Smart On-Street ANPR Camera
User Manual
Iniaves on the Use of Video Products
Thank you for choosing Hikvision products.
Technology aects every aspect of our life. As a high-tech company, we are increasingly aware of
the role technology plays in improving business eciency and quality of life, but at the same me,
the potenal harm of its improper usage. For example, video products are capable of recording
real, complete and clear images. This provides a high value in retrospect and preserving real-me
facts. However, it may also result in the infringement of a third party's legimate rights and
interests if improper distribuon, use and/or processing of video data takes place. With the
philosophy of "Technology for the Good", Hikvision requests that every end user of video
technology and video products shall comply with all the applicable laws and regulaons, as well as
ethical customs, aiming to jointly create a beer community.
Please read the following iniaves carefully:
●
Everyone has a reasonable expectaon of privacy, and the installaon of video products should
not be in conict with this reasonable expectaon. Therefore, a warning noce shall be given in
a reasonable and eecve manner and clarify the monitoring range, when installing video
products in public areas. For non-public areas, a third party's rights and interests shall be
evaluated when installing video products, including but not limited to, installing video products
only aer obtaining the consent of the stakeholders, and not installing highly-invisible video
products.
●
The purpose of video products is to record real acvies within a specic me and space and
under specic condions. Therefore, every user shall rst reasonably dene his/her own rights in
such specic scope, in order to avoid infringing on a third party's portraits, privacy or other
legimate rights.
●
During the use of video products, video image data derived from real scenes will connue to be
generated, including a large amount of biological data (such as facial images), and the data could
be further applied or reprocessed. Video products themselves could not disnguish good from
bad regarding how to use the data based solely on the images captured by the video products.
The result of data usage depends on the method and purpose of use of the data controllers.
Therefore, data controllers shall not only comply with all the applicable laws and regulaons and
other normave requirements, but also respect internaonal norms, social morality, good
morals, common pracces and other non-mandatory requirements, and respect individual
privacy, portrait and other rights and interests.
●
The rights, values and other demands of various stakeholders should always be considered when
processing video data that is connuously generated by video products. In this regard, product
security and data security are extremely crucial. Therefore, every end user and data controller,
shall undertake all reasonable and necessary measures to ensure data security and avoid data
leakage, improper disclosure and improper use, including but not limited to, seng up access
Smart On-Street ANPR Camera User Manual
i
control, selecng a suitable network environment (the Internet or Intranet) where video
products are connected, establishing and constantly opmizing network security.
●
Video products have made great contribuons to the improvement of social security around the
world, and we believe that these products will also play an acve role in more aspects of social
life. Any abuse of video products in violaon of human rights or leading to criminal acvies are
contrary to the original intent of technological innovaon and product development. Therefore,
each user shall establish an evaluaon and tracking mechanism of their product applicaon to
ensure that every product is used in a proper and reasonable manner and with good faith.
Smart On-Street ANPR Camera User Manual
ii
Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Smart On-Street ANPR Camera User Manual
iii
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Smart On-Street ANPR Camera User Manual
iv
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the LVD Direcve 2014/35/EU, the RoHS
Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collecon points. For
more informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the baery to your supplier or to a
designated collecon point. For more informaon see: www.recyclethis.info
Smart On-Street ANPR Camera User Manual
v
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Smart On-Street ANPR Camera User Manual
vi
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Smart On-Street ANPR Camera User Manual
vii
Safety Instrucon
Regulatory Informaon
This is a class A product and may cause radio interference in which case the user may be required
to take adequate measures.
Laws and Regulaons
Use of the product must be in strict compliance with the local laws and regulaons. Please shut
down the device in prohibited area.
Power Supply
●
Use of the product must be in strict compliance with the local electrical safety regulaons.
●
Use the power adapter provided by qualied manufacturer. Refer to the product specicaon for
detailed power requirements.
●
It is recommended to provide independent power adapter for each device as adapter overload
may cause over-heang or a re hazard.
●
Make sure that the power has been disconnected before you wire, install, or disassemble the
device in the authorized way according to the descripon in the manual.
●
To avoid electric shock, DO NOT directly touch exposed contacts and components once the
device is powered up.
●
DO NOT use damaged power supply devices (e.g., cable, power adapter, etc.) to avoid electric
shock, re hazard, and explosion.
●
DO NOT directly cut the power supply to shut down the device. Please shut down the device
normally and then unplug the power cord to avoid data loss.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
Make sure the power supply has been disconnected if the power adapter is idle.
●
Connect to earth before connecng to the power supply.
●
The power source should meet limited power source or PS2 requirements according to IEC
60950-1 or IEC 62368-1 standard.
Transportaon, Use, and Storage
●
To avoid heat accumulaon, good venlaon is required for a proper operang environment.
●
Store the device in dry, well-venlated, corrosive-gas-free, no direct sunlight, and no heang
source environment.
●
Avoid re, water, and explosive environment when using the device.
●
Install the device in such a way that lightning strikes can be avoided. Provide a surge suppressor
at the inlet opening of the equipment under special condions such as the mountain top, iron
tower, and forest.
●
Keep the device away from magnec interference.
●
Avoid device installaon on vibratory surfaces or places. Failure to comply with this may cause
device damage.
Smart On-Street ANPR Camera User Manual
viii
●
DO NOT touch the heat dissipaon component to avoid burns.
●
DO NOT expose the device to extremely hot, cold, or humidity environments. For temperature
and humidity requirements, see device specicaon.
●
No naked ame sources, such as lighted candles, should be placed on the equipment.
●
DO NOT touch the sharp edges or corners.
●
To prevent possible hearing damage, DO NOT listen at high volume levels for long periods.
Maintenance
●
If smoke, odor, or noise arises from the device, immediately turn o the power, unplug the
power cable, and contact the service center.
