User manual of Friedrich FD36K4RPACK12 (47 pages)

See other models: FD36K2RPACK01 FD36K2RPACK02 FD36K3RPACK01 FD36K3RPACK02 FPHW363B

Specs Sheet

Width: 37 3/8 Inch
Depth: 13 3/8 Inch
Height: 41 3/8 Inch
Net Weight: 186 Lbs.
Shipping Weight: 216 Lbs.
Heating Capacity: 36,000 BTU
Max Connectable Capacity: 48,000 BTU
Liquid Line Outer Diameter: 1/4 Inch
Suction Line Outer Diameter: 3/8 Inch
Min. Line Length Each: 25 Ft.
Max. Line Length Each: 66 Ft.
Min. Line Length Total: 197 Ft.
Max. Line Length Total: 197 Ft.
Max. Height Diff. btwn. Indoor and Outdoor Units: 49 Ft.
Max. Height Diff. btwn. Indoor Units: 24 Ft.
Operation: Cooling with Heat Pump
Compressor Noise Level Cooling: 59 dB
Compressor Noise Level Heating: 59 dB
Energy Star Certified: Yes
Drain Line Inner Diameter: 13/22 Inch
Outside Temperature Range for Cooling Min.: 14 °F
Outside Temperature Range for Cooling Max.: 115 °F
Outside Temperature Range for Heating Min.: 13 °F
Outside Temperature Range for Heating Max.: 75 °F
Low Ambient Operating Threshold: 4
Parts Warranty: 5 Year
Operating Sound Level Low: 32 dB
Operating Sound Level Medium: 33 dB
Operating Sound Level High: 35 dB
Auto Operation: Yes
Operating Sound Level Quiet: 26 dB
Program Timer: Yes
Sleep Mode: Yes
Self Cleaning Indoor Coil: Yes
Quiet/Sleep Mode: Yes
Min No. of Connectible Indoor Units: 1
Max No. of Connectible Indoor Units: 4
WiFi Connected: Yes
Refrigerant Connection Type: Flare
Wireless Remote Control Included: Included
Power Input Cooling Min.: 700 Watts
Power Input Cooling Rated: 2,520 Watts
Power Input Cooling Max.: 5,000 Watts
Power Input Heating Min.: 600 Watts
Power Input Heating Rated: 3,060 Watts
Power Input Heating Max.: 6,000 Watts
Power and Communication Cable No.: 4
Power and Communication Cable AWG: 14
Factory Precharge: 106 Oz.
Voltage: 230/208 Volts
Auto Restart on Power Failure: Yes
Control Lock Function: Yes
Wired Remote Control Included: Optional
