USER
MANUAL
EN User Manual
Hob
IAE64851FB
CONTENTS
1. SAFETY INFORMATION............................................................................................. 3
2. CONDITIONS OF USE................................................................................................5
3. SAFETY INSTRUCTIONS.............................................................................................5
4. INSTALLATION............................................................................................................ 7
5. PRODUCT DESCRIPTION...........................................................................................8
6. QUICK GUIDE............................................................................................................. 9
7. BEFORE FIRST USE................................................................................................... 11
8. DAILY USE.................................................................................................................. 11
9. FLEXIBLE INDUCTION COOKING AREA............................................................... 16
10. HINTS AND TIPS..................................................................................................... 18
11. CARE AND CLEANING.......................................................................................... 21
12. TROUBLESHOOTING.............................................................................................21
13. TECHNICAL DATA.................................................................................................. 24
14. ENERGY EFFICIENCY.............................................................................................25
15. WARRANTY .............................................................................................................26
IMPORTANT INFORMATION THAT MAY IMPACT
YOUR MANUFACTURER'S WARRANTY
Adherence to the directions for use in this manual is extremely important for
health and safety. Failure to strictly adhere to the requirements in this manual may
result in personal injury, property damage and affect your ability to make a claim
under the AEG manufacturer’s warranty provided with your product. Products
must be used, installed and operated in accordance with this manual. You may
not be able to claim on the AEG manufacturer’s warranty in the event that your
product fault is due to failure to adhere to this manual.
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
www.aeg.com
2
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot during use.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH
3
1.2 General Safety
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements.
• WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire.
• NEVER try to extinguish a fire with water, but switch off
the appliance and then cover flame e.g. with a lid or a
fire blanket.
• CAUTION: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
• CAUTION: The cooking process has to be supervised.
A short term cooking process has to be supervised
continuously.
• WARNING: Danger of fire: Do not store items on the
cooking surfaces.
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot.
• Do not use the appliance before installing it in the
built-in structure.
• Do not use a steam cleaner to clean the appliance.
• After use, switch off the hob element by its control
and do not rely on the pan detector.
• If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains.
In case the appliance is connected to the mains
directly using junction box, remove the fuse to
disconnect the appliance from power supply. In either
case contact the Authorised Service Centre.
• If the supply cord is damaged, it must be replaced by
the manufacturer, an authorized Service or similarly
qualified persons in order to avoid a hazard.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by
www.aeg.com
4
the manufacturer of the appliance in the instructions
for use as suitable or hob guards incorporated in the
appliance. The use of inappropriate guards can cause
accidents.
2. CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• Farm houses
• By clients in serviced apartments,
holiday apartments and other
residential type environments.
3. SAFETY INSTRUCTIONS
3.1 Installation
WARNING!
Only a qualified person must
install this appliance.
WARNING!
Risk of injury or damage to
the appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Keep the minimum distance from
other appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Seal the cut surfaces with a sealant to
prevent moisture from causing
swelling.
• Protect the bottom of the appliance
from steam and moisture.
• Do not install the appliance next to a
door or under a window. This
prevents hot cookware from falling
from the appliance when the door or
the window is opened.
• Each appliance has cooling fans on
the bottom.
• If the appliance is installed above a
drawer:
– Do not store any small pieces or
sheets of paper that could be
pulled in, as they can damage the
cooling fans or impair the cooling
system.
– Keep a distance of minimum 2 cm
between the bottom of the
appliance and parts stored in the
drawer.
• Remove any separator panels
installed in the cabinet below the
appliance.
3.2 Electrical Connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation
make sure that the appliance is
disconnected from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect
electricity mains cable or plug (if
applicable) can make the terminal
become too hot.
• Use the correct electricity mains
cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the
cable.
ENGLISH
5
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to the near
sockets.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug (if applicable) or to the
mains cable. Contact our Authorised
Service Centre or an electrician to
change a damaged mains cable.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
3.3 Use
WARNING!
Risk of injury, burns and
electric shock.
• Remove all the packaging, labelling
and protective film (if applicable)
before first use.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Set the cooking zone to “off” after
each use.
• Do not rely on the pan detector.
• Do not put cutlery or saucepan lids on
the cooking zones. They can become
hot.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is
cracked, disconnect immediately the
appliance from the power supply. This
to prevent an electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it
may splash.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food
remnants, can cause
fire at a lower
temperature than oil used for the first
time.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• Do not keep hot cookware on the
control panel.
• Do not put a hot pan cover on the
glass surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.
• Do not activate the cooking zones
with empty cookware or without
cookware.
• Do not put aluminium foil on the
appliance.
• Cookware made of cast iron,
aluminium or with a damaged bottom
can cause scratches on the glass /
www.aeg.com
6
glass ceramic. Always lift these
objects up when you have to move
them on the cooking surface.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
3.4 Care and cleaning
• Clean the appliance regularly to
prevent the deterioration of the
surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
3.5 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
3.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
4. INSTALLATION
WARNING!
Refer to Safety chapters.
4.1 Before the installation
Before you install the hob, write down
the information below from the rating
plate. The rating plate is on the bottom
of the hob.
Serial number ...........................
4.2 Built-in hobs
Only use the built-in hobs after you
assemble the hob into correct built-in
units and work surfaces that align to the
standards.
