1
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Dehumidifier.
• Before using your unit into the mains, visually check that
the unit is intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• The Dehumidifier shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
• DO NOT immerse the Dehumidifier or its power cord in
water or any other liquids.
• DO NOT leave the Dehumidifier unattended during use.
• DO NOT leave the Dehumidifier unattended whilst
connected to a mains power supply.
• Avoid touching any moving parts within the appliance.
• DO NOT insert fingers, pencils or any other objects
through the guard.
3
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT push objects into any openings as damage to the
product and/or electric shock may occur.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Close supervision is required when using this Dehumidifier
near children.
• DO NOT leave this Dehumidifier within reach of children.
• It is imperative to unplug from mains supply after the
Dehumidifier has been used, before it is cleaned and
whilst being repaired.
• Unplug after each use.
• DO NOT operate this appliance if the power cord or plug
are damaged. Ensure that the power cord is not stretched
or exposed to sharp objects or edges.
• DO NOT operate this appliance after a malfunction or
after being dropped or damaged in any way.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Individuals who operate or work in the refrigerant circuit
must have the appropriate certification issued by an
accredited organization that ensure competence in
handling refrigerants according to a specific evaluation
recognized by associations in the industry.
• This product is intended for household use only and
should not be used for industrial purposes.
• DO NOT connect the appliance to an electrical outlet
4
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
using an extension lead. If an outlet is not available, one
should be installed by a qualified electrician.
• DO NOT use the mains plug or external timer as a means
of switching the Dehumidifier on or off. Use the ON/OFF
button located on the unit.
• Always place the unit on a dry and stable surface.
• The appliance should not be placed in a laundry or wet
room.
• DO NOT position the Dehumidifier close to sources of
heat and/or ignition such as radiators, heaters, other
electronic equipment, etc.
• No naked flame sources, such as lighted candles, should
be placed on the Dehumidifier.
• The appliance must be stored in such a way as to prevent
mechanical failure.
• DO NOT use any accessories or attachments with this
product other than those supplied or recommended by
supplier.
• DO NOT use this product for anything other than its
intended use.
5
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This Class 2 symbol indicates that the product is electrically
double insulated and does not require an earth connection.
This symbol provides useful additional information on the
use of this product.
This symbol identifies that the supply uses an alternating
current mains supply.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
6
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before First Use of Your Dehumidifier
Remove all packing materials and discard responsibly.
Ensure all parts are present (if applicable) see Description of Parts below.
Description of Parts
1
1. ON/OFF Button
2. Air Inlet
3. Air Outlet
4. Mains Cable
5. Handle
6. Water Outlet
7. Hydraulic Cut-Off
8. Water Tank
2
4
5
7
6
8
3
7
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Dehumidifier
1. Insert the Mains plug into the nearest socket.
2. Press the ON/OFF Button (1), the green light will illuminate as shown below and
the dehumidifier will begin to operate with air blowing from the Air Outlet (3).
Water Tank
When the Water Tank (8) is full, the yellow light will illuminate as shown below
and the dehumidifier will switch off automatically.
To remove the Water Tank (8):
1. Grasp the handle at the bottom and pull the tank away from the body of the
unit as shown in Fig(a) below.
2. Pull the rubber bung out from the Water Outlet (6) and pour away the water as
shown in Fig(b) below.
3. Replace the bung and push the water tank back fully into the body.
Fig(a)
Fig(b)
8
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Storage
Whilst not in use for long periods ensure that you:
1. Empty the water tank and wipe away any excess moisture from the tank and
body.
2. Place the appliance in a cool, dry environment away from direct sunlight.
Care and Use of Your Dehumidifier
• Always disconnect the Dehumidifier from the mains supply before cleaning.
• Clean the water tank with warm soapy water, do not use harsh abrasive
chemicals.
• Clean the body of the unit with a soft damp cloth.
• Dry thoroughly before refitting to the unit.
Technical Specification
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Model Number
COL1382
Rated Voltage
100-240V~ 50/60Hz
Rated Power
40W
Water Tank Capacity
2L
Protection Class
II
Operating Parameters
10°C-50°C, over 80% RH
9
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of plastics in the appropriate plastics collection service.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products at
the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or retailer
for recycling advice or visit www.recycle-more.co.uk, enter your
postcode to find out your nearest recycling site.
10
2L Dehumidifier
Model No. COL1382
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year
guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
