30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
7 Explanation of Symbols
8 Before First Use of Your Dehumidifier
8 Installing the Hepa Filter
9 Description of Parts
10 Description of Parts – The Control Panel
10 Installing Your Dehumidifier
11 Using Your Dehumidifier
11 Powering Up
11 Selecting Modes – Dehumidifier/Laundry/Fan
12 Swing/Oscillate
12 Setting the Humidity Level
12 Using the Timer
13 Child Lock
13 Defrost
13 Water Tank Full Alarm/ Emptying the Water Tank
15 Continuous Drainage
16 Cleaning and Replacing the Hepa Filter
16 Replacement Hepa Filters
16 Storage
16 Care and Maintenance of Your Dehumidifier
17 Technical Specification
17 Plug Wiring Information
18 Recycling Information
18 Troubleshooting Guide
19 Customer Support
Back Page Warranty Information
3
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Dehumidifier.
• Before using your unit into the mains, visually check that
the unit is intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• The Dehumidifier shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
• DO NOT immerse the Dehumidifier or its power cord in
water or any other liquids.
• DO NOT leave the Dehumidifier unattended during use.
• DO NOT leave the Dehumidifier unattended whilst
connected to a mains power supply.
• Avoid touching any moving parts within the appliance.
• DO NOT insert fingers, pencils or any other objects
through the guard.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
• DO NOT push objects into any openings as damage to the
product and/or electric shock may occur.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Close supervision is required when using this Dehumidifier
near children.
• DO NOT leave this Dehumidifier within reach of children.
• It is imperative to unplug from mains supply after the
Dehumidifier has been used, before it is cleaned and
whilst being repaired.
• Unplug after each use.
• DO NOT operate this appliance if the power cord or plug
are damaged. Ensure that the power cord is not stretched
or exposed to sharp objects or edges.
• DO NOT operate this appliance after a malfunction or
after being dropped or damaged in any way.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Individuals who operate or work in the refrigerant circuit
must have the appropriate certification issued by an
accredited organization that ensure competence in
handling refrigerants according to a specific evaluation
recognized by associations in the industry.
• Repairs must be performed on the recommendation from
the manufacturing company. Maintenance and repairs
that require the assistance of other qualified persons must
5
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
be performed under the supervision of an individual
specified in the use of flammable refrigerants.
• This product is intended for household use only and
should not be used for industrial purposes.
• DO NOT connect the appliance to an electrical outlet
using an extension lead. If an outlet is not available, one
should be installed by a qualified electrician.
• DO NOT use the mains plug or external timer as a means
of switching the Dehumidifier on or off. Use the ON/OFF
button located on the control panel.
• Always place the unit on a dry and stable surface.
• The appliance should not be placed in a Bathroom or Wet
room.
• DO NOT position the Dehumidifier close to sources of
heat and/or ignition such as radiators, heaters, other
electronic equipment, etc.
• No naked flame sources, such as lighted candles, should
be placed on the Dehumidifier.
• The appliance must be installed and used in a room with a
floor are larger than 4m².
• This appliance contains R290 refrigerant gas. For quantity
see rating label on rear of the unit.
• R290 refrigerant gas complies with the EU environmental
directives.
• Refrigerant gas may be odourless, if the appliance is used
or stored in an unventilated room, the room must be as
such to prevent stagnation of possible leaks of refrigerant
gas as there could be a danger of fire or explosion hazard
should the refrigerant come into contact with electric
heaters, stoves or other sources of ignition.
• The refrigerant system should not be perforated.
• The appliance must be stored in such a way as to prevent
mechanical failure.
• DO NOT use any accessories or attachments with this
product other than those supplied or recommended by
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
the supplier.
• DO NOT use this product for anything other than its
intended use.
• The Dehumidifier must always be stored and transported
upright, otherwise irreparable damage be caused to the
compressor; if in doubt, wait at least 24 hours before
restarting the unit.
• Avoid restarting the Dehumidifier unless 3 minutes have
passed since being turned off. This prevents damage to
the compressor.
7
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol provides useful additional information on the
use of this product.
This symbol identifies that the supply uses an alternating
current mains supply.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
These symbols indicate the presence of flammable
materials, in this instance R290 Refrigerant Gas.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
Before First Use of Your Dehumidifier
Remove all packing materials and discard responsibly.
Installing the Hepa Filter
Before using your Dehumidifier, the Hepa Filter (9) must first be installed as
follows:
1. Remove the Hepa Filter (9) from the
paper bag:
2. Remove the Air Filter Cover (8) by
pulling the Air Filter Cover Pull (7) as
shown right:
3. Insert the Hepa Filter (9) behind the Air Filter Cover (8) and replace the cover:
9
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ensure all parts are present – see Description of Parts below.