4.3 Connection cable
• The hob is supplied with a connection
cable.
4.4 Assembly
min.
50mm
min.
500mm
ENGLISH 7
min.
12
min.
60
min.
28
If the appliance is installed
above a drawer, the hob
ventilation can warm up the
items stored in the drawer
during the cooking process.
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG
Induction Hob - Worktop installation
5. PRODUCT DESCRIPTION
5.1 Cooking surface layout
1
2
1
3
1
Induction cooking zone
2
Control panel
3
Flexible induction cooking area
consisting of four sections
5.2 Control panel layout
1
32
4
5 6 7 8
10 911
12
To see the available settings touch the appropriate symbol.
www.aeg.com
8
Symbol Comment
1
ON / OFF To activate and deactivate the hob.
2
Menu To open and close the Menu.
3
Zone selection To open the slider for the selected zone.
4
- Zone indicator To show for which zone the slider is active.
5
- To set the timer functions.
6
- Slider To adjust the heat setting.
7
PowerBoost To activate the function.
8
Lock To activate and deactivate the function.
9
- The window of the Hob²Hood infrared signal com-
municator. Do not cover it.
10
Pause To activate and deactivate the function.
11
0 - 9 - To show the current heat setting.
12
FlexiBridge To switch between three modes of the function.
5.3 OptiHeat Control(3 step
Residual heat indicator)
WARNING!
III / II / I There is a risk of
burns from residual heat.
The indicator shows the level
of the residual heat.
The induction cooking zones produce
the heat necessary for the cooking
process directly in the bottom of the
cookware. The glass ceramic is heated by
the heat of the cookware.
6. QUICK GUIDE
6.1 Using the display
• Only the backlit symbols can be used.
• To activate a given option, touch the
relevant symbol on the display.
• The selected function is activated
when you remove the finger from the
display.
• To scroll the available options, use a
quick gesture or drag your finger
across the display. The speed of the
gesture determines how fast the
screen moves.
• The scrolling can stop by itself or you
can stop it immediately if you touch
the display.
• You can change most of the
parameters shown on the display
when you touch the relevant symbols.
• To select the required function or time
you can scroll through the list and / or
touch the option you want to choose.
• When the hob is activated and some
of the symbols disappear from the
display, touch it again. All the symbols
come back on.
• For certain functions, when you start
them, a pop-up window with
additional information appears. To
deactivate the pop-up window
ENGLISH 9
permanently, check before you
activate the function.
• Select a zone first to activate the timer
functions.
Symbols useful for display navigation
To confirm the selection or setting.
To go back / forwards one level in
the Menu.
To scroll up / down the instructions
on the display.
Symbols useful for display navigation
To activate / deactivate the options.
To close the pop-up window.
To cancel a setting.
6.2 Menu structure
Touch to access and change the
settings of the hob or activate some
functions. The table shows the basic
Menu structure.
Menu
Assisted Cooking
Hob Functions PowerSlide
Melting
Settings Child Lock
Stopwatch
Hob²Hood H0 - Off
H1 - Light only
H2 - Fan speed low
H3 - Auto Fan Low
H4 - Auto Fan Medium
H5 - Auto Fan High
H6 - Auto Fan Boost
Setup Assisted Cooking
Language
Key Tones
Buzzer Volume
Display Brightness
Service Demo Mode
License
Show Software Version
Alarm History
Reset All Settings
www.aeg.com10
To leave the Menu touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu
use or .
When you touch and hold some of the
options available in the Menu, a short
description appears. Follow the tips to
easily navigate through the Menu.
If you are at the bottom of the Menu
scroll the list up and use or touch to
leave the Menu.
7. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
7.1 First connection to the
mains
When you connect the hob to the mains
you have to set Language, Display
Brightness and Buzzer Volume.
You can change the setting in Menu >
Settings > Setup. Refer to "Daily use".
8. DAILY USE
WARNING!
Refer to Safety chapters.
8.1 Activating and
deactivating
Touch for 1 second to activate or
deactivate the hob.
8.2 Automatic Switch Off
The function deactivates the hob
automatically if:
• all cooking zones are deactivated,
• you do not set the heat setting after
you activate the hob,
• you spill or put something on the
control panel for more than 10
seconds (a pan, a cloth, etc.). An
acoustic signal sounds and the hob
deactivates. Remove the object or
clean the control panel.
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking
zone cool down before you use the
hob again.
• you use incorrect cookware or there is
no cookware on a given zone. The
white cooking zone symbol blinks and
the induction cooking zone
deactivates automatically after 2
minutes.
• you do not deactivate a cooking zone
or change the heat setting. After
some time a message comes on and
the hob deactivates.
The relation between the heat setting
and the time after which the hob
deactivates:
Heat setting The hob deacti-
vates after
1 - 2 6 hours
3 - 5 5 hours
6 4 hours
7 - 9 1.5 hour
When you use Pan Fry the
hob deactivates after 1.5
hours. For Sous Vide the hob
deactivates after 4 hours.
8.3 Heat setting
1. Activate the hob.
2. Place the pot on the selected
cooking zone.
ENGLISH
11
The slider for the active cooking zone
appears on the display and is active for 8
seconds.
3. Touch or slide your finger to set the
desired heat setting.
The symbol turns red and becomes
bigger.
