circular movements and
moderate pressure. Wipe the glass
surface dry with a microfibre cloth.
ENGLISH 19
WARNING!
Do not use the classic yellow and
green sponge as the aluminium
particles on its hard layer may
damage and discolour the glass.
Using cleaning tools different than the
recommended ones will not be
effective and may damage or
discolour the glass surface.
• Always use a scraper recommended for
hobs with a glass surface. Use the scraper
only as an additional tool for cleaning the
glass after the standard cleaning
procedure.
WARNING!
Do not use knives or any other sharp,
metal tools to clean the glass surface.
• For the metal side trim, use only a
dishwashing detergent with warm water.
Use a cloth to clean and wipe the trim.
WARNING!
Do not use the mildly abrasive
cleaning milk, any polishing
detergents, scrapers, or the hard layer
of a sponge to clean the side trim.
• The gap between the glass surface and
the side trim may gather dirt and small
particles of food. Use a wooden toothpick
to clean the gap between the glass
surface and the side trim.
WARNING!
Do not use any sharp metal tools to
clean the gap as they may widen the
gap and damage the side trim or the
glass surface.
The printing on the flexible induction
cooking area may become dirty or
change its colour as an effect of moving
the cookware. You can clean the area in
the described way.
8.2 Cleaning the glass surface of
the hob
• Remove immediately: melted plastic,
plastic foil, salt, sugar and food with sugar,
otherwise, the dirt can cause damage to
the hob. Take care to avoid burns. Use a
special hob scraper on the glass surface
at an acute angle and move the blade on
the surface.
• Remove when the hob is sufficiently
cool: limescale rings, water rings, fat
stains, shiny metallic discoloration. Clean
the hob with a mildly abrasive cleaning
milk and an anti-scratch, delicate sponge
(see General information). After cleaning,
wipe the hob dry with a microfibre cloth.
• Persistent marks and stains: apply
moderate pressure and scrub the surface
with an anti-scratch, delicate sponge (see
General information) and a mildly abrasive
cleaning milk until the stains are no longer
visible.
9. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
20 ENGLISH
9.1 What to do if...
Problem Possible cause Remedy
You cannot activate or operate
the hob.
The hob is not connected to an elec‐
trical supply or it is connected incor‐
rectly.
Check if the hob is correctly connected
to the electrical supply.
The fuse is blown. Make sure that the fuse is the cause of
the malfunction. If the fuse is blown
again and again, contact a qualified
electrician.
You did not set the heat setting for
60 seconds.
Activate the hob again and set the
heat setting in less than 60 seconds.
You touched 2 or more sensor fields
at the same time.
Touch only one sensor field.
Pause operates. Refer to "Pause".
There is water or fat stains on the
control panel.
Clean the control panel.
You can hear a constant beep
noise.
The electrical connection is incor‐
rect.
Disconnect the hob from the electrical
supply. Ask a qualified electrician to
check the installation.
You cannot select the maximum
heat setting for one of the cook‐
ing zones.
The other zones consume the maxi‐
mum available power.
Your hob works properly.
Reduce the heat setting of the other
cooking zones connected to the same
phase. Refer to "Power management".
An acoustic signal sounds and
the hob deactivates.
An acoustic signal sounds when
the hob is deactivated.
You put something on one or more
sensor fields.
Remove the object from the sensor
fields.
The hob deactivates. You put something on the sensor
field .
Remove the object from the sensor
field.
Residual heat indicator does not
come on.
The zone is not hot because it oper‐
ated only for a short time or the sen‐
sor is damaged.
If the zone operated sufficiently long to
be hot, speak to an Authorised Service
Centre.
Hob²Hood does not work. You covered the control panel. Remove the object from the control
panel.
You use a very tall pot which blocks
the signal.
Use a smaller pot, change the cooking
zone or operate the hood manually.
There is no sound when you
touch the panel sensor fields.
The sounds are deactivated. Activate the sounds. Refer to "Daily
use".
The flexible induction cooking
area does not heat up the cook‐
ware.
The cookware is in a wrong position
on the flexible induction cooking
area.
Place the cookware in the correct posi‐
tion on the flexible induction cooking
area. The position of the cookware de‐
pends on the activated function or
function mode. Refer to "Flexible in‐
duction cooking area".
ENGLISH 21
Problem Possible cause Remedy
The diameter of the bottom of the
cookware is incorrect for the activa‐
ted function or function mode.