●
If the device cannot work properly, contact the store you purchased it or the nearest service
center. DO NOT disassemble or modify the device in the unauthorized way (For the problems
caused by unauthorized modicaon or maintenance, the company shall not take any
responsibility).
●
Keep all packaging aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original packaging. Transportaon without the
original packaging may result in damage to the device and the company shall not take any
responsibility.
Network
●
Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Contact us if network security risks occur.
●
Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Lens
●
DO NOT touch the lens with ngers directly in case the acidic sweat of the ngers erodes the
surface coang of the lens.
●
DO NOT aim the lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the device.
Baery
●
DO NOT charge the baery connuously more than one week. Overcharging may shorten the
baery life.
●
Baery will discharge gradually if it is not used for a long me. It must be recharged before
using.
●
If the device contains dismountable baery, store the device and baery separately if it is not
used.
●
The baery must be charged and discharged every three months if it is not used, and recharged
to 60% to 70% power percentage to store.
●
The scrapped baery should be discarded in compliance with the local laws and regulaons. If
there are no corresponding laws or regulaons, throw it in a hazardous trash can.
Smart On-Street ANPR Camera User Manual
ix
●
DO NOT pierce the baery or shorten the electrodes, or it may cause explosion or re hazard.
●
DO NOT dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
●
CAUTION: Please use the specic baery supported by the device, or it may cause explosion. If
the baery is damaged and needs to be changed, contact the device manufacturer or local
distributor.
●
If the device contains buon baery, keep it far away from children.
●
DO NOT expose the baery pack or baery combinaon to sunlight, re, or similar overheated
environment. DO NOT leave the baery in an extremely high temperature surrounding
environment or subject the baery to extremely low air pressure, which may result in an
explosion or the leakage of ammable liquid or gas.
●
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children.
Data
DO NOT disconnect the power during formang, uploading, and downloading. Or les may be
damaged.
Smart On-Street ANPR Camera User Manual
x
Contents
Chapter 1 Introducon ............................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key Feature ............................................................................................................................ 1
Chapter 2 Acvaon and Login ................................................................................................... 2
2.1 Acvaon ............................................................................................................................... 2
2.1.1 Default Informaon ...................................................................................................... 2
2.1.2 Acvate via SADP .......................................................................................................... 2
2.1.3 Acvate via Web Browser ............................................................................................. 3
2.2 Login ...................................................................................................................................... 4
Chapter 3 Parking Space Detecon ............................................................................................. 5
3.1 Set Parking Parameters .......................................................................................................... 5
3.2 Set Parking Space Indicator .................................................................................................... 6
3.3 Set Allowlist and Blocklist ...................................................................................................... 6
3.4 Set Capture Parameters ......................................................................................................... 8
3.4.1 Set Flash Light Parameters ............................................................................................ 8
3.4.2 Set Picture Composion ................................................................................................ 9
3.4.3 Set Capture Overlay .................................................................................................... 10
3.4.4 Set Image Encoding Parameters .................................................................................. 11
3.5 View Real-Time Picture ........................................................................................................ 12
Chapter 4 Live View and Local Conguraon ............................................................................ 14
4.1 Live View .............................................................................................................................. 14
4.1.1 Start/Stop Live View .................................................................................................... 14
4.1.2 Select Image Display Mode ......................................................................................... 14
4.1.3 Select Stream Type ...................................................................................................... 14
4.1.4 Capture Picture Manually ........................................................................................... 14
4.1.5 Record Manually ......................................................................................................... 14
Smart On-Street ANPR Camera User Manual
xi
4.1.6 Enable Digital Zoom .................................................................................................... 15
4.2 Local Conguraon .............................................................................................................. 15
Chapter 5 Storage ..................................................................................................................... 17
5.1 Set FTP ................................................................................................................................. 17
5.2 Set Listening Host ................................................................................................................. 18
5.3 Set Cloud Storage ................................................................................................................. 18
Chapter 6 Encoding and Display ................................................................................................ 20
6.1 Set Video Encoding Parameters ........................................................................................... 20
6.2 Set Image Parameters .......................................................................................................... 21
6.3 Set ICR .................................................................................................................................. 24
6.4 Set ROI ................................................................................................................................. 24
6.5 Set OSD ................................................................................................................................ 26
Chapter 7 Network Conguraon ............................................................................................. 28
7.1 Set IP Address ...................................................................................................................... 28
7.2 Connect to ISUP Plaorm .................................................................................................... 30
7.3 Set DDNS .............................................................................................................................. 31
7.4 Set Port ................................................................................................................................ 31
Chapter 8 Serial Port Conguraon ........................................................................................... 33
8.1 Set RS-485 ............................................................................................................................ 33
8.2 Set RS-232 ............................................................................................................................ 33
Chapter 9 Excepon Alarm ....................................................................................................... 35
Chapter 10 Safety Management ............................................................................................... 36
10.1 Manage User ...................................................................................................................... 36
10.2 Enable User Lock ................................................................................................................ 36
10.3 Set HTTPS ........................................................................................................................... 37
10.3.1 Create and Install Self-signed Cercate .................................................................. 37
10.3.2 Install Authorized Cercate ..................................................................................... 37
10.4 Set SSH ............................................................................................................................... 38
Smart On-Street ANPR Camera User Manual
xii
Chapter 11 Maintenance .......................................................................................................... 39
11.1 View Device Informaon .................................................................................................... 39
11.2 Enable System Log Service ................................................................................................. 39
11.3 Upgrade ............................................................................................................................. 39
11.4 Reboot ............................................................................................................................... 40
11.5 Restore Parameters ............................................................................................................ 40
11.6 Synchronize Time ............................................................................................................... 40
11.7 Set DST ............................................................................................................................... 41
11.8 Export Parameters ............................................................................................................. 41
11.9 Import Conguraon File ................................................................................................... 41
11.10 Export Debug File ............................................................................................................. 42
Appendix A. Communicaon Matrix and Device Command ...................................................... 43
Smart On-Street ANPR Camera User Manual
xiii
Chapter 1 Introducon
1.1 Product Introducon
Embedded with camera and radar, Smart On-Street ANPR Camera (hereinaer referred to as
"device") adopts advanced deep-learning algorithm and integrates radar detecon to realize the
road side parking spaces capture. It supports license plate recognion and vehicle entry and exit
detecon.