You can also change the heat setting
while cooking. Touch the zone selection
symbol on the main view of the control
panel and move you finger to the left or
right (to lower or increase the heat
setting).
8.4 Using the cooking zones
Place the cookware in the centre of the
selected cooking zone. Induction
cooking zones adapt to the dimensions
of the bottom of the cookware
automatically.
Once you place a pot on the selected
cooking zone the hob automatically
detects it and the relevant slider appears
on the display. The slider is visible for 8
seconds, after that time the display goes
back to the main view. To close the slider
faster tap the screen outside of the slider
area.
When other zones are active the heat
setting for the zone you want to use may
be limited. Refer to "Power
Management".
Make sure that the pot is
suitable for induction hobs.
For more information on
cookware types refer to
"Hints and tips". Check the
size of the pot in "Technical
data".
8.5 PowerBoost
This function activates more power for
the appropriate induction cooking zone;
it depends on the cookware size. The
function can be activated only for a
limited period of time.
1.
Touch the desired zone symbol first.
2. Touch or slide your finger to the
right to activate the function for the
chosen cooking zone.
The symbol turns red and becomes
bigger.
The function deactivates automatically.
To deactivate the function manually
select the zone and change its heat
setting.
For maximum duration
values, refer to "Technical
data".
8.6 Power Management
• Cooking zones are grouped
according to the location and number
of the phases in the hob. See the
illustration.
• Each phase has a maximum electricity
loading of 3680 W.
• The function divides the power
between cooking zones connected to
the same phase.
• The function activates when the total
electricity loading of the cooking
zones connected to a single phase
exceeds 3680 W.
• The function decreases the power of
the other cooking zones connected to
the same phase, which has an
influence on the available heat
setting.
• The maximum heat setting is visible
on the slider. Only the digits in white
are active.
• If a higher heat setting is not available
reduce it for the other cooking zones
first.
www.aeg.com
12
8.7 Timer
+STOP
Count Down Timer
Use this function to specify how long a
cooking zone should operate during a
single cooking session.
You can set the function for each cooking
zone separately.
1. Set the heat setting for the
appropriate cooking zone
first and
then set the function.
2. Touch the zone symbol.
3. Touch .
The timer menu window appears on the
display.
4. Check
to activate the function.
The symbols change to
+STOP
.
5. Slide your
finger to the left or right to
select the desired time (e.g. hours
and/or minutes).
6. Touch OK to confirm your selection.
You can also choose to cancel your
selection.
When the time comes to an end, a signal
sounds and blinks. Touch to stop
the signal.
To deactivate the function set the heat
setting to 0. Alternatively, touch to
the left of the timer value, touch next
to it and confirm your choice when a
pop-up window appears.
Minute Minder
You can use this function when the hob is
activated but the cooking zones do not
operate.
The function has no effect on the
operation of the cooking zones.
1. Select any cooking zone.
The relevant slider appears on the
display.
2. Touch .
The timer menu window appears on the
display.
3. Slide your finger to the left or right to
select the desired time (e.g. hours
and minutes).
4. Touch OK to confirm your selection.
You can also choose
to cancel your
selection.
When the time comes to an end, a signal
sounds and blinks. Touch to stop
the signal.
To deactivate the function touch to
the left of the timer value, touch next
to it and confirm your choice when a
pop-up window appears.
Stopwatch
The function automatically starts
counting immediately after you activate a
cooking zone. You can use this function
to monitor how long it operates.
1. Touch to access the Menu.
2. Scroll the Menu to select Settings >
Stopwatch.
3. Touch the switch to turn the function
on / off.
The function does not stop when you lift
the pot. To reset the function and start it
again manually touch , select Reset
from the pop-up window. The function
starts counting from 0. To Pause the
function for one cooking session touch
and select Pause from the pop-up
window. Select Start to continue
counting.
8.8 Pause
This function sets all cooking zones that
operate to the lowest heat setting.
When the function operates only
and
symbols can be used. All other
symbols on the control panel are locked.
The function does not stop the timer
functions.
Touch to activate the function.
comes on. The heat setting is lowered
to 1.
To deactivate the function touch
.
The function stops PowerBoost. The
highest heat setting reactivates when you
touch again.
ENGLISH
13
8.9 Lock
You can lock the control panel while the
hob operates. It prevents an accidental
change of the heat setting.
Set the heat setting first.
Touch to activate the function.
To deactivate the function, touch for 3
seconds.
When you deactivate the
hob, you also deactivate this
function.
8.10 Child Lock
This function prevents an accidental
operation of the hob.
1. Touch on the display to open the
Menu.
2. Select Settings > Child Lock from the
list.
3. Turn the switch on and touch the
letters A-O-X in the alphabetical
order to activate the function. To
deactivate the function turn the
switch off.
To leave the Menu, touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,
use or .
8.11 Language
1. Touch on the display to open the
Menu.
2. Select Settings > Setup > Language
from the list.
3. Choose the appropriate language
from the list.
If you chose the wrong language, touch
. A list appears. Select the third option
from the top, then the last but one
option. Next, select the second option.
Scroll down to choose the appropriate
language from the list. Finally, choose
the option on the right.
To leave the Menu, touch
or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,
use or .
8.12
Key Tones / Buzzer
Volume
You can choose the type of sound your
hob emits or turn the sounds off entirely.