Description of Parts
9
8
1
2
3
4
6
7
1. Control Panel
2. Air Outlet Louvres
3. Handle
4. Main Body
5. Water Tank (with window)
6. Castors (x4)
7. Air Filter Cover Pull
8. Air Filter Cover
9. Hepa Filter (behind cover)
10. Continuous Drain Outlet/Cable Tidy
11. Mains Cable
12. Drain Hose
11
10
5
10
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
Description of Parts – The Control Panel
Installing Your Dehumidifier
• Place the unit on a firm, level surface in an area with at least 20cm of free space
on all sides to allow for proper air circulation – see below:
• Ensure the Hepa Filter (9) is correctly installed as described above. DO NOT use
your dehimidifier without installing the filter.
• Never install the unit where it could be subject to:
1. Heat sources such as radiators, stoves or other products that produce heat.
2. In an area where oil or water may be splashed.
3. Direct sunlight.
4. Mechanical vibration or shock.
5. Excessive dust.
6. Lack of ventilation, such as cabinet or bookcase.
7. An uneven surface.
13
14
15
17
18
19
16
20
21
22
24
25
26
27
13. Timer Button
14. Speed Button
15. Swing (Oscillate) Button
16. LED Display
17. Humidity Set Button
18. Mode Button
19. Power Button
20. Timer Indicator
21. High Fan Speed Indicator
22. Low Fan Speed Indicator
23. Child Lock Indicator
24. Swing Indicator
25. Defrost Indicator
26. Fan Mode Indicator
27. Laundry Mode Indicator
28. Dehumidify Mode Indicator
29. Water Tank Full Indicator
23
28
29
11
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Dehumidifier
• Insert the mains plug into the nearest available
socket.
Powering Up
• Press the Power Button (19) to power the unit up.
• The Dehumidifier will power up in Dehumidifier mode.
• The LED Display (16) will show the current humidity level.
• The Dehumidifying Mode Indicator (28) (DEH) will illuminate and the Air Outlet
Louvers (1) will open. The High or Low Fan Speed Indicator (21&22) will
illuminate accordingly (to whichever fan speed was selected previously).
• Press the Power Button (19) again to turn the unit off, the compressor will stop
immediately and the fan will shut down after a 30 second delay.
Selecting Modes
There are 3 modes to select from, press the Mode Button (18) to select from:
1. Dehumidify Mode - DEH
Press the Mode (18) button until the Dehumidifying Mode Indicator (28) (DEH)
illuminates.
A. If the "Co" (Continuous) dehumidification is selected, the dehumidifier will
continue to run (compressor and fan) regardless of the humidity level.
B. If the humidity is higher than or equal to 3% of the set humidity, the compressor
and fan will run in dehumidify mode.
C. Once the humidity drops below 2% of the set humidity, the compressor will stop
dehumidifying and the fan will stop after 3 minutes.
2. Laundry Mode - LAUNDRY
Press the Mode (18) until button until the Laundry Indicator (27) (LAUNDRY)
illuminates. In this mode, the Dehumidifier will run continuously and the humidity
setting cannot be adjusted.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
3. Fan Only Mode - FAN
Press the Speed Button (21) to select the airflow speed:
• Low Fan Speed – the Low Fan Speed Indicator (22) (LOW) will illuminate.
• High Fan Speed – the High Fan Speed Indicator (21) (HIGH) will illuminate.
Swing (Oscillate)
Press the Swing (Oscillate) button (15) (SWING) to enable the Swing/Oscillate
Mode which enables the Air Outlet Louvres (1) to move back and forth to disperse
air over a larger area.
Press the Swing (Oscillate) button (15) (SWING) to cancel the Swing/Oscillate
Mode.
Setting the Humidity Level - % ADJUST
• Press the Humidity Set Button (17) (% ADJUST) to set the desired humidity level
which will be shown on the LED Display (16).
• Each press of the Humidity Set Button (17) will show a range of target humidity
settings: Co, 30%, 35%, 40%, 45%, 50%, 55%, 60%, 65%, 70%, 75%, 80%, 85%,
90%, Co. where ‘Co’ is Continuous running of the dehumidifier.
• After setting the desired humidity level, the LED Display (16) will confirm the set
value for about 3 seconds and then return to show the actual current ambient
humidity.
• To view the current humidity setting on the LED Display (16), press the
Humidity Set Button (17) (% ADJUST) which will show for about 3 seconds and
then return to show the actual current ambient humidity.
In “Laundry Mode” the humidity setting cannot be changed.
Using the Timer
• Press the Timer Button (13) (TIMER) to enter the timer mode.
• The timer can be set in 1 hour increments up to a maximum of 24 hours, every
press of the Timer Button (13) will increase the timer by 1 hour, the time will be
displayed on the LED Display (16).
• The set time on the LED Display (16) will show as “07” for 7 hours, etc.
• The Timer Indicator (20) above the Timer Button (13) will illuminate during the
set time period. After the set time period has ended, the Timer Indicator (23)
will go out.
If the Timer is set with the unit on, the Timer will turn the Dehumidifier off at
the end of the set time.
If the Timer is set with the unit in standby mode, (i.e. with the Dehumidifier
plugged in but not running), the Timer will turn the Dehumidifier on at the
end of the set time.
• To cancel the timer, press the Timer Button (13) until the LED Display (16)
returns to “00”.