The device supports the scenes of parallel parking, reverse parking, and pulling-in-head parking,
applicable to the outdoor road side parking space management widely.
1.2 Key Feature
●
Embedded with HD camera. Dual detecon via video and radar.
●
Adopts energy-saving LED indicator with high brightness and low consumpon to indicate seven
colors.
●
Vehicle entry and exit detecon, and license plate recognion.
●
Supports short lens applicable to wider scenes.
●
Supports hand-in-hand network cascade allocaon.
Smart On-Street ANPR Camera User Manual
1
Chapter 2 Acvaon and Login
2.1 Acvaon
For the rst-me access, you need to acvate the device by seng an admin password. No
operaon is allowed before acvaon. The device supports mulple acvaon methods, such as
acvaon via SADP soware, web browser, and client soware.
Note
Refer to the user manual of client soware for the acvaon via client soware.
2.1.1 Default Informaon
Device default informaon are as follows.
●
Default IP address: 192.168.1.64
●
Default user name: admin
2.1.2 Acvate via SADP
SADP is a tool to detect, acvate, and modify the IP address of the devices over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website ( hps://
www.hikvision.com/ ), and install it according to the prompts.
●
The device and the computer that runs the SADP tool should belong to the same network
segment.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Enter a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click Acvate to start acvaon.
Smart On-Street ANPR Camera User Manual
2
Figure 2-1 Acvate via SADP
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same network segment as your computer by either
modifying the IP address manually or checking Enable DHCP.
3) Enter the admin password and click Modify to acvate your IP address modicaon.
2.1.3 Acvate via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware or client soware to acvate the device.
Before You Start
Ensure the device and the computer connect to the same LAN.
Steps
1.
Change the IP address of your computer to the same network segment as the device.
2.
Open the web browser, and enter the default IP address of the device to enter the acvaon
interface.
3.
Create and conrm the admin password.
Smart On-Street ANPR Camera User Manual
3
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click OK to complete acvaon.
5.
Go to the network sengs interface to modify IP address of the device.
2.2 Login
You can log in to the device via web browser for further operaons such as live view and local
conguraon.
Before You Start
Connect the device to the network directly, or via a switch or a router.
Steps
1.
Open the web browser, and enter the IP address of the device to enter the login interface.
2.
Enter User Name and Password.
3.
Click Login.
4.
Download and install appropriate plug-in for your web browser. Follow the installaon prompts
to install the plug-in.
5.
Reopen the web browser aer the installaon of the plug-in and repeat steps 1 to 3 to login.
6.
Oponal: Click Logout on the upper right corner of the interface to log out of the device.
Smart On-Street ANPR Camera User Manual
4
Chapter 3 Parking Space Detecon
3.1 Set Parking Parameters
Set parking parameters to detect the parking status of the parking space, and capture license
plates.
Steps
1.
Go to Conguraon → Device Conguraon → Smart Analysis .
Figure 3-1 Set Parking Parameters
2.
Adjust the lane lines on the live view image to make them overlap with the parking space lines in
the actual scene.
3.
Set the parameters below.
Parking Duraon
The capture will be triggered aer the set duraon.
Parking Space No.
The No. will be overlaid on the captured pictures.
Parking Mode
Smart On-Street ANPR Camera User Manual
5
Select the parking mode according to the actual scene.
One word parallel
Parallel parking.
Perpendicular to the middle line
Backing into a parking space or pulling in head.
LED Energy Saving Mode
It is used to control the supplement light. If you enable the mode, only when the vehicle is
being parked into or driven out of the parking space, will the supplement light be enabled.
4.
Click Save.
3.2 Set Parking Space Indicator
Set the parking space indicator to indicate dierent colors for dierent parking status.
Before You Start
Set the detecon lanes of the parking space.
Steps
1.
Go to Conguraon → Device Conguraon → Parking Space Indicator → Parking Space
Indicator .
Figure 3-2 Set Parking Space Indicator
2.
Select Indicator Control Mode.
3.
Set Indicator Flicker and Indicator Color for dierent parking space status.
4.
Oponal: Check Vehicle Entry Alarm.
The indicator will icker the set color for the occupied parking status when the vehicle is
entering into the parking space.
5.
Click Save.
3.3 Set Allowlist and Blocklist
You can set the parking lock linked allowlist and blocklist to control the parking.
Smart On-Street ANPR Camera User Manual
6
Before You Start
●
Connect the parking lock to the RS-485 interface of the device.
●
Install the storage media, and ensure the storage status is normal.
Steps
1.
Go to Conguraon → Device Conguraon → Capture Parameters → Blocklist/Allowlist .
2.
Add a allowlist or blocklist.
1) Click Add.
2) Set License Plate Number and Card No., and select the list type.
3) Oponal: If you want to control vehicles during xed me period, check Time Sengs, and
set the eecve start me and end me.
4) Click OK.
Note
Wait for 15 minutes to let the added allowlist or blocklist write into the storage. Do not reboot
the device during the process.
The informaon of the added vehicles in the allowlist or blocklist will be listed in the table.
Figure 3-3 Set Allowlist and Blocklist
3.
You can search, edit, delete, or import the allowlist or blocklist.