You can choose between the click
(default) or beep.
1. Touch on the display to open the
Menu.
2. Select Settings > Setup > Key
Tones / Buzzer Volume from the list.
3. Choose the appropriate option.
To leave the Menu, touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,
use
or .
8.13 Display Brightness
You can change the brightness of the
display.
There are 4 brightness levels, 1 is the
lowest and 4 is the highest.
1. Touch on the display to open the
Menu.
2. Select Settings > Setup > Display
Brightness from the list.
3. Choose the appropriate level.
To leave the Menu, touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,
use
or .
8.14 Assisted Cooking
This function adjusts the temperature to
different types of food and maintains it
throughout cooking. It can only be
activated for the left front cooking zone
or both zones on the left when bridged.
1. Touch on the display to open the
Menu.
2. Select Assisted Cooking and choose
the type of food you would like to
prepare from the list.
For each type of food there are a few
options available. Follow the
instructions shown on the display.
• You can touch OK on top of the
pop-up window to use the default
settings.
www.aeg.com
14
• You can set the timer function.
When the pot reaches the
intended temperature you can
activate the timer.
• You can change the default heat
level.
3. Once the pot reaches the intended
temperature an acoustic signal
sounds and a pop-up window
appears. To close the window and
start the function touch OK. To
deactivate the window permanently
check before you activate the
function.
To stop the function touch and Stop
or touch
and select Assisted
Cooking, choose any type of food and
touch Stop.
To leave the Menu touch or the right
side of the display, outside of the pop-up
window. To navigate through the Menu
use or .
8.15 Melting
You can use this function to melt
different products, e.g. chocolate or
butter. You can use the function only for
one cooking zone at a time.
1. Touch on the display to open the
Menu.
2. Select Hob Functions > Melting from
the list.
3. Touch Start.
You need to select the desired
cooking zone.
If the cooking zone is already active a
pop-up window appears. Cancel the
previous heat setting to activate the
function.
To leave the Menu, touch
or the right
side of the display, outside of the pop-up
window. To navigate through the Menu,
use or .
To stop the function, touch the zone
selection symbol and then touch Stop.
8.16 Hob²Hood
It is an advanced automatic function
which connects the hob to a special
hood. Both the hob and the hood have
an infrared signal communicator. The
speed of the fan is
defined automatically
on the basis of the mode setting and the
temperature of the hottest pot on the
hob.
For most of the hoods the remote system
is originally deactivated. Activate it
before you use the function. For more
information refer to the hood user
manual.
To operate the function automatically, set
the automatic mode to H1 - H6. The hob
is originally set to H5. The hood reacts
whenever you operate the hob. The hob
recognizes the temperature of the
cookware automatically and adjusts the
speed of the fan. You can set the hob to
activate only the light by selecting H1.
If you change the fan speed
on the hood, the default
connection with the hob is
deactivated. To reactivate
the function, turn both
appliances OFF and ON
again.
Mod
e
Auto-
matic
light
Boiling
1)
Frying
2)
H0 Off Off Off
H1 On Off Off
H2
3)
On Fan speed 1 Fan speed 1
H3 On Off Fan speed 1
H4 On Fan speed 1 Fan speed 1
H5 On Fan speed 1 Fan speed 2
H6 On Fan speed 2 Fan speed 3
1)
The hob detects the boiling process and acti-
vates fan speed in accordance with the automatic
mode.
2)
The hob detects the frying process and acti-
vates fan speed in accordance with the automatic
mode.
3)
This mode activates the fan and the light and
does not rely on the temperature.
ENGLISH 15
Changing the modes
If you are not satisfied with the noise
level / fan speed, you can switch
between modes manually.
1. Touch .
Select Settings > Hob²Hood from the
list.
2. Choose the appropriate mode.
To leave the Menu touch
or the right
side of the display, outside of the pop-up
window.
When you finish cooking and deactivate
the hob, the hood fan may still operate
for a certain period of time. After that
time the system deactivates the fan
automatically and prevents you from an
accidental activation for the next 30
seconds.
The light on the hood deactivates 2
minutes after deactivating the hob.
9. FLEXIBLE INDUCTION COOKING AREA
WARNING!
Refer to Safety chapters.
9.1 FlexiBridge
The area on the left side can be
combined into two cooking zones with
different sizes, or into one large cooking
area. You may choose a combination of 4
sections which depends on the size of
the cookware you want to use. The
cooking zone indicators change
automatically and show the possible
combination.
FlexiBridge Standard is the default mode
which activates automatically when you
activate the hob. Two cooking zones
operate independently.
Touch to switch between the
FlexiBridge modes.
9.2 FlexiBridge Standard
mode
This mode is active when you activate
the hob. It connects the sections into two
separate cooking zones. You can set the
heat setting for each zone separately.
Correct cookware position:
Incorrect cookware position:
9.3 FlexiBridge Big Bridge
mode
To activate the mode touch until you
see the correct mode indicator . This
mode connects three rear sections into
one cooking zone. The front section is
not connected and operates as a
separate cooking zone. You can set the
www.aeg.com
16
heat setting for each zone separately.
Correct cookware position:
To use this mode you have to place the
cookware on the three connected
sections. If you use cookware smaller
than two sections the
blinks on the
display and after 1 minute the zone
switches off.