Use cookware with a diameter applica‐
ble to the activated function or function
mode. Refer to "Flexible induction
cooking area".
The indicator above the symbol
comes on.
Child Safety Device or Lock oper‐
ates.
Refer to "Child Safety Device" and
"Lock".
The control bar blinks. There is no cookware on the zone or
the zone is not fully covered.
Put cookware on the zone so that it
fully covers the cooking zone.
The cookware is unsuitable. Use cookware suitable for induction
hobs. Refer to "Hints and tips".
The diameter of the bottom of the
cookware is too small for the zone.
Use cookware with correct dimen‐
sions. Refer to "Technical data".
Flex Bridge (Flexible Bridge) oper‐
ates. One or more sections of the
function mode which operates are
not covered by the cookware.
Place the cookware on the correct
number of sections of the function
mode which operates or change the
function mode. Refer to "Flexible in‐
duction cooking area".
Heating up takes a long time. Cookware is too small and receives
only a part of the power generated
by the cooking zone.
For optimal heat transfer use cook‐
ware with bottom diameter similar to
the size of the cooking zone (i.e. the
maximum cookware diameter value in
"Technical data" > "Cooking zones
specification").
PowerSlide operates. Two pots are
placed on the flexible induction
cooking area or the cookware covers
more than one cooking area activa‐
ted by the function.
Use only one pot. Refer to "Flexible in‐
duction cooking area".
and a number come on.
There is an error in the hob. Deactivate the hob and activate it
again after 30 seconds. If comes
on again, disconnect the hob from the
electrical supply. After 30 seconds,
connect the hob again. If the problem
continues, speak to an Authorised
Service Centre.
9.2 If you cannot find a solution...
If you cannot find a solution to the problem
yourself, contact your dealer or an Authorised
Service Centre. Give the data from the rating
plate. Make sure, you operated the hob
correctly. If not the servicing by a service
technician or dealer will not be free of charge,
also during the warranty period. The
information about guarantee period and
Authorised Service Centres are in the
guarantee booklet.
22 ENGLISH
10. TECHNICAL DATA
10.1 Rating plate
Model NII64G00AZ PNC 949 598 190 00
Typ 62 B4A 09 AA 220 - 240 V / 400 V 2N, 50 Hz
Induction 7.35 kW Made in: Germany
Ser.Nr. ................. 7.35 kW
AEG
10.2 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
PowerBoost [W] PowerBoost
maximum dura‐
tion [min]
Cookware diame‐
ter [mm]
Right front 2300 3200 10 145 - 265
Right rear 2300 3200 10 145 - 265
Flexible induction
cooking area
2300 3200 10 minimum 105
The power of the cooking zones can be
different in some small range from the data in
the table. It changes with the material and
dimensions of the cookware.
For optimal heat transfer and cooking results
use cookware with bottom diameter similar to
the size of the cooking zone (i.e. the
maximum cookware diameter value in the
table). Do not use cookware larger than the
diameter of the cooking zone.
11. ENERGY EFFICIENCY
11.1 Product Information according to EU and UK Ecodesign Regulations
Model identification NII64G00AZ
Type of hob Built-In Hob
Number of cooking areas 2
Heating technology Induction
Length (L) and width (W) of the cooking area Left L 45.8 cm
W 21.4 cm
Length (L) and width (W) of the cooking area Right L 36.8 cm
W 26.5 cm
Energy consumption of the cooking area (EC electric
cooking)
Left 191.1 Wh/kg
ENGLISH 23
Energy consumption of the cooking area (EC electric
cooking)
Right 182.9 Wh/kg
Energy consumption of the hob (EC electric hob) 187.0 Wh/kg
IEC / EN 60350-2, BS EN 60350-2 -
Household electric cooking appliances - Part
2: Hobs - Methods for measuring
performance.
11.2 Energy saving
You can save energy during everyday
cooking if you follow the hints below.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on the
cookware.
• Put the cookware directly in the centre of
the cooking zone.
• Use the residual heat to keep the food
warm or to melt it.
11.3 Product Information for power consumption and maximum time to
reach applicable low power mode
Power consumption in off mode 0.3 W
Maximum time needed for the equipment to automatically reach the applicable low
power mode
2 min
12. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
24 ENGLISH
*
867384582-C-362024