Smart On-Street ANPR Camera User Manual
7
Search Select the search type, or enter the keywords. Click Search. The searched vehicle
informaon will be listed in the table.
Edit Select an item from the list, and click Edit. Edit the informaon, and click OK.
Delete Select the deleng type, or enter the keywords. Click Delete.
Import a. Click Import.
b. Click Download Template, and save the template.
c. Open the template, edit the informaon, and save it.
d. Click Import again.
e. Click
to select the edited template.
f. Click Import to import the informaon to the device.
3.4 Set Capture Parameters
3.4.1 Set Flash Light Parameters
Flash light can enhance the image stabilizaon and adjust the brightness and color temperature.
You can use ash light to supplement light at night or when the light is dim.
Steps
Note
Only when the constant light is connected, can the set parameters take eect.
1.
Go to Conguraon → Device Conguraon → Capture Parameters → Flash Light Parameters .
Figure 3-4 Set Flash Light Parameters
2.
Set constant light control mode and other parameters.
-
Check Control Constant Light by Brightness when you want the constant light to be controlled
by detecng the surroundings brightness automacally. Set Brightness Threshold. The higher
the threshold is, the harder the constant light can be enabled.
Smart On-Street ANPR Camera User Manual
8
-
Check Control Constant Light by Schedule when you want the constant light to be enabled
during xed me period. Set the start me and end me.
Note
Controlling constant light by brightness and schedule conict with each other.
3.
Set Constant Light Brightness.
Note
The higher the brightness is, the more the light will be supplemented.
4.
Click Save.
3.4.2 Set Picture Composion
You can enable the picture composion to composite several pictures into one to make it
convenient to view the violaon captured pictures.
Steps
Note
Funcons and parameters vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → Capture Parameters → Image Composion .
Figure 3-5 Set Picture Composion
2.
Check Enable Composion.
3.
Set composion types for dierent picture quanes.
4.
Set other composion parameters.
Close-up Zooming Rao
The higher the value is, the larger the close-up is.
Close-up Picture No.
It is the picture where the close-up comes from.
Smart On-Street ANPR Camera User Manual
9
Plate Close-up Oset
The default value is 0, which is recommended to be adopted. The device can capture close-up
pictures according to the set oset when no license plate is recognized.
5.
Click Save.
3.4.3 Set Capture Overlay
If you want to overlay informaon on the captured pictures, set capture overlay.
Steps
1.
Go to Conguraon → Device Conguraon → Text Overlay → Single Picture Overlay .
2.
Check Capture Picture Overlay.
Figure 3-6 Set Capture Overlay
3.
Set the font size, color, overlay posion, etc.
Percentage
It is the percentage that the overlaid informaon occupies on the picture.
Overlay Number Zeroizing
Smart On-Street ANPR Camera User Manual
10
When the overlaid number digits are smaller than the xed digits, 0 will be overlaid before
the overlaid number. E.g., the xed digits for lane No. is 2. If the lane No. is 1, 01 will be
overlaid on the picture.
Overlay Plate Close-up
Check it, and a license plate close-up picture will be overlaid on the upper le corner of the
captured picture.
4.
Select the overlay informaon from the list.
Note
The overlay informaon may vary with dierent models. The actual device prevails.
5.
Set the overlay informaon.
Type You can edit the type.
Overlay Informaon For some informaon types, you can edit the detailed informaon.
Overlay Posion Check it, and the current informaon will be displayed from a new line.
Space Edit the number of space between the current informaon and the
next one from 0 to 255. 0 means there is no space.
Line Break
Characters
Edit the number of characters from 0 to 100 between the current
informaon line and the previous informaon line. 0 means no line
break.
/ Adjust the display sequence of the overlay informaon.
6.
Click Save.
3.4.4 Set Image Encoding Parameters
If the captured pictures are not clear, set the resoluon of the captured pictures and the picture
size.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Image Encoding .
Figure 3-7 Set Image Encoding Parameters
2.
Select Capture Resoluon.
3.
Enter JPEG Picture Size.
4.
Click Save.
Smart On-Street ANPR Camera User Manual
11
3.5 View Real-Time Picture
You can view the real-me captured pictures and informaon of the captured vehicles.
Steps
1.
Go to Live View → Live Trac Stascs .
2.
Select the captured picture from the picture list, and you can view the capture scene picture and
the captured license plate picture.
Figure 3-8 Real-Time Picture
3.
You can do the following operaons on this interface.
-
Select the arming mode. Level 1 Arming can only connect one client or web. The uploaded
pictures will not be stored in the storage card. The pictures in the storage card will be
uploaded to the level 1 arming. Level 2 Arming can connect three clients or webs. The
pictures will be uploaded to the client/web, and stored in the storage card. Disarming is to
cancel the alarm status or real-me picture.
Smart On-Street ANPR Camera User Manual
12
-
Click Measuring license plate to measure the license plate pixel. Aer the measurement, click
Closing measurement.
-
Click Enable Ruler to enable ruler when measuring the license plate. Aer the measurement,
click Disable Ruler.
-
Click Capture to enable manual capture. The captured pictures will be saved in the set local
path. Or you can click Open Folder to view the pictures.
-
Click
on the right of Connuous Capture to set the connuous capture parameters. Aer
the conguraon, click Connuous Capture to capture pictures.
Capture Times
Up to ve mes are supported.
Connuous Capture Intervals
Up to four intervals are supported. You can set the me of each interval.
Smart On-Street ANPR Camera User Manual
13
Chapter 4 Live View and Local Conguraon
4.1 Live View
4.1.1 Start/Stop Live View
Click to start live view. Click to stop live view.
4.1.2 Select Image Display Mode
Click to display the image in 4:3/16:9/original/self-adapve display mode.