Incorrect cookware position:
9.4 FlexiBridge Max Bridge
mode
To activate the mode touch until you
see the correct mode indicator . This
mode connects all sections into one
cooking zone.
Correct cookware position:
To use this mode you have to place the
cookware on the four connected
sections. If you use cookware smaller
than three sections the display shows
and after 1 minute the zone switches off.
Incorrect cookware position:
9.5 PowerSlide
This function allows you to adjust the
temperature by moving the cookware to
a different position on the induction
cooking surface. This function
automatically divides the left cooking
zones into three areas with different heat
settings. The hob detects the position of
the cookware and adjusts the pre-set
power level accordingly. You can place
the pot in the front, middle or rear
ENGLISH
17
position. If you place the cookware at the
front you get the highest heat setting
(i.e. 9). To decrease it, move the
cookware to the middle (heat setting - 5)
or rear position (heat setting -1).
Use only one pot with a
minimum bottom diameter
of 160 mm when you
operate the function.
1. Touch once.
2. Scroll the Menu > Hob Functions to
select the function from the list.
• If any of the left zones operates a
pop-up window appears asking
you to confirm whether or not you
want to cancel the previous heat
settings.
• The
symbol and the symbols of
three zones with default heat
settings appear on the display.
You can change the default heat
setting in accordance with your
needs and the heat setting will be
saved for future use.
3. Place the pot on the cooking zone
with the desired heat setting.
Place the cookware in the centre of
the desired zone and make sure you
do not cover the neighbouring
zones. Red indicators come on.
Unless you see the red indicators the
function cannot be activated.
If you want to change the position of
the pot lift it up and place on a
different zone. Sliding the cookware
can cause scratches and
discolouration of the surface.
To deactivate the function touch
, a
pop-up window appears. Touch Stop to
deactivate the function. You can also
deactivate the function from the Menu.
Move the pot from time to
time. The function
deactivates after 10 minutes
of inactivity.
10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
10.1 Cookware
For induction cooking zones
a strong electro-magnetic
field creates the heat in the
cookware very quickly.
Use the induction cooking
zones with suitable
cookware.
Cookware material
• correct: cast iron, steel, enamelled
steel, stainless steel, multi-layer
bottom (with a correct marking from a
manufacturer).
• not correct: aluminium, copper,
brass, glass, ceramic, porcelain.
Cookware is suitable for an induction
hob if:
• water boils very quickly on a zone set
to the highest heat setting.
• a magnet pulls on to the bottom of
the cookware.
The bottom of the cookware
must be as thick and flat as
possible.
Ensure pan bases are clean
and dry before placing on
the hob surface.
Cookware dimensions
Induction cooking zones adapt to the
dimension of the bottom of the
cookware automatically.
The cooking zone efficiency is related to
the diameter of the cookware. The
cookware with a diameter smaller than
the minimum receives only a part of the
power generated by the cooking zone.
Refer to "Technical data".
www.aeg.com18
10.2 Correct pans for Pan Fry
function
Use only pans with flat bottom. To check
if the pan is correct:
1. Put your pan upside down.
2. Put a ruler on the bottom of the pan.
3. Try to put a coin of 1, 2 or 5 Euro
Cent (or with similar thickness)
between the ruler and the bottom of
the pan.
a. The pan is incorrect if you can
put the coin between the ruler
and the pan.
b. The pan is correct if you cannot
put the coin between the ruler
and the pan.
10.3 The noises during
operation
If you can hear:
• crack noise: cookware is made of
different materials (a sandwich
construction).
• whistle sound: you use a cooking
zone with a high power level and the
cookware is made of different
materials (a sandwich construction).
• humming: you use a high power level.
• clicking: electric switching occurs, the
pot is detected after you place it on
the hob.
• hissing, buzzing: the fan operates.
The noises are normal and do not
indicate any malfunction.
10.4 Öko Timer (Eco Timer)
To save energy, the heater of the cooking
zone deactivates before the count down
timer sounds. The difference in the
operation time depends on the heat
setting level and the length of the
cooking operation.
10.5 Examples of cooking
applications
The correlation between the heat setting
of a zone and its consumption of power
is not linear. When you increase the heat
setting, it is not proportional to the
increase of the consumption of power. It
means that a cooking zone with the
medium heat setting uses less than a half
of its power.
The data in the table is for
guidance only.
Heat setting Use to: Time
(min)
Hints
1 Keep cooked food warm. as nec-
essary
Put a lid on the cookware.
ENGLISH 19
Heat setting Use to: Time
(min)
Hints
1 - 2 Hollandaise sauce, melt: but-
ter, chocolate, gelatine.
5 - 25 Mix from time to time.
1 - 2 Solidify: fluffy omelettes,
baked eggs.
10 - 40 Cook with a lid on.
2 - 3 Simmer rice and milkbased
dishes, heat up ready-cooked
meals.
25 - 50 Add at least twice as much liq-
uid as rice, mix milk dishes
halfway through the proce-
dure.
3 - 4 Steam vegetables, fish, meat. 20 - 45 Add a couple of tablespoons
of liquid.
4 - 5 Steam potatoes. 20 - 60 Use max. ¼ l of water for 750 g
of potatoes.
4 - 5 Cook larger quantities of food,
stews and soups.
60 - 150 Up to 3 l of liquid plus ingredi-
ents.