13
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Child lock - LOCK
Press and hold the Swing (Oscillate) button (15) (SWING) for 3 seconds to turn the
child lock function on.
The Child Lock Indicator (23) will illuminate when the lock is activated.
Press and hold the Swing (Oscillate) button (15) (SWING) for 3 seconds to turn the
child lock function off.
Defrost - DEF
During use the dehumidifier will automatically defrost itself. Whilst defrosting, the
compressor will stop running and the Defrost Indicator (25) will illuminate.
Defrosting mode will take approximately 10 minutes, after which the unit will
return to a normal mode of working.
NB The dehumidifier will not operate in temperatures below 5°C.
Water Tank Full Alarm - FULL
1. When the Water Tank (5) is full, the Tank Full Indicator (29) (FULL) will
illuminate, the Dehumidifier will stop running and the alarm will sound.
2. Press any button to stop the alarm. The compressor and fan will shut down and
all functions will pause until the Water Tank (5) has been emptied and replaced.
Emptying the Water Tank (5)
1. Grasp the Water Tank (5) at the
bottom edge and pull the tank
out:
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
2. Lift the flap (arrowed below) at the top
right rear corner of the tank lid and
empty the tank:
DO NOT remove the float from the tank otherwise the dehumidifier will not
operate:
15
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Close the flap at the top right rear corner and replace the Water Tank (5) into
the Dehumidifier ensuring that it is full pushed back into place:
Continuous Drainage
If preferred, continuous drainage can be used with the appliance rather than
emptying the Water Tank (5).
For this option:
• Remove the Water Tank (5) as described
above.
• Remove the bung from the Continuous Drain
Outlet (9) on the rear of the unit.
• Fit the Drain Hose (11) to the hose point on
the rear of the Main Body (4), arrowed right.
• Replace the Water Tank (5).
• Run the hose into a suitable drainage point,
ensuring that the hose is not kinked or bent
and leads down away from the unit.
16
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
Cleaning and Replacing the Hepa Filter
Replacement Hepa Filters
However, we recommend that the Hepa Filter (9) is replaced at least once a year.
Replacement Hepa filters are available by telephoning 0161 831 7879 (9.00am-
5.00pm Monday-Thursday, 8.00am – 4.00pm Friday) or contacting us via email:
help@daewooelectricals.com
Storage
Whilst not in use for long periods, please ensure that you:
1. Empty the water tank and wipe away any excess moisture from the tank and
body.
2. Clean the filter.
3. Place the appliance in a cool, dry environment away from direct sunlight.
Care and Maintenance of Your Dehumidifier
• Always disconnect the Dehumidifier from the mains supply before cleaning.
• Do not remove the float from the water tank as this will prevent the unit from
operating.
• Clean the water tank with warm soapy water, do not use harsh abrasive
chemicals.
• Clean the body of the unit with a soft damp cloth.
• Remove the Air Filter Cover (8)
using the Air Filter Cover Pull (7),
remove the Hepa Filter (9) from
behind the cover.
• To clean the Hepa Filter (9), use a
vacuum cleaner to remove any
built up dust or lint.
• If the filter is badly soiled it can be
washed in warm soapy water and a
mild detergent.
• Dry thoroughly for 24 hours before
refitting it to the unit.
17
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Product Code
COL1614
Rated Voltage
220-240V ~
Rated Frequency
50Hz
Rated Current
3.3A
Rated Power
600W
Rated Capacity
30L/D (30°C, 80%RH)
Water Tank Capacity
4L
Maximum Refrigerant Charge
R290/50g
Operating Temperature Range
5°C – 35°C
Net Weight
13.5kg
Permissible Excessive Operating Pressure
Discharge 2.6MPa
Suction 1.0MPa
Maximum Allowable Pressure
Discharge 3.2MPa
Suction 1.2MPa
Suitable Room Size
32-40m
2
Dimensions (Approx.)
500mm (h) x 290mm (w) x
250mm (d)
IP Rating
IPX0
Protection Class
I (This Appliance must be Earthed)
18
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of plastics in the appropriate plastics collection service.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
Trouble Shooting Guide
Problem
Possible Cause
Possible Solution
Not working
No power
Ensure that the mains plug is
inserted into a socket and the
socket is switched on.
Water Full Indicator is
illuminated.
Empty the water tank
Room temperature ˂ 5°C, or
˃ 35 °C
Unit will not operate below 5°C
or above 35°C.
Defrost Indicator (28) is
illuminated.
The unit is defrosting, it takes
around 10mins to complete. Do
not unplug whilst the unit is
defrosting.
Unit not
performing
well
Is the air filter clogged?
Clean the air filter.
Is the air intake obstructed?
Remove the obstruction from
the air intake.
No air intake
Is the filter clogged?
Clean the air filter.
Noisy when
running
Ensure the unit is on a level
surface.
Place the unit on a solid, level
surface.
Is the filter clogged?
Clean the air filter.
E1 code
Sensor problem.
Change the sensor/contact
customer services.
19
30L Dehumidifier
Product Code: COL1613
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
20
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
30L Dehumidifier
Product Code: COL1614
User Manual
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