4.1.3 Select Stream Type
Click / / to select the stream type. It is recommended to select the main
stream to get the high-quality image when the network condion is good, and select the sub-
stream to get the uent image when the network condion is not good enough. The third stream is
the custom stream.
Note
The supported stream types vary with dierent models. The actual device prevails.
4.1.4 Capture Picture Manually
You can capture pictures manually on the live view image and save them to the computer.
Steps
1.
Click to start live view.
2.
Click to capture a picture.
3.
Oponal: Click Conguraon → Local Conguraon to view the saving path of snapshots in live
view.
4.1.5 Record Manually
You can record videos manually on the live view image and save them to the computer.
Steps
1.
Click
to start live view.
2.
Click to start recording.
3.
Click to stop recording.
Smart On-Street ANPR Camera User Manual
14
4.
Oponal: Click Conguraon → Local Conguraon to view the saving path of record les.
4.1.6 Enable Digital Zoom
You can enable digital zoom to zoom in a certain part of the live view image.
Steps
1.
Click to start live view.
2.
Click to enable digital zoom.
3.
Place the cursor on the live view image posion which needs to be zoomed in. Drag the mouse
rightwards and downwards to draw an area.
The area will be zoomed in.
4.
Click any posion of the image to restore to normal image.
5.
Click to disable digital zoom.
4.2 Local Conguraon
Go to Conguraon → Local Conguraon to set the live view parameters and change the saving
paths of videos, captured pictures, downloaded pictures, etc.
Figure 4-1 Local Conguraon
Protocol Type
Select the network transmission protocol according to the actual needs.
Smart On-Street ANPR Camera User Manual
15
TCP
Ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected.
UDP
Provides real-me audio and video streams.
Live View Performance
Real-Time
The video is real-me, but the video uency may be aected.
Balanced
Balanced mode considers both the real me and uency of the video.
Fluent
When the network condion is good, the video is uent.
Rules
If you enable rules, the colored rectangles will display on the live view image when the moon
detecon is triggered.
Record File Size
Select the packed size of the manually recorded video les. Aer the selecon, the max. record
le size is the value you selected.
Save record les to
Set the saving path for the manually recorded video les.
Save snapshots in live view to
Set the saving path for the manually captured pictures in live view mode.
Save downloaded picture to
Set the saving path for the downloaded pictures.
Save captured picture to
Set the saving path for the captured pictures in Live View → Live Trac Stascs .
Smart On-Street ANPR Camera User Manual
16
Chapter 5 Storage
5.1 Set FTP
Set FTP parameters if you want to upload the captured pictures to the FTP server.
Before You Start
Set the FTP server, and ensure the device can communicate normally with the server.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → FTP .
Figure 5-1 Set FTP
2.
Oponal: Check Upload Addional Informaon to FTP, and then the related informaon can be
aached when uploading.
3.
Enable the FTP server.
4.
Set FTP parameters.
1) Enter Server Address and Port.
2) Enter User Name and Password, and conrm the password.
3) Select Directory Structure.
Note
If mulple directories are needed, you can customize the directory name.
5.
Oponal: Check Not Upload Plate Close-up if the license plate close-up pictures are not needed
to upload.
6.
Set the name rule and separator according to the actual needs.
7.
Oponal: Edit OSD informaon which can be uploaded to the FTP server with the pictures to
make it convenient to view and disnguish the data.
Smart On-Street ANPR Camera User Manual
17
8.
Click Save.
5.2 Set Listening Host
The listening host can be used to receive the uploaded informaon and pictures of the device
arming alarm.
Before You Start
The listening service has been enabled for the listening host, and the network communicaon with
the device is normal.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → TCP/IP .
Figure 5-2 Set Listening Host
2.
Set ANPR IP Address/Domain and ANPR Port if you need to upload the alarm informaon and
pictures.
3.
Set Listening Host IP and Listening Host Port No., and check Enable Uploading Picture while
Listening if you need to upload the alarm informaon and pictures.
Note
ANPR and listening conict with each other. When you enable listening host, pictures will be
uploaded via listening host in priority. When you disable listening and have set ANPR IP address
and port, pictures will be uploaded via ANPR protocol.
4.
Click Save.
5.3 Set Cloud Storage
Cloud storage is a kind of network storage. It can be used as the extended storage to save the
captured pictures.
Before You Start
●
Arrange the cloud storage server.
●
You have enabled level 1 arm in Live View → Live Trac Stascs .
Smart On-Street ANPR Camera User Manual
18
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Cloud Storage .
Figure 5-3 Set Cloud Storage
2.
Check Enable.
3.
Set the server parameters.
1) Enter Server IP Address and Port No.
2) Enter User Name and Password.
3) Enter the ID according to the storage area No. of the server.
4.
Click Save.
Smart On-Street ANPR Camera User Manual
19
Chapter 6 Encoding and Display
6.1 Set Video Encoding Parameters
Set video encoding parameters to adjust the live view and recording eect.
●
When the network signal is good and the speed is fast, you can set high resoluon and bitrate to
raise the image quality.
●
When the network signal is bad and the speed is slow, you can set low resoluon, bitrate, and
frame rate to guarantee the image uency.
●
When the network signal is bad, but the resoluon should be guaranteed, you can set low
bitrate and frame rate to guarantee the image uency.
●
Main stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission. Sub-stream
usually oers comparavely low resoluon opons, which consumes less bandwidth and storage
space. Third stream is oered for customized usage.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Video Encoding .
2.
Set the parameters for dierent streams.
Stream Type
Video stream and video & audio stream are selectable.
Max. Bitrate
Select relavely large bitrate if you need good image quality and eect, but more storage
spaces will be consumed. Select relavely small bitrate if storage requirement is in priority.