6 - 7 Gentle fry: escalope, veal cor-
don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts.
as nec-
essary
Turn halfway through.
7 - 8 Heavy fry, hash browns, loin
steaks, steaks.
5 - 15 Turn halfway through.
9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
Boil large quantities of water. PowerBoost is activated.
10.6 Hints and Tips for
Hob²Hood
When you operate the hob with the
function:
• Protect the hood panel from direct
sunlight.
• Do not spot halogen light on the
hood panel.
• Do not cover the hob control panel.
• Do not interrupt the signal between
the hob and the hood (e.g. with the
hand, a cookware handle or a tall pot).
See the picture.
The hood in the picture is only
exemplary.
Keep the window of the
Hob²Hood infrared signal
communicator clean.
www.aeg.com20
Other remotely controlled
appliances may block the
signal. Do not use any such
appliances near to the hob
while Hob²Hood is on.
Cooker hoods with the Hob²Hood
function
To find the full range of cooker hoods
which work with this function refer to our
consumer website. The AEG cooker
hoods that work with this function must
have the symbol .
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 General information
• Clean the hob after each use.
• Always use cookware with a clean
base.
• Scratches or dark stains on the surface
have no effect on how the hob
operates.
• Use a special cleaner suitable for the
surface of the hob.
• Use a special scraper for the glass.
The printing on the
flexible
induction cooking area may
become dirty or change its
colour from sliding the
cookware. You can clean the
area in a standard way.
11.2 Cleaning the hob
• Remove immediately: melted plastic,
plastic foil, sugar and food with sugar,
otherwise, the dirt can cause damage
to the hob. Take care to avoid burns.
Use a special hob scraper on the glass
surface at an acute angle and move
the blade on the surface.
• Remove when the hob is sufficiently
cool: limescale rings, water rings, fat
stains, shiny metallic discoloration.
Clean the hob with a moist cloth and
a non-abrasive detergent. After
cleaning, wipe the hob dry with a soft
cloth.
• Remove shiny metallic
discoloration: use a solution of water
with vinegar and clean the glass
surface with a cloth.
• The surface of the hob has horizontal
grooves. Clean the hob with a moist
cloth and some detergent with
smooth movement from left to right.
After cleaning, wipe the hob dry with
a soft cloth from left to right.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
Problem Possible cause Remedy
You cannot activate or oper-
ate the hob.
The hob is not connected to
an electrical supply or it is
connected incorrectly.
Check if the hob is correctly
connected to the electrical
supply. Refer to the connec-
tion diagram.
ENGLISH 21
Problem Possible cause Remedy
The fuse is blown. Make sure that the fuse is
the cause of the malfunction.
If the fuse is blown again
and again, contact a quali-
fied electrician.
You do not set the heat set-
ting for 60 seconds.
Activate the hob again and
set the heat setting in less
than 60 seconds.
You touched 2 or more sen-
sor fields at the same time.
Touch only one sensor field.
Pause operates. Refer to "Daily use".
The display does not react
to the touch.
Part of the display is covered
or the pots are placed too
near to the display.
There is some liquid or an
object on the display.
Remove the objects. Move
the pots away from the dis-
play.
Clean the display, wait until
the appliance is cold. Dis-
connect the hob from the
electrical supply. After 1 min,
connect the hob again.
An acoustic signal sounds
and the hob deactivates.
An acoustic signal sounds
when the hob is deactivated.
You put something on one
or more sensor fields.
Remove the object from the
sensor fields.
The hob deactivates. You put something on the
sensor field .
Remove the object from the
sensor field.
Residual heat indicator does
not come on.
The zone is not hot because
it operated only for a short
time or the sensor under the
hob surface is damaged.
If the zone operated suffi-
ciently long to be hot, speak
to an Authorised Service
Centre.
You cannot activate the
highest heat setting.
Another zone is already set
to the highest heat setting.
First reduce the power of the
other zone.
The sensor fields become
hot.
The cookware is too large or
you put it too near to the
controls.
Put large cookware on the
rear zones if possible.
Hob²Hood does not work. You covered the control pan-
el.
Remove the object from the
control panel.
Hob²Hood operates, but on-
ly the light is on.
You activated the H1 mode. Change the mode to H2 - H6
or wait until the automatic
mode starts.
Hob²Hood modes H1 - H6
operate, but the light is off.
There might be a problem
with the light bulb.
Contact an Authorised Serv-
ice Centre.
www.aeg.com22
Problem Possible cause Remedy
There is no sound when you
touch the panel sensor
fields.
The sounds are deactivated. Activate the sounds. Refer to
"Daily use".
Wrong language is set. You changed the language
by mistake.
Reset all functions to the fac-
tory settings. Select Reset All
Settings from the Menu.
Disconnect the hob from the
electrical supply. After 1 min,
connect the hob again. Set
Language, Display Bright-
ness and Buzzer Volume.
The flexible induction cook-
ing area does not heat up
the cookware.
The cookware is in a wrong
position on the flexible in-
duction cooking area.
Place the cookware in the
correct position on the flexi-
ble induction cooking area.
The position of the cook-
ware depends on the activa-
ted function or function
mode. Refer to "Flexible in-
duction cooking area".
The diameter of the bottom
of the cookware is incorrect
for the activated function or
function mode.