Frame Rate
It is to describe the frequency at which the video stream is updated and it is measured by
frames per second (fps). A higher frame rate is advantageous when there is movement in the
video stream, as it maintains image quality throughout.
Resoluon
The higher the resoluon is, the clearer the image will be. Meanwhile, the network
bandwidth requirement is higher.
SVC
Scalable Video Coding (SVC) is an extension of the H.264/AVC and H.265 standard. Enable the
funcon and the device will automacally extract frames from the original video when the
network bandwidth is insucient.
Bitrate Type
Select the bitrate type to constant or variable.
Smart On-Street ANPR Camera User Manual
20
Video Quality
When bitrate type is variable, 6 levels of video quality are selectable. The higher the video
quality is, the higher requirements of the network bandwidth.
Encoding Complexity
Under the same bitrate, the higher the encoding complexity is, the higher the image quality
is, and the higher the requirement of the network bandwidth is.
I Frame Interval
It refers to the number of frames between two key frames. The larger the I frame interval is,
the smaller the stream uctuaon is, but the image quality is not that good.
Video Encoding
The device supports mulple video encoding types, such as H.264, H.265, and MJPEG.
Supported encoding types for dierent stream types may dier. H.265 is a new encoding
technology. Compared with H.264, it reduces the transmission bitrate under the same
resoluon, frame rate, and image quality.
3.
Click Save.
6.2 Set Image Parameters
You can adjust the image parameters to get clear image.
Steps
Note
The supported parameters may vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → Image Parameters → General Parameters /
Conguraon → Device Conguraon → Image Parameters → Video .
Smart On-Street ANPR Camera User Manual
21
Figure 6-1 Set General Parameters
Figure 6-2 Set Video Image Parameters
2.
Adjust the parameters.
Saturaon
It refers to the colorfulness of the image color.
Sharpness
It refers to the edge contrast of the image.
White Balance
Smart On-Street ANPR Camera User Manual
22
It is the white rendion funcon of the device used to adjust the color temperature according
to the environment.
WDR Mode
Wide Dynamic Range (WDR) can be used when there is a high contrast of the bright area and
the dark area of the scene.
Select WDR Switch and set corresponding parameters according to your needs.
On
Set WDR Level. The higher the level is, the higher the WDR strength is.
Time
Enable WDR according to the me.
Brightness
Set Light Threshold. When the brightness reaches the threshold, WDR will be enabled.
Brightness Enhancement at Night
The scene brightness will be enhanced at night automacally.
Enable Defog
Enable defog to get a clear image in foggy days.
Light Compensaon on License Plate
Check it. The light compensaon on license plates can be realized, and various light
supplement condions can be adapted via seng license plate expectant brightness and
supplement light correcon coecient. The higher the sensivity is, the easier this funcon
can be enabled.
Enable Gamma Correcon
The higher the gamma correcon value is, the stronger the correcon strength is.
Brightness
It refers to the max. brightness of the image.
Contrast
It refers to the contrast of the image. Set it to adjust the levels and permeability of the image.
Shuer Speed
If the shuer speed is quick, the details of the moving objects can be displayed beer. If the
shuer speed is slow, the outline of the moving objects will be fuzzy and trailing will appear.
Gain
It refers to the upper limit value of liming image signal amplicaon. It is recommended to
set a high gain if the illuminaon is not enough, and set a low gain if the illuminaon is
enough.
3D DNR
Digital Noise Reducon (DNR) reduces the noise in the video stream.
Smart On-Street ANPR Camera User Manual
23
In Normal Mode, the higher the 3D DNR Level is, the stronger the noise will be reduced. But
if it is too high, the image may become fuzzy.
In Expert Mode, set Spaal Intensity and Time Intensity. If the special intensity is too high,
the outline of the image may become fuzzy and the details may lose. If the me intensity is
too high, trailing may appear.
2D DNR
The higher the 2D DNR Level is, the stronger the noise will be reduced. But if it is too high,
the image may become fuzzy.
Video Standard
Select the video standard according to the actual power supply frequency.
6.3 Set ICR
ICR adopts mechanical IR lter to lter IR in the day to guarantee the image eect, and to remove
the IR lter at night to guarantee full-spectrum rays can get through the device.
Steps
1.
Go to Conguraon → Device Conguraon → Image Parameters → ICR .
2.
Select ICR Mode.
Auto-switch Switches to ICR mode automacally at night or in dark light condions.
Manual Switch Switches to the day or night manually.
Scheduled Switch Set day/night mode, start me, and end me to switch to ICR mode only
during the set me period.
Do not switch Disable ICR mode.
3.
Click Save.
6.4 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resources to the region of
interest, thus to increase the quality of the ROI whereas the background informaon is less
focused.
Before You Start
Please check the video encoding type. ROI is supported when the video encoding type is H.264 or
H.265.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → ROI .
Smart On-Street ANPR Camera User Manual
24
Figure 6-3 Set ROI
2.
Select Stream Type.
3.
Set ROI region.
1) Check Enable.
2) Select Area Code.
3) Click Draw Area.
4) Drag the mouse on the live view image to draw the xed area.
5) Select the xed area that needs to be adjusted and drag the mouse to adjust its posion.
6) Click Stop Drawing.
4.
Enter Area Name and select ROI Level.
Smart On-Street ANPR Camera User Manual
25
Note
The higher the ROI level is, the clearer the image of the detected area is.
5.
Click Save.
6.
Oponal: Select other area codes and repeat the steps above if you need to draw mulple xed
areas.
6.5 Set OSD
You can customize OSD informaon on the live view.
Steps
1.
Go to Conguraon → Device Conguraon → Text Overlay → Video .
Figure 6-4 Set OSD
2.
Set OSD property, font size, alignment, etc.
3.
Oponal: Set the display content.
1) Check Camera Name and enter the name.
2) Check Display Date, and set the me and date format.
3) Check Display Week.
4) Check Display Parked Status.
4.
Oponal: Check the display item(s) and enter the informaon in the text eld(s).
5.
Drag the red frames on the live view image to adjust the OSD posions.
Smart On-Street ANPR Camera User Manual
26
6.
Click Save.
Result
The set OSD will be displayed in live view image and recorded videos.
Smart On-Street ANPR Camera User Manual
27
Chapter 7 Network Conguraon
7.1 Set IP Address
IP address must be properly congured before you operate the device over network. IPv4 and IPv6
are both supported. Both versions can be congured simultaneously without conicng to each
other.
Go to Conguraon → Device Conguraon → System Conguraon → TCP/IP for parameter
sengs.
Figure 7-1 Set IP Address
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
Auto-Obtain
Smart On-Street ANPR Camera User Manual
28
The device automacally gets the IPv4 parameters from the network if you check Auto-
Obtain. The device IP address is changed aer enabling the funcon. You can use SADP to get
the device IP address.
Note
The network that the device is connected to should support auto-obtain.
Manual
You can set the device IPv4 parameters manually. Enter IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway.
IPv6
Three IPv6 modes are available.
Route Announcement
The IPv6 address is generated by combining the route announcement and the device Mac
address.
Note
Route announcement mode requires the support from the router that the device is connected
to.
Auto-Obtain
The IPv6 address is assigned by the server, router, or gateway.
Manual
Enter IPv6 Address, IPv6 Subnet Mask, and IPv6 Default Gateway. Consult the network
administrator for required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
Mulcast Address
Mulcast is group communicaon where data transmission is addressed to a group of
desnaon devices simultaneously. Aer seng the IP address of the mulcast host, you can
send the source data eciently to mulple receivers.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server properly if needed.
Smart On-Street ANPR Camera User Manual
29
7.2 Connect to ISUP Plaorm
ISUP is a plaorm access protocol. The device can be remotely accessed via ISUP plaorm.
Before You Start
●
Create the device ID on ISUP plaorm.
●
Ensure the device can communicate with the plaorm normally.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → ISUP .
Figure 7-2 Connect to ISUP Plaorm
2.
Check Enable Protocol.
3.
Select Address Type.
Domain Name
When the server is in extranet, and the IP address is dynamic, you can select it.
IP
When the server IP address is stac, you can select it.
4.
Enter the parameters below.
Server IP
Enter the stac IP address of ISUP plaorm.
Server Port
The default value is 7660.
Device ID
The ID of the device registered on the ISUP plaorm. If you leave it empty, the device will be
logged in to the plaorm with serial No.
5.
Click Save.
Smart On-Street ANPR Camera User Manual
30
7.3 Set DDNS
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
●
Register the domain name on the DDNS server.
●
Set the LAN IP address, subnet mask, gateway, and DNS server parameters. Refer to "Set IP
Address" for details.
●
Complete port mapping. The default port is 80, 8000, and 554.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → DDNS .
Figure 7-3 Set DDNS
2.
Check Enable DDNS.
3.
Enter the server address and other informaon.
4.
Click Save.
5.
Access the device.
By Browsers Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client soware
manual for specic adding methods.
7.4 Set Port
The device port can be modied when the device cannot access the network due to port conicts.
Smart On-Street ANPR Camera User Manual
31
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Go to Conguraon → Device Conguraon → System Conguraon → Port for port sengs.
Figure 7-4 Set Port
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
RTSP Port
It refers to the port of real-me streaming protocol.
SDK Port
It refers to the port through which the client adds the device.
Smart On-Street ANPR Camera User Manual
32
Chapter 8 Serial Port Conguraon
8.1 Set RS-485
Set RS-485 parameters if the device needs to be connected to other peripheral devices controlled
by RS-485 serial port.
Before You Start
The corresponding device has been connected via the RS-485 serial port.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Serial Port
Parameters .
Figure 8-1 Set RS-485
2.
Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
3.
Select Work Mode.
Applicaon Mode Trigger
Select it if the vehicle detector has been connected via the RS-485 serial port.
Transparent Transmission
Select it, and the network command can be transmied to RS-485 control command via the
RS-485 serial port.
4.
Click Save.
8.2 Set RS-232
Set RS-232 parameters if you need to debug the device via RS-232 serial port.
Before You Start
The corresponding device has been connected via the RS-232 serial port.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Serial Port
Parameters .
2.
Click Advanced Sengs.
Smart On-Street ANPR Camera User Manual
33
Figure 8-2 Set RS-232
3.
Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
4.
Select Working Mode.
Console
Select it when you need to debug the device via RS-232 serial port.
Transparent Channel
Select it, and the network command can be transmied to RS-232 control command via the
RS-232 serial port.
Narrowband
Reserved.
5.
Click Save.
Smart On-Street ANPR Camera User Manual
34
Chapter 9 Excepon Alarm
Set excepon alarm when the network is disconnected or the IP address is conicted.
Steps
1.
Go to Conguraon → Device Conguraon → Excepon → Excepon .
Figure 9-1 Set Excepon Alarm
2.
Check the excepon type to be alarmed.
3.
Click Save.
Smart On-Street ANPR Camera User Manual
35
Chapter 10 Safety Management
10.1 Manage User
The administrator can add, modify, or delete other accounts, and grant dierent permissions to
dierent user levels.
Steps
1.
Go to Conguraon → Device Conguraon → User Management .
2.
Add a user.
1) Click Add.
2) Enter User Name and select User Type.
3) Enter Admin Password, Password, and conrm the password.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is
used in high-risk environment, it is recommended that the password should be changed every
month or week.
4) Assign remote permission to users based on needs.
User
Users can be assigned permission of viewing live video and changing their own passwords,
but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
5) Click OK.