Use cookware with a diame-
ter applicable to the activa-
ted function or function
mode. Use cookware with a
diameter smaller than 160
mm on a single section of
the flexible induction cook-
ing area. Refer to "Flexible
induction cooking area".
A cooking zone deactivates.
A warning message saying
the cooking zone is going to
switch off comes on.
Automatic Switch Off deacti-
vates the cooking zone.
Refer to "Daily use".
Deactivate the hob and acti-
vate it again.
and a message come on.
Lock operates. Refer to "Daily use".
O - X - A appears. Child Lock operates. Refer to "Daily use".
blinks.
There is no cookware on the
zone.
Put cookware on the zone.
The cookware is unsuitable. Use suitable cookware. Refer
to "Hints and tips".
The diameter of the bottom
of the cookware is too small
for the zone.
Use cookware with correct
dimensions. Refer to "Tech-
nical data".
ENGLISH 23
Problem Possible cause Remedy
FlexiBridge operates. One
or more sections of the func-
tion mode which operates
are not covered by the cook-
ware.
Place the cookware on the
correct number of sections
of the function mode which
operates or change the func-
tion mode. Refer to "Flexi-
ble induction cooking area".
PowerSlide operates. Two
pots are placed on the flexi-
ble induction cooking area.
Use only one pot. Refer to
"Flexible induction cooking
area".
and a number come on.
There is an error in the hob. Deactivate the hob and acti-
vate it again after 30 sec-
onds. If comes on again,
disconnect the hob from the
electrical supply. After 30
seconds, connect the hob
again. If the problem contin-
ues, speak to an Authorised
Service Centre.
You can hear a constant
beep noise.
The electrical connection is
incorrect.
Disconnect the hob from the
electrical supply. Ask a quali-
fied electrician to check the
installation.
12.2 If you cannot find a
solution...
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre. Give the
data from the rating plate. Make sure,
you operated the hob correctly. If not the
servicing by a service technician or
dealer will not be free of charge, also
during the warranty period. The
instructions about the Service Centre and
conditions of guarantee are in the
guarantee booklet.
13. TECHNICAL DATA
13.1 Rating plate
Model IAE64851FB PNC 949 597 568 00
Typ 62 B4A 05 CA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in Germany
Ser.Nr. ................. 7.35 kW
AEG
13.2 Software Licences
The software included in the hob
contains copyrighted software that is
licensed under the BSD, fontconfig, FTL,
GPL-2.0, LGPL-2.0, LGPL-2.1, libJpeg,
zLib/ libpng, MIT, OpenSSL / SSLEAY
ISC, Apache 2.0 and others.
www.aeg.com24
Check the full copy of the licence in:
Menu > Settings > Service > License.
You can download the source code of
the open source software by following
the hyperlink present in the web product
page.
13.3 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
PowerBoost
[W]
PowerBoost
maximum dura-
tion [min]
Cookware diam-
eter [mm]
Right front 1400 2500 4 125 - 145
Right rear 1800 2800 10 145 - 180
Flexible induc-
tion cooking
area
2300 3200 10 minimum 100
The power of the cooking zones can be
different in some small range from the
data in the table. It changes with the
material and dimensions of the
cookware.
For optimal cooking results use
cookware no larger than the diameter in
the table.
14. ENERGY EFFICIENCY
14.1 Product information according to EU 66/2014 valid for EU
market only
Model identification IAE64851FB
Type of hob Built-In Hob
Number of cooking zones 2
Number of cooking areas 1
Heating technology Induction
Diameter of circular cook-
ing zones (Ø)
Right front
Right rear
14.5 cm
18.0 cm
Lenght (L) and width (W) of
the cooking area
Left L 45.9 cm
W 21.4 cm
Energy consumption per
cooking zone (EC electric
cooking)
Right front
Right rear
187.5 Wh / kg
174.6 Wh / kg
Energy consumption of the
cooking area (EC electric
cooking)
Left 187.0 Wh / kg
ENGLISH 25
Energy consumption of the
hob (EC electric hob)
184.6 Wh / kg
EN 60350-2 - Household electric cooking
appliances - Part 2: Hobs - Methods for
measuring performance
14.2 Energy saving
You can save energy during everyday
cooking if you follow below hints.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on
the cookware.
• Before you activate the cooking zone
put the cookware on it.
• Put the smaller cookware on the
smaller cooking zones.
• Put the cookware directly in the
centre of the cooking zone.
• Use the residual heat to keep the
food warm or to melt it.
15. WARRANTY
FOR SALES IN AUSTRALIA AND NEW
ZEALAND
ALL AEG BRANDED APPLIANCES
This document sets out the terms and
conditions of the product warranties
for AEG Appliances. It is an important
document. Please keep it with your
proof of purchase documents in a safe
place for future reference should there
be a manufacturing defect in your
Appliance. This warranty is in addition
to other rights you may have under
the Australian Consumer Law.
1. In this warranty:
a) ‘ACL’ or ‘Australian Consumer
Law’ means Schedule 2 to the
Competition and Consumer Act
2010;
b) ‘Appliance’ means any Electrolux
product purchased by you and
accompanied by this document;
c) ‘ASC’ means Electrolux’s
authorised serviced centres;
d) ‘AEG’ is the brand controlled by
Electrolux Home Products Pty Ltd
of 163 O’Riordan Street, Mascot
NSW 2020, ABN 51 004 762 341
in respect of Appliances
purchased in Australia and
Electrolux (NZ) Limited
(collectively “Electrolux”) of 3-5
Niall Burgess Road, Mount
Wellington, in respect of
Appliances purchased in New
Zealand;
e) ‘Warranty Period’ means the
period
specified in clause 3 of
this warranty;
f) ‘you’ means the purchaser of the
Appliance not having purchased
the Appliance for re-sale, and
‘your’ has a corresponding
meaning.
2. Application: This warranty only
applies to new Appliances,
purchased and used in Australia or
New Zealand and is in addition to
(and does not exclude, restrict, or
modify in any way) other rights and
remedies under a law to which the
Appliances or services relate,
including any non-excludable
statutory guarantees in Australia and
New Zealand.
3. Warranty Period: Subject to these
terms and conditions, this warranty
continues for in Australia for a period
of 60 months and in New Zealand for
a period of 60 months, following the
date of original purchase of the
Appliance.
4. Repair or replace warranty: During
the Warranty Period, Electrolux or its
ASC will, at no extra charge if your
Appliance is readily accessible for
service, without special equipment
and subject to these terms and
conditions, repair or replace any
parts which it considers to be
defective. Electrolux may, in its
absolute discretion, choose whether
the remedy offered for a valid
warranty claim is repair or
www.aeg.com
26
replacement. Electrolux or its ASC
may use refurbished parts to repair
your Appliance. You agree that any
replaced Appliances or parts
become the property of Electrolux.
5. Travel and transportation costs:
Subject to clause 7, Electrolux will
bear the reasonable cost of
transportation, travel and delivery of
the Appliance to and from Electrolux
or its ASC. Travel and transportation
will be arranged by Electrolux as part
of any valid warranty claim.
6. Proof of purchase is required before
you can make a claim under this
warranty.
7. Exclusions: You may not make a
claim under this warranty unless the
defect claimed is due to faulty or
defective parts or workmanship. This
warranty does not cover:
a) light globes, batteries, filters or
similar perishable parts;
b) parts and Appliances not
supplied by Electrolux;
c) cosmetic damage which does
not affect the operation of the
Appliance;
d) damage to the Appliance caused
by:
– negligence or accident;
– misuse or abuse, including
failure to properly maintain or
service;
– improper, negligent or faulty
servicing or repair works done
by anyone other than an
Electrolux authorised repairer
or ASC;
– normal wear and tear;
– power surges, electrical storm
damage or incorrect power
supply;
– incomplete or improper
installation;
– incorrect, improper or
inappropriate operation;
– insect or vermin infestation;
– failure to comply with any
additional instructions
supplied with the Appliance;
In addition, Electrolux is not
liable under this warranty if:
– the Appliance has been, or
Electrolux reasonably believes
that the Appliance has been,
used for purposes other than
those for which the Appliance
was intended, including
where the Appliance has
been used for any non-
domestic purpose;
– the Appliance is
modified
without authority from
Electrolux in writing;
– the Appliance’s serial number
or warranty seal has been
removed or defaced.
8. How to claim under this warranty:
To enquire about claiming under this
warranty, please follow these steps:
a. carefully check the operating
instructions, user manual and the
terms of this warranty;
b. have the model and serial
number of the Appliance
available;
c. have the proof of purchase (e.g.
an invoice) available;
d. telephone the numbers shown
below.
9. Australia: For Appliances and
services provided by Electrolux in
Australia: Electrolux goods come
with guarantees that cannot be
excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major
failure and for compensation for any
other reasonably foreseeable loss or
damage. You are also entitled to
have the Appliance repaired or
replaced if the Appliance fails to be
of acceptable quality and the failure
does not amount to a major failure.
‘Acceptable quality’ and ‘major
failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and
services provided by Electrolux in
New Zealand, the Appliances come
with a guarantee by Electrolux
pursuant to the provisions of the
Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading
Act. Where the Appliance was
purchased in New Zealand for
commercial purposes the Consumer
Guarantee Act does not apply.
11. Confidentiality: You accept that if
you make a warranty claim, Electrolux
and its agents including ASC may
ENGLISH
27
exchange information in relation to
you to enable Electrolux to meet its
obligations under this warranty.
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been
followed.
SERVICE AUSTRALIA
aeg.com/au
FOR SERVICE
or to find the address of your nearest au-
thorised service centre in Australia
PLEASE CALL 1300 363 664
OR EMAIL
customercar[email protected]
For the cost of a local call (Australia only)
FOR SPARE PARTS
or to find the address of your nearest spare
parts centre in Australia
PLEASE CALL 13 13 50
OR EMAIL
customercar[email protected]
For the cost of a local call (Australia only)
SERVICE NEW ZEALAND
aegnewzealand.co.nz
FOR SERVICE
or to find the address of your nearest au-
thorised service centre in New Zealand
PLEASE CALL 0800 234 234
OR EMAIL
customercar[email protected]
(New Zealand only)
FOR SPARE PARTS
or to find the address of your nearest spare
parts centre in New Zealand
PLEASE CALL 0800 10 66 20
OR EMAIL
customercar[email protected]
(New Zealand only)
AEG_Warr_May_17
16. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
www.aeg.com
28
www.aeg.com/au
867358210-A-122020