Note
The administrator can add up to 15 user accounts.
3.
You can do the following operaons.
-
Select a user and click Edit to change the password and permission.
-
Select a user and click Delete to delete the user.
10.2 Enable User Lock
To raise the data security, you are recommended to lock the current IP address.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Service .
2.
Check Enable User Lock.
Smart On-Street ANPR Camera User Manual
36
3.
Click Save.
Result
When the mes you entered incorrect passwords have reached the limit, the current IP address
will be locked automacally.
10.3 Set HTTPS
10.3.1 Create and Install Self-signed Cercate
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → HTTPS .
2.
Select Create Self-signed Cercate.
3.
Click Create.
4.
Follow the prompt to enter Country/Region, Hostname/IP, Validity, and other parameters.
5.
Click OK.
Result
The device will install the self-signed cercate by default.
10.3.2 Install Authorized Cercate
If the demand for external access security is high, you can create and install authorized cercate
via HTTPS protocol to ensure the data transmission security.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → HTTPS .
2.
Select Create cercate request rst and connue the installaon.
3.
Click Create.
4.
Follow the prompt to enter Country/Region, Hostname/IP, Validity, and other parameters.
5.
Click Download to download the cercate request and submit it to the trusted authority for
signature.
6.
Import cercate to the device.
-
Select Signed cercate is available, start the installaon directly. Click Browse and Install to
import the cercate to the device.
-
Select Create the cercate request rst and connue the installaon. Click Browse and
Install to import the cercate to the device.
7.
Click Save.
Smart On-Street ANPR Camera User Manual
37
10.4 Set SSH
To raise network security, disable SSH service. The conguraon is only used to debug the device
for the professionals.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Port .
2.
Uncheck SSH Port.
3.
Click Save.
Smart On-Street ANPR Camera User Manual
38
Chapter 11 Maintenance
11.1 View Device Informaon
Basic Informaon and Algorithms Library Version
Go to Conguraon → Device Conguraon → System Conguraon → Device Informaon to
view the basic informaon and algorithms library version of the device.
You can edit Device Name and Device No. The device No. is used to control the device. It is
recommended to reserve the default value.
Device Status
Go to Conguraon → Device Status to view the device status.
11.2 Enable System Log Service
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you are recommended to save the logs on a log
server.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Service .
2.
Check Enable syslog.
3.
Enter IP and Port of the log server.
4.
Click Save.
Result
The device will upload the security audit logs to the log server regularly.
11.3 Upgrade
Upgrade the system when you need to update the device version.
Before You Start
Prepare the upgrade le.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Upgrade .
2.
Click Browse to select the upgrade le.
3.
Click Upgrade.
Smart On-Street ANPR Camera User Manual
39
4.
Click OK in the popup window.
Note
The upgrade process will take 1 to 10 minutes. Do not cut o the power supply.
Result
The device will reboot automacally aer upgrade.
11.4 Reboot
When the device needs to be rebooted, reboot it via the soware instead of cung o the power
directly.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Reboot .
2.
Click Reboot.
3.
Click OK to reboot the device.
11.5 Restore Parameters
When the device is abnormal caused by the incorrect set parameters, you can restore the
parameters.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Default .
2.
Select the restoraon mode.
-
Click Restore to restore the parameters except the IP address, subnet mask, gateway, and port
No. to the default sengs.
-
Click Default to restore all the parameters to the factory sengs.
3.
Click OK.
11.6 Synchronize Time
Synchronize the device me when it is inconsistent with the actual me.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Time Sengs .
2.
Select Time Zone.
3.
Select Synchronizaon Mode.
NTP Synchronizaon
Smart On-Street ANPR Camera User Manual
40
Select it to synchronize the device me with that of the NTP server. Set Server Address, NTP
Port, and Interval. Click NTP Test to test if the connecon between the device and the server
is normal.
Manual Synchronizaon
Select it to synchronize the device me with that of the computer. Set me manually, or
check Sync. with computer me.
Note
The me synchronizaon modes vary with dierent models. The actual device prevails.
4.
Click Save.
11.7 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → DST .
2.
Check Enable DST.
3.
Set Start Time, End Time, and DST Bias.
4.
Click Save.
11.8 Export Parameters
You can export the parameters of one device, and import them to another device to set the two
devices with the same parameters.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Export Conguraon
File .
2.
Click Export.
3.
Set a password, and click OK.
Note
The password is used for imporng the conguraon le of the current device to other devices.
4.
Select the saving path, and enter the le name.
5.
Click Save.
11.9 Import Conguraon File
Import the conguraon le of another device to the current device to set the same parameters.
Smart On-Street ANPR Camera User Manual
41
Before You Start
Save the conguraon le to the computer.
Steps
Cauon
Imporng conguraon le is only available to the devices of the same model and same version.
1.
Go to Conguraon → Device Conguraon → System Maintenance → Import Conguraon
File .
2.
Select Imporng Method.
Note
If you select Import Part, check the parameters to be imported.
3.
Click Browse to select the conguraon le.
4.
Enter the password which is set when the conguraon le is exported, and click OK.
5.
Click Import.
6.
Click OK on the popup window.
Result
The parameters will be imported, and the device will reboot.
11.10 Export Debug File
The technicians can export the debug le to troubleshoot and maintain the device.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Export Debug File .
2.
Click Export Debug.
3.
Select the saving path, and enter the le name.
4.
Click Save.
Smart On-Street ANPR Camera User Manual
42
Appendix A. Communicaon Matrix and Device
Command
Scan the QR code below to get the communicaon matrix of the device.
Figure A-1 Communicaon Matrix
Scan the QR code below to get the device command.
Figure A-2 Device Command
Smart On-Street ANPR Camera User Manual
43
UD24322B
